STABILIZER BAR
Removing
Scheme 27
Remove noise insulation. Refer to Description and Operation .
Disconnect left and right connectors -2-.
Remove the left and right nuts -1- and the clamp -3-.
Remove the stabilizer bar.
Installing
Install in reverse order of removal. Note the following
Tightening specifications, refer to SUBFRAME, CROSSBRACE, STABILIZER BAR, COUPLING ROD AND SUBFRAME SHIELD OVERVIEW .
Note. Bonded rubber bushings can only be turned to a limited extent. Only tighten suspension bolts when vehicle is in curb weight or control position. Lifting wheel bearing to curb weight position, refer to WHEEL BEARING, WITH COIL SPRING, LIFTING TO CURB WEIGHT POSITION .
Note. If you replace the stabilizer, note chassis version. Stabilizer and mounting must be free of grease. Install the rubber bushing opening in the direction of the subframe contact surface.
Install the nuts -1- but do not tighten them.
Install the left and right threaded connections -2- but do not tighten them.
Lifting wheel bearing to curb weight position. Refer to WHEEL BEARING, WITH COIL SPRING, LIFTING TO CURB WEIGHT POSITION
Tighten connections -1 and 2-.
