3.0l - Cooling System - Engine Code(s): Ccba (sedan) Audi S4 B8 рестайлинг

COOLANT, DRAINING AND FILLING

Special tools and workshop equipment required

1. Adapter V.A.G 1274/8
2. Adapter for V.A.G 1274 tester V.A.G 1274/10
3. Cooling System Charge Unit VAS 6096
4. DRIP TRAY FOR VAS 6100 VAS 6208
5. Hose Clip Pliers VAS 6362
6. Refractometer T10007
7. Hose Clip Pliers VAS 6340

DRAINING

Note. Collect escaping coolant in a clean container for disposal or reuse.

Scheme 59

Open the coolant reservoir cap.

Remove the front noise insulation -1-. Refer to Description and Operation .

Scheme 60

Place the VAS 6208 under the engine.

Scheme 61

Remove the drain plug -1- and drain the coolant.

Note. Ignore -2-.

Loosen the hose clamp -arrow-, remove the coolant hose from the oil cooler and drain the coolant.

Scheme 62

Note. The engine is not shown in the following illustrations.

Vehicles with Left Front Coolant Pipes, Version 1

Scheme 63

Loosen the hose clamps -1 and 3-, remove the left front coolant hoses from the coolant pipes and drain any remaining coolant.

Note. Ignore -2-.

Vehicles with Left Front Coolant Pipes, Version 2

Scheme 64

Loosen the clamps -arrows-, drain any remaining coolant and then remove the coolant hoses from the left front coolant pipes.

Note. Ignore -1-.

FILLING

1. Ignition turned off

Note. The cooling system is filled year year-round with a mixture of water and coolant additive. Use only the coolant additive approved for this engine. Other coolant additives may above all reduce the corrosion protection effect significantly. The damage resulting from this may lead to loss of coolant and consequently to severe engine damage. The coolant additive prevents frost and corrosion damage as well as lime deposits. It also raises the boiling temperature. The cooling system must be filled with coolant additive year-round. Because of its high boiling point, the coolant improves engine reliability under heavy loads, particularly in countries with tropical climates. Protection against frost must be assured down to approximately -25 °C (-13 °F) (in arctic climatic countries down to approximately -35 °C (-31 °F)). The coolant concentration must not be reduced by adding water even in warmer seasons and in warmer countries. The coolant additive portion must be at least 40%. When stronger freeze protection is needed due to the climate, the portion of coolant additive can be increased. It can be increased up to 60% (freeze protection down to -40 °C (-40 °F). If it is increased even more, the freeze protection and cooling effect are decreased. Only use clean drinking water for mixing coolant. Only reuse drained coolant if the radiator, the heater heat exchanger, cylinder head, cylinder head gasket or cylinder block were not replaced. Dirty coolant may not be used again. Secure all hose connections with hose clamps of the same type as those equipped by the factory. Replace the O-rings for the bleeder screws on the charge air coolers. Use the T10007 to determine the level of freeze protection in the coolant system.

Close the drain plug -1-.

Install the coolant hose on the engine oil cooler -arrow-.

Vehicles with Left Front Coolant Pipes, Version 1

Install the coolant hoses -1 and 3- to the left front coolant pipes.

Vehicles with Left Front Coolant Pipes, Version 2

Attach the coolant hoses -arrows- to the left front coolant pipes.

All Vehicles

Scheme 65

Fill the coolant reservoir in the VAS 6096 with 12 liters of coolant having the correct mixture ratio

1. Coolant additive (40%) and water (60%) for freeze protection down to -25 °C (-13 °F)
2. Coolant additive (50%) and water (50%) for freeze protection down to -35 °C (-31 °F)
3. For the correct coolant additive.

Attach V.A.G 1274/8 to coolant reservoir.

Install the VAS 6096 on the V.A.G 1274/8.

Place air outlet -1- in a small container -2-.

Note. A small amount of coolant which should be collected is drawn off with the discharged air.

Close valves -A and B- by turning lever at a right angle to direction of flow.

Connect hose -3- to compressed air.

1. Pressure: 6 to 10 bar pressure.

Open valve -B- by turning level in direction of flow.

Scheme 66

1. A further vacuum is created in the cooling system by the suction jet pump. Needle on the instrument display must travel into the green region.

Briefly open valve -A- by turning lever in direction of flow so that the hose on VAS 6096 coolant reservoir fills with coolant.

Close valve -A- again.

Leave valve -B- open another 2 minutes.

1. A further vacuum is created in the cooling system by the suction jet pump. Needle on the instrument display must still remain in the green region.

Close valve -B-.

1. Needle in the display instrument must remain in the green region, then the sufficient vacuum in the cooling system is obtained for the upcoming filling.

Note. If needle stands below the green area, repeat procedure. If pressure falls, check coolant system for leaks.

Remove pressurized air hose.

Open valve -A-.

1. Coolant is extracted from the VAS 6096 coolant reservoir by pressure in the coolant system and the system is filled.

Remove VAS 6096 form V.A.G 1274/8 on coolant reservoir.

Connect the V.A.G 1274/10 to the V.A.G 1274/8.

Scheme 67

Fill the coolant until the coolant system tester tube is full. Fill again during the bleeding procedure if necessary.

Remove the rear engine cover -2- upward.

Scheme 68

Note. Use a cloth to catch any leaking coolant.

Open the bleeder screws -1 and 2- one after the other until coolant starts to come out.

Close the bleeder screw.

Remove the seal from the plenum chamber bulkhead.

Scheme 69

Remove the plenum chamber cover. Refer to Removal and Installation .

Disconnect the heat exchanger coolant hose and pull it back until coolant starts to drain out of the bleed hole -arrow- in the coolant hose.

Scheme 70

Slide the coolant hose onto the connection and secure with a spring clamp.

If the vehicle has an auxiliary heater, switch it on for about 30 seconds.

Turn the coolant reservoir cap until it closes completely.

Start the engine.

Set the temperature to "HI" for all zones and set the fan speed (0).

Press the AC button to turn off the Air Conditioning (A/C) compressor.

1. The LED in the button must not come on.

Run the engine at 2000 RPM for 3 minutes.

Run the engine at idle until both large coolant hoses on the radiator are warm.

Run the engine at 2000 RPM for 2 minutes.

Turn off engine and allow it to cool off.

Install the noise insulation. Refer to Description and Operation .

CHECK THE COOLANT LEVEL.

