IDENTIFICATION
| WARNING | Vehicles are equipped with air bag supplemental restraint system. Before attempting any repairs involving steering column, instrument panel or related components, see SAFETY REQUIREMENTS FOR AIRBAGS in BODY INTERIOR article. |
ENGINE CODE
Engines are identified by a 3-letter code stamped on the engine. For engine code locations (Scheme 1)- (Scheme 4). Engine codes are also located on the vehicle data plate.
Scheme 1
Scheme 2
Scheme 3
Scheme 4
Scheme 5
| Location No. | Description | Refer to |
|---|---|---|
| 1 | Main Fuse | (Scheme 7) |
| 2 | Connector station - Right A-pillar | (Scheme 13) |
| 3 | Connector station - RF seat wiring | (Scheme 17) |
| 4 | Relay panel (3-position) | (Scheme 9) |
| 5 | Relay panel (9-position) at Vehicle Electrical System Control Module | (Scheme 12) |
| 6 | Relay panel (4-position) with threaded connection | (Scheme 11) |
| 7 | Connector station - LF seat wiring | (Scheme 17) |
| 8 | Fuse panel | (Scheme 8) |
| 9 | Connector station - Left A-pillar | (Scheme 15) |
| 10 | Connector station with threaded connection | (Scheme 18) |
| 11 | Relay panel (4-position) | (Scheme 10) |
| For component locations refer to overview illustration (Scheme 5) | ||
| WARNING | Never replace a fuse with one that has a higher amperage rating. A fuse with a too high amperage could damage the electrical part and cause a fire. |
For access to fuse box (Scheme 6)
Scheme 6
Main Fuse (Engine Compartment)
The main fuse is located on the battery positive post, the fuse is numbered "S88" and has an amperage rating of 150 amps. The battery is located in the plenum chamber on right side of engine compartment.
Scheme 7
| Designation | Amp Rating |
|---|---|
| S88 - Strip fuse | 150A |
MAIN FUSE IDENTIFICATION (ENGINE COMPARTMENT - RIGHT SIDE)
Scheme 8
| Fuse No. | Function/Component | Amp Rating (A) |
|---|---|---|
| 1 | J255 - Climatronic Control Module | 10A |
| 2 | W9 - Left Footwell Light W10 - Right Footwell Light W45 - Left Rear Footwell Light W46 - Right Rear Footwell Light | 5A |
| 3 | Z20 - Left Washer Nozzle Heater Z21 - Right Washer Nozzle Heater | 5A |
| 4 | J293 - Coolant Fan Control (FC) Control Module J671 - Coolant Fan Control (FC) Control Module 2 | 5A |
| 5 | E149 - Rear Window Shade Switch E272 - Function Selector Switch II F189 - Tiptronic Switch G266 - Oil Level Thermal Sensor J262 - Rear Window Shade Control Module J401 - Navigation System with CD Drive Control Module J446 - Parking Aid Control Module | 10A |
| 6 | G65 - High Pressure Sensor G238 - Sensor for air quality | 5A |
| 7 | E132 - Anti-Slip Control Switch F36 - Clutch Pedal Switch F47 - Brake Pedal Switch J104 - ABS Control Module | 10A |
| 8 | R36 - Telephone Transceiver R86 - Telephone Amplifier | 5A |
| 9 | J569 - Brake Booster Relay | 15A |
| 10 | E102 - Headlamp Adjuster J431 - Headlamp Range Control Module J745 - Headlamp Range/Cornering Lamp Control Module V48 - Left Headlamp Beam Adjusting Motor V49 - Right Headlamp Beam Adjusting Motor V319 - Right Dynamic Cornering Light Motor | 5A |
| 11 | J234 - Airbag Control Module K145 - Warning Lamp for airbag off, passenger side | 5A |
| 12 | T16 - 16-pin connector, black, diagnostic connector | 10A |
