IDENTIFICATION
| WARNING | Vehicles are equipped with air bag supplemental restraint system. Before attempting any repairs involving steering column, instrument panel or related components, see AIRBAG SAFETY PRECAUTIONS in BODY INTERIOR article. |
ENGINE CODE
Engines are identified by a 4 letter code stamped onto the engine block, for engine identification see engine code on the vehicle data plate.
| Engine Displacement | Engine Stamp Code |
|---|---|
| 3.2L | CALA |
| 4.2L | CAUA |
Relay & Fuse Holder Panel Locations
Note. For relay identification within the relay and fuse holder panels, refer to RELAY LOCATIONS under relays.
Scheme 1
| Location No. | Description | Refer To |
|---|---|---|
| 1 | Fuse Panel A -SA | (Scheme 2) |
| 2 | Relay / Fuse Panel B -SB | (Scheme 3) |
| 3 | Fuse Panel C -SC | (Scheme 4) (1) (Scheme 5) (2) |
| 4 | Relay /Fuse Panel with Vehicle Electrical System Control Module -J519 | (Scheme 12) |
| 5 | 6-Pin connector station A-pillar, driver's side | (Scheme 10) |
| 6 | 3-Pin Relay /Fuse Panel | (Scheme 9) |
| 7 | 6-Pin connector station A-pillar, front passenger's side | (Scheme 11) |
| 8 | Fuse Panel D -SD | (Scheme 6) |
| 9 | Terminal 30 Wire Junction 2 -TV22- With Battery Jump Start Terminal -U3 | (Scheme 8) |
| 10 | Relay /Fuse Panel F -SF | (Scheme 7) (3) |
| (1) Illustration represent m.y. 2008-09. (2) Illustration represent m.y. 2010. (3) Illustration represent m.y. 2008-10, callouts differ between 2008/09 and 2010 relay/fuse panels. | ||
| (1) | Illustration represent m.y. 2008-09. |
| (2) | Illustration represent m.y. 2010. |
| (3) | Illustration represent m.y. 2008-10, callouts differ between 2008/09 and 2010 relay/fuse panels. |
Scheme 2
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Scheme 7
Scheme 8
Scheme 9
Scheme 10
Scheme 11
Scheme 12
Relay Locations
Note. For fuse identification within the relay and fuse holder panels, refer to RELAY & FUSE HOLDER PANEL LOCATIONS under fuses.
Scheme 13
| Location No. | Description | Refer To |
|---|---|---|
| 1 | Relay / Fuse Panel with Vehicle Electrical System Control Module -J519- Component: -J329-, -J413-, -J910 | (Scheme 12) |
| 2 | 3-Pin Relay / Fuse Panel Component: -J359-, -J360 | (Scheme 9) |
| 3 | Relay / Fuse Panel B -SB- Component: -J17-, -J53-, -J151-, -J179-, -J271-, -J299-, -J317-, -J496-, -J569-, -J695 | See scheme 21 |
| 4 | Relay / Fuse Panel F -SF- Component: -J9-, -J807 | (Scheme 7) |
FUSES - CIRCUIT PROTECTION
| WARNING | Never replace a fuse with one that has a higher amperage rating. A fuse with a too high amperage could damage the electrical part and cause a fire. |
For access to fuse boxes, refer to illustrations below.
Scheme 14
Identifying Instrument Panel Left Side Fuse Box Panel Cover Components. Scheme 15
Scheme 16
Scheme 17
Scheme 18
The individual circuits are protected by fuses. The fuse panels with the fuses are located on the left and right front faces of the instrument panel behind a cover and in the right storage area in the luggage compartment.
There is a plastic clip (fuse puller 'A') in the cover on the left side of the instrument panel, which can be used to remove the fuses. The crank (B) is used for emergency operation of the power roof (if equipped). You will also find a label (C) on both end covers of the instrument panel with the fuse layout) for the corresponding fuse panel. (Scheme 15)
Two spare fuses and a sticker identifying the fuses are located on the inside of the fuse box cover.
Fuses with the proper ampere ratings are available at your Audi dealer.
Note. On no account should fuses be repaired (e.g. with tin foil or wire) as this may cause serious damage elsewhere in the electrical circuit or cause fire. If a fuse blows repeatedly, do not keep replacing it. Proceed to diagnose and fix shorted or overloaded circuit.
AUTOMATIC CIRCUIT BREAKERS
The electric seat adjusters are protected with circuit breakers which reset automatically after the circuit overload has been corrected.
Fuse - Color Codes
Identifying fuse color and ampere rating, refer to table below.
| WARNING | Never replace a fuse with one that has a higher amperage rating. A fuse with a too high amperage could damage the electrical part and cause a fire. |
| Current Rating Amperes | Color |
|---|---|
| 1A | Black |
| 3A | Violet |
| 5A | Light Brown |
| 7.5A | Brown |
| 10A | Red |
| 15A | Blue |
| 20A | Yellow |
| 25A | White or Natural |
| 30A | Green |
| 35A | Green-Blue |
| 40A | Orange |
| 50A | Red |
IDENTIFYING FUSE BY COLOR
Replacing A Fuse
A problem in the electrical system may be caused by a blown fuse.
- Switch off the ignition and the electrical component affected.
- Carefully pry the face cover off the instrument panel using the ignition key or a screwdriver. (Scheme 14)
- Check the fuse index to find out which fuse belongs to the component which has failed. See «FUSE INDEX INFORMATION»(/audi/s5/i-2007-2011/remont/fuses-circuit-breakers/#fuses-circuit-breakers).
- Remove the blown fuse with the plastic clip provided. The clip is located on the holder in the fuse box cover.
- Replace a blown fuse (recognizable by the melted metal strip inside) with a fuse of the same amperage.
- Firmly snap the cover back onto the instrument panel face.
1.2- FUSE PANEL A -SA- CENTER OF TRUNK (BATTERY)
Note. The fuse panel A -SA- is located on battery positive terminal in luggage compartment. The battery is located in the center of the trunk in the well area under the trim, refer to illustrations below.
For fuse identification and amperage rating refer to FUSE - COLOR CODES .
Scheme 19
1.2.1 - FUSES
| Location/ Position | Rating (A) | Function/Component | Wiring ID | Terminal |
|---|---|---|---|---|
| A | Battery Interrupt Igniter -N253 | |||
| 1 | 110A | Vehicle Electrical System Supply Engine Component Supply | SA1 | 30 |
| 2 | 110A | Vehicle Electrical System Supply Engine Component Supply | SA2 | 30 |
| 3 | 40A | Driving School Option | SA3 | 30 |
| 3 | 50A | Rental Car Option | SA3 | 30 |
| 3 | 110A | Council Car Option | SA3 | 30 |
| 3 | 80A (1) | ABS Control Module Fuse 1 -S123- (1) ABS Control Module Fuse 2 -S124- (1) ABS Control Module Fuse 3 -S137- (1) | SA3 | 30 |
| (1) Only models with right-hand drive. | ||||
| (1) | Only models with right-hand drive. |
IDENTIFYING FUSES (FUSE PANEL A -SA- CENTER OF TRUNK)
Note. Whenever replacing a fuse, always consult the sticker on the inside of the fuse panel cover. It contains the most up-to-date information regarding the fuse arrangement.
