Body Interior - Cabriolet Audi S4 B7

Scheme 1

1 - Instrument panel

2 - Instrument panel cover, right

1. Removing «Removing right instrument panel cover»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__removing-right-instrument-panel-cover)

3 - Glove compartment

1. Removing

1. Remove instrument panel cover - 2 -.
2. Open glove compartment lid.
3. Remove three bolts - 4 - in recesses at top of glove compartment - 3 -.
4. Remove bolts - 5 - (2x) from underneath (footwell).

1. For vehicles with CD changer - 8 - : Remove bolt - 6 -.
2. Vehicles with insulation box: Remove vent.
3. Pull out glove compartment downward.
4. Disconnect connector - 7 - from glove compartment light.

1. Disconnect connectors to electrical components in glove compartment (if applicable).

4 - Bolts (3x)

1. Tightening torque 3.5 Nm

5 - Bolts (2x)

1. Tightening torque 3.5 Nm

6 - Bolt

1. Tightening torque 3.5 Nm
2. Vehicles with CD changer only

7 - Connector

8 - CD changer

Scheme 2

Special tools and workshop equipment required

1. Front end hook 3370

Removing

1. Remove right instrument panel cover - arrow - using front end hook 3370.

Glove compartment lock handle, removing and installing

1. Removing

1. Open glove compartment lid - 2 -.
2. Use a screwdriver to carefully pry cover - 1 - from glove compartment lid.

Scheme 3

1. Remove bolt - 4 - from handle - 3 - on left side of glove compartment.
2. Use a screwdriver to carefully press central locking lever - 5 - out of glove compartment lock.
3. Remove handle - 3 - from glove compartment lid.

1. Installing

1. Installation is in reverse order of removal.

Damping mechanism for glove compartment lid, removing and installing

Special tools and workshop equipment required

1. Front end hook 3370

Removing

1. Open glove compartment.

1. Remove right instrument panel cover - arrow - using front end hook 3370.

Scheme 4

1. Disconnect connector - 2 -.
2. Remove joint pin - 1 -.
3. Unlock glove compartment lid damping mechanism - 3 - in clockwise direction and remove.

Note. Shown in illustration with glove box removed. Installing Installation is in reverse order of removal.

Scheme 5

1 - Instrument panel

2 - Instrument panel cover, right

1. Removing «Removing right instrument panel cover»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__removing-right-instrument-panel-cover)

3 - Glove compartment

Removing

1. Remove instrument panel cover - 2 - «Removing right instrument panel cover»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__removing-right-instrument-panel-cover) .
2. Open glove compartment lid.
3. Remove three bolts - 4 - in recesses at top of glove compartment - 3 -.
4. Remove bolts - 5 - (2x) from underneath (footwell).

1. For vehicles with CD changer - 8 - : Remove bolt - 6 -.
2. Remove bolts - 9 -.
3. Vehicles with insulation box: Screw out vent
4. Pull out glove compartment downward.

1. Disconnect connector - 7 - of glove compartment light.
2. Disconnect connectors to electrical components in glove compartment (if applicable).

4 - Bolts (3x)

1. Tightening torque 3.5 Nm

5 - Bolts (2x)

1. Tightening torque 3.5 Nm

6 - Bolt

1. Tightening torque 5 Nm
2. Only for vehicles with CD changer

7 - Connector

8 - CD changer

9 - Bolts (2x)

Removing instrument panel cover, right

Special tools and workshop equipment required

1. Front end hook 3370

Removing

1. Remove right instrument panel cover - arrow - using front end hook 3370.

Glove compartment lock handle (vehicles with knee bolster), removing and installing

1. Removing

1. Open glove compartment lid - 2 -.
2. Use a screwdriver to carefully pry cover - 1 - from glove compartment lid.

1. Remove bolt - 4 - from handle - 3 - on left side of glove compartment.
2. Use a screwdriver to carefully press central locking lever - 5 - out of glove compartment lock.
3. Remove handle - 3 - from glove compartment lid.

1. Installing

1. Installation is in reverse order of removal.

Glove compartment lid damping mechanism (vehicles with knee bolster), removing and installing

Special tools and workshop equipment required

1. Front end hook 3370

Removing

1. Open glove compartment.

1. Remove right instrument panel cover - arrow - using front end hook 3370.

1. Disconnect connector - 2 -.
2. Remove joint pin - 1 -.
3. Unlock glove compartment lid damping mechanism - 3 - in clockwise direction and remove.

Note. Shown in illustration with glove compartment removed.

Scheme 6

1 - Cold air hose

2 - Glove compartment

3 - Bolts (3x)

1. Tightening torque 0.6 Nm

4 - Insulation box

Removing

1. Remove vent - 5 -.
2. Remove bolts - 3 - (3x) and carefully pull insulation box out off glove compartment - 2 -.

Note. Install cold air hose - 1 - and screw to vent - 5 -.

5 - Vent

1. Tighten as far as possible

Scheme 7

1 - Drivers storage compartment

1. Removing

1. Remove instrument panel cover - 6 - «Removing left instrument panel cover»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__removing-left-instrument-panel-cover) .
2. Remove bolts - 2 - (3x).
3. Pull storage compartment at top of instrument panel to back and remove.
4. Unclip diagnostic connector.

