Special tools and workshop equipment required
- Ignition Coil Puller T40039
Removing
Remove the engine covers -1 and 2- upward.
Free up the fuel line -4- and hose connection -1- from the Evaporative Emission (EVAP) canister on the air filter housing and on the air guide tube.
Scheme 7
Remove the vacuum hose -2- from the air guide hose connection.
Remove the air guide pipe by loosening the hose clamp -3- and opening the clips -arrows-.
Remove the air filter housing.
Remove the bolts -arrows- and disconnect the connectors on the ignition coils.
Scheme 8
Lay the electrical wiring harness down slightly.
Note. Ignore -1 and 2-.
Cylinder Bank 2 (left)
Scheme 9
Remove bolt -arrow-.
Disconnect the electrical connector to the engine coolant level warning switch -F66- on the bottom of the coolant reservoir and lay the reservoir aside with the coolant hoses -1 and 2- attached.
Remove the bolts -arrows- and disconnect the connectors on the ignition coils.
Scheme 10
Lay the electrical wiring harness down slightly.
Note. Ignore -1, 2 and 3-.
Continued for Both Sides
Scheme 11
Remove the ignition coils with the T40039.
Installing
- Tightening specifications, refer to «AIR FILTER OVERVIEW»(ref-511966-S34918758342012102900000) and «IGNITION OVERVIEW»(ref-511969-S18559791432012102900000) .
Install in reverse order of removal.