| 13 | J527 - Steering Column Electronic Systems Control Module | 10A |
| 14 | F - Brake Light Switch | 10A |
| 15 | J285 - Instrument Cluster Control Module J401 - Navigation System with CD Drive Control Module J503 - Radio/Navigation Display Control Module | 10A |
| 16 | E284 - Garage Door Opener Control Head J530 - Garage Door Opener Control Module | 5A |
| 17 | G397 - Rain/Light Recognition Sensor J446 - Parking Aid Control Module J502 - Tire Pressure Monitoring Control Module | 10A |
| 18 | V318 - Left Dynamic Cornering Light Motor | 5A |
| 19 | L22 - Left Front Fog Lamp L23 - Right Front Fog Lamp | 10A |
| 20 | Not used | |
| 21 | Not used | |
| 22 | J386 - Drivers Door Control Module J387 - Front Passenger's Door Control Module | 15A |
| 23 | J388 - Left Rear Door Control Module J389 - Right Rear Door Control Module | 15A |
| 24 | J393 - Comfort System Central Control Module | 20A |
| 25 | J126 - Fresh Air Blower Control Module | 30A |
| 26 | J9 - Rear Window Defogger Relay | 30A |
| 27 | J345 - Towing Recognition Control Module | 30A |
| 28 | G6 - Transfer Fuel Pump (FP) J538 - Fuel Pump (FP) Control Module | 20A |
| G6 - Transfer Fuel Pump (FP) (1) J538 - Fuel Pump (FP) Control Module (1) | 30A | |
| 29 | Not used | |
| 30 | J245 - Convertible Top Control Module | 30A |
| 31 | F4 - Back-Up Light Switch G70 - Mass Air Flow (MAF) Sensor G399 - Light Recognition Sensor J207 - Starting Interlock Relay J217 - Transmission Control Module (1CM) N110 - Shift Lock solenoid T16 - 16 Position Connector, Black Data Link Connector (DLC) Y6 - Automatic Day/Night Interior Mirror | 15A |
| 32 | Not used | |
| 33 | U1 - Cigarette lighter | 20A |
| 34 | U5 - 12V Socket | 20A |
| 35 | U - Socket | 20A |
| 36 | J519 - Vehicle Electrical System Control Module | 30A |
| 37 | J519 - Vehicle Electrical System Control Module V11 - Headlamp Washer Pump | 30A |
| 38 | G303 - Radar Interior Monitoring Control Module 1 G305 - Radar Interior Monitoring Control Module 2 H12 - Alarm Horn J393 - Comfort System Central Control Module | 15A |
| 39 | J401 - Navigation System with CD Drive Control Module J503 - Radio/Navigation Display Control Module T8 - 8-Pin Connector, black, radio connector III R - Radio R12 - Amplifier | 20A |
| 40 | H2 - High Tone Horn H7 - Low Tone Horn J4 - Horn Relay | 25A |
| 41 | Not used | 30A |
| 42 | J104 - ABS Control Module | 25A |
| 43 | Engine Timing G70 - Mass Air Flow (MAF) Sensor G212 - EGR Potentiometer J363 - SIMOS Control Module Power Supply Relay J623 - Engine Control Module (ECM) J757 - Engine Component Power Supply Relay N18 - EGR Vacuum Regulator Solenoid Valve | 15A |
| 44 | J255 - Climatronic Control Module | 35A |
| (1) Engine code BNS only. Some of the equipment items listed are optional or only available on certain model configurations. | ||
| (1) | Engine code BNS only. |
IDENTIFYING FUSES (INSTRUMENT PANEL - LEFT SIDE)
AUTOMATIC CIRCUIT BREAKERS
The electric power windows and the electric seat adjusters are protected with Circuit breakers which reset automatically after the circuit overload has been corrected.
Note. Whenever replacing a fuse, always consult the sticker on the inside of the fuse panel cover. It contains the most up-to-date information regarding the fuse arrangement.