1.3- RELAY / FUSE PANEL B -SB- IN E-BOX PLENUM CHAMBER
Note. The relay and fuse panel B -SB- is located in electronic box on left side of the engine compartment in plenum chamber, refer to illustration below. For relay identification related to relay and fuse panel B -SB- refer to RELAY AND FUSE HOLDER IN E-BOX PLENUM CHAMBER under relays.
For fuse identification and amperage rating refer to FUSE - COLOR CODES .
1.3.1 - SINGLE FUSES
| Location | Rating (A) | Function/Component |
|---|---|---|
| K | 60A | Strip fuse for engine glow plugs -S39- (1) |
| K | 80A | Strip fuse for engine glow plugs -S39- (2) |
| K | 50A | Secondary Air Injection (AIR) Pump Fuse -S130- (3) , (4) |
| L | 15A | Brake System Vacuum Pump Fuse -S283- (4) |
| ST1 | Fuse Carrier 1, Fuses (5) | |
| (1) Only models with 4 cylinder diesel engine. (2) Only models with 6 cylinder diesel engine. (3) Only models with 6 cylinder gasoline engine. (4) Only models with 8 cylinder gasoline engine. (5) Refer to the fuse carrier ST1 (Black) table. | ||
| (1) | Only models with 4 cylinder diesel engine. |
| (2) | Only models with 6 cylinder diesel engine. |
| (3) | Only models with 6 cylinder gasoline engine. |
| (4) | Only models with 8 cylinder gasoline engine. |
| (5) | Refer to the fuse carrier ST1 (Black) table. |
IDENTIFYING SINGLE FUSES (RELAY & FUSE PANEL IN E-BOX PLENUM CHAMBER)
1.3.2 - FUSES IN FUSE CARRIER ST1 (BLACK)
| Fuse No. | Rating (Amperage) | Function/Component | Wiring ID. | Terminal |
|---|---|---|---|---|
| 1 | 15A | Transmission Control Module (TCM) -J217- Direct Shift Gearbox (DSG) Mechatronic -J743 | SB1 | 30 |
| 2 | 5A | Oil Level Thermal Sensor -G266 | SB2 | 87 |
| 3 | 5A | Engine Control Module (ECM) -J623- Mass Air Flow (MAF) Sensor -G70- (1) (2) | SB3 | 15 |
| 4 | 5A | Engine Control Module (ECM) -J623 | SB4 | 30 |
| 5 | 10A (2) 15A (3) 15A (4) 15A (5) 15A (6) 15A (7) 20A (1) | Mass Air Flow (MAF) Sensor -G70- (5) Automatic Glow Time Control Module -J179- (6) (7) Secondary Air Injection (AIR) Pump Relay -J299- (4) (5) Throttle Valve Control Module -J338- (7) Preheating Coolant, Low Heat Output Relay -J359- (6) (7) Preheating Coolant, High Heat Output Relay -J360- (6) (7) Wastegate Bypass Regulator Valve -N75- (6) Positive Crankcase Ventilation (PCV) Heating Element -N79- (6) Evaporative Emission (EVAP) Canister Purge Regulator Valve 1 -N80- (4) (5) Secondary Air Injection (AIR) Solenoid Valve -N112- (4) Left electrohydraulic engine mounting regulator valve -N144- (5) (6) (7) Right electrohydraulic engine mounting regulator valve -N145- (5) (7) Intake Manifold Tuning (IMT) Valve -N156- (4) Air filter bypass flap valve -N275- (6) (7) Fuel Pressure Regulator Valve -N276- (1) (2) Fuel Metering Valve -N290- (4) (5) Secondary Air Injection (AIR) Solenoid Valve 2 -N320- (4) Intake Manifold Change-Over Valve -N335- (5) Exhaust Gas Recirculation (EGR) Cooler Switch-Over Valve -N345- (6) (7) Fuel Metering Valve 2 -N402- (5) Oil Pressure Regulation Valve -N428- (4) (7) Leak Detection Pump (LDP) -V144- (4) (5) | SB5 | 87 |
| 6 | 15A | Engine Control Module (ECM) -J623 | SC6 | 87 |
| 7 | 10A (1) 10A (3) 10A (5) 10A (6) 10A (7) 15A (2) 15A (4) | Map Controlled Engine Cooling Thermostat -F265- (5) Actuator 1 for camshaft adjustment -F366- (2) (4) Actuator 2 for camshaft adjustment -F367- (2) (4) Actuator 3 for camshaft adjustment -F368- (2) (4) Actuator 4 for camshaft adjustment -F369- (2) (4) Actuator 5 for camshaft adjustment -F6370- (2) (4) Actuator 6 for camshaft adjustment -P371- (2) (4) Actuator 7 for camshaft adjustment -P372- (2) (4) Actuator 8 for camshaft adjustment -F373- (2) (4) Actuator 9 for camshaft adjustment -F374- (4) Actuator 10 for camshaft adjustment -F375- (4) Actuator 11 for camshaft adjustment -F376- (4) Actuator 12 for camshaft adjustment -F377- (4) Coolant Circulation Pump Relay -J151- (1) (2) (5) Auxiliary Engine Coolant (EC) Pump Relay -J496- (4) Wastegate Bypass Regulator Valve -N75- (1) (2) Evaporative Emission (EVAP) Canister Purge Regulator Valve 1 -N80- (1) (2) Left electrohydraulic engine mounting regulator valve -N144- (1) (2) Camshaft Adjustment Valve 1 -N205- (1) (2) (4) (5) Camshaft Adjustment Valve 2 -N208- (4) (5) Turbocharger Recirculating Valve -N249- (1) (2) Fuel Pressure Regulator Valve -N276- (6) (7) Fuel Metering Valve -N290- (6) (7) Intake Manifold Runner Control (IMRC) Valve -N316- (2) Camshaft Adjustment Valve 1 (exhaust) -N318- (4) (5) Camshaft Adjustment Valve 2 (exhaust) -N319- (1) (4) (5) Engine Coolant (EC) Switch-Off Valve (Climatronic) -N422- (1) (2) (4) Oil Pressure Regulation Valve -N428- (1) (2) Leak Detection Pump (LDP) V144- (2) Driver's Window Regulator Motor -V147- (5) Variable Intake Manifold Runner Motor -V183- (5) | SC7 | 87 |
| 8 | 10A (6) 10A (7) 20A (1) 20A (2) 20A (3) 20A (4) 30A (5) | Ignition Coil 1 with Power Output Stage -N70- (1) (2) (5) Ignition Coil 2 with Power Output Stage -N127- (1) (2) (5) Ignition Coil 3 with Power Output Stage -N291- (1) (2) (5) Ignition Coil 4 with Power Output Stage -N292- (1) (2) (5) Ignition Coil 5 with Power Output Stage -N323- (5) Ignition Coil 6 with Power Output Stage -N324- (5) Ignition Coil 7 with Power Output Stage -N325- (5) Ignition Coil 8 with Power Output Stage -N326- (5) Engine Coolant (EC) Switch-Off Valve (Climatronic) -N422- (6) Exhaust Gas Recirculation (EGR) Cooler Pump -V400- (6) (7) | SC8 | 87 |
| 9 | 15A (3) 15A (4) 15A (5) 20A (6) 20A (7) | Auxiliary Fuel Pump Relay -J832- (6) (7) Oxygen Sensor (O2S) Heater 1 (behind Three Way Catalytic Converter (TWO) -Z29- (5) Oxygen Sensor (O2S) Heater 2 (behind Three Way Catalytic Converter (TWC) -Z30- (5) | SB9 | 87 |
| 10 | 15A | Oxygen Sensor (O2S) Heater -Z19- (1) (2) (5) (6) (7) Oxygen Sensor (02S) Heater 2 -Z28- (1) (5) Oxygen Sensor (O2S) Heater 1 (behind Three Way Catalytic Converter TWC) -Z29- (2) | SB10 | 87 |
