Audi S4
Wiring diagram

Wiring diagram: Shift interlock — Steering column circuit

Audi S4 B8 facelift · 2011-2015

Repair manual
All systems

Steering column circuit — Shift interlock Audi S4 B8 facelift

Components on the diagram

    Components on these wiring diagrams

    Click a component to highlight it on every diagram it appears on.