1. With the engine cold, coolant level must be at MAX marking.
2. Coolant level may be above MAX marking with engine at operating temperature.

Scheme 71

1. Coolant Hose
2. Bracket
3. Bolts 9 Nm
4. Coolant Hose
5. Bolt 4 Nm
6. After-Run Coolant Pump -V51- Removing and installing, refer to «After-Run Coolant Pump -V51»(/audi/s4/b8-2011-2015/remont/cooling-fan/#30l-cooling-system-engine-codes-ccba-sedan__after-run-coolant-pump-v51)

COOLANT HOSE CONNECTION DIAGRAM

Note. Secure all hose connections with hose clamps of the same type as those equipped by the factory. The arrows on the coolant pipes and ends of coolant hoses must align.

Note. Blue = large coolant circuit. Red = small coolant circuit. Orange = coolant circuit for the charge air cooler. Brown = heating circuit. The arrows show the coolant flow direction.

Vehicles without Auxiliary Heater

Scheme 72

1. Front Charge Air Cooling Circuit Radiator Change coolant after replacing
2. Radiator Vehicles with dual clutch transmission: With integrated ATF cooler Change coolant after replacing
3. Coolant Temperature Sensor -G62
4. Coolant Thermostat
5. Coolant pump
6. Charge Air Cooler on the Right Side inside the compressor housing change coolant after replacing
7. Coolant Switch-Off Valve is controlled by the auxiliary heater exhaust gas sensor -N422- The auxiliary heater exhaust gas sensor -N422- is controlled by the Climatronic control module -J255-. Removing and installing, refer to «Air Conditioning»(/audi/s4/b8-2011-2015/remont/automatic-hvac-system/#air-conditioning-sedan)
8. Bleeder Screw
9. Cylinder Head Bank 1 (right) change coolant after replacing
10. Heat Exchanger for Heater Unit Removing and installing, refer to «Removal and Installation»(/audi/s4/b8-2011-2015/remont/automatic-hvac-system/#air-conditioning-sedan) change coolant after replacing
11. Bleeder Hole
12. Cylinder Head Bank 2 (left) change coolant after replacing
13. Bleeder Screw
14. Left Charge Air Cooler Inside the compressor housing Change coolant after replacing
15. Coolant Reservoir Cap Pressure relief valve, checking «PRESSURE RELIEF VALVE IN CAP, CHECKING»(/audi/s4/b8-2011-2015/remont/cooling-fan/#30l-cooling-system-engine-codes-ccba-sedan)
16. Coolant Reservoir
17. Engine Oil Cooler
18. After-Run Coolant Pump -V51- Depending on country
19. Non-Return Valve In the coolant hose
20. Charge Air Coolant Pump -V188
21. Left Charge Air Cooling Circuit Radiator change coolant after replacing
22. Non-Return Valve In the coolant hose
23. Non-Return Valve In the coolant hose

COOLANT PIPES OVERVIEW

Version 1

Scheme 73

1. Bolt 9 Nm
2. Left Front Coolant Pipes Removing and installing, refer to «LEFT FRONT COOLANT PIPES»(/audi/s4/b8-2011-2015/remont/cooling-fan/#30l-cooling-system-engine-codes-ccba-sedan__left-front-coolant-pipes)
3. Bolt 9 Nm
4. Bolt 9 Nm
5. Bracket
6. Bolt 22 Nm
7. Retaining Clip
8. Bolt 9 Nm
9. Front Coolant Pipe Removing and installing, refer to «FRONT COOLANT PIPE»(/audi/s4/b8-2011-2015/remont/cooling-fan/#30l-cooling-system-engine-codes-ccba-sedan__front-coolant-pipe)
10. Seal Replace
11. O-ring Replace
12. Coolant Temperature Sensor -G62- Removing and installing, refer to «Engine Coolant Temperature Sensor -G62»(/audi/s4/b8-2011-2015/remont/cooling-fan/#30l-cooling-system-engine-codes-ccba-sedan__engine-coolant-temperature-sensor-g62)
13. Lower Coolant Pipe on the Supercharger With -17-, removing and installing «SUPERCHARGER COOLANT PIPES»(/audi/s4/b8-2011-2015/remont/cooling-fan/#30l-cooling-system-engine-codes-ccba-sedan__supercharger-coolant-pipes)
14. Bolt 5 Nm
15. Alignment Bushing Quantity: 2
16. Bolt 5 Nm
17. Seals Replace
18. Upper Coolant Pipe on the Supercharger With -11-, removing and installing «SUPERCHARGER COOLANT PIPES»(/audi/s4/b8-2011-2015/remont/cooling-fan/#30l-cooling-system-engine-codes-ccba-sedan__supercharger-coolant-pipes)
19. O-ring Replace
20. Upper Coolant Pipe Removing and installing, refer to «UPPER COOLANT PIPE»(/audi/s4/b8-2011-2015/remont/cooling-fan/#30l-cooling-system-engine-codes-ccba-sedan__upper-coolant-pipe)
21. Bolt 9 Nm
22. Gasket Replace
23. Bolt 9 Nm
24. Bolts 9 Nm
25. Left Coolant Pipes Removing and installing, refer to «LEFT COOLANT PIPES»(/audi/s4/b8-2011-2015/remont/cooling-fan/#30l-cooling-system-engine-codes-ccba-sedan__left-coolant-pipes)
26. O-ring Replace