| 11 | 5A | Coolant Fan Control (FC) Control Module -J293- (7) Coolant Fan Control (FC) Control Module 2 -J671- (7) | SB11 | 87 |
| 12 | 5A | Mass Air Flow (MAF) Sensor-G70- (6) (7) Transmission Control Module (TCM) -J217- Direct Shift Gearbox (DSG) Mechatronic -J743 | SB12 | 15 |
| (1) Only models with 1.8L - 4 cylinder gasoline engine. (2) Only models with 2.0L - 4cylinder gasoline engine. (3) Only models with 3.0L - 6 cylinder gasoline engine. (4) Only models with 3.2L - 6 cylinder gasoline engine. (5) Only models with 4.2L - 8 cylinder gasoline engine. (6) Only models with 2.0L - 4 cylinder diesel engine. (7) Only models with 2.7L / 3.0L - 6 cylinder diesel engine. | ||||
| (1) | Only models with 1.8L - 4 cylinder gasoline engine. |
| (2) | Only models with 2.0L - 4cylinder gasoline engine. |
| (3) | Only models with 3.0L - 6 cylinder gasoline engine. |
| (4) | Only models with 3.2L - 6 cylinder gasoline engine. |
| (5) | Only models with 4.2L - 8 cylinder gasoline engine. |
| (6) | Only models with 2.0L - 4 cylinder diesel engine. |
| (7) | Only models with 2.7L / 3.0L - 6 cylinder diesel engine. |
IDENTIFYING FUSES IN CARRIER ST1 (IN E-BOX PLENUM CHAMBER - ST1 BLACK)
1.4- FUSE PANEL C -SC- INSTRUMENT PANEL - DRIVER'S SIDE (THROUGH MODEL YEAR 2009)
Note. The fuse panel C -SC- is located on the left side end of the dash panel (driver's side), refer to illustrations below.
Note. The fuse box consist of several fuse carriers identified as ST1 (Black ), ST2 (Brown) and ST3 (Red). For fuse identification and amperage rating refer to FUSE - COLOR CODES .
1.4.1 - FUSES IN FUSE CARRIER ST1 (BLACK)
| Fuse No. | Rating (Amperage) | Function/Component | Wiring ID. | Terminal |
|---|---|---|---|---|
| 1 | 5A | Active Steering Control Module -J792 | SC1 | 15 |
| 2 | 10A | Clutch Pedal Switch F36- Clutch Pedal Starter Interlock Switch -F194 Clutch Position Sensor -G476 | SC2 | 15 |
| 3 | 5A | Garage Door Opener Control Head -E284- Garage Door Opener Control Module -J530 | SC3 | 15 |
| 4 | 15A | Directional Stabilization Assistance Control Module -J759 | SC4 | 15 |
| 5 | 15A | Air Quality Sensor -G238 | SC5 | 15 |
| 6 | 15A | Headlamp Adjuster -E102- Headlamp Range Control Module -J431- Right Headlamp Power Output Stage -J668- Headlamp Range/Cornering Lamp Control Module -J745- Left Headlamp Beam Adjustment Motor -V48- Right Headlamp Beam Adjustment Motor -V49 | SC6 | 15 |
| 7 | 15A | Left Headlamp Power Output Stage -J667 | SC7 | 15 |
| 8 | 10A | Vehicle Electrical System Control Module -J519 | SC8 | 15 |
| 9 | 5A | Automatic Day/Night Interior Mirror -Y7 | SC9 | 15 |
| 10 | 10A | Selector Lever Sensors Control Module -J587- Shift Lock Solenoid -N110 | SC10 | 15 |
| 11 | 5A | Left Washer Nozzle Heater -Z20- Right Washer Nozzle Heater -Z21 | SC11 | 15 |
| 12 | 5A | A/C Pressure/temperature Sensor -G395 | SC12 | 15 |
IDENTIFYING FUSES IN FUSE CARRIER ST1 BLACK (INTERIOR COMPARTMENT - DRIVER'S SIDE - 2008-09)
1.4.2 - FUSES IN FUSE CARRIER ST2 (BROWN)
| Fuse No. | Rating (Amperage) | Function/Component | Wiring ID. | Terminal |
|---|---|---|---|---|
| 1 | 5A | Recirculation Pump Relay -J160- () | SC1 | 87 |
| 2 | 5A | Clutch Pedal Switch F36- Clutch Pedal Starter Interlock Switch -F194 Clutch Position Sensor -G476 | SC2 | 87 |
| 3 | 20A (2) 25A (1) | Transfer Fuel Pump (FP) -G6- (2) Fuel Pump Control Module -J538- (1) | SC3 | 87 |
| 4 | 5A | Recirculation Pump Relay -J160- (3) | SC4 | 15 |
| 5 | 30A | Vehicle Electrical System Control Module -J519 | SC5 | 30 |
| 6 | 10A | ABS Control Module -J104- (4) | SC6 | 30 |
| 7 | 25A | Horn Relay -J413 | SC7 | 30 |
| 8 | 30A | Driver's Door Control Module -J386 | SC8 | 30 |
| 9 | 30A | Wiper Motor Control Module -J400 | SC9 | 30 |
| 10 | 25A | ABS Control Module -J104- (4) | SC10 | 30 |
| 11 | 15A | Driver's Door Control Module -J386 | SC11 | 30 |
| 12 | 5A | Rain/Light Recognition Sensor -G397 | SC12 | 30 |
| (1) Only models with gasoline engine. (2) Only models with diesel engine. (3) Only models with 6 cylinder gasoline engine. (4) Only models with left-hand drive. | ||||
| (1) | Only models with gasoline engine. |
| (2) | Only models with diesel engine. |
| (3) | Only models with 6 cylinder gasoline engine. |
| (4) | Only models with left-hand drive. |
IDENTIFYING FUSES IN FUSE CARRIER ST2 BROWN (INTERIOR COMPARTMENT - DRIVER'S SIDE - 2008-09)
1.4.3 - FUSES IN FUSE CARRIER ST3 (RED)
| Fuse No. | Rating (Amperage) | Function/Component | Wiring ID. | Terminal |
|---|---|---|---|---|
| 1 | Not used | SC1 | ||
| 2 | Not used | SC2 | ||
| 3 | 10A | Driver's Seat Lumbar Support Adjustment Switch -E176- Front Passenger's Seat Lumbar Support Adjustment Switch -E177 | SC3 | 30 |
| 4 | 35A | Active Steering Control Module -J792 | SC4 | 30 |
| 5 | Not used | SC5 | ||
| 6 | 35A | Vehicle Electrical System Control Module -J519 | SC6 | 30 |
| 7 | 30A (1) 20A (2) | Vehicle Electrical System Control Module -J519 | SC7 | 30 |
| 8 | 30A | Vehicle Electrical System Control Module -J519 | SC8 | 30 |
| 9 | 20A | Power Sunroof Control Module -J245 | SC9 | 30 |
| 10 | 30A | Vehicle Electrical System Control Module -J519 | SC10 | 30 |
| 11 | Not used | SC11 | ||
| 12 | 5A | Alarm Horn -H12- Anti-Theft Alarm System Sensor -G578 | SC12 | 30 |
| (1) Not applicable, phased-in modification (2) Phased-in modification | ||||
| (1) | Not applicable, phased-in modification |
| (2) | Phased-in modification |
IDENTIFYING FUSES IN FUSE CARRIER ST3 RED (INTERIOR COMPARTMENT - DRIVER'S SIDE - 2008-09)
Note. Whenever replacing a fuse, always consult the sticker on the inside of the fuse panel cover. It contains the most up-to-date information regarding the fuse arrangement.
