INSTALLING BUSHING Audi S5 I facelift

Front Suspension (Coupe) 3 illustrations ~178 words

INSTALLING BUSHING

Transfer the marking from the old hydraulic bonded rubber bushing to the new one.

Lightly coat the new hydraulic bonded rubber bushing with installation lubricant --.

Scheme 112

Scheme 112: INSTALLING BUSHING
Scheme 112: INSTALLING BUSHING

The notch -1- is on the steering axle and faces the inside of the guide link.

The arrow -2- faces the inside of the guide link.

Install the hydraulic bonded rubber bushing -4- in the guide link -5- paying close attention to the installed position.

Scheme 113

Scheme 113
Scheme 113

Order the special tools as illustrated.

  1. V.A.G 1290A punch
  2. VW 412
  3. Sleeve VW 463/2
  4. Hydraulic bonded rubber bushing
  5. Guide Link
  6. 3144
  7. VW 402

Note. Do not tilt the hydraulic bonded rubber bushing when installing it.

Install the hydraulic bonded rubber bushing -4- into the guide link -5-.

Pay close attention to the marking -arrow-.

Check the press-in depth -a- of the hydraulic bonded rubber bushing inside the guide link.

Scheme 114

Scheme 114
Scheme 114

Dimension -a- = 18 mm.

If dimension -a- if not reached, then press the hydraulic bonded rubber bushing again.

Install the guide link. Refer to GUIDE LINK .