Relay Panel (3 Position) Dash Panel Driver's Side
Note. The relay panel (3 position) carrier is located on the driver's side dash panel area on the right side. For fuse and relay positions within the panel (Scheme 9)
Scheme 9
| Position | Socket Color | Circuit Protected |
|---|---|---|
| 2 | Black | J359 - Preheating Coolant , Low Heat Output Relay |
| 3 | Brown | J360 - Preheating Coolant , High Heat Output Relay |
| Note: The remaining items in the relay carrier are not used. | ||
IDENTIFYING RELAYS (3 POSITION) DASH PANEL DRIVER'S SIDE)
| Position | Socket Color | Circuit Protected | Amp Rating |
|---|---|---|---|
| B | Black | S328 - Auxiliary Heater Fuse 2 | 60A |
| C | Green | S126 - Auxiliary Heater Fuse | 40A |
| Note: The remaining items in the relay carrier are not used. | |||
IDENTIFYING RELAYS (3 POSITION) DASH PANEL DRIVER'S SIDE
Relay Panel (4 Position) In Electronics Box, Plenum Chamber
For fuse and relay positions within the panel (Scheme 10)
For relay number, position number and circuits protected, see the appropriate IDENTIFYING RELAYS table.
For fuse number, position number, amperage rating and circuits protected, see the appropriate IDENTIFYING FUSES table.
Note. The relay panel (4 position) carrier is located in electronics box, plenum chamber, in the left rear corner of the engine compartment.
Scheme 10
Relay Panel (4 Position) In E-Box (Engine Code BRC, BPW, BRF & BRE)
For identification of the relay panel 4 position carrier and it's layout (Scheme 10)
| Position | Socket Color | Circuit Protected |
|---|---|---|
| 1.1 | Blue | J17 - Fuel Pump (FP) Relay |
| 1.2 | Blue | J207- Starter Interlock Relay |
| 2 | Brown | J317 - Power Supply Relay (terminal 30, B+) |
| 3 | Black | J179 - Automatic Glow Time Control Module |
| Note: The remaining items in the relay carrier are not used. | ||
IDENTIFYING RELAYS (4 POSITION) IN E-BOX (ENGINE CODE BRC, BPW, BRF & BRE)
| Position No. | Socket Color | Amp Rating | Circuit Protected |
|---|---|---|---|
| A | Blue | 15A | S282 - Engine Electronics Fuse |
| B | Black | 80A | S39 - Engine Glow Plug Fuse Strip |
| C | Red | 15A | S102 - Engine Control Module (ECM) Fuse |
| D | Grey | 15A | S286 - Auto-transmission After-Run Fuse |
| E | Black | 15A | S344- Engine Electronics Fuse 2 |
| Note: The remaining items in the relay carrier are not used. | |||
IDENTIFYING FUSES (4 POSITION) IN E-BOX (ENGINE CODE BRC, BPW, BRF & BRE)
Relay Panel (4 Position) In E-Box (Engine Code BKN, ASB, BSG & BPP)
For identification of the relay panel 4 position carrier and it's layout (Scheme 10)
| Position | Socket Color | Circuit Protected |
|---|---|---|
| 1.1 | Blue | J17 - Fuel Pump (FP) Relay |
| 1.2 | Blue | J207- Starter Interlock Relay |
| 2 | Brown | J317 - Power Supply Relay (terminal 30, B+) |
| 3 | Black | J179 - Automatic Glow Time Control Module |
| Note: The remaining items in the relay carrier are not used. | ||
IDENTIFYING RELAYS (4 POSITION) IN E-BOX (ENGINE CODE BKN, ASB, BSG & BPP)
| Position No. | Socket Color | Amp Rating | Circuit Protected |
|---|---|---|---|
| A | Blue | 15A | S282 - Engine Electronics Fuse |
| B | Black | 80A | S39 - Engine Glow Plug Fuse Strip |
| C | Red | 15A | S102 - Engine Control Module (ECM) Fuse |