Version 2

Scheme 74

1. Bolt 9 Nm
2. Left Front Coolant Pipes Removing and installing, refer to «LEFT FRONT COOLANT PIPES»(/audi/s4/b8-2011-2015/remont/cooling-fan/#30l-cooling-system-engine-codes-ccba-sedan__left-front-coolant-pipes)
3. Bolt 9 Nm
4. Bracket
5. Bolt 22 Nm
6. Bolt 9 Nm
7. Bolt 9 Nm
8. Front Coolant Pipe Removing and installing, refer to «FRONT COOLANT PIPE»(/audi/s4/b8-2011-2015/remont/cooling-fan/#30l-cooling-system-engine-codes-ccba-sedan__front-coolant-pipe)
9. Seal Replace
10. O-ring Replace
11. Engine Coolant Temperature (ECT) Sensor -G62- Removing and installing, refer to «Engine Coolant Temperature Sensor -G62»(/audi/s4/b8-2011-2015/remont/cooling-fan/#30l-cooling-system-engine-codes-ccba-sedan__engine-coolant-temperature-sensor-g62)
12. Bolt 5 Nm
13. Lower Coolant Pipe on the Supercharger With -19-, removing and installing, refer to «SUPERCHARGER COOLANT PIPES»(/audi/s4/b8-2011-2015/remont/cooling-fan/#30l-cooling-system-engine-codes-ccba-sedan__supercharger-coolant-pipes)
14. Bolt 5 Nm
15. Alignment Bushing
16. Gasket Replace
17. Bolt 5 Nm
18. Gasket Replace
19. Upper Coolant Pipe on the Supercharger With -13-, removing and installing «SUPERCHARGER COOLANT PIPES»(/audi/s4/b8-2011-2015/remont/cooling-fan/#30l-cooling-system-engine-codes-ccba-sedan__supercharger-coolant-pipes)
20. Alignment Bushing
21. Bolt 5 Nm
22. Seals Replace
23. O-ring Replace
24. Upper Coolant Pipe Removing and installing, refer to «UPPER COOLANT PIPE»(/audi/s4/b8-2011-2015/remont/cooling-fan/#30l-cooling-system-engine-codes-ccba-sedan__upper-coolant-pipe)
25. Bolt 9 Nm
26. Gasket Replace
27. Bolt 9 Nm
28. Bolt 9 Nm
29. Bolt 9 Nm
30. Left Coolant Pipes Removing and installing, refer to «LEFT COOLANT PIPES»(/audi/s4/b8-2011-2015/remont/cooling-fan/#30l-cooling-system-engine-codes-ccba-sedan__left-coolant-pipes)
31. O-ring Replace
32. Retaining Clip

Scheme 75

Tighten the nut -2- to 9 Nm.

Scheme 76

1. Bolt 9 Nm
2. Bolt 20 Nm
3. Ribbed Belt Pulley for Coolant Pump
4. Coolant Pump With gasket Removing and installing, refer to «COOLANT PUMP»(/audi/s4/b8-2011-2015/remont/cooling-fan/#30l-cooling-system-engine-codes-ccba-sedan__coolant-pump)
5. Bolt 9 Nm
6. Bolt Tightening specification, refer to item 2: «SUPERCHARGER RIBBED BELT DRIVE OVERVIEW»(/audi/s4/b8-2011-2015/remont/mechanical/#30l-crankshaft-cylinder-block-engine-codes-ccba-sedan)
7. Washer
8. Idler Roller for Ribbed Belt
9. Connecting Piece For coolant hose
10. Gasket Replace
11. Gasket Replace
12. Coolant Thermostat Removing and installing, refer to «COOLANT THERMOSTAT»(/audi/s4/b8-2011-2015/remont/cooling-fan/#30l-cooling-system-engine-codes-ccba-sedan__coolant-thermostat) Checking, refer to «COOLANT THERMOSTAT, CHECKING»(/audi/s4/b8-2011-2015/remont/cooling-fan/#30l-cooling-system-engine-codes-ccba-sedan__coolant-thermostat-checking)
13. Bolt 9 Nm
14. Cylinder Head Coolant Valve -N489

RADIATOR AND COOLANT FAN OVERVIEW

Radiator, Front Charge Air Cooling Circuit Radiator, Fan Shroud and Radiator Fan - Version 1

Scheme 77

1. Bolt 4.5 Nm
2. Fan Shroud Removing and installing together with the radiator, refer to «RADIATOR AND FAN SHROUD»(/audi/s4/b8-2011-2015/remont/cooling-fan/#30l-cooling-system-engine-codes-ccba-sedan__radiator-and-fan-shroud)
3. Coolant Fan -V7- With coolant fan control module -J293- Removing and installing, refer to «Coolant Fan -V7- AND Coolant Fan 2 -V177-, VERSION 1»(/audi/s4/b8-2011-2015/remont/cooling-fan/#30l-cooling-system-engine-codes-ccba-sedan__coolant-fan-v7-and-coolant-fan)
4. Coolant Hose Lift the retaining clamp to remove Connect to the radiator see scheme 28
5. O-ring Replace
6. Rubber Buffer
7. Radiator Bracket
8. Coolant Hose Lift the retaining clamp to remove Connect to the radiator see scheme 28
9. O-ring Replace
10. O-ring Replace
11. Coolant Hose Lift the retaining clamp to remove Connect to the radiator see scheme 28
12. Coolant Hose Lift the retaining clamp to remove Connect to the radiator see scheme 28
13. O-ring Replace
14. Retaining Pin Disengage and remove using screwdriver
15. Rubber Bushing For radiator
16. Radiator Removing and installing with the fan shroud, refer to «RADIATOR AND FAN SHROUD»(/audi/s4/b8-2011-2015/remont/cooling-fan/#30l-cooling-system-engine-codes-ccba-sedan__radiator-and-fan-shroud) Change coolant after replacing
17. Coolant Hose
18. Bolt 4.5 Nm
19. Front Charge Air Cooling Circuit Radiator Removing and installing, refer to «FRONT CHARGE AIR COOLING CIRCUIT RADIATOR»(/audi/s4/b8-2011-2015/remont/cooling-fan/#30l-cooling-system-engine-codes-ccba-sedan__front-charge-air-cooling-circuit-radiator)
20. Coolant Hose
21. Rubber Bushing For radiator
22. Bolt 5 Nm
23. Bolt 4.5 Nm
24. Radiator Fan 2 -V177- Removing and installing, refer to «Coolant Fan -V7- AND Coolant Fan 2 -V177-, VERSION 1»(/audi/s4/b8-2011-2015/remont/cooling-fan/#30l-cooling-system-engine-codes-ccba-sedan__coolant-fan-v7-and-coolant-fan)

Fan Shroud and Radiator Fan - Version 2

Scheme 78

1. Coolant Fan -V7- With coolant fan control module -J293- Removing and installing, refer to «Coolant Fan -V7- AND Coolant Fan 2 -V177-, VERSION 1»(/audi/s4/b8-2011-2015/remont/cooling-fan/#30l-cooling-system-engine-codes-ccba-sedan__coolant-fan-v7-and-coolant-fan)
2. Radiator Fan 2 -V177- With coolant fan control module 2 -J671- Removing and installing, refer to «Coolant Fan -V7- AND Coolant Fan 2 -V177-, VERSION 1»(/audi/s4/b8-2011-2015/remont/cooling-fan/#30l-cooling-system-engine-codes-ccba-sedan__coolant-fan-v7-and-coolant-fan)
3. Fan Shroud
4. Bolt 3.5 Nm
5. Fan Wheel The bolt must lock into the hole.
6. Bolt 5 Nm
7. Fan Wheel The bolt must lock into the hole.
8. Bolt 5 Nm
9. Bolt 3.5 Nm

