ACCESS/START AUTHORIZATION SWITCH, CONNECTOR ASSIGNMENT Audi S5 I

Exterior Lights, Switches (coupe) 2 illustrations ~268 words

ACCESS/START AUTHORIZATION SWITCH, CONNECTOR ASSIGNMENT

Connector mount

Scheme 1

Scheme 1: ACCESS/START AUTHORIZATION SWITCH, CONNECTOR ASSIGNMENT
Scheme 1: ACCESS/START AUTHORIZATION SWITCH, CONNECTOR ASSIGNMENT

3 - Not used

4 - Not used

5 - S-contact

6 - Terminal 15

7 - LIN

8 - Terminal 30

9 - Not used

10 - Not used

11 - Not used

12 - Not used

13 - RED2, terminal 15

14 - RED, terminal 15

15 - Ignition/starter switch +

16 - Terminal 31

Scheme 2

Scheme 2: AUTOMATIC HEADLAMP VERTICAL AIM CONTROL OVERVIEW
Scheme 2: AUTOMATIC HEADLAMP VERTICAL AIM CONTROL OVERVIEW
  1. Right Headlamp Beam Adjustment Motor -V49- Various periods of time are determined depending on the model version. Removing and installing Through MY 2011, refer to «HEADLAMP BEAM ADJUSTMENT MOTORS -V48- / -V49»(/audi/s5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) . From MY 2012, refer to «HEADLAMP BEAM ADJUSTMENT MOTORS -V48- / -V49»(/audi/s5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
  2. Control Module Vehicles without cornering lamp: Headlamp Range Control Module -J431-. Vehicles with cornering lamps: headlamp range/cornering lamp control module -J745-. Removing and installing, refer to «CONTROL MODULES -J431-, -J745»(/audi/s5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__control-modules-j431-j745) . Integrated in the vehicle electrical system control module -J519- depending on the date of manufacture from MY 2012.
  3. Electrical Connector
  4. Left Rear Level Control System Sensor -G76- Component location: On rear left control arm. Removing and installing, refer to «Removal and Installation»(/audi/s5/i-2007-2011/remont/suspension-rear/#rear-suspension-coupe) .
  5. Left Front Level Control System Sensor -G78- Component location: On left front control arm Depending on the date of manufacture Removing and installing, refer to «Removal and Installation»(/audi/s5/i-2007-2011/remont/suspension-front/#front-suspension-coupe) .
  6. Left Headlamp Beam Adjustment Motor -V48- Various periods of time are determined depending on the model version. Removing and installing Through MY 2011, refer to «HEADLAMP BEAM ADJUSTMENT MOTORS -V48- / -V49»(/audi/s5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) . From MY 2012, refer to «HEADLAMP BEAM ADJUSTMENT MOTORS -V48- / -V49»(/audi/s5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