| D | Grey | 15A | S286 - Auto-transmission After-Run Fuse |
| E | Black | 15A | S344- Engine Electronics Fuse 2 |
| G | Black | 15A | S345- Engine Electronics Fuse 3 |
| Note: The remaining items in the relay carrier are not used. | |||
IDENTIFYING FUSES (4 POSITION) IN E-BOX (ENGINE CODE BKN, ASB, BSG & BPP)
Relay Panel (4 Position) In E-Box (Engine Code BWE, BPG & BWT)
For identification of the relay panel 4 position carrier and it's layout (Scheme 10)
| Position No. | Socket Color | Circuit Protected |
|---|---|---|
| 1.2 | Blue | J207 - Starting Interlock Relay |
| 2 | Brown | J271- Motronic (ECM) Power Supply Relay |
| 3 | Black | J757 - Engine Component Power Supply Relay |
| Note: The remaining items in the relay carrier are not used. | ||
IDENTIFYING RELAYS (4 POSITION) IN E-BOX (ENGINE CODE BWE, BPG & BWT)
| Position No. | Socket Color | Amp Rating | Circuit Protected |
|---|---|---|---|
| A | Blue | 15A | S282 - Engine Electronics Fuse |
| B | Brown | 15A | S345 - Engine Electronics Fuse 3 |
| C | Grey | 15A | S102 - Engine Control Module (ECM) Fuse |
| D | Yellow | 20A | S103 - Ignition Coil Circuit Breaker |
| E | Black | 15A | S344 - Engine Electronics Fuse 2 |
| G | Purple | 15A | S286 - Automatic Transmission After-Run Fuse |
| Note: The remaining items in the relay carrier are not used. | |||
IDENTIFYING FUSES (4 POSITION) IN E-BOX (ENGINE CODE BWE, BPG & BWT)
Relay Panel (4 Position) In E-Box (Engine Code ALT)
For identification of the relay panel 4 position carrier and it's layout (Scheme 10)
| Position No. | Socket Color | Circuit Protected |
|---|---|---|
| 2 | Brown | J271- Motronic (ECM) Power Supply Relay |
IDENTIFYING RELAYS (4 POSITION) IN E-BOX (ENGINE CODE ALT)
| Position No. | Socket Color | Amp Rating | Circuit Protected |
|---|---|---|---|
| A | Blue | 15A | S344 - Engine Electronics Fuse 2 |
| B | Red | 15A | S282 - Engine Electronics Fuse |
| C | Grey | 15A | S286 - Automatic Transmission After-Run Fuse |
| D | Yellow | 20A | S102 - Engine Control Module (ECM) Fuse |
| E | Black | 15A | S116 - Injector Fuse |
| Note: The remaining items in the relay carrier are not used. | |||
IDENTIFYING FUSES (4 POSITION) IN E-BOX (ENGINE CODE ALT)
Relay Panel (4 Position) In E-Box (Engine Code BFB, BBK & BHF)
For identification of the relay panel 4 position carrier and it's layout (Scheme 10)
Note. Four-pin relay carrier is located in electronics box, plenum chamber, in the left rear corner of the engine compartment.
| Position | Socket Color | Circuit Protected |
|---|---|---|
| 1.1 | Blue | J151 - Coolant Circulation Pump Relay |
| 1.2 | Blue | J207 - Starter Interlock Relay J434 - Starter Lock/Clutch Pedal Switch Relay (1) |
| 2 | Brown | J271 - Motronic (ECM) Power Supply Relay |
| 3 | Black | J299 - Secondary Air Injection Pump Relay |
| (1) Applies to vehicles equipped with engine code BBK only. Note: The remaining items in the relay carrier are not used. | ||
| (1) | Applies to vehicles equipped with engine code BBK only. |
IDENTIFYING RELAYS (4 POSITION) IN E-BOX (ENGINE CODE BFB, BBK & BHF)
| Position No. | Socket Color | Amp Rating | Circuit Protected |
|---|---|---|---|
| A | Blue | 15A | S344 - Engine Electronics Fuse 2 |