Left Charge Air Cooling Circuit Radiator

Scheme 79

1. Air Guide
2. Left Charge Air Cooling Circuit Radiator Removing and installing, refer to «LEFT CHARGE AIR COOLING CIRCUIT RADIATOR»(/audi/s4/b8-2011-2015/remont/cooling-fan/#30l-cooling-system-engine-codes-ccba-sedan__left-charge-air-cooling-circuit-radiator)
3. Coolant Hoses
4. Nut 9 Nm
5. Bracket
6. Nut 9 Nm
7. Rubber Bushing For radiator
8. Nut 9 Nm
9. Coolant Hose
10. Bracket
11. Bracket
12. Charge Air Coolant Pump -V188- Removing and installing, refer to «Charge Air Cooling Pump -V188»(/audi/s4/b8-2011-2015/remont/cooling-fan/#30l-cooling-system-engine-codes-ccba-sedan__charge-air-cooling-pump-v188)
13. Coolant Hose
14. Rubber Bushing For radiator

Scheme 80

Remove the old O-ring -2- in the coolant hose -3-.

Coat the new O-ring with coolant and install it in the coolant hose.

Press the coolant hose onto the connection -1- until it engages audibly.

Press the coolant hose on again and pull to make sure the connection is engaged correctly.

FASTENER TIGHTENING SPECIFICATIONS

Charge Air Cooling Pump -V188-, Tightening Specifications

Tighten the nut -2- to 9 Nm.

COOLING SYSTEM, CHECKING FOR LEAKS

Special tools and workshop equipment required

1. Cooling System Tester V.A.G 1274 B
2. Adapter V.A.G 1274/8
3. Adapter V.A.G 1274/9

Procedure

1. Engine at operating temperature.

Open the coolant reservoir cap.

Position V.A.G 1274 B with V.A.G 1274/8 on coolant reservoir.

Scheme 81

Generate approximately 1 bar pressure using the cooling system tester hand pump.

If pressure falls, search for leaks and correct problem.

Scheme 82

Attach V.A.G 1274 B with V.A.G 1274/9 to sealing cap.

Generate pressure with cooling system tester hand pump.

1. The pressure release valve must open at 1.4 to 1.6 bar.

If pressure relief valve does not open as specified, replace cap.

COOLANT THERMOSTAT, CHECKING

Heat up the removed thermostat in water.

AFTER-RUN COOLANT PUMP -V51

Special tools and workshop equipment required

1. Drip Tray for VAS 6100 VAS 6208
2. Hose Clip Pliers VAS 6340

Removing

Open the coolant reservoir cap.

Remove the front noise insulation -1-. Refer to Description and Operation .

Disconnect the connector -2- and remove the bolt -1-.

Scheme 83

Place the VAS 6208 under the engine.

Open the clamps -arrows- and remove the after-run coolant pump from the coolant hoses.

Installing

Install in reverse order of removal. Note the following

1. Tightening specification, refer to «After-Run Coolant Pump -V51- OVERVIEW»(/audi/s4/b8-2011-2015/remont/cooling-fan/#30l-cooling-system-engine-codes-ccba-sedan) .

Note. Secure all hose connections with hose clamps of the same type as those equipped by the factory.

Fill with coolant. Refer to FILLING .

Install the noise insulation. Refer to Description and Operation .

CHARGE AIR COOLING PUMP -V188

Special tools and workshop equipment required

1. Hose Clamps Up to 25 mm Dia. 3094
2. Hose Clip Pliers VAS 6362

Removing

Remove the left front wheel. Refer to Removal and Installation .

Remove the left front wheel housing liner. Refer to Removal and Installation .

Disconnect the connector -3-.

Remove nut -2- and bracket.

Clamp off the coolant hoses on the charge air cooling pump with the 3094.

Loosen the hose clamps -1-, remove the coolant hoses and then remove the charge air cooling pump.

Installing

Install in reverse order of removal. Note the following

Note. Secure all hose connections with hose clamps of the same type as those equipped by the factory

Tighten the nut the charge air cooling pump bracket. (Scheme 76)

Install the front wheel housing liner. Refer to Removal and Installation .

Install the front wheels. Refer to Removal and Installation .

Fill with coolant. Refer to FILLING .

COOLANT FAN -V7- AND COOLANT FAN 2 -V177-, VERSION 1

Removing

Scheme 84

Cooler with fan shroud, removing. Refer to RADIATOR AND FAN SHROUD .

Remove the bolts -arrows- on the coolant fan (left)

Free up the wiring harness and remove the radiator fan.

Remove the bolts -arrows- on the right coolant fan 2.

Scheme 85

Free up the wiring harness.

Unclip the coolant fan control module -1- from the fan shroud and remove the fan with the control module.

Installing

Install in reverse order of removal. Note the following

1. Tightening specifications, refer to «RADIATOR AND COOLANT FAN OVERVIEW»(/audi/s4/b8-2011-2015/remont/cooling-fan/#30l-cooling-system-engine-codes-ccba-sedan__radiator-and-coolant-fan-overview) .

Install the cooler with the fan shroud. Refer to RADIATOR AND FAN SHROUD .

COOLANT FAN -V7- AND COOLANT FAN 2 -V177-, VERSION 2

Removing

Scheme 86

Note. When installing, bring all cable ties back to same positions.

Remove the fan shroud

1. Audi A4 refer to «RADIATOR AND FAN SHROUD»(/audi/s4/b8-2011-2015/remont/cooling-fan/#30l-cooling-system-engine-codes-ccba-sedan__radiator-and-fan-shroud) .

Remove the bolts -1 or 2- and remove the fan wheel.

Remove the radiator fan bolts -arrows-.

Free up the wiring harness and remove the radiator fan.

Installing

Install in reverse order of removal. Note the following

1. Tightening specifications, refer to «RADIATOR AND COOLANT FAN OVERVIEW»(/audi/s4/b8-2011-2015/remont/cooling-fan/#30l-cooling-system-engine-codes-ccba-sedan__radiator-and-coolant-fan-overview) .

