CENTRAL LOCKING, SERVICING Audi S5 I facelift

Front Doors, Central Locking System (Coupe) 4 illustrations ~466 words

CENTRAL LOCKING, SERVICING

Note. Central locking functions electronically. The adjusters in the doors are integrated inside the door lock and have 2 motors. The adjusters cannot be replaced separately. The first motor locks the door and the second motor locks the interior door mechanism (Safe function). The door can no longer be opened from the inside. The central locking control module will unlock any locked doors if there is a crash and the air bag deploys. The central locking control module is located inside the right rear side panel.

Hood Switch, Safe Indicator Lamp, Driver And Front Passenger Door Control Module, Comfort System Central Control Module

Scheme 159

Scheme 159: CENTRAL LOCKING, SERVICING
Scheme 159: CENTRAL LOCKING, SERVICING
  1. Driver door control module -J386- Removing and Installing, refer to «DRIVER DOOR AND FRONT PASSENGER DOOR CONTROL MODULES J386/ J387»(ref-520194-S22716248802012123100000)
  2. Front passenger door control module -J387- Removing and Installing, refer to «DRIVER DOOR AND FRONT PASSENGER DOOR CONTROL MODULES J386/ J387»(ref-520194-S22716248802012123100000)
  3. Vehicle positioning system interface control module -J843- Only for Sportback
  4. Cover For comfort system central control module -J393- 5-door vehicles
  5. Comfort system central control module -J393- 5-door vehicles Removing and installing, refer to «REMOVAL AND INSTALLATION»(ref-520162-S10562266032012123100000)
  6. Mounting bracket For control modules 5-door vehicles
  7. Comfort system central control module -J393- 2-door vehicles Removing and installing, refer to «REMOVAL AND INSTALLATION»(ref-520162-S10562266032012123100000)
  8. Mounting bracket For control modules 2-door vehicles
  9. Mounting bracket For control modules 2-door vehicles
  10. Vehicle positioning system interface control module -J843- 2-door vehicles Removing and Installing, refer to «VEHICLE POSITIONING SYSTEM INTERFACE CONTROL MODULE J843, COUPE»(ref-520194-S38561830412012123100000)
  11. Central Locking -SAFE- Indicator Lamp -K133- Removing and Installing, refer to «REMOVAL AND INSTALLATION»(ref-520166-S39646063012012123100000)

Contact Switch In The Lock Cylinder For The Rear Lid, Rear Lid Central Locking System Motor, Anti-Theft Alarm System Sensor, Fuel Tank Lid Unlock Motor

Scheme 160

Scheme 160
Scheme 160
  1. Engine hood contact switch -F266- Hood Latch, Removing and Installing. Refer to «HOOD ASSEMBLY OVERVIEW»(ref-520195-S04461768152012123100000)
  2. Fuel filler door unlock motor -V155- Removing and Installing, refer to «FUEL FILLER DOOR UNLOCK MOTOR V155»(ref-520194-S15961355242012123100000)
  3. Rear lid lock With the rear lid central locking system motor -V53- /rear lid alarm switch -F123-, and cannot be replaced separately. Assembly Overview, refer to «REAR LID»(ref-520195-S18037739152012123100000)
  4. Rear lid lock cylinder unlock button -F248- Integrated inside the handle strip, cannot be replaced separately
  5. Anti-Theft Alarm System Sensor -G578- Removing and installing, refer to «REMOVAL AND INSTALLATION»(ref-520166-S39646063012012123100000)
  6. Front interior monitoring individual sensor Can only be removed and installed together with the anti-theft alarm system sensor -G578
  7. Interior light/front reading light

Scheme 161

Scheme 161
Scheme 161

Tighten the bolts -arrow- to 2 Nm.

Scheme 162

Scheme 162: REMOVING
Scheme 162: REMOVING

Proceed as follows

Disconnect the door connector on the A-pillar. Refer to REMOVAL AND INSTALLATION .

Remove the door arrester bolt -2-.

Remove the cover caps -1- and -3- from the stud bolts.

Remove the stud bolts -4- on the upper and lower door hinge.

CAUTIONThere is a risk of damaging the paint. Protect the painted surfaces on the door or on the side panel from damage.

Carefully remove the door upward out of the door hinges.