| B | Black | 40A | S130- Secondary Air Injection (AIR) Pump Fuse |
| C | Grey | 15A | S286 - Automatic Transmission After-Run Fuse |
| D | Yellow | 20A | S102 - Engine Control Module (ECM) Fuse |
| E | Black | 15A | S116 - Injector Fuse |
| G | Red | 15A | S282 - Engine Electronics Fuse |
| Note: The remaining items in the relay carrier are not used. | |||
IDENTIFYING FUSES (4 POSITION) IN E-BOX (ENGINE CODE BFB, BBK & BHF)
Relay Panel (4 Position) In E-Box (Engine Code AUK, BKH)
For identification of the relay panel 4 position carrier and it's layout (Scheme 10)
| Position | Socket Color | Circuit Protected |
|---|---|---|
| 1.1 | Blue | J496 - Auxiliary Engine Coolant (EC) Pump Relay |
| 2 | Brown | J271 - Motronic (ECM) Power Supply Relay |
| 3 | Black | J757 - Engine Component Power Supply Relay |
| Note: The remaining items in the relay carrier are not used. | ||
IDENTIFYING RELAYS (4 POSITION) IN E-BOX (ENGINE CODE AUK, BKH)
| Position No. | Socket Color | Amp Rating | Circuit Protected |
|---|---|---|---|
| A | Blue | 15A | S344 - Engine Electronics fuse 2 |
| B | Brown | 15A | S282 - Engine Electronics fuse |
| C | Grey | 15A | S102 - Engine Control Module (ECM) fuse |
| D | Yellow | 20A | S131 - Safety fuse 1 |
| E | Black | 15A | S73 - Heated Oxygen Sensor (HO2S) Circuit Breaker |
| G | Purple | 15A | S286 - Automatic Transmission After-Run Fuse |
| Note: The remaining items in the relay carrier are not used. | |||
IDENTIFYING FUSES (4 POSITION) IN E-BOX (ENGINE CODE AUK, BKH)
Relay Panel (4 Position) In E-Box (Engine Code BNS)
For identification of the relay panel 4 position carrier and it's layout (Scheme 10)
| Position No. | Socket Color | Circuit Protected |
|---|---|---|
| 1.1 | Blue | J151- Coolant Circulation Pump Relay |
| 1.2 | Blue | J569 - Brake Booster Relay |
| 2 | Brown | J271- Motronic (ECM) Power Supply Relay |
| 3 | Black | J757 - Engine Component Power Supply Relay |
| 4 | Black | J299 - Secondary Air Injection (AIR) Pump Relay |
IDENTIFYING RELAYS (4 POSITION) IN E-BOX (ENGINE CODE BNS)
| Position No. | Socket Color | Amp Rating | Circuit Protected |
|---|---|---|---|
| A | Yellow | 10A | S344 - Engine Electronics Fuse 2 |
| B | Black | 15A | S282 - Engine Electronics Fuse |
| C | Red | 15A | S102 - Engine Control Module (ECM) Fuse |
| D | Blue | 30A | S131 - Safety Fuse 1 |
| E | Black | 15A | S73 - Heated Oxygen Sensor (HO2S) Circuit Breaker |
| E | Red | 15A | S283 - Brake Vacuum Pump Fuse |
| H (1) | Black | 50A | S130 - Secondary Air Injection (AIR) Pump Fuse |
| (1) On under side of relay carrier Note: The remaining items in the relay carrier are not used. | |||
| (1) | On under side of relay carrier |
IDENTIFYING FUSES (4 POSITION) IN E-BOX (ENGINE CODE BNS)
Relay Panel (4-Position) With Threaded Connection
For fuse and relay positions within carrier (Scheme 11) For relay number, position number and circuits protected, see RELAY IDENTIFICATION (RELAY PANEL (4-POSITION) WITH THREADED CONNECTION) table. For fuse number, position number, amperage rating and circuits protected, see FUSE IDENTIFICATION (RELAY PANEL (4-POSITION) WITH THREADED CONNECTION) table.
Note. The relay panel (4-position) carrier is located under driver's side of instrument panel.