Pay attention to the installed position of the fan wheel

Scheme 87

1. The bolt -2- must lock into the hole -1-.

Install the fan shroud

1. Audi A4 refer to «RADIATOR AND FAN SHROUD»(/audi/s4/b8-2011-2015/remont/cooling-fan/#30l-cooling-system-engine-codes-ccba-sedan__radiator-and-fan-shroud) .

COOLANT PUMP

Special tools and workshop equipment required

1. Spanner Wrench 3212

Removing

Drain the coolant. Refer to COOLANT, DRAINING AND FILLING .

Remove the front left coolant pipes. Refer to LEFT FRONT COOLANT PIPES .

Remove the bolts -1 and 2- and the coolant pipes.

Scheme 88

Remove the ribbed belt from the Air Conditioning (A/C) compressor but do not remove it completely

1. «RIBBED BELT, VEHICLES WITH HYDRAULIC POWER STEERING»(/audi/s4/b8-2011-2015/remont/mechanical/#30l-crankshaft-cylinder-block-engine-codes-ccba-sedan__ribbed-belt-vehicles-with-hydraulic-power)
2. «RIBBED BELT, VEHICLES WITH ELECTRO-MECHANICAL POWER STEERING»(/audi/s4/b8-2011-2015/remont/mechanical/#30l-crankshaft-cylinder-block-engine-codes-ccba-sedan__ribbed-belt-vehicles-with-electro-mechanical-power)

Remove the coolant hose -arrow- from the front coolant pipe by lifting the retaining clamp.

Scheme 89

Remove the bolts for the coolant pump ribbed belt pulley, using a 3212 to counter hold.

Scheme 90

Vehicles with Hydraulic Power Steering

Scheme 91

Remove the bolts for the coolant pump ribbed belt pulley, using a 3212 to counter hold.

Vehicles with Electro-Mechanical Power Steering

Scheme 92

Remove the cylinder head coolant valve -N489- -arrow- from the bracket and move it to the side.

Disconnect vacuum hose -1-.

Scheme 93

All Vehicles

Note. Use a cloth to catch any leaking coolant.

Remove the coolant pump bolts -arrows- and the coolant pump.

Installing

Install in reverse order of removal. Note the following

1. Tightening specifications, refer to «COOLANT PUMP, COOLANT THERMOSTAT AND CONNECTING PIECE OVERVIEW»(/audi/s4/b8-2011-2015/remont/cooling-fan/#30l-cooling-system-engine-codes-ccba-sedan) .

Clean any oil or grease off the sealing surfaces.

Install the power steering pump ribbed belt pulley. Refer to Removal and Installation .

Connect the coolant hose to the coupling. see scheme 28

Installing the ribbed belt

1. «RIBBED BELT, VEHICLES WITH HYDRAULIC POWER STEERING»(/audi/s4/b8-2011-2015/remont/mechanical/#30l-crankshaft-cylinder-block-engine-codes-ccba-sedan__ribbed-belt-vehicles-with-hydraulic-power)
2. «RIBBED BELT, VEHICLES WITH ELECTRO-MECHANICAL POWER STEERING»(/audi/s4/b8-2011-2015/remont/mechanical/#30l-crankshaft-cylinder-block-engine-codes-ccba-sedan__ribbed-belt-vehicles-with-electro-mechanical-power)

Install the coolant pipes. Refer to COOLANT PIPES OVERVIEW .

Fill with coolant FILLING .

COOLANT THERMOSTAT

Removing

Drain the coolant. Refer to COOLANT, DRAINING AND FILLING .

Remove the supercharger. Refer to SUPERCHARGER .

Remove the front coolant pipe. Refer to FRONT COOLANT PIPE .

Note. Place a cloth underneath to catch any coolant leaking out.

Remove the bolts -arrows-.

Remove the coolant thermostat with the connections.

Installing

Install in reverse order of removal. Note the following

1. Tightening specifications, refer to «COOLANT PUMP, COOLANT THERMOSTAT AND CONNECTING PIECE OVERVIEW»(/audi/s4/b8-2011-2015/remont/cooling-fan/#30l-cooling-system-engine-codes-ccba-sedan) .

Note. Replace the gasket.

Install front coolant pipe. Refer to FRONT COOLANT PIPE .

Install the supercharger. Refer to SUPERCHARGER .

Fill with coolant FILLING .

ENGINE COOLANT TEMPERATURE SENSOR -G62

Removing

1. Engine cold.

Quickly open the coolant reservoir cap and release any remaining pressure in the cooling system and then close it again.

Remove the front engine cover -1- upward.

Disconnect the connector -1- from the Engine Coolant Temperature (ECT) sensor -G62-.

Scheme 94

Note. Use a cloth to catch any leaking coolant.

Remove the clip -2- and the ECT sensor.

Note. Ignore -arrow-.

Installing

Install in reverse order of removal. Note the following

Note. Replace the O-ring. To prevent coolant loss, install the ECT sensor immediately into the connection.

Check the coolant level FILLING .

FRONT CHARGE AIR COOLING CIRCUIT RADIATOR

Special tools and workshop equipment required

1. Hose Clamps Up to 25 mm Dia. 3094
2. Drip Tray for VAS 6100 VAS 6208

Removing

Scheme 95

Remove the lock carrier cover -4-. Refer to Removal and Installation .

Remove the bolts -arrows-.

Scheme 96

Remove the air duct -1- from the air filter housing intermediate flange -2-.

Remove the bumper cover end plate. Refer to "Front Bumper" in Removal and Installation .

Scheme 97

Remove the left and right air intake grille -1-. Refer to "Front Bumper" in Removal and Installation .

Scheme 98

Note. The bumper is not shown in the following illustrations.

Release the retaining tabs -A arrows- and tilt the left and right air ducts -1- toward the center of the vehicle -arrow B-.

Place the VAS 6208 under the front charge air cooling circuit radiator.

Vehicles with Version 2 Front Charge Air Cooling Circuit Radiator

Scheme 99

Disconnect and remove the coolant hoses and 3094, to do this, loosen the hose clamps -arrows-.

Vehicles with Version 1 Front Charge Air Cooling Circuit Radiator

Scheme 100

Disconnect and remove the coolant hose and 3094, to do this, loosen the hose clamps -arrows-.

