PUMP Audi S4 B8 рестайлинг

Rear Final Drive 0bf & 0be (sedan) 2 illustrations ~236 words

PUMP

Special tools and workshop equipment required

  1. Hex Ball Socket T10058
  2. Drip Tray

Note. Observe general repair notes, refer to REPAIR INFORMATION . Follow all safety precautions, refer to SAFETY PRECAUTIONS AND TEST PROCEDURES .

Removing

Place the vehicle on a hoist.

  1. Turn off the ignition.

Place the drip tray under the rear final drive.

Disconnect the connector -1- from the All Wheel Drive (AWD) pump -V415- -2-.

Scheme 130

Scheme 130
Scheme 130

Remove the 4 AWD pump bolts on the hydraulic control unit using the T10058.

Carefully remove the AWD pump -2- while paying attention to the adapter, refer to item 4 in (Scheme 140) in the hydraulic pump.

Note. The adapter could fall out when removing the AWD pump. Insert the adapter into the recesses in the hydraulic pump before installing the AWD pump.

Installing

Scheme 131

Scheme 131
Scheme 131
  1. The hydraulic pump -A- is installed inside the hydraulic control unit in its Installed position; assembling the hydraulic pump. (Scheme 183)
  2. The adapter -B- is installed into the recesses in the hydraulic pump.
  3. The new O-ring -D- is installed on the AWD pump.

Install the AWD pump and the shaft -C- into the adapter -B-.

Tighten the four bolts on the AWD pump diagonally, refer to item 2 in (Scheme 140).

Connect the connector -1- to the AWD pump.

Fill the ATF in the rear final drive. Refer to ATF IN REAR FINAL DRIVE 0BF AND 0BE, FILLING .
