MULTIMEDIA SYSTEM CONTROL HEAD -E380- CONNECTOR

Multimedia System Control Head

Note. Unlisted connector terminals are not used.

Scheme 241

All pins are connected to the information electronics control module 1 -J794-.

6 - Wake up

7 - Voltage Supply

8 - Ground

13 - RES ET

14 - RES ET

15 - Data

16 - Data

Scheme 242

1. Radio Removal Tool T10057
2. CD Changer -R41- MMI connectors, refer to «MMI CD CHANGER -R41»(ref-522368-S18787047072013011400000) MMI, removing and installing. Refer to «MMI CD CHANGER -R41»(ref-522368-S18787047072013011400000) - External Audio Source Connection -R199- (interface) Interface connectors, refer to «EXTERNAL AUDIO SOURCE CONNECTION -R199- CONNECTORS, INTERFACE»(ref-522368-S05286752762013011400000) . Removing and installing (interface), refer to «EXTERNAL AUDIO SOURCE CONNECTION -R199-, INTERFACE»(ref-522368-S03663912872013011400000)
3. Information Electronics Control Module 1 -J794- Connectors, refer to «SOUND SYSTEMS»(ref-522368-S05501377152013011400000) . Removing and installing, refer to «INFORMATION ELECTRONICS CONTROL MODULE 1 -J794»(ref-522368-S28671117632013011400000)
4. Radio Removal Tool T10057
5. Multimedia System Control Head -E380- Connectors, refer to «MULTIMEDIA SYSTEM CONTROL HEAD -E380- CONNECTOR»(ref-522368-S32786155812013011400000) Removing and installing, refer to «MULTIMEDIA SYSTEM CONTROL HEAD -E380»(ref-522368-S03569880612013011400000)
6. Trim Removal Wedge 3409
7. Nut 3.5 Nm
8. Nut 3.5 Nm
9. Nut 3.5 Nm
10. Radio -R- MMI connectors, refer to «MMI RADIO -R- CONNECTORS»(ref-522368-S32496267612013011400000) MMI, Removing and installing, refer to «MMI RADIO -R»(ref-522368-S38939052492013011400000)
11. Nut 3.5 Nm
12. Screw 2 Nm
13. Front Information Display Control Head -J685- MMI connectors, refer to «MMI DISPLAY CONNECTORS»(ref-522368-S29345523452013011400000) Removing and installing, refer to «DISPLAY»(ref-522368-S31340909212013011400000)

Scheme 243

1. (AM/FM1/FM2) jack
2. Jack (SAT) for the satellite antenna -R170
3. Connection block with four connectors
4. MOST bus

Note. Unlisted connector terminals are not used.

Scheme 244

A - AM/FM1 jack 2 for the antenna amplifier -R24- (radio antenna 2 -R93-)

B - FM2 jack 1 for the antenna amplifier (antenna -R11-)

3 - Connection Block with Four Connectors

Scheme 245

1. Right rear speaker (+)
2. Right front speaker (+)
3. Left front speaker (+)
4. Left rear speaker (+)
5. Right rear speaker (-)
6. Right front speaker (-)
7. Left front speaker (-)
8. Left rear speaker (-)

17 - Left LF IN

18 - LF IN ground

19 - LF IN diag

21 - LF diag

22 - LF (-)

23 - Right LF IN

24 - LF IN ground shielding

27 - LF ground shielding

28 - LF (+)

29 - Headphones output 1 diag

31 - Headphones output 1/2 diag

34 - Headphones output 2 diag

35 - Headphones output 1 left

36 - Headphones output 1 ground

37 - Headphones output 1 right

38 - Headphones output 2 left

39 - Headphones output 2 ground

40 - Headphones output 1 right

9 - Subwoofer in rear shelf -R157

10 - Center mid-treble speaker -R158

11 - Ring-break diagnostic cable

13 - Subwoofer in rear shelf

14 - Center mid-treble speaker

41 - Terminal 31

42 - Terminal 30

1. IN
2. OUT

Scheme 246

1. GPS Antenna -R50
2. Front Information Display Control Head -J685- in Center of the Instrument Panel
3. Multimedia System Control Head -E380- inside the Center Console
4. Information Electronics Control Module 1 -J794- inside the Instrument Panel
5. External Audio Source Connection -R199- (AUX IN socket) in the Center Console Storage Compartment
6. MOST Bus
7. CD Changer -R41- inside the Glove Compartment
8. Radio -R- behind the Left Luggage Compartment Left Side Trim
9. Digital Sound System Control Module -J525- behind the Luggage Compartment Left Side Trim Panel
10. Data Bus On Board Diagnostic (OBD) Interface -J533- behind Glove Compartment on the Left Side
11. Microphone unit in front roof module -R164- (Left Front Microphone -R140-) inside the Front Interior Lamp -W1

Scheme 247

1. Multifunction Buttons
2. Screw 3 Nm

Scheme 248

1. Tiptronic Downshift Button on Steering Wheel -E439- Removing and installing, refer to «TIPTRONIC SWITCH FROM MY 2012»(ref-522368-S17436668212013011400000)
2. 3-Spoke Steering Wheel
3. Tiptronic Upshift Button on Steering Wheel -E438- Removing and installing, refer to «TIPTRONIC SWITCH FROM MY 2012»(ref-522368-S17436668212013011400000)
4. Screw 1.2 Nm
5. Trim
6. Right Multifunction Buttons on Steering Wheel -E441- Removing and installing, refer to «3-SPOKE-STEERING WHEEL MULTIFUNCTION BUTTONS FROM MY 2012»(ref-522368-S09744195502013011400000)
7. Left Multifunction Buttons on Steering Wheel -E440- Removing and installing, refer to «3-SPOKE-STEERING WHEEL MULTIFUNCTION BUTTONS FROM MY 2012»(ref-522368-S09744195502013011400000)

Scheme 249

1. Tiptronic Downshift Button on Steering Wheel -E439- Removing and installing, refer to «TIPTRONIC SWITCH FROM MY 2012»(ref-522368-S17436668212013011400000)
2. 4-Spoke Steering Wheel
3. Tiptronic Upshift Button on Steering Wheel -E438- Removing and installing, refer to «TIPTRONIC SWITCH FROM MY 2012»(ref-522368-S17436668212013011400000)
4. Screw 1.2 Nm
5. Right Multifunction Buttons on Steering Wheel -E441- Removing and installing, refer to «4-SPOKE-STEERING WHEEL MULTIFUNCTION BUTTONS FROM MY 2012»(ref-522368-S10500643602013011400000)
6. Trim
7. Left Multifunction Buttons on Steering Wheel -E440- Removing and installing, refer to «4-SPOKE-STEERING WHEEL MULTIFUNCTION BUTTONS FROM MY 2012»(ref-522368-S10500643602013011400000)
8. Screw 1.2 Nm