Remove the bolt -1-.

Open the clamp -1-. Then remove both the coolant hose and the 3094

Scheme 101

All Vehicles

Press the catch downward -arrow A- and move the front charge air cooling circuit radiator in direction of -arrow B-.

Remove the front charge air cooling circuit radiator from the radiator -arrows A- and move it in direction of -arrow B-.

Scheme 102

Remove the front charge air cooling circuit radiator downward from the right side -arrow C-.

Installing

Install in reverse order of removal. Note the following

1. Tightening specification, refer to «RADIATOR AND COOLANT FAN OVERVIEW»(/audi/s4/b8-2011-2015/remont/cooling-fan/#30l-cooling-system-engine-codes-ccba-sedan__radiator-and-coolant-fan-overview) .

Note. Secure all hose connections with hose clamps of the same type as those equipped by the factory.

Install the bumper cover end panel. Refer to Removal and Installation .

Install the air duct on the air filter housing intermediate flange. Refer to Removal and Installation .

Install the lock carrier cover. Refer to Removal and Installation .

Fill with coolant FILLING .

Note. All of the coolant must be changed if the radiator was replaced.

FRONT COOLANT PIPE

Special tools and workshop equipment required

1. Spanner Wrench 3212
2. Hose Clip Pliers VAS 6362

Removing

Scheme 103

Drain the coolant. Refer to COOLANT, DRAINING AND FILLING remove the after-run coolant pump -V51-, refer to After-Run Coolant Pump -V51 .

Remove the air duct -arrows-.

Remove the front left coolant pipes. Refer to LEFT FRONT COOLANT PIPES .

Removing the ribbed belt

1. «RIBBED BELT, VEHICLES WITH HYDRAULIC POWER STEERING»(/audi/s4/b8-2011-2015/remont/mechanical/#30l-crankshaft-cylinder-block-engine-codes-ccba-sedan__ribbed-belt-vehicles-with-hydraulic-power)
2. «RIBBED BELT, VEHICLES WITH ELECTRO-MECHANICAL POWER STEERING»(/audi/s4/b8-2011-2015/remont/mechanical/#30l-crankshaft-cylinder-block-engine-codes-ccba-sedan__ribbed-belt-vehicles-with-electro-mechanical-power)

Remove vacuum pump. Refer to Removal and Installation .

Scheme 104

Remove the bolts for the coolant pump ribbed belt pulley, using a 3212 to counter hold.

Remove the ribbed belt pulley.

Disconnect the connector -1- for the wiring leading to the Air Conditioning (A/C) compressor clutch solenoid.

Scheme 105

Remove A/C compressor bolts -arrows-.

Remove the A/C compressor from the bracket and move it to the side with the lines still connected.

Loosen the hose clamp -3- and remove the left coolant pipe bolts -1 and 2-.

Scheme 106

Tip the coolant pump to the left slightly -arrow- and remove it from the upper coolant pipe.

Remove the bolt -arrow- and remove the left front coolant pipe bracket.

Scheme 107

Disconnect the connector -3- from the Engine Coolant Temperature (ECT) sensor -G62-.

Scheme 108

Open the clamps and remove the coolant hoses -1 and 4-.

Loosen the clamp -2- and remove the upper coolant hose.

Loosen the hose clamp -5-.

Remove the bolts -arrows- and the front coolant pipe.

Installing

Install in reverse order of removal. Note the following

1. Tightening specifications, refer to «COOLANT PIPES OVERVIEW»(/audi/s4/b8-2011-2015/remont/cooling-fan/#30l-cooling-system-engine-codes-ccba-sedan__coolant-pipes-overview) .

Note. Replace the gaskets and O-rings. Secure all hose connections with hose clamps of the same type as those equipped by the factory.

Clean or smooth the seal and O-ring sealing surfaces.

Coat the sealing rings and O-rings with coolant and then mount them on the coolant pipe.

Connect the coolant hose to the coupling. see scheme 28

Install the left coolant pipes. Refer to LEFT COOLANT PIPES .

Install A/C compressor. Refer to Removal and Installation .

Install the coolant pump ribbed belt pulley. Refer to COOLANT PUMP, COOLANT THERMOSTAT AND CONNECTING PIECE OVERVIEW .

Install the vacuum pump. Refer to Removal and Installation .

Installing the ribbed belt

1. «RIBBED BELT, VEHICLES WITH HYDRAULIC POWER STEERING»(/audi/s4/b8-2011-2015/remont/mechanical/#30l-crankshaft-cylinder-block-engine-codes-ccba-sedan__ribbed-belt-vehicles-with-hydraulic-power)
2. «RIBBED BELT, VEHICLES WITH ELECTRO-MECHANICAL POWER STEERING»(/audi/s4/b8-2011-2015/remont/mechanical/#30l-crankshaft-cylinder-block-engine-codes-ccba-sedan__ribbed-belt-vehicles-with-electro-mechanical-power)

Install the left front coolant pipes. Refer to LEFT FRONT COOLANT PIPES .

Install after-run coolant pump -V51-. Refer to After-Run Coolant Pump -V51 .

Fill with coolant FILLING .

LEFT CHARGE AIR COOLING CIRCUIT RADIATOR

Special tools and workshop equipment required

1. Hose Clamps Up to 25 mm Dia. 3094
2. Drip Tray for VAS 6100 VAS 6208

Removing

Scheme 109

Remove front bumper cover. Refer to Removal and Installation .

Remove the left front wheel. Refer to Removal and Installation .

Remove the left front wheel housing liner. Refer to Removal and Installation .

Remove the air duct -1- -arrow-.

Remove the nuts -arrows- and lower the bracket -1- with the left charge air cooling circuit radiator just a little.

Scheme 110

Place the VAS 6208 under the left front charge air cooling circuit radiator.

Scheme 111

Disconnect and remove the coolant hoses and 3094, to do this, loosen the hose clamps -arrows-.

Remove the left charge air cooling circuit radiator -1- upward from the bracket.

Installing

Install in reverse order of removal. Note the following

1. Tightening specifications, refer to «RADIATOR AND COOLANT FAN OVERVIEW»(/audi/s4/b8-2011-2015/remont/cooling-fan/#30l-cooling-system-engine-codes-ccba-sedan__radiator-and-coolant-fan-overview) .

Note. Secure all hose connections with hose clamps of the same type as those equipped by the factory.