1. Disconnect connector on footwell light and on additional speaker - 5 - if required.

1. Installing

1. First engage drivers storage compartment in guides on bottom edge, then clip onto instrument panel at top.

2 - Bolts (3x)

1. Tightening torque 3.5 Nm

3 - Bolt

1. Tightening torque 1.5 Nm

4 - Angle bracket

5 - Additional speaker

1. Removing «Removing additional speaker»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__removing-additional-speaker)

6 - Instrument panel cover, left

1. Removing «Removing left instrument panel cover»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__removing-left-instrument-panel-cover)

Scheme 8

Special tools and workshop equipment required

1. Front end hook 3370

Removing

1. Remove left instrument panel cover - arrow - using front end hook 3370.

Scheme 9

1. Disconnect connector - 2 -.
2. Remove bolt - 1 - and remove retaining bracket - 3 - and additional speaker - 4 -.

Scheme 10

1 - Drivers storage compartment

1. Removing

1. Remove instrument panel cover - 6 - «Removing left instrument panel cover»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__removing-left-instrument-panel-cover) .
2. Remove bolts - 2 - (3x).
3. Pull storage compartment at top of instrument panel to back and remove.
4. Unclip diagnostic connector.

1. Disconnect connector on footwell light and on additional speaker - 5 - if required.

1. Installing

1. First engage drivers storage compartment in guides on bottom edge, then clip onto instrument panel at top.

2 - Bolts (3x)

1. Tightening torque 3.5 Nm

3 - Bolt

1. Tightening torque 1.5 Nm

4 - Angle bracket

5 - Additional speaker

1. Removing «Removing additional speaker»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__removing-additional-speaker)

6 - Instrument panel cover, left

1. Removing «Removing left instrument panel cover»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__removing-left-instrument-panel-cover)

7 - Support, left

1. Only for vehicles with knee bolster

8 - Bolts (4x)

1. Tightening torque 9 Nm

9 - Support, right

1. Only for vehicles with knee bolster

Removing left instrument panel cover

Special tools and workshop equipment required

1. Front end hook 3370
2. Removing

1. Remove left instrument panel cover - arrow - using front end hook 3370.

Removing additional speaker

1. Disconnect connector - 2 -.
2. Remove bolt - 1 - and remove retaining bracket - 3 - and additional speaker - 4 -.

Scheme 11

1. Pull instrument cluster trim - 1 - in direction of - arrow -.

Scheme 12

1 - Center armrest

1. Removing

1. Remove rear ashtray - 3 -.
2. Remove nut - 2 - in ashtray well.
3. On center armrest with telephone, disconnect telephone connector.
4. Remove center armrest - 1 -.

2 - Nut

1. Tightening torque 26 Nm

3 - Rear ashtray

1. Removing

1. Unclip lid - 4 -.
2. Detach ashtray at rear - 3 -.
3. If installed, unclip mount for seat heating switch - 5 -.

4 - Cover

5 - Mount for switch

1. Removing and installing «Removing and installing mount for switch»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet)

Scheme 13

1. Removing

1. Remove rear ashtray.
2. Press left and right engaging hooks - arrow A - outward and fold back switch mount - arrow B -.
3. Disengage lower switch mount on rear of center console.
4. Disconnect connectors.

1. Unclip switches - 1 - and - 2 -.

1. Installing

1. Installation is in reverse order of removal.

Support bracket for center armrest, removing and installing

1. Removing

1. Remove center armrest --> «Rear center armrest and ashtray, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
2. Remove center console --> «Center console, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .

Scheme 14

1. Remove nuts - 2 - (2x).
2. Tightening torque 10 Nm
3. Detach support bracket - 1 -.

1. Installing

1. Installation is in reverse order of removal.

Scheme 15

1 - Center console

1. Removing

1. Refer to coding on vehicles with encoded radio/radio navigation system (RNS); if necessary, interrogate.
2. Disconnect ground (GND) strap at battery with ignition switched off.
3. Vehicles with radio: Remove radio. --> «91 - COMMUNICATION»(/audi/s4/b7-2004-2008/remont/accessories-control-systems/#communication) «91 RADIO, TELEPHONE, NAVIGATION, TRIP COMPUTER»(/audi/s4/b7-2004-2008/remont/accessories-control-systems/#communication-cabriolet) for COMMUNICATION, CABRIOLET
4. For vehicles with on-screen navigation system: Remove Control module for operating electronics, navigation J401. --> «91 - COMMUNICATION»(/audi/s4/b7-2004-2008/remont/accessories-control-systems/#communication) «91 RADIO, TELEPHONE, NAVIGATION, TRIP COMPUTER»(/audi/s4/b7-2004-2008/remont/accessories-control-systems/#communication-cabriolet) for COMMUNICATION, CABRIOLET

1. Remove radio trim and storage compartment trim in front center section --> «Radio cover and trim, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__radio-cover-and-trim-assembly-overview) .
2. Remove center armrest --> «Rear center armrest and ashtray, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
3. Remove A/C Control Head E87. --> «87 AIR CONDITIONING»(/audi/s4/b7-2004-2008/remont/ac-compressor/#heating-air-conditioning)
4. Apply parking brake firmly.

1. In the case of an automatic transmission push selector lever fully back.
2. Remove caps - 4 - from bolts - 3 - on right and left of front footwell at side of center console.
3. Remove bolts - 3 - on right and left of front footwell at side of center console.
4. Remove parking brake lever handle --> «Parking brake handle, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .

1. Remove parking brake trim --> «Parking brake lever trim, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
2. Pry out cover - 7 - from front.
3. Remove the two Phillips head screws - 9 - on connecting piece - 8 - and remove connecting piece. Otherwise the center console cannot be pulled over the parking brake lever.
4. Manual transmission: Remove cover and boot --> «Gear cover and boot, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .

1. Automatic gearbox: Pry gear cover off upward --> «Gear cover and boot, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
2. Remove front ashtray --> «Front ashtray, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
3. Remove two bolts - 5 - in ashtray opening.
4. Remove four bolts - 10 - around the gear lever, which secure the center console.

1. Disconnect connector for convertible-top actuation, cigarette lighter and/or navigation module --> «Navigation system operating unit in center console, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
2. Remove two bolts - 2 -.
3. Remove hex combi nut - 6 -.
4. Push center console carefully backward and remove from vehicle. .

Note. Before installing center console, make sure all insulating elements have been installed correctly --> Insulation, center console .

2 - Bolts (2x)

1. Tightening torque 3.5 Nm

3 - Bolts (2x)

1. Tightening torque 3.5 Nm

4 - Covers (2x)

5 - Bolts (2x)

1. Tightening torque 3.5 Nm

6 - Hex combi nut

1. Vehicles with center armrest: Tightening torque 10 Nm
2. Vehicles without center armrest: Tightening torque 5 Nm

7 - Parking brake cover

8 - Connecting piece

9 - Bolts (2x)

1. Tightening torque 2 Nm

10 - Bolts (4x)

1. Tightening torque 3.5 Nm

Scheme 16

1 - Insulation, center console mount

2 - Glove compartment

3 - Bolts (3x)

1. Only for 5-speed manual transmissions

4 - Insulation, gearshift

1. For manual transmission

5 - Interior monitor control module

6 - Insulation, tunnel

7 - Parking brake lever filler piece

1. Only with interior monitor

8 - Filler piece

1. Only with interior monitor

9 - Insulation, gearshift

1. For automatic transmission

Scheme 17

1 - Cassette tray

1. Removing

1. Remove center console --> «Center console, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
2. Turn center console over.
3. Pry off catch - 3 -.
4. Press two spring clips - 4 - on cassette tray (danger of injury from sharp-edged spring clips. Proceed carefully).

1. Remove cassette tray - 1 - from recess - 2 -.

2 - Recess for cassette tray in center console

3 - Cassette tray catch

4 - Spring clips

Scheme 18

1 - Connector mount

1. Removing

1. Remove center console --> «Center console, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
2. Turn center console over.
3. Pry off catch - 3 -.
4. Remove connector mount - 1 - from recess - 2 -.

2 - Recess for connector mount in center console

3 - Connector mount catch

Scheme 19

1 - Automatic transmission cover

1. Removing

1. Pry off gear cover - 1 -.

2 - Manual transmission cover

1. Removing

1. Pry off gear cover - 2 -.

3 - Boot

1. Removing

1. Unclip mounting frame - 6 -.
2. Turn connecting piece - 5 - to right in direction of - arrow A - until it unlocks.
3. Remove selector lever knob - 4 -.

1. Installing

1. Install selector lever knob - 4 -.
2. Turn connecting piece - 5 - to left in direction of - arrow B - until it locks.
3. Clip in mounting frame - 6 - in direction of - arrow C - arrow C.

4 - Selector lever knob

5 - Connecting piece

6 - Mounting frame

Scheme 20

1 - Recess

2 - Clamp

1. Only for vehicles with center armrest.

3 - Mounting frame

1. Removing

1. Remove navigation system operating unit with cigarette lighter - 5 - or tray with cigarette lighter - 6 -.
2. Remove center console - 7 - --> «Center console, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
3. Turn center console over.
4. Remove two bolts - 4 - on mounting frame - 3 -.

1. Remove mounting frame - 3 - from recess - 1 -.

4 - Bolts (2x)

1. Tightening torque 2 Nm

5 - Navigation system operating unit with cigarette lighter

1. Removing

1. Apply parking brake firmly.
2. Pry out cover underneath parking brake lever
3. Reach into opening below the parking brake lever and press navigation system operating unit with cigarette lighter out of center console - 7 - from below.

6 - Tray with cigarette lighter

1. Removing

1. Apply parking brake firmly.
2. Pry out cover underneath parking brake lever
3. Reach into opening below parking brake lever and press tray with cigarette lighter out of center console - 7 - from below.

7 - Center console

Footwell trim, removing and installing

1. Removing

Scheme 21

1. Remove bolt - 1 -.
2. Remove footwell trim - 2 - from its mount - 3 -.

1. Installing

1. Installation is in reverse order of removal.

Scheme 22

1 - Parking brake lever trim

1. Removing

1. Apply parking brake firmly.
2. Remove parking brake handle --> «Parking brake handle, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
3. Using a small screwdriver, press fastener - 2 - outward at left and right and pull parking brake lever trim out of its retainer tabs - 6 - and its mounts - 3 -.

1. Installing

1. Engage parking brake lever trim - 1 - in its rear mounts - 3 -.
2. Press parking brake lever trim - 1 - firmly, until fastener - 2 - engages in retainer tabs - 6 -.
3. Install handle on parking brake lever.

2 - Fastener

3 - Mounts for trim

4 - Support bracket

1. Removing

1. Remove parking brake lever trim - 1 -.
2. Apply parking brake firmly.
3. Remove two bolts - 5 - at support bracket - 4 - and remove support bracket.

1. Installing

1. Apply parking brake firmly.
2. Place support bracket to parking brake lever.
3. Tighten bolts - 5 - by hand.
4. Release parking brake.

1. Tighten two bolts - 5 -.
2. Install parking brake lever trim - 1 -.

5 - Bolts (2x)

1. Tightening torque 4 Nm

6 - Retainer tabs

Scheme 23

1. Use a screwdriver to pry out locking pin - 2 - in direction of arrow - A -.
2. Detach parking brake lever handle - 1 - in direction of arrow - B -.

