STEERING COLUMN
Special tools and workshop equipment required
- Torque wrench V.A.G 1331
| WARNING | Note the following before removing the steering column: Create a sketch showing the: Routing of the electrical wiring harnesses Securing the electrical wiring harnesses Cable tie locations This especially applies to the wiring harness to the electronic steering column lock control module -J764-. Note the following before installing the steering column: Route the electrical wiring harnesses exactly the way they were before removal. Secure the electrical wiring harnesses exactly the way they were before removal. Install all the cable ties that were loosened or cut in the same locations when installing the steering column. Make sure the wiring harness to the electronic steering column lock control module is not pinched and does not come into contact with sharp edges when adjusting the steering column. |
Note. The steering column is delivered only as a complete replacement part. Service is not possible. Only the electronic steering column lock control module can be replaced separately.
Set the wheels to the straight ahead position.
Position the steering wheel as far down as possible using the full range of the steering column adjuster.
Remove the driver airbag. Refer to Removal and Installation .
Remove the airbag steering wheel. Refer to STEERING WHEEL WITH AIRBAG .
Remove the driver side instrument panel cover. Refer to Removal and Installation .
Remove the driver side knee airbag if installed. Refer to Removal and Installation .
If installed, remove the right driver side knee bar. Refer to Removal and Installation .
Remove the driver side footwell vent. Refer to [For engine(s) CAUA, CAEB, CALA] Removal and Installation .
Remove the steering column trim. Refer to Removal and Installation .
Remove the steering column switch module. Refer to [For engine(s) CAUA, CAEB, CALA] Removal and Installation .
| WARNING | Never loosen or remove the bolts on the dynamic steering unit on steering column. |
Disengage the wiring guide -1- at the steering column -arrows- and lay it aside.
Scheme 62
On vehicles equipped with dynamic steering, disconnect the connector on the adjustor and free up the cable guide on the left side of the steering column.
Remove the bolt -2- and remove the steering intermediate shaft -3- from the steering column -1-.
Remove the lower steering column bolts -1 through 4- on the mounting bracket and pedal assembly.
Scheme 63
Remove the steering column bolts -1- and -2- on the central tube while supporting the steering column from below with the hand.
Scheme 64
Pull the steering column back slightly, disengage it from the positioning holes on the central tube and lower it.
If the vehicle has a lock locking system, disconnect the connector -2- from the electronic steering column lock control module -1-, remove the clip -5-, free up the wiring harness -3- and remove the steering column.
Scheme 65
Install in reverse order of removal. Note the following
- If the steering column was replaced on a vehicle with the lock locking system, then use the bolt, refer to item 4 already installed in the new steering column, for the electronic steering column lock control module.
Tightening specifications, refer to STEERING COLUMN OVERVIEW .
Clean the threaded hole (for example, using a thread tap) before installing the new bolt -2-.
Applies to Vehicles with Lock Locking System
- After re-connecting the connector, -2- make sure the wiring harness -3- is secured by the clip -5-.
- If the steering column needs to be adjusted, be careful not to pinch the wiring harness -3- for the electronic steering column lock control module -1- and that it does not come in contact with any sharp edges.
Follow the assembly sequence when installing.
Scheme 66
Position the steering column with the positioning pins -1- in the positioning holes on the central tube.
Install all bolts loosely.
First tighten the bolt -2- to the tightening specification.
Then tighten the bolt -3- to the tightening specification.
Then tighten the bolt -4- and bolt -5- to the tightening specification.
If equipped, install the right driver side knee bar. Refer to Removal and Installation .
Then tighten the bolt -6- and bolt -7- to the tightening specification.
Tighten the bolt -8- and bolt -9- to the tightening specification.
Replace the spring nut -10- if the steering column was replaced.
Install the steering intermediate shaft -3- on the steering column -1- as far as the stop and tighten the bolt -2-.
Install the steering column switch module. Refer to [For engine(s) CAUA, CAEB, CALA] Removal and Installation .
Install the steering column trim. Refer to Removal and Installation .
Install the driver side footwell vent. Refer to [For engine(s) CAUA, CAEB, CALA] Removal and Installation .
Install the driver side knee airbag if installed. Refer to Removal and Installation .
Install the driver side instrument panel cover. Refer to Removal and Installation .
Install the airbag steering wheel. Refer to STEERING WHEEL WITH AIRBAG .
Install the airbag unit. Refer to Removal and Installation .
After replacing the electronic steering column lock control module, the module must be adapted to the immobilizer.
Note. If the same steering column and the same electronic steering column lock control module are being re-installed, then it is not necessary to adapt the electronic steering column lock control module again.
Connect the vehicle diagnostic tester and proceed with a vehicle-specific entry in Guided Fault Finding.
Select the corresponding program in "Guided Functions".
Follow the prompts on the screen.
The steering angle sensor -G85- must be calibrated after installing the steering column switch module.
Connect the vehicle diagnostic tester and proceed with a vehicle-specific entry in Guided Fault Finding.
Follow the prompts on the screen.