Install the front wheel housing liner. Refer to Removal and Installation .

Install the front wheel. Refer to Removal and Installation .

Install front bumper. Refer to Removal and Installation .

Fill with coolant FILLING .

Note. All of the coolant must be changed if the radiator was replaced.

LEFT COOLANT PIPES

Special tools and workshop equipment required

1. Hose Clip Pliers VAS 6362

Removing

Drain the coolant. Refer to COOLANT, DRAINING AND FILLING remove the after-run coolant pump -V51-. Refer to After-Run Coolant Pump -V51 .

Remove Air Conditioning (A/C) compressor. Refer to Removal and Installation .

Scheme 112

Remove the bolts -arrows- and the A/C compressor bracket.

Scheme 113

Remove the bolts -arrows-.

Scheme 114

Remove the coolant pipes from the coolant hoses by loosening the hose clamps -1 and 2-.

Note. The installation location is shown with the power steering pump removed.

Installing

Install in reverse order of removal. Note the following

1. Tightening specifications, refer to «COOLANT PIPES OVERVIEW»(/audi/s4/b8-2011-2015/remont/cooling-fan/#30l-cooling-system-engine-codes-ccba-sedan__coolant-pipes-overview) .

Note. Replace the O-ring. Secure all hose connections with hose clamps of the same type as those equipped by the factory.

Clean and smooth the O-ring sealing surface.

Coat the O-ring with coolant and slide it onto the coolant pipe.

Install the A/C compressor bracket. Refer to RIBBED BELT DRIVE, VEHICLES WITH HYDRAULIC POWER STEERING OVERVIEW .

Install A/C compressor. Refer to Removal and Installation .

Install after-run coolant pump. Refer to After-Run Coolant Pump -V51 .

Fill with coolant FILLING .

LEFT FRONT COOLANT PIPES

Special tools and workshop equipment required

1. Hose Clamps Up to 25 mm Dia. 3094
2. Drip Tray for VAS 6100 VAS 6208
3. Hose Clip Pliers VAS 6362

Removing

Remove the front engine cover -1- upward.

Remove the front noise insulation -1-. Refer to Description and Operation .

Open the coolant reservoir cap.

Place the VAS 6208 under the engine.

Note. The engine is not shown in the following illustrations.

Vehicles with Left Front Coolant Pipes, Version 1

Loosen the hose clamps -1 and 3-, then close off the coolant hoses with the 3094 and remove them from the left front coolant pipes.

Remove the bolts -2-.

Vehicles with Left Front Coolant Pipes, Version 2

Disconnect the coolant hoses with the 3094 and remove them from the left front coolant pipes by loosening the clamps -arrows-.

Remove the bolt -1-.

All Vehicles

Scheme 115

Loosen the hose clamps -1- and remove the coolant hoses from the coolant pipes on the A/C compressor.

Remove the bolt -2-.

Remove the front left coolant pipes downward.

Installing

Install in reverse order of removal. Note the following

1. Tightening specifications, refer to «COOLANT PIPES OVERVIEW»(/audi/s4/b8-2011-2015/remont/cooling-fan/#30l-cooling-system-engine-codes-ccba-sedan__coolant-pipes-overview) .

Note. Secure all hose connections with hose clamps of the same type as those equipped by the factory.

Fill with coolant FILLING .

Install the noise insulation. Refer to Description and Operation .

RADIATOR AND FAN SHROUD

Note. The radiator and fan shroud can only be removed and installed together. It is not possible to remove the Air Conditioning (A/C) condenser from the radiator with the refrigerant pipes still connected on new models. This is described under "version 2".

Special tools and workshop equipment required

1. Used Oil Collection and Extraction Device V.A.G 1782 for vehicles with S-Tronic transmission 0B5
2. Engine Bung Set VAS 6122 for vehicles with S-Tronic transmission 0B5
3. Drip Tray for VAS 6100 VAS 6208

Removing

Remove the front noise insulation -1-. Refer to Description and Operation .

Remove the impact member -5-. Refer to Removal and Installation .

Scheme 116

Remove the front charge air cooling circuit radiator. Refer to FRONT CHARGE AIR COOLING CIRCUIT RADIATOR .

Vehicles with Version 2 Refrigerant Pipes

Scheme 117

Remove the condenser. Refer to "Refrigerant Circuit" in Removal and Installation .

Audi A4

Scheme 118

Remove the headlamp housing mount. Refer to Description and Operation .

All Vehicles

Place the VAS 6208 under the engine.

Remove the drain plug -1- and drain the coolant.

Lift the clip -2- and disconnect the coolant hose from the radiator.

Lift the clamp -arrow- and remove the connection from the radiator.

Scheme 119

Scheme 120

Disconnect the radiator fan electrical connectors -1 and 2-, to do this, push the clamp to the rear -arrow- and push the release down.

Vehicles with S-Tronic Transmission 0B5

Scheme 121

Place the V.A.G 1782 under the disconnection point.

Note. Follow the rules for clean working conditions when working on the transmission. Refer to CLEAN WORKING CONDITIONS .

Remove the bolts -arrow- and disconnect the ATF lines from the transmission.

Note. To prevent ATF from leaking, secure all ATF lines to the top of the longitudinal member.

Seal any open lines and connections with a clean plug from the VAS 6122.

All Vehicles

Scheme 122

Open the clamps -1 and 2- and remove the connection from the radiator.

Remove the bolts -arrows-.

Remove the air duct -1- from the air filter housing intermediate flange -2-.

Vehicles with Hydraulic Power Steering

Scheme 123

If applicable, release the clamps -arrow A- and tilt the power steering coolant hose -1- forward -arrow B-.

Pull the power steering coolant hose upward off the condenser and lay it on the engine.

All Vehicles

Scheme 124

Release the retaining tabs -A arrows- and remove the left and right air ducts -1- upward -arrow B-.

Release the left and right radiator retaining pins and remove by pulling upward -arrows-.

Scheme 125

Remove the left and right bolts -1- and remove the radiator bracket with the radiator from the lock carrier -arrow-.

Scheme 126

Lower the radiator slightly.

Vehicles with Version 1 Refrigerant Pipes

Have a second technician release the retaining clamps -1- in the direction of -arrow A- and remove the condenser -2- upward out of the mounts on the radiator -B arrows-.

Tilt the condenser forward with the refrigerant lines still connected.