1. Installing

1. Installation is in reverse order of removal.

Scheme 24

1 - Threaded moulding

1. Engaged in center console from rear

2 - Center console

1. With mounting holes for base plate
2. Retrofitting mounting holes --> «Making mounting holes for mobile phone holder on center console»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__making-mounting-holes-for-mobile-phone)

3 - Mounting plate

4 - Base plate

1. For mobile phone handset holder

5 - Bolts (6x)

1. Tightening torque 0.5 Nm

6 - Bolts (2x)

1. Tightening torque 1.5 Nm

7 - Connector

Note. Ensure correct seating of connector.

Making mounting holes for mobile phone holder on center console

When supplied as a spare part, center console has no openings or mounting holes for mobile phone holder. Openings must be created.

1. Remove center console --> «Center console, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .

Scheme 25

1. Produce mounting holes of the following dimensions

a - 10 mm

b - 6 mm

c - 20 mm

d - 100 mm

e - 31 mm

f - 8 mm

g - 5 mm

h - 9 mm

1. Engage threaded molding in center console from rear and fasten the mobile phone holder with a torque of 1.5 Nm

Note. After installation check that glove compartment lid will open.

Scheme 26

1 - Threaded molding

1. Engaged in center console from rear

2 - Center console

1. With mounting holes for base plate
2. Retrofitting mounting holes --> «Mounting holes for telephone handset bracket in center console, fabricating»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__mounting-holes-for-telephone-handset-bracket)

3 - Mounting plate

1. For handset holder

4 - Bolts (4x)

1. Tightening torque 0.5 Nm

5 - Receiver holder

6 - Telephone handset R37

7 - Base plate

8 - Bolt

1. Tightening torque 1.5 Nm

9 - Connector

Note. Ensure correct seating of connector.

10 - Bolt

1. Tightening torque 1.5 Nm

Mounting holes for telephone handset bracket in center console, fabricating

When supplied as a spare part, center console has no mounting holes for telephone handset bracket. Mounting holes must be created.

1. Remove center console --> «Center console, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .

1. Fabricate mounting holes of the following dimensions

a - 10 mm

b - 6 mm

c - 22 mm

d - 101 mm

e - 25 mm

f - 16 mm

g - 5 mm

h - 8 mm

1. Engage threaded molding in center console from rear and fasten bracket with a torque of 1.5 Nm.

Note. After installation check that glove compartment lid will open.

Version for "Chorus" or "Concert" radio

Version of instrument panel center section for "symphony" radio/on-screen navigation system

Scheme 27

1 - Center section of instrument panel

1. Removing

1. Remove center console --> «Center console, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
2. Remove bolts - 2 - on instrument panel center section.
3. Remove bolts - 3 - on instrument panel center section.
4. Remove center section of the instrument panel.

2 - Bolts (2x)

1. Tightening torque 5 Nm

3 - Bolts (2x)

1. Tightening torque 3.5 Nm

4 - Center section securing bracket

5 - Light strip

Scheme 28

1 - Center section of instrument panel

1. Removing

1. Remove center console --> «Center console, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
2. Remove bolts - 3 - on instrument panel center section.
3. Remove bolts - 4 - on instrument panel center section.
4. Detach center section from instrument panel.

2 - Bolts (4x)

1. Tightening torque 3.5 Nm

3 - Bolts (2x)

1. Tightening torque 5 Nm

4 - Bolts (2x)

1. Tightening torque 3.5 Nm

5 - Center section securing bracket

6 - Bracket

1. Removing

1. Remove center console --> «Center console, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
2. Remove instrument panel center section - 1 -.
3. Remove bolts on instrument panel center section - 2 - (4x) and remove console.

Scheme 29

1 - Storage compartment

1. Removing and installing «Removing and installing storage tray»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet)

2 - Cup holder

1. Removing and installing «Removing and installing cup holder»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet)

3 - Switch mounting

1. Removing and installing «Removing and installing switch mount»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet)

4 - Hazard warning switch mounting

1. Removing and installing hazard warning switch: --> «96 LIGHTS, SWITCHES - INTERIOR, ANTI-THEFT»(/audi/s4/b7-2004-2008/remont/cruise-control-systems/#electrical-equipment) 96 LIGHTS, SWITCHES - INTERIOR, ANTI-THEFT for ELECTRICAL EQUIPMENT, CABRIOLET

Scheme 30

Removing

1. Insert two thing wedge like tools - 1 - or scrapers between the instrument panel and storage tray - 2 - in the position of the retaining tabs. See - arrows - in (Scheme 31).

Scheme 31

1. Depress retaining tabs with thin wedge type tool and remove storage tray - 2

Installing

1. Installation is in reverse order of removal.

Scheme 32

1. Removing

1. Remove tray «Removing and installing storage tray»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
2. Using a screwdriver, push the retainer tabs - arrows - down while pulling the cup holder out.

Installing

1. Installation is in reverse order of removal.

Scheme 33

1. Removing

1. Remove tray «Removing and installing storage tray»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
2. Remove switch in switch panel.
3. Using a screwdriver, push the retainer tabs - arrows - down while pulling the switch mount out.

Installing

1. Installation is in reverse order of removal.

Radio cover and trim, assembly overview

Note. Radio cover and trim are only installed in instrument panel center section for "Chorus" and "Concert" radios.