1.5- FUSE PANEL C -SC- INSTRUMENT PANEL - DRIVER'S SIDE (FROM MODEL YEAR 2010)
Note. The fuse panel C -SC- is located on the left side end of the dash panel (driver's side), refer to illustrations below.
Note. The fuse box consist of several fuse carriers identified as ST1 (Black ), ST2 (Brown) and ST3 (Red). To remove end cover see scheme 22 For fuse identification and amperage rating refer to FUSE - COLOR CODES.
1.5.1 - FUSES IN FUSE CARRIER ST1 (BLACK)
| Fuse No. | Rating (Amperage) | Function/Component | Wiring ID. | Terminal |
|---|---|---|---|---|
| 1 | 5A | Active Steering Control Module -J792 | SC1 | 15 |
| 2 | Not used | SC2 | ||
| 3 | 5A | Garage Door Opener Control Head -E284- Garage Door Opener Control Module -J530 | SC3 | 15 |
| 4 | 10A | Directional Stabilization Assistance Control Module -J759 | SC4 | 15 |
| 5 | 5A | Air Quality Sensor -G238 | SC5 | 15 |
| 6 | 5A | Headlamp Adjuster -E102- Headlamp Range Control Module -J431- Right Headlamp Power Output Stage -J668- Headlamp Range/Cornering Lamp Control Module -J745- Left Headlamp Beam Adjustment Motor -V48- Right Headlamp Beam Adjustment Motor -V49 | SC6 | 15 |
| 7 | 5A | Left Headlamp Power Output Stage -J667 | SC7 | 15 |
| 8 | 5A | Vehicle Electrical System Control Module -J519 | SC8 | 15 |
| 9 | 5A | Distance Regulation Control Module -J428 | SC9 | 15 |
| 10 | 5A | Cutch Position Sensor -G476- Selector Lever Sensors Control Module -J587- Shift Lock Solenoid -N110 | SC10 | 15 |
| 11 | 5A | Left Washer Nozzle Heater -Z20- Right Washer Nozzle Heater -Z21 | SC11 | 15 |
| 12 | 5A | A/C Pressure/temperature Sensor -G395 | SC12 | 15 |
| 13 | 5A | 18-Pin Connector -T18a | SC13 | 15 |
| 14 | 5A | Emergency Flasher Button -E229- Airbag Control Module -J234- Seat Occupied Recognition Control Module -J706- Emergency Flasher Indicator Lamp -K6 | SC14 | 15 |
| 15 | 25A | ABS Control Module -J104- Fuse Carrier 2 -ST2- on fuse panel C -SC Fuse Carrier 1 -ST1- on fuse panel D -SD Fuse Carrier 4 -ST4- on fuse panel F -SF | SC15 | 15 |
| 16 | 40A | Starter Relay -J53- Starter Relay 2 -J695- Fuse Carrier 1 -ST1- with fuse 3 (on fuse panel B) -SB3- Fuse Carrier 1 -ST1- with fuse 12 (on fuse panel B) -SB12 | SC16 | 15 |
IDENTIFYING FUSES IN FUSE CARRIER ST1 BLACK (INTERIOR COMPARTMENT - DRIVER'S SIDE - 2010)
1.5.2 - FUSES IN FUSE CARRIER ST2 (BROWN)
| Fuse No. | Rating (Amperage) | Function/Component | Wiring ID. | Terminal |
|---|---|---|---|---|
| 1 | 5A | Automatic Day/Night Interior Mirror -Y7 | SC1 | 87 |
| 2 | 5A | Clutch Position Sensor -G476 | SC2 | 87 |
| 3 | 20A (2) 25A (1) | Transfer Fuel Pump (FP) -G6- (2) Fuel Pump Control Module -J538- (1) | SC3 | 87 |
| 4 | 10A | Recirculation Pump Relay -J160- (3) Reducing Agent Metering System Control Module -J880 | SC4 | 15 |
| 5 | 30A | Vehicle Electrical System Control Module -J519 | SC5 | 30 |
| 6 | 10A | ABS Control Module -J104- (4) | SC6 | 30 |
| 7 | 25A | Horn Relay -J413 | SC7 | 30 |
| 8 | 30A | Driver's Door Control Module -J386 | SC8 | 30 |
| 9 | 30A | Wiper Motor Control Module -J400 | SC9 | 30 |
| 10 | 25A | ABS Control Module -J104- (4) | SC10 | 30 |
| 11 | 15A | Driver's Door Control Module -J386 | SC11 | 30 |
| 12 | 5A | Rain/Light Recognition Sensor -G397 | SC12 | 30 |
| (1) Only models with gasoline engine. (2) Only models with diesel engine. (3) Only models with 6 cylinder gasoline engine. (4) Only models with left-hand drive. | ||||
| (1) | Only models with gasoline engine. |
| (2) | Only models with diesel engine. |
| (3) | Only models with 6 cylinder gasoline engine. |
| (4) | Only models with left-hand drive. |
IDENTIFYING FUSES IN FUSE CARRIER ST2 BROWN (INTERIOR COMPARTMENT - DRIVER'S SIDE - 2010)
1.5.3 - FUSES IN FUSE CARRIER ST3 (RED)
| Fuse No. | Rating (Amperage) | Function/Component | Wiring ID. | Terminal |
|---|---|---|---|---|
| 1 | Not used | SC1 | ||
| 2 | Not used | SC2 | ||
| 3 | 10A | Driver's Seat Lumbar Support Adjustment Switch -E176- Front Passenger's Seat Lumbar Support Adjustment Switch -E177 | SC3 | 30 |
| 4 | 35A | Active Steering Control Module -J792 | SC4 | 30 |
| 5 | Not used | SC5 | ||
| 6 | 35A | Vehicle Electrical System Control Module -J519 | SC6 | 30 |
| 7 | 20A | Vehicle Electrical System Control Module -J519 | SC7 | 30 |
| 8 | 30A | Vehicle Electrical System Control Module -J519 | SC8 | 30 |
| 9 | 20A | Power Sunroof Control Module -J245 | SC9 | 30 |
| 10 | 30A | Vehicle Electrical System Control Module -J519 | SC10 | 30 |
| 11 | Not used | SC11 | ||
| 12 | 5A | Alarm Horn -H12- Anti-Theft Alarm System Sensor -G578 | SC12 | 30 |
IDENTIFYING FUSES IN FUSE CARRIER ST3 RED (INTERIOR COMPARTMENT - DRIVER'S SIDE - 2010)
Note. Whenever replacing a fuse, always consult the sticker on the inside of the fuse panel cover. It contains the most up-to-date information regarding the fuse arrangement.
