MMI BASIC DISPLAY CONNECTORS

Front information display control head -J685

Note. Unlisted connector terminals are not used.

Scheme 34

2 - Voltage supply from Front Information Display Control Head Control Module -J523

3 - Ground (GND) from Front Information Display Control Head Control Module

6 - Terminal 31, ground (GND)

7 - Data (+) from Front Information Display Control Head Control Module

8 - Data (-) from Front Information Display Control Head Control Module

9 - Data (+) to Front Information Display Control Head Control Module

10 - Data (-) to Front Information Display Control Head Control Module

Scheme 35

1. 8-pin multi-pin connector (T8aa)
2. MOST bus

Note. Unlisted connector terminals are not used.

1 - Terminal 31

2 - Terminal 30

4 - Terminal 31 (MMI basic only)

5 - Ring-break Diagnostic Cable

1. IN
2. OUT