Scheme 34

1 - Radio trim

1. Removing

1. Carefully unclip radio cover - 3 - or
2. Remove radio. --> «91 - COMMUNICATION»(/audi/s4/b7-2004-2008/remont/accessories-control-systems/#communication) «91 RADIO, TELEPHONE, NAVIGATION, TRIP COMPUTER»(/audi/s4/b7-2004-2008/remont/accessories-control-systems/#communication-cabriolet) for COMMUNICATION, CABRIOLET
3. Remove bolts - 2 -.
4. Pull radio trim - 1 - out of instrument panel center section.

2 - Bolts (2x)

1. Tightening torque 1.7 Nm

3 - Radio/radio cover

4 - Tray trim

1. Removing

1. Carefully unclip tray trim.

Scheme 35

1 - Tray trim

1. Only on instrument panel center section for "Chorus" and "Concert" radios

2 - Ashtray trim

3 - Front ashtray

1. Removing

1. Manual transmission: Pry gear cover upward and remove --> «Gear cover and boot, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
2. Automatic transmission: Pry gear cover off upward --> «Gear cover and boot, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
3. For vehicles with air conditioner and "Symphony" radio/on-screen navigation system: Remove A/C Control Head E87 for air conditioner. --> «87 AIR CONDITIONING»(/audi/s4/b7-2004-2008/remont/ac-compressor/#heating-air-conditioning)
4. Remove two bolts - 4 - from ashtray.

1. Unclip tray trim - 1 -.
2. Remove ashtray - 3 -.
3. Disengage trim - 2 - from ashtray - 3 -.

4 - Bolts (2x)

1. Tightening torque 3.5 Nm

Interior mirror with fixed base, removing and installing

1. Removing

Scheme 36

1. When removing, turn mirror - 1 - at an angle 60... 90° - arrows B - until locking spring disengages and detach mirror - arrow A -.

1. Installing

Scheme 37

1. When installing, install mirror - 1 - at an angle of 60... 90° at angle to attachment position - arrow A - and twist - arrows B - until locking spring engages.

Interior mirror (automatic anti-glare mirror, interior mirror with compass), removing and installing

1. Removing

Scheme 38

1. Unclip cable duct cover - 3 -.
2. Remove connector from fastener and disconnect.

Note. Never grasp hold of cable duct - 2 - for twisting mirror. When removing, turn mirror - 1 - at an angle of 60... 90° - arrows B - until locking spring disengages and detach mirror - arrow A -.

1. Installing

Note. Never grasp hold of cable duct - 2 - for twisting mirror. When installing, install mirror - 1 - at an angle of 60... 90° at angle to attachment position - arrow A - and twist - arrows B - until locking spring engages.

Function of automatic anti-glare interior rear-view mirror, testing

Note. Interior mirror installed Ignition on Reverse gear not engaged

Test sequence

1. Cover (or mask) front of photosensor.
2. Shine a light onto back of photo sensor.

1. The interior mirror should darken quickly.

Scheme 39

The interior mirror is permanently adjusted to world-zone-dependent North via an integrated magnetic field.

The digital display indicates the cardinal points N, NE, E, SE, S, SW, W and NW.

Calibration is required for new interior mirrors or for mirrors which have been disconnected from the power supply for some time (no display or display indicates "C").

Calibrating new compass

1. Switch ignition on.
2. "C" must be display.
3. If no "C" is displayed, then press adjustment switch on underside of mirror using a thin object (e.g. ballpoint pen) until "C" is displayed.

1. Drive slowly 2 or 3 times in circles at approx. 10 km/h, until a cardinal point is displayed.
2. Keep pressing adjustment switch on underside of mirror using a thin object (e.g. ballpoint pen) until the number of your zone is displayed.
3. Refer to adjacent map for relevant zone.
4. After a few seconds a cardinal point is displayed.

Calibrating existing compass

1. Switch on ignition.
2. "C" must appear on display.
3. If "C" does not appear, press a thin object (e.g. ballpoint pen) against the adjuster switch on the underside of the mirror until "C" is displayed.
4. Drive slowly 2 or 3 times in circles at approx. 10 km/h, until a cardinal point is displayed.

Zone adjustment

1. Switch ignition on.
2. Keep pressing adjustment switch on underside of mirror using a thin object (e.g. ballpoint pen) until the number of your zone is displayed.
3. Refer to adjacent map for relevant zone.
4. After a few seconds a cardinal point is displayed.

Repair method using glass-metal-adhesive

Special tools and workshop equipment required

Scheme 40

1. Glass-Metal-Adhesive-Set D 000 703 A1

1 - Glass scraper (commercially available)

2 - Razor blade (commercially available)

Scheme 41

1. Dimension for interior rear-view mirror a = 153 mm (top edge of trim strip to center of bonding surface of mirror base).

Procedure

1. Take mirror plate out of mirror base.
2. Use wire brush to remove PUR adhesive from mirror plate.
3. Grind off three spacers on bonding surface. Use sandpaper (360/400 grain) on flat surface.
4. Keep sanded surface clean and free from dirt and grease.

1. Use glass scraper to remove PUR adhesive and primer from windscreen down to ceramic layer.

1. Clean bonding area with adhesive remover D 002 000 10 or cleaning solution D 009 401 04.
2. Cut nylon mesh fabric exactly to the size of the mirror base.

Note. Wear hand protection (rubber glove).

1. Apply adhesive evenly and smoothly to base of mirror.
2. Install nylon mesh fabric onto base of mirror.
3. Apply further adhesive to nylon mesh fabric by dabbing with the tube.

30 seconds are available for applying the adhesive to the nylon mesh fabric before pressing it onto the windshield.