1.6- FUSE PANEL D -SD- INSTRUMENT PANEL - PASSENGER SIDE
Note. The fuse panel D -SD- is located on the right side end of the dash panel (passenger side), refer to illustrations below.
Note. The fuse box consist of several fuse carriers identified as ST1 (Black) and ST2 (Brown). For sample of end cover removal see scheme 22 For fuse identification and amperage rating refer to FUSE - COLOR CODES.
Component "A" - 46 pin connector, black, CAN separating connector, instrument panel -T46s-.
1.6.1 - FUSES IN FUSE CARRIER ST1 (BLACK)
| Fuse No. | Rating (Amperage) | Function/Component | Wiring ID. | Terminal |
|---|---|---|---|---|
| 1 | Not used | SD1 | ||
| 2 | Not used | SD2 | ||
| 3 | Not used | SD3 | ||
| 4 | Not used | SD4 | ||
| 5 | 5A | Steering Column Electronic Systems Control Module -J527 | SD5 | |
| 6 | 5A | ASR/ESP Button -E256- Parking Aid Button -E266 | SD6 | 15 |
| 7 | 5A | 16-Pin Connector -T16- diagnostic connector | SD7 | 15 |
| 8 | 5A | Data Bus On Board Diagnostic Interface -J533 | SD8 | 15 |
| 9 | 5A | Preheating Coolant, High Heat Output Relay -J360 | SD9 | 15 |
| 10 | Not used | SD10 | ||
| 11 | Not used | SD11 | ||
| 12 | Not used | SD12 |
IDENTIFYING FUSES IN FUSE CARRIER ST1 BLACK (INTERIOR COMPARTMENT - PASSENGER SIDE)
1.6.2 - FUSES IN FUSE CARRIER ST2 (BROWN)
| Fuse No. | Rating (Amperage) | Function/Component | Wiring ID. | Terminal |
|---|---|---|---|---|
| 1 | 5A | CD Changer -R41- DVD Changer -R161- External Audio Source Connector -R199 | SD1 | 30 |
| 2 | 5A | Switch module for Charisma -E592 | SD2 | 30 |
| 3 | 5A (1) 20A (2) | Front Information Display Control Module -J685- (1) Control module for information electronics1 -J794- (1) Radio -R- (2) | SD3 | 30 |
| 4 | 5A | Light Switch -E1- Instrument Cluster Control Module -J285 | SD4 | 30 |
| 5 | 5A | Instrument Cluster Control Module -J285- Data Bus On Board Diagnostic Interface -J533 | SD5 | 30 |
| 6 | 5A | Access/Start Authorization Switch -E415 | SD6 | 30 |
| 7 | 5A | Light Switch -E1 | SD7 | 30 |
| 8 | 40A | Fresh Air Blower Control Module -J126 | SD8 | 30 |
| 9 | 5A | Electronic Steering Column Lock Control Module -J764 | SD9 | 30 |
| 10 | 10A | Climatronic Control Module -J255 | SD10 | 30 |
| 11 | 10A | 16-Pin Connector -T16- diagnostic connector | SD11 | 30 |
| 12 | 5A | Steering Column Electronic Systems Control Module -J527 | SD12 | 30 |
| (1) Only models with MMI (MOST). (2) Only models with Infotainment CAN. | ||||
| (1) | Only models with MMI (MOST). |
| (2) | Only models with Infotainment CAN. |
IDENTIFYING FUSES IN FUSE CARRIER ST2 BROWN (INTERIOR COMPARTMENT - PASSENGER SIDE)
Note. Whenever replacing a fuse, always consult the sticker on the inside of the fuse panel cover. It contains the most up-to-date information regarding the fuse arrangement.
1.7- FUSE PANEL F -SF- LUGGAGE COMPARTMENT - RIGHT SIDE (2008-09)
Note. This luggage compartment fuse holder is located behind the trim on the right side of trunk, refer to illustrations below. For relay identification, refer to RELAY AND FUSE HOLDER IN LUGGAGE COMPARTMENT - RIGHT SIDE . The fuse box consist of several fuse carriers identified as ST1 (Black ), ST2 (Black), ST3 (Brown), ST4 (Red), ST5 (Black) and a Single Fuse "H". For fuse identification and amperage rating refer to FUSE - COLOR CODES .
1.7.1 - FUSES IN CARRIER ST1 (BLACK)
| Position/ Location | Rating (Amperage) | Function/Component | Wiring ID | Terminal |
|---|---|---|---|---|
| 1 | Not used | SF1 | ||
| 2 | Not used | SF2 | ||
| 3 | Not used | SF3 | ||
| 4 | Not used | SF4 | ||
| 5 | Not used | SF5 | ||
| 6 | Not used | SF6 | ||
| 7 | Not used | SF7 | ||
| 8 | Not used | SF8 | ||
| 9 | Not used | SF9 | ||
| 10 | Not used | SF10 | ||
| 11 | Not used | SF11 | ||
| 12 | Not used | SF12 |
IDENTIFYING FUSES IN FUSE CARRIER ST1 BLACK (LUGGAGE COMPARTMENT - RIGHT SIDE - 2008-09)
1.7.2 - FUSES IN CARRIER ST2 (BLACK)
| Fuse No. | Rating (Amperage) | Function/Component | Wiring ID | Terminal |
|---|---|---|---|---|
| 1 | 5A | Tire Pressure Monitoring Control Module -J502 | SF1 | 30 |
| 2 | 15A | Towing Recognition Control Module -J345 | SF2 | 30 |
| 3 | 20A | Towing Recognition Control Module -J345 | SF3 | 30 |
| 4 | 20A | Towing Recognition Control Module -J345 | SF4 | 30 |
| 5 | 5A | Electro-Mechanical Parking Brake Button -E538 | SF5 | 30 |
| 6 | 15A | Electronic Damping Control Module -J250 | SF6 | 30 |
| 7 | 30A | Electro-Mechanical Parking Brake Control Module -J540 | SF7 | 30 |
| 8 | 30A | Comfort System Central Control Module -J393 | SF8 | 30 |
| 9 | 35A | All-Wheel Drive Control Module -J492 | SF9 | |
| 10 | 30A | Comfort System Central Control Module -J393 | SF10 | 30 |
| 11 | 20A | Comfort System Central Control Module -J393 | SF11 | 30 |
| 12 | 5A | Models Location System Control Module Interface -J843 | SF12 | 30 |
IDENTIFYING FUSES IN FUSE CARRIER ST2 BLACK (LUGGAGE COMPARTMENT - RIGHT SIDE - 2008-09)
1.7.3 - FUSES IN CARRIER ST3 (BROWN)
| Fuse No. | Rating (Amperage) | Function/Component | Wiring ID | Terminal |
|---|---|---|---|---|
| 1 | 15A (1) 30A (2) | Converter with Socket, 12V, 230V -U13 | SF1 | 30 |
| 2 | Not used | SF2 | ||