Scheme 11
| Position No. | Socket Color | Circuit Protected |
|---|---|---|
| 3 | White | J662 - NG Engine Throttle Relay 1 (Driving school) |
| 4 | Blue | J663 - NG Engine Throttle Relay 2 (Driving school) |
| Note: The remaining items in the relay carrier are not used. | ||
RELAY IDENTIFICATION (RELAY PANEL (4-POSITION) WITH THREADED CONNECTION)
| Position No. | Socket Color | Amp Rating | Circuit Protected |
|---|---|---|---|
| F | Black | 10A 40A 40/60A | S51 - Fuse (Driver Fan training vehicle) (3) S42 - Coolant Fan Fuse (1) S42 - Coolant Fan Fuse (2) |
| G | Black | 30A 40A 40/60A | S214 - Radiator After run Fuse (2) S214 - Radiator After run Fuse (1) S42 - Coolant Fan Fuse (4) |
| H | Brown | 40A | S123 ABS Control Module Fuse 1 |
| (1) Engine code BBK, BHF, BNS only. (2) Engine code BKN, ASB, BPP, BSG only. (3) Not for Engine code BBK, BHF only. (4) Not for Engine code BKN, BBK, BHF, ASB, BPP, BSG only. Note: The remaining items in the relay carrier are not used. | |||
| (1) | Engine code BBK, BHF, BNS only. |
| (2) | Engine code BKN, ASB, BPP, BSG only. |
| (3) | Not for Engine code BBK, BHF only. |
| (4) | Not for Engine code BKN, BBK, BHF, ASB, BPP, BSG only. |
FUSE IDENTIFICATION (RELAY PANEL (4-POSITION) WITH THREADED CONNECTION)
Relay Panel (9-Position) At Vehicle Electrical System Control Module
For fuse and relay position within carrier (Scheme 12) For relay number, position number and circuits protected, see RELAY IDENTIFICATION (RELAY PANEL (9-POSITION)) table. For fuse number, position number, amperage rating and circuits protected, see FUSE IDENTIFICATION (RELAY PANEL (9-POSITION)) table.
Note. The relay panel (9-position) is located behind instrument panel, driver's side, behind 3-position relay panel.
Scheme 12
| Position No. | Socket No. | Circuit Protected |
|---|---|---|
| 1 | Green | J17 - Fuel Pump (FP) Relay |
| 2 | Red | J236 - Servotronic Control Module |
| 3 | Green | J695 - Starter Relay 2 (1) |
| 4 | Brown | J53 - Starter Relay (1) J569 - Brake Booster Relay (2) |
| 5 | Purple | J9 - Rear Window Defogger Relay |
| 6 | Black | J59 - Load Reduction Relay |
| 8 | Black | J4 - Horn Relay |
| (1) For engine code AUK, BKH, BNS only. (2) Not applicable for engine code AUK, BKH only. Note: The remaining items in the relay carrier are not used. | ||
| (1) | For engine code AUK, BKH, BNS only. |
| (2) | Not applicable for engine code AUK, BKH only. |
RELAY IDENTIFICATION (RELAY PANEL (9-POSITION))
| Position No. | Socket Color | Amp Rating | Circuit Protected |
|---|---|---|---|
| B | Brown | 40A | S67 - Convertible Top Operation Fuse |
| D | Brown | 30A | S280 - Power Windows Fuse 2 |
| E | Red | 30A | S45 - Driver's Power Seat Adjustment Circuit Breaker 2 |
| F | Black | 30A | S37 - Power Windows Fuse |
| G | Green | 30A | S77 - Trailer (terminal 30, B+) Fuse |
| Note: The remaining items in the relay carrier are not used. | |||
FUSE IDENTIFICATION (RELAY PANEL (9-POSITION))
CONNECTOR STATION - RIGHT A PILLAR
The connector station is located at the right side footwell below the A-pillar trim. For pin and fuse position in connector station, see illustrations below.
Scheme 13
Scheme 14
| Fuse Position | Socket Color | Amp Rating | Circuit Protected |
|---|---|---|---|
| Black | 30A | S46 - Power Seat | |
| E | Black | 10A | S46 - Power Seat, Lumbar Adj. |
| Pin Connectors | Designation | Component | |
| 13 | T6p, 6 pin con. Lilac | Satellite radio | |
| 14 | T6q, 6 pin con. Lilac | Satellite radio | |
| 15 | T17c, 17 pin con. Red | Headlamp | |
| Note: The remaining items in the connector point are not used. | |||
PIN & FUSE IDENTIFICATION (CONNECTOR STATION - RIGHT)
CONNECTOR STATION - LEFT A PILLAR
The connector station is located at the left side footwell below the A-pillar trim. For pin and fuse position in connector station, see illustrations below.