1. Press base of mirror firmly (do not use force) against windshield for 15 seconds.
2. Remove excess adhesive with a cloth.

Note. Interior rear view mirror can be reinstalled after 15 minutes.

Seat belts

Safety rules for handling pyrotechnic belt tensioners

1. Testing, removing, installing and repair work may ONLY be performed by qualified personnel.
2. When connecting the belt tensioner unit, all mechanical parts (including those of the three-point seat belt) must be properly attached.
3. Only the person carrying out repairs to belt tensioner is allowed to be in vehicle.
4. Belt tensioner components may neither be opened nor repaired; always use new parts.

1. Belt tensioner units which have been dropped from a height of more than 50 cm must not be installed in a vehicle.
2. Belt tensioner units which are mechanically damaged (dents, fractures) must be replaced.
3. The belt tensioner unit must be installed IMMEDIATELY after removal from transport container.
4. If the work is interrupted, the belt tensioner unit should again be placed in its transport container.

1. Never point open end of belt tensioner at another person.
2. Always wash hands after handling belt tensioners which have been activated.
3. Storage and transportation are subject to the legislation for explosive substances.
4. It is not permitted to leave the belt tensioner unit unattended.

1. The belt tensioner unit must not be treated with grease, cleaning or similar agents, nor may it be exposed to temperatures above 100° C, even for short periods.

Disposal of pyrotechnic belt tensioners

1. Make sure that your dealership complies with federal, state and local regulations for explosive substances.
2. Deployed airbags and pyrotechnic seatbelts can be disposed of as normal scrap.
3. Undeployed airbags and pyrotechnic seatbelts are considered to be hazardous materials.
4. When disposing of an undeployed airbag or pyrotechnic seatbelt that is either defective or expired, use the appropriate repair information and Airbag Deployment Device J-44210.

1. Do NOT deploy airbags and pyrotechnic seatbelts in the vehicle
2. All airbags and pyrotechnic seatbelts of a vehicle scheduled to be scrapped must be deployed using the Airbag Deployment Device J-44210.
3. When using Airbag Deployment Device J-44210, wear appropriate eye and ear protection.
4. If the airbag or pyrotechnic seatbelt cannot be safely deployed or removed from the vehicle, contact the Audi Dealer Technicians Helpline.

1. Shipment of active airbag gas generators and pyrotechnic seatbelt retractors must be in accordance with the regulations published in the latest edition of the Code of Federal Regulations #49 (49 CFR). Shipment must be initiated and received by certified individuals. The penalties for noncompliance are severe. Civil penalties range the $250 to $27,500 per violation, per day. Criminal penalties, for willfully violating the regulations, range up to $250,000 for individuals and $500,000 for corporations.
2. Undeployed pyrotechnic components (such as airbags, seat belts, pyrotechnic battery components) must be disposed of in an orderly manner in their original packaging, according to national legislation. If questions arise, contact Audi of America!
3. Pyrotechnic components deployed in an actual accident can be disposed of as industrial waste

Front pyrotechnic belt tensioners, triggering

Note. Observe safety regulations for handling pyrotechnic belt tensioners --> Disposal of pyrotechnic belt tensioners . Belts can be disposed of with commercial refuse after removal. Always wash hands after handling ignited belt tensioners.

1. Remove rear bench seat --> «Rear seat bench, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
2. Remove rear seat backrest --> «Rear seat backrest, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
3. Remove side trim --> «Rear side trim, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
4. Remove floor panel anchorage point --> «Front anchorage point for outer floor panel»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__front-anchorage-point-for-outer-floor) .

1. Cut off belt above latch plate approx. 20 cm below belt reel.
2. Disconnect connector from belt reel and connect wiring harness (part no. 8D1 971 259).
3. Cut connector off at other end and insulate both cable ends.
4. Slit cable sheath until ends of cables are at least 30 cm apart.

1. Make sure there is no-one in the vehicle.
2. Close doors and open windows.
3. Trigger gas generator using wiring harness and external battery, which is positioned outside of vehicle.
4. Ventilate vehicle adequately.

Rear pyrotechnic belt tensioners, triggering

Note. Observe safety rules for handling pyrotechnic belt tensioners --> Disposal of pyrotechnic belt tensioners . Belts can be disposed of with commercial refuse after removal. Always wash hands after handling belt tensioners which have been activated.

1. Remove rear bench seat --> «Rear seat bench, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
2. Remove rear seat backrest --> «Rear seat backrest, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
3. Except USA: Cut off belt above latch plate approx. 20 cm below belt reel.
4. In USA: Pull belt out completely and prevent belt rolling up with a knot which is as close as possible to the belt reel (because of the belt-fastened sensor).

1. Disconnect connector from belt reel and connect wiring harness (part no. 8D1 971 259).
2. Cut connector off at other end and insulate both cable ends.
3. Slit cable sheath until ends of cables are at least 30 cm apart.
4. Make sure there is no-one in the vehicle.

1. Close doors and open windows.
2. Trigger gas generator using wiring harness and external battery, which is positioned outside of vehicle.
3. Ventilate vehicle adequately.