| 3 | 7.5A | Navigation System Control Module with CD drive -J401- Radio -R Telephone Transceiver -R36- TV Tuner -R78- Amplifier for telephone -R86- Telephone Baseplate -R126- Satellite Radio -R146- Digital Radio -R147- 18-Pin Connector, black -T18a | SF3 | 30 |
| 4 | 30A | Digital Sound System Control Module -J525 | SF4 | 30 |
| 5 | 5A | Front Information Display Control Module -J523 | SF5 | 30 |
| 6 | 30A | Auxiliary Heater Control Module -J364 | SF6 | 30 |
| 7 | 30A | Electro-Mechanical Parking Brake Control Module -J540 | SF7 | 30 |
| 8 | 30A | Left Rear Heated Seat Regulating Switch -E128- Right Rear Heated Seat Regulating Switch -E129 | SF8 | 30 |
| 9 | 30A | Front Passenger's Door Control Module -J387 | SF9 | 30 |
| 10 | 5A | Auxiliary Heater RF Receiver -R64 | SF10 | 30 |
| 11 | 15A | Front Passenger's Door Control Module -J387 | SF11 | 30 |
| 12 | 5A | View Camera System Control Module -J772 | SF12 | 30 |
| (1) Not applicable, phased-in modification (2) Phased-in modification | ||||
| (1) | Not applicable, phased-in modification |
| (2) | Phased-in modification |
IDENTIFYING FUSES IN FUSE CARRIER ST3 BROWN (LUGGAGE COMPARTMENT - RIGHT SIDE - 2008-09)
1.7.4 - FUSES IN CARRIER ST4 (RED)
| Fuse No. | Rating (Amperage) | Function/Component | Wiring ID | Terminal |
|---|---|---|---|---|
| 1 | 15A | 12V Socket 2 -U18 | SF1 | 87 |
| 2 | 15A | 12V Socket -U5 | SF2 | 87 |
| 3 | 15A | 12V Socket 3 -U19 | SF3 | 87 |
| 4 | 15A | Cigarette Lighter -Ul | SF4 | 87 |
| 5 | 5A | Parallel Parking Assistance Control Module -J791 | SF5 | 15 |
| 6 | 5A | 18-Pin Connector, black -T18a | SF6 | 15 |
| 7 | 5A | Distance Regulation Control Module -J428 | SF7 | 15 |
| 8 | Not used | SF8 | ||
| 9 | 5A | Electro-Mechanical Parking Brake Button -E538 | SF9 | 15 |
| 10 | 5A | Lane Change Assistance Control Module 2 -J770 | SF10 | 15 |
| 11 | 5A | Left Rear Heated Seat Regulating Switch -E128 | SF11 | 15 |
| 12 | 5A | Emergency Flasher Switch -E3- Airbag Control Module -J234- Seat Occupied Recognition Control Module -J706- Front Passengers Airbag Disabled Indicator Lamp -K145 | SF12 | 15 |
IDENTIFYING FUSES IN FUSE CARRIER ST4 RED (LUGGAGE COMPARTMENT - RIGHT SIDE - 2008-09)
1.7.5 - FUSES IN CARRIER ST5 (BLACK)
| Fuse No. | Rating (Amperage) | Function/Component | Wiring ID | Terminal |
|---|---|---|---|---|
| 1 | Not used | SF1 | ||
| 2 | Not used | SF2 | ||
| 3 | Not used | SF3 | ||
| 4 | Not used | SF4 | ||
| 5 | Not used | SF5 | ||
| 6 | Not used | SF6 | ||
| 7 | Not used | SF7 | ||
| 8 | Not used | SF8 | ||
| 9 | Not used | SF9 | ||
| 10 | Not used | SF10 | ||
| 11 | Not used | SF11 | ||
| 12 | Not used | SF12 |
IDENTIFYING FUSES IN FUSE CARRIER ST5 BLACK (LUGGAGE COMPARTMENT - RIGHT SIDE - 2008-09)
1.7.6 - SINGLE FUSES
| Position/Location | Function/Component | Wiring ID | Terminal |
|---|---|---|---|
| H | Rear Window Defogger Relay -J9 | S41 | 30 |
IDENTIFYING SINGLE FUSES (LUGGAGE COMPARTMENT - RIGHT SIDE)
1.8- FUSE PANEL F -SF- LUGGAGE COMPARTMENT - RIGHT SIDE (2010)
Note. This luggage compartment fuse holder is located behind the trim on the right side of trunk, refer to illustrations below. For relay identification, refer to RELAY AND FUSE HOLDER IN LUGGAGE COMPARTMENT - RIGHT SIDE . The fuse box consist of several fuse carriers identified as ST1 (Black ), ST2 (Black), ST3 (Brown), ST4 (Red), ST5 (Black) and a Single Fuse "H". For fuse identification and amperage rating refer to FUSE - COLOR CODES .
1.8.1 - FUSES IN CARRIER ST1 (BLACK)
| Position/ Location | Rating (Amperage) | Function/Component | Wiring ID | Terminal |
|---|---|---|---|---|
| 1 | Not used | SF1 | ||
| 2 | Not used | SF2 | ||
| 3 | Not used | SF3 | ||
| 4 | Not used | SF4 | ||
| 5 | Not used | SF5 | ||
| 6 | Not used | SF6 | ||
| 7 | Not used | SF7 | ||
| 8 | Not used | SF8 | ||
| 9 | Not used | SF9 | ||
| 10 | Not used | SF10 | ||
| 11 | Not used | SF11 | ||
| 12 | Not used | SF12 |
IDENTIFYING FUSES IN FUSE CARRIER ST1 BLACK (LUGGAGE COMPARTMENT - RIGHT SIDE - 2010)
1.8.2 - FUSES IN CARRIER ST2 (BLACK)
| Fuse No. | Rating (Amperage) | Function/Component | Wiring ID | Terminal |
|---|---|---|---|---|
| 1 | 30A | Tire Pressure Monitoring Control Module -J502 | SF1 | 30 |
| 2 | 15A | Towing Recognition Control Module -J345 | SF2 | 30 |
| 3 | 20A | Towing Recognition Control Module -J345 | SF3 | 30 |
| 4 | 20A | Towing Recognition Control Module -J345 | SF4 | 30 |
| 5 | 5A | Electro-Mechanical Parking Brake Button -E538 | SF5 | 30 |
| 6 | 15A | Electronic Damping Control Module -J250 | SF6 | 30 |
| 7 | 30A | Electro-Mechanical Parking Brake Control Module -J540 | SF7 | 30 |
| 8 | 30A | Comfort System Central Control Module -J393 | SF8 | 30 |
| 9 | 35A | All-Wheel Drive Control Module -J492 | SF9 | 30 |
| 10 | 30A | Comfort System Central Control Module -J393 | SF10 | 30 |
| 11 | 20A | Comfort System Central Control Module -J393 | SF11 | 30 |
| 12 | 5A | Models Location System Control Module Interface -J843 | SF12 | 30 |
IDENTIFYING FUSES IN FUSE CARRIER ST2 BLACK (LUGGAGE COMPARTMENT - RIGHT SIDE - 2010)
1.8.3 - FUSES IN CARRIER ST3 (BROWN)
| Fuse No. | Rating (Amperage) | Function/Component | Wiring ID | Terminal |
|---|---|---|---|---|
| 1 | Not used | SF1 | ||
| 2 | 15A | Front Right Seat Ventilation Control Module -J779 | SF2 | 30 |