Scheme 15
Scheme 16
| Position No. | Designation | Component |
|---|---|---|
| 8 | T10i - 10-pin connector, blue | Parking aid (where applicable) |
| 11 | T6b - 6-pin connector, brown | Servotronic |
| 13 | T10c - 10 pin con. Violet | Wiper motor |
| 14 | T10d -10 pin con. Grey | Fan/compressor |
| 15 | T17b - 17 pin con. Green | Left headlight (connector 3) |
| 16 | T17a - 17 pin con. Red | Left headlight (connector 2) |
| 17 | T17 - 17 pin con. Black | Left headlight (connector 1) |
| Note: The remaining items in the connector point are not used. | ||
PIN & FUSE IDENTIFICATION (CONNECTOR STATION - LEFT)
CONNECTOR STATION - LF/RF SEAT WIRING
The connector stations are located under the passenger seat and under the driver seat. For pin position in connector station, see illustration below.
Scheme 17
| Position No. | Designation | Component |
|---|---|---|
| 1 | T3d - 3 pin connector, Yellow | Side airbag |
| 2 | T10p - 10 pin connector, Red | Supply |
| 3 | T6e - 6-pin connector, Green | Seat heating |
| 4 | T8c - 8 pin con. Black | Seat belt buckle |
PIN IDENTIFICATION (CONNECTOR STATION - RIGHT SEAT WIRING)
| Position No. | Designation | Component |
|---|---|---|
| 1 | T3c - 3 pin connector, Yellow | Side airbag |
| 2 | T10o - 10 pin connector, Red | Supply |
| 3 | T6d - 6-pin connector, Green | Seat heating |
| 4 | T8b - 8 pin con. Black | Seat belt buckle |
PIN IDENTIFICATION (CONNECTOR STATION - LEFT SEAT WIRING)
CONNECTOR STATION WITH THREADED CONNECTION
The connector station is located In the electronic box in plenum chamber on left side of engine compartment. For pin position in connector station, see illustration below.
Scheme 18
| Position No. | Designation | Component |
|---|---|---|
| 2 | T17j - 17-pin connector, Brown | Engine/Transmission (connector 3) |
| 3 | T17d - 17 pin connector, Red | Engine/Transmission (connector 1) |
| 6 | T17e - 17 pin connector, White | Engine/Transmission (connector 2) |
| Note: The remaining items in the connector point are not used. | ||
PIN IDENTIFICATION (CONNECTOR STATION WITH THREADED CONNECTION - E-BOX)
FUSES - CIRCUIT PROTECTION
| WARNING | Never replace a fuse with one that has a higher amperage rating. A fuse with a too high amperage could damage the electrical part and cause a fire. |
For access to fuse box see scheme 19
REPLACING A FUSE
A problem in the electrical system may be caused by a blown fuse.
- Switch off the ignition and the electrical component affected.
- Carefully pry the face cover off the instrument panel using the ignition key or a screwdriver. see scheme 19
- Check the fuse index to find out which fuse belongs to the component which has failed. See RR. FUSE INDEX INFORMATION.
- Remove the blown fuse with the plastic clip provided. The clip is located on the holder in the fuse box.
- Replace a blown fuse (recognizable by the melted metal strip inside) with a fuse of the same amperage.
- Firmly snap the cover back onto the instrument panel face.
The various electrical circuits are protected by fuses. The fuses are clustered in a centralized unit. The unit is located behind the face panel at the end of the instrument panel. The crank for operating the sunroof in case of a power failure is also stored behind the face panel (If equipped with sunroof).
Two spare fuses end a sticker identifying the fuses are located on the inside of the fuse box cover.
You are well advised to keep a supply of spare fuses in your vehicle. Fuses with the proper ampere ratings are available at your Audi dealer.
Note. On no account should fuses be repaired (e.g. with tin foil or wire) as this may cause serious damage elsewhere in the electrical circuit or cause fire. If a fuse blows repeatedly, do not keep replacing it. Track and fix shorted or overloaded circuit.
FUSE - COLOR CODES
Identifying fuse color and ampere rating, refer to table below.
| WARNING | Never replace a fuse with one that has a higher amperage rating. A fuse with a too high amperage could damage the electrical part and cause a fire. |
| Current Rating Amperes | Color |
|---|---|
| 1A | Black |
| 3A | Violet |
| 5A | Light Brown |
| 7.5A | Brown |
| 10A | Red |
| 15A | Blue |
| 20A | Yellow |
| 25A | White or Natural |
| 30A | Green |
| 35A | Green-Blue |
| 40A | Orange |
| 50A | Red |
IDENTIFYING FUSE BY COLOR