Scheme 42

1 - Three-point seat belt with belt tensioner, front left and right

1. Refer to --> «Front 3-point seat belt with belt tensioner, assembly overivew»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet)

2 - Three-point seat belt with belt tensioner, rear left and right

1. Refer to --> «Rear 3-point seat belt with belt tensioner, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet)

3 - Rear anchorage point for center floor panel

1. Refer to --> «Anchorage points for center floor panel, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet)

4 - Front anchorage point for outer floor panel

1. Refer to --> «Front anchorage point for outer floor panel»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__front-anchorage-point-for-outer-floor)

5 - Front anchorage point for belt buckle

1. Refer to --> «Front anchorage point for belt buckle»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__front-anchorage-point-for-belt-buckle)

Scheme 43

1 - Belt guide

2 - Belt

3 - Latch plate

4 - Belt reel/belt tensioner

1. Removing

1. Disconnect battery.
2. Remove rear bench seat --> «Rear seat bench, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
3. Remove rear seat backrest --> «Rear seat backrest, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
4. Remove side trim --> «Rear side trim, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .

1. Remove bolt - 5 -.
2. Disconnect belt tensioner connector «Disconnecting connector for front seat belt tensioner»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
3. Remove anchorage point for outer floor panel - 6 - --> «Front anchorage point for outer floor panel»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__front-anchorage-point-for-outer-floor) .
4. Unclip belt guide - 1 -.

1. Pull belt - 2 - out of guide - 1 -.
2. Remove belt reel - 4 -.

1. Installing

1. Install front seat belt in reverse order of removal.

5 - Bolt

1. Tightening torque 55 Nm

6 - Anchorage point: Outer floor panel

Scheme 44

1. Detach catch - 4 -.
2. Disconnect connector - 3 -.

Scheme 45

1 - Belt

2 - Belt guide

3 - Connecting bar

4 - Idler roller

5 - Locating projection

6 - Anchorage point: Outer floor panel

7 - Bolt

1. Tightening torque 55 Nm

8 - Bolt

1. Tightening torque 55 Nm

9 - Belt reel/belt tensioner

1. Removing

1. Disconnect battery.
2. Remove rear bench seat --> «Rear seat bench, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
3. Remove rear seat backrest --> «Rear seat backrest, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
4. Open convertible top compartment.

1. Remove bolt - 8 -.
2. Disconnect belt tensioner connector «Disconnect connector for rear seat belt tensioner»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
3. Remove belt reel - 9 -.
4. Remove bolt - 7 -.

1. Unclip front belt guide - 2 - and detach - 2 -.
2. Open connecting bar - 3 - on belt guide - 2 -.
3. Pull belt - 1 - out of belt guide - 2 - and Idler roller - 4 -.

1. Installing

1. Plug in connector to belt tensioner «Disconnect connector for rear seat belt tensioner»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
2. Screw belt reel - 9 - with bolt - 8 -.
3. Feed belt - 1 - into idler roller - 4 -.
4. Feed belt - 1 - into belt guide - 2 - with connecting bar - 3 - open.

1. Close connecting bar - 3 -.
2. Attach belt guide - 2 - at rear and press on belt guide - 2 - at front.
3. Make sure belt guide - 2 - is engaged at front in side trim.
4. Make sure outer floor panel anchorage point - 6 - is engaged in locating projection - 5 -.

1. Screw outer floor panel anchorage point - 6 - with bolt - 7 -.
2. Install rear seat belt in reverse order of removal.

10 - Latch plate

Scheme 46

1. Disconnect connector - 3 -.

Scheme 47

1 - Belt buckle

1. Removing

1. Remove rear bench seat --> «Rear seat bench, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
2. Remove nut - 4 -.
3. Remove belt buckle - 1 -.

1. Installing

1. Make sure that mounting - 2 - engages in locating projection - 3 -.
2. Continue installing belt buckle - 1 - in reverse order of removal.

2 - Mounting

3 - Locating projection

4 - Nut

1. Tightening torque 55 Nm

Front anchorage point for outer floor panel

1. Removing

Scheme 48

1. Detach trim cap - 3 -.
2. Remove bolt - 2 -.

1. Tightening torque 55 Nm

1. Remove washer - 4 -.
2. Swing clip - 5 - upward.
3. Remove belt - 1 - from clip - 5 -.

1. Installing

1. Install washer - 6 - under clip - 5 -.
2. Continue installing anchorage point for outer floor panel in reverse order of removal.

Front anchorage point for belt buckle

1. Remove seat --> «Seat, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__seat-assembly-overview) .

Scheme 49

1. Remove bolt - 2 - from buckle - 1 -.

1. Tightening torque 24 Nm
2. For vehicles with "belt fastened" detector and belt buckle switch (only on drivers side, country-specific) remove wires from red connector housing.

Scheme 50

1. Use a screwdriver to pry out retaining hooks - 4 - of red connector housing - 1 -.
2. Push red connector housing - 1 - through toward the rear.
3. Wire pin - 6 - (2x) for "belt fastened" detector.

Scheme 51

1. Red connector housing - 1 - for belt buckle interrogation and main power supply.
2. Release cable retainer - 2 - in direction of arrow by prying out at cut-out - 3 -.

1. Illustration shows cable retainer - 2 - in released position.

1. Remove wires - 4 - for "belt fastened" detector from terminals 5 and 6; on drivers side (country-specific) also remove wires - 4 - for belt buckle switch from terminals 1 and 2.
2. Open cable ties.

1. Installing

1. Installation is in reverse order of removal.

Removing and installing ISOFIX holder (front)

Special tools, testers and auxiliary items required

Scheme 52

1. Torque wrench V.A.G 1410

1. Remove front passengers seat --> «Seat, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__seat-assembly-overview) (manual adjustment) or --> «Front seat, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__front-seat-assembly-overview) (electrical adjustment).