| 3 | 40A | Radio -R Telephone Transceiver -R36- TV Tuner -R78- Amplifier for telephone -R86- Telephone Baseplate -R126- 18-Pin Connector, black -T18a | SF3 | 30 |
| 4 | 40A | Voltage Stabilizer -J532 | SF4 | 30 |
| 5 | 30A | Converter with Socket 12V, 230V -U13 | SF5 | 30 |
| 6 | 30A | Auxiliary Heater Control Module -J364 | SF6 | 30 |
| 7 | 30A | Electro-Mechanical Parking Brake Control Module -J540 | SF7 | 30 |
| 8 | 30A | Left Rear Heated Seat Regulating Switch -E128- Right Rear Heated Seat Regulating Switch -E129 | SF8 | 30 |
| 9 | 30A | Front Passenger's Door Control Module -J387 | SF9 | 30 |
| 10 | 5A | Auxiliary Heater RF Receiver -R64 | SF10 | 30 |
| 11 | 15A | Front Passenger's Door Control Module -J387 | SF11 | 30 |
| 12 | 30A | Reducing Agent Metering System Control Module -J880 | SF12 | 30 |
IDENTIFYING FUSES IN FUSE CARRIER ST3 BROWN (LUGGAGE COMPARTMENT - RIGHT SIDE - 2010)
1.8.4 - FUSES IN CARRIER ST4 (RED)
| Fuse No. | Rating (Amperage) | Function/Component | Wiring ID | Terminal |
|---|---|---|---|---|
| 1 | 15A | 12V Socket 2 -U18 | SF1 | 87 |
| 2 | 15A | 12V Socket -U5- Converter with Socket 12V, 230V -U13 | SF2 | 87 |
| 3 | 15A | 12V Socket 3 -U19 | SF3 | 87 |
| 4 | 15A | Cigarette Lighter -Ul | SF4 | 87 |
| 5 | Not used | SF5 | ||
| 6 | Not used | SF6 | ||
| 7 | 7.5A | Parallel Parking Assistance Control Module -J791 | SF7 | 15 |
| 8 | Not used | SF8 | ||
| 9 | 5A | Electro-Mechanical Parking Brake Button -E538 | SF9 | 15 |
| 10 | 5A | Lane Change Assistance Control Module 2 -J770 | SF10 | 15 |
| 11 | 5A | Left Rear Heated Seat Regulating Switch -E128 | SF11 | 15 |
| 12 | 5A | Electronic Damping Control Module -J250- Towing Recognition Control Module -J235- Voltage Stabilizer -J532- Electro-Mechanical Parking Brake Control Module -J540 | SF12 | 15 |
IDENTIFYING FUSES IN FUSE CARRIER ST4 RED (LUGGAGE COMPARTMENT - RIGHT SIDE - 2010)
1.8.5 - FUSES IN CARRIER ST5 (BLACK)
| Fuse No. | Rating (Amperage) | Function/Component | Wiring ID | Terminal |
|---|---|---|---|---|
| 1 | Not used | SF1 | ||
| 2 | Not used | SF2 | ||
| 3 | 20A (1) 30A (2) | Digital Sound System Control Module -J525- Radio -R | SF3 | 15 |
| 4 | 7.5A | Control Module for Information Electronics 1 -J794 | SF4 | 15 |
| 5 | 7.5A | Navigation System Control Module with CD drive -J401- Radio -R Telephone Transceiver -R36- TV Tuner -R78- Amplifier for telephone -R86- Telephone Baseplate -R126- Satellite Radio -R146- Digital Radio -R147- 18-Pin Connector, black -T18a | SF5 | 30 |
| 6 | 5A | View Camera System Control Module -J772 | SF6 | 30 |
| 7 | Not used | SF7 | ||
| 8 | Not used | SF8 | ||
| 9 | Not used | SF9 | ||
| 10 | Not used | SF10 | ||
| 11 | Not used | SF11 | ||
| 12 | Not used | SF12 | ||
| (1) Only models with sound system Basic (8RE)/Basic plus (8RX) (2) Not for models with sound system Basic (8RE)/Basic plus (8RX) | ||||
| (1) | Only models with sound system Basic (8RE)/Basic plus (8RX) |
| (2) | Not for models with sound system Basic (8RE)/Basic plus (8RX) |
IDENTIFYING FUSES IN FUSE CARRIER ST5 BLACK (LUGGAGE COMPARTMENT - RIGHT SIDE - 2010)
1.8.6 - SINGLE FUSES
| Position/Location | Function/Component | Wiring ID | Terminal |
|---|---|---|---|
| H | Rear Window Defogger Relay -J9 | S41 | 30 |
IDENTIFYING SINGLE FUSES (LUGGAGE COMPARTMENT - RIGHT SIDE)
1.9- TERMINAL 30 WIRE JUNCTION 2 -TV22- WITH BATTERY JUMP START TERMINAL -U6
Note. The Terminal 30 Wire Junction 2 fuse holder is located in the engine compartment in plenum chamber, refer to illustrations below. For fuse identification and amperage rating refer to FUSE - COLOR CODES .
1.9.1 - FUSES
| Position/Location | Rating (Amps) | Function/Component | Wiring ID | Terminal |
|---|---|---|---|---|
| A | Terminal 30 Wire Junction 2 -TV22 | |||
| B | Battery Jump Start Terminal -U6 | |||
| 1 | 40A 60A 60A | Coolant Fan control 400 W Coolant Fan control 600 W (1) Coolant Fan control 600 W | S204 | 30 |
| 2 | 40A | Coolant Fan control 400 W (1) | S205 | 30 |
| (1) S204 (600 W) and S205 (400 W) are installed in models with coolant fan control 1000 W. | ||||
| (1) | S204 (600 W) and S205 (400 W) are installed in models with coolant fan control 1000 W. |
IDENTIFYING SINGLE FUSES (LUGGAGE COMPARTMENT - RIGHT SIDE)
1.10- 3-PIN RELAY/FUSE PANEL (DIESEL)
Note. The 3-pin relay/fuse panel is located below the instrument panel, driver's side, on relay/fuse panel with vehicle electrical system control module (BCM1) and threaded connection, refer to illustrations below. For fuse identification and amperage rating refer to FUSE - COLOR CODES .
1.10 - FUSES
| Position/Location | Rating (Amps) | Function/Component |
|---|---|---|
| A | Not used | |
| B | Not used | |
| C | 40A | Auxiliary Heater Fuse -S126- (1) |
| D | 60A | Auxiliary Heater Fuse 2 -S328- (1) |
| (1) Only models with diesel engine. | ||
| (1) | Only models with diesel engine. |
IDENTIFYING FUSES (3-PIN RELAY/FUSE PANEL - DRIVER'S SIDE)
1.11- 6-PIN CONNECTOR STATION A-PILLAR - DRIVER'S SIDE
Note. The 6-pin connector station A-pillar is located in driver's footwell on A-pillar, behind side trim, refer to illustrations below. For fuse identification and amperage rating refer to FUSE - COLOR CODES .