All Vehicles

Remove the radiator.

Press the fan shroud left and right locking tabs at the same time -arrow- and remove the fan shroud upward from the radiator.

Scheme 127

Installing

Install in reverse order of removal. Note the following

1. Tightening specifications, refer to «RADIATOR AND COOLANT FAN OVERVIEW»(/audi/s4/b8-2011-2015/remont/cooling-fan/#30l-cooling-system-engine-codes-ccba-sedan__radiator-and-coolant-fan-overview) .

Note. If there are small impressions on the fins, refer to COOLERS AND CONDENSERS .

Install the air duct on the air filter housing intermediate flange. Refer to Removal and Installation .

Vehicles with S-Tronic transmission 0B5: Tighten the ATF pipes. Refer to Removal and Installation .

Connect the coolant hose to the coupling. see scheme 28

Install the front charge air cooling circuit radiator. Refer to FRONT CHARGE AIR COOLING CIRCUIT RADIATOR .

Audi A4: Install the headlamp housing mount. Refer to Removal and Installation .

Install condenser. Refer to "Refrigerant Circuit" in Removal and Installation .

Install the impact member. Refer to Removal and Installation .

Fill with coolant FILLING .

Note. All of the coolant must be changed if the radiator was replaced.

Vehicles with S-Tronic transmission 0B5: Check the ATF level. Refer to General Information .

SUPERCHARGER COOLANT PIPES

Special tools and workshop equipment required

1. Hose Clamps up to 25 mm Dia. 3094
2. Drip Tray for VAS 6100 VAS 6208
3. Hose Clip Pliers VAS 6362

Removing

Remove the front engine cover -1- upward.

Remove the front noise insulation -1-. Refer to Description and Operation .

Open the coolant reservoir cap.

Place the VAS 6208 under the engine.

Disconnect the coolant hoses with the 3094 and remove them from the left front coolant pipes on the supercharger by loosening the clamps -1-.

Note. Ignore -2-.

Remove the bolts -1 and 2- and the coolant pipes.

Installing

Install in reverse order of removal. Note the following

1. Tightening specifications, refer to «COOLANT PIPES OVERVIEW»(/audi/s4/b8-2011-2015/remont/cooling-fan/#30l-cooling-system-engine-codes-ccba-sedan__coolant-pipes-overview) .

Note. Replace the seals Secure all hose connections with hose clamps of the same type as those equipped by the factory.

Fill with coolant. Refer to FILLING .

Install the noise insulation. Refer to Description and Operation .

UPPER COOLANT PIPE

Removing

Note. When installing, bring all cable ties back to same positions.

Drain the coolant. Refer to COOLANT, DRAINING AND FILLING .

Remove the right lower section of the intake manifold. Refer to Removal and Installation .

Remove the nuts -arrows- and the high pressure line protective plate -1-.

Scheme 128

Remove the front secondary air hose -arrow- from its bracket and disconnect it; do to this press the release buttons.

Scheme 129

Remove the threaded connection -1-.

Scheme 130

Loosen the union nuts -2 and 3- by counter holding at the connections.

Remove the bolts -arrows- on the retaining plates and the high pressure line.

Note. Lay a cloth below the coolant pipe to catch escaping coolant.

Open the clamp -2- and remove the coolant hose form the coolant pipe.

Remove the bolt -1- and remove the coolant pipe back out of the cylinder block -arrow-.

Installing

Install in reverse order of removal. Note the following

1. Tightening specification, refer to «COOLANT PIPES OVERVIEW»(/audi/s4/b8-2011-2015/remont/cooling-fan/#30l-cooling-system-engine-codes-ccba-sedan__coolant-pipes-overview) .

Note. Replace the O-rings.

Clean and smooth the O-ring sealing surface.

Coat the O-ring with coolant and slide it onto the coolant pipe.

Connect the coolant hose to the coupling. see scheme 28

Install the high pressure line and the lower intake manifold. Refer to Removal and Installation .

Fill with coolant FILLING .

Scheme 131

Special tools and workshop equipment required

1. Adapter V.A.G 1274/8
2. Adapter for V.A.G 1274 tester V.A.G 1274/10
3. Cooling System Charge Unit VAS 6096
4. Drip Tray for VAS 6100 VAS 6208
5. Hose Clip Pliers VAS 6362
6. Refractometer T10007

Special tools and workshop equipment required

Scheme 132

Scheme 133

Scheme 134

Scheme 135

Scheme 136

Scheme 137

Scheme 138

1. Hose Clamps Up to 25 mm Dia. 3094
2. Spanner Wrench 3212
3. Cooling System Tester V.A.G 1274 B
4. Adapter V.A.G 1274/9
5. Used Oil Collection and Extraction Device V.A.G 1782
6. Engine Bung Set VAS 6122
7. Hose Clip Pliers VAS 6340

See also:
• Description and Operation
• Removal and Installation
• Air Conditioning
• SUPERCHARGER RIBBED BELT DRIVE OVERVIEW
• Removal and Installation
• RIBBED BELT, VEHICLES WITH HYDRAULIC POWER STEERING
• RIBBED BELT, VEHICLES WITH ELECTRO-MECHANICAL POWER STEERING
• Removal and Installation
• Removal and Installation
• Removal and Installation
• Removal and Installation
• Description and Operation
• CLEAN WORKING CONDITIONS
• COOLERS AND CONDENSERS
• Removal and Installation
• After-Run Coolant Pump -V51
• PRESSURE RELIEF VALVE IN CAP, CHECKING
• LEFT FRONT COOLANT PIPES
• FRONT COOLANT PIPE
• Engine Coolant Temperature Sensor -G62
• SUPERCHARGER COOLANT PIPES
• UPPER COOLANT PIPE
• LEFT COOLANT PIPES
• COOLANT PUMP
• COOLANT THERMOSTAT
• COOLANT THERMOSTAT, CHECKING
• RADIATOR AND FAN SHROUD
• Coolant Fan -V7- AND Coolant Fan 2 -V177-, VERSION 1
• FRONT CHARGE AIR COOLING CIRCUIT RADIATOR
• LEFT CHARGE AIR COOLING CIRCUIT RADIATOR
• Charge Air Cooling Pump -V188
• RADIATOR AND COOLANT FAN OVERVIEW
• FILLING
• COOLANT, DRAINING AND FILLING
• COOLANT PIPES OVERVIEW