1.11 - CIRCUIT BREAKERS
| Position/Location | Rating (Amps) | Function/Component |
|---|---|---|
| A | Not used | |
| B | Not used | |
| C | Not used | |
| D | Not used | |
| E | Not used | |
| F | 30A | Driver's and front passenger's seat circuit breaker -S346- (1) |
| F | 15A | Front Passenger's Power Seat Adjustment Circuit Breaker 1 -S46- (2) |
| G | 15A | Driver's Power Seat Adjustment Circuit Breaker 1 -S44- (2) |
| (1) Through June 2007. (2) From June 2007. | ||
| (1) | Through June 2007. |
| (2) | From June 2007. |
IDENTIFYING FUSES (6-PIN CONNECTOR STATION A-PILLAR - DRIVER'S SIDE)
1.12- 6-PIN CONNECTOR STATION A-PILLAR - PASSENGER SIDE
Note. The 6-pin connector station A-pillar is located in driver's footwell on A-pillar, behind side trim, refer to illustrations below. For fuse identification and amperage rating refer to FUSE - COLOR CODES .
1.12 - FUSES
| Position/Location | Rating (Amps) | Function/Component |
|---|---|---|
| A | Not used | |
| B | Not used | |
| C | Not used | |
| D | Not used | |
| E | Not used | |
| F | 40A | ABS Control Module Fuse 1 -S123- (1) |
| G1 | 25A | ABS Control Module Fuse 3 -S137- (1) |
| G2 | 10A | ABS Control Module Fuse 2 -S124- (1) |
| (1) Only models with right-hand drive. | ||
| (1) | Only models with right-hand drive. |
IDENTIFYING FUSES (6-PIN CONNECTOR STATION A-PILLAR - PASSENGER SIDE)
1.13- RELAY/FUSE PANEL WITH VEHICLE ELECTRICAL SYSTEM CONTROL MODULE -J519
Note. This relay/fuse panel is located below the instrument panel, driver's side, refer to illustrations below. For fuse identification and amperage rating refer to FUSE - COLOR CODES .
1.12 - FUSES
| Position/Location | Rating (Amps) | Function/Component |
|---|---|---|
| A | 40A | ABS Control Module Fuse 1 -S123- (1) |
| (1) Only models with left-hand drive. For models with right-hand drive, see 1.12 - 6-Pin Connector Station A-Pillar - Passenger Side . | ||
| (1) | Only models with left-hand drive. |
IDENTIFYING FUSE (RELAY/FUSE PANEL WITH VEHICLE ELECTRICAL SYSTEM CONTROL MODULE - DRIVER'S SIDE)
1.2- Relay / Fuse Panel with Vehicle Electrical System Control Module -J519
Note. This relay and fuse holder is located below instrument panel on driver's side, refer to illustration below. For fuse identification, refer to 1.13 - Relay/Fuse Panel With Vehicle Electrical System Control Module -J519 .
Scheme 20
| Position/Location | Function/Component |
|---|---|
| 1 | Not used |
| 2 | Horn Relay -J413 |
| 2 | Automatic Day/Night Interior Mirror Relay -J910 |
| 3 | Power Supply Relay (terminal 15) -J329- (1) |
| 4 | Driving School Option |
| (1) Component location applicable from September 2007, through August 2008. From August 2008 refer to 1.5 - Relay / Fuse Panel F -SF in luggage compartment. | |
| (1) | Component location applicable from September 2007, through August 2008. |
IDENTIFYING RELAYS (RELAY/FUSE PANEL WITH VEHICLE ELECTRICAL SYSTEM CONTROL MODULE - DRIVER'S SIDE)
1.3- 3 Pin Relay / Fuse Panel (Diesel)
Note. This relay and fuse holder is located below instrument panel drivers side on relay / fuse panel with Vehicle Electrical System Control Module -J519- and threaded connection. Refer to illustration below. For fuse identification, refer to 1.10 - 3-Pin Relay/Fuse Panel FUSE INDEX INFORMATION .
| Position/Location | Function/Component |
|---|---|
| 1 | Not used |
| 2 | Preheating Coolant, Low Heat Output Relay J359- (1) |
| 2 | Preheating Coolant, High Heat Output Relay -J360- (1) |
| (1) Only models with diesel engine. | |
| (1) | Only models with diesel engine. |
IDENTIFYING RELAYS (3 PIN RELAY/FUSE PANEL (DIESEL) - DRIVER'S SIDE)
1.4- Relay / Fuse Panel B -SB
Note. This relay and fuse holder (s) in e-box plenum chamber is located on the left side of engine compartment, refer to illustration below. For fuse identification, refer to 1.3 - RELAY / FUSE PANEL B -SB- IN E-BOX PLENUM CHAMBER .
| Position/Location | Function/Component |
|---|---|
| A | Automatic Glow Time Control Module -J179- (1) |
| A | Engine Component Power Supply Relay -J757- (2) (3) |
| B | Starter Relay -J53 |
| B | Starter Relay 2 -J695 |
| C | Secondary Air Injection (AIR) Pump Relay -J299- (3) |
| D | Power Supply Relay (terminal 30) -J317- (1) |
| D | Motronic Engine Control Module (ECM) Power Supply Relay -J271- (2) (3) |
| E | Fuel Pump (FP) Relay -J17- (1) |
| E | Auxiliary Fuel Pump Relay -J832- (1) |
| E | Coolant Circulation Pump Relay -J151- (2) |
| E | Auxiliary Engine Coolant (EC) Pump Relay -J496- (3) |
| E | Brake Booster Relay -J569- (4) |
| F | Not used |
| (1) Only models with diesel engine. (2) Only models with 4 cylinder gasoline engine. (3) Only models with 6 cylinder gasoline engine. (4) Only models with 8 cylinder gasoline engine. | |
| (1) | Only models with diesel engine. |
| (2) | Only models with 4 cylinder gasoline engine. |
| (3) | Only models with 6 cylinder gasoline engine. |
| (4) | Only models with 8 cylinder gasoline engine. |
IDENTIFYING RELAYS (ENGINE COMPARTMENT - IN E-BOX PLENUM CHAMBER)
1.5- Relay / Fuse Panel F -SF
Note. This luggage compartment relay / fuse holder is located on the right side interior of trunk, refer to illustrations below. For identification of all other fuses, circuit breakers and threaded connections, refer to 1.7 - FUSE PANEL F -SF- LUGGAGE COMPARTMENT - RIGHT SIDE (2008-09) and/or 1.8 - FUSE PANEL F -SF- LUGGAGE COMPARTMENT - RIGHT SIDE (2010) .
| Position/Location | Function/Component |
|---|---|
| A | Not used |
| B | Not used |
| C | Rear Window Defogger Relay -J9 |
| D | Power Supply Relay (terminal 15) -J329- (1) |
| E | Sockets Relay -J807 |
| (1) Component location applicable from August 2008. | |
| (1) | Component location applicable from August 2008. |
IDENTIFYING RELAYS (LUGGAGE COMPARTMENT - RIGHT SIDE)
See also:
• RELAY LOCATIONS
• RELAY & FUSE HOLDER PANEL LOCATIONS
• FUSE INDEX INFORMATION
• FUSE - COLOR CODES
• 1.12 - 6-Pin Connector Station A-Pillar - Passenger Side
• 1.13 - Relay/Fuse Panel With Vehicle Electrical System Control Module -J519
• 1.5 - Relay / Fuse Panel F -SF
• 1.10 - 3-Pin Relay/Fuse Panel
• 1.3 - RELAY / FUSE PANEL B -SB- IN E-BOX PLENUM CHAMBER
• 1.7 - FUSE PANEL F -SF- LUGGAGE COMPARTMENT - RIGHT SIDE (2008-09)
• 1.8 - FUSE PANEL F -SF- LUGGAGE COMPARTMENT - RIGHT SIDE (2010)