Scheme 53

1. Remove upholstery from front passengers seat --> «Seat pan cover and padding (standard seat), removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) (manual adjustment) or --> «Cover and padding for seat pan (standard seat), assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) (electrical adjustment).
2. Remove bolts - 3 - (2x). Tightening torque 7 Nm
3. Remove ISOFIX holder - 2 -.

1 - Frame, front seat

Seat belts, checking

Check points

1. Check belt strap.
2. Check belt retractor (locking action).
3. Visual inspection of belt buckle
4. Functional test of belt buckle

1. Check belt guides and latch plate
2. Check securing parts and anchorage points

Note. If customer refuses to have a damaged seat belt replaced, appropriate note should be made.

Checking belt

1. Pull belt as far as it will go out of belt retractor or lap belt adjuster.
2. Check belt for dirt and wash if necessary with a mild soap solution --> Refer also to Owners Manual.

1. If either of the following types of damage (1 and 2) illustrated below is found on a vehicle following an accident, replace seat belt complete with buckle.

Scheme 54

1. If damage such as illustrated by items 1, 2 or 3 is found on a vehicle which has not been involved in an accident, only the damaged seat belt has to be replaced.

Scheme 55

1. 1 Belt cut, torn or chafed

Scheme 56

1. 2 Frayed fabric at edge of belt
2. 3 Burn marks caused by cigarettes or the like

Belt retractor (locking action), checking

The belt retractor has two locking functions.

1. The first locking function is triggered by pulling belt quickly out of belt retractor (accelerated belt unwinding).

Checking

1. Pull belt firmly out of belt retractor.

1. If there is no locking effect, replace seat belt complete with buckle.
2. In the event of problems with belt unwinding or retraction, start by checking whether position of belt retractor has changed.
3. The second locking function is triggered by altering vehicle motion (vehicle-dependent locking function).

Checking

1. Fasten seat belt.
2. Accelerate vehicle to 20 km/h and then press foot brake to implement emergency braking.

1. If braking does not cause belt to lock by locking mechanism, replace seat belt complete with buckle.

Visual inspection of buckle

1. Examine buckle for cracks and chipping.

1. If damage, replace seat belt complete with buckle.

Checking operation of buckle

Checking buckle

1. Insert latch plate in buckle until it is audibly engage. Pull firmly on belt to check whether locking mechanism has engaged.

1. If latch plate fails to lock even once in the course of at least 5 test operations, replace seat belt complete with buckle.

Checking release function

1. Release seat belt by pressing buckle button with finger.
2. Latch plate must be automatically ejected from buckle when webbing is loose.

1. Check at least 5 times. If latch plate fails to be ejected even once, replace seat belt complete with buckle.

Checking guide fittings and latch plate

If belt system has been subjected to load (seat belt fastened in an accident), plastic-coated fittings will reveal fine parallel score marks (in contrast, wear induced by frequent use can be seen from a smooth surface with no score marks).

1. Examine plastic for deformation, chipping and cracks.

1. In the event of score marks and/or damage, replace seat belt complete with buckle.

Checking attachment components and anchorage points

1. Latch plate deformed (elongated)
2. Height adjuster not working
3. Anchorage points (seat, pillar, floor) deformed or thread damaged
4. If component is damage, replace seat belt complete with buckle.

1. Replace anchorage points.

Note. Only the damaged component has to be replaced in the event of damage not resulting from an accident (e.g. wear).

Child-seat restraint function for additional child seats (not for drivers seat belt), checking

1. The complete belt assembly (including side panel trim) must be installed when checking this function.
2. Activation of restraint function
3. Pull out webbing as far as possible.
4. Correct function

1. The belt should retract with an audible noise.
2. If the belt retraction is stopped, it should not be possible to pull the belt out again until the function is deactivated.
3. Deactivation
4. Allow the belt to retract as far as the last 100 mm (approx.).

1. Restraint function must be deactivated at the latest when the last 100 mm are reached. The belt then re-assumes its normal function.

Belt-fastened sensor for rear 3-point belts with belt tensioner, checking

1. Switch ignition on.
2. Connect vehicle diagnostic, testing and information system VAS 5051 A or vehicle diagnostic and service information system VAS 5052 and select vehicle system "15 - Airbag" on.
3. Read measured value block, display group 004.

Scheme 57

Belt fully retracted, display on vehicle diagnostic, testing and information system VAS 5051 A or vehicle diagnostic and service information system VAS 5052 : - no

Latch plate engaged in belt buckle and belt pulled out by dimension - L -, display on vehicle diagnostic, testing and information system VAS 5051 A or vehicle diagnostic and service information system VAS 5052 : - yes

1. Pull out belt as far as possible. For this purpose, display on vehicle diagnostic, testing and information system VAS 5051 A or vehicle diagnostic and service information system VAS 5052 must remain - yes -.
2. Retract belt as far as dimension - L - without releasing latch plate, display on vehicle diagnostic, testing and information system VAS 5051 A or vehicle diagnostic and service information system VAS 5052 must remain - yes -.
3. Release latch plate and slowly retract belt; at the latest when the belt has retracted as far as the last 100 mm, display must switch from -yes- to -no-.

Belt fully retracted, display on vehicle diagnostic, testing and information system VAS 5051 A or vehicle diagnostic and service information system VAS 5052 : - no

1. Dimension - L - is 300 mm for left and right belt.

Safety precautions when working on airbag

Always observe the following sequence when replacing an airbag unit

1 - Remove old airbag unit and place down with padding facing upward; with head airbag observe procedure for head airbag --> Additional safety precautions for head airbag .

2 - Take new airbag unit from transport container and store with padding facing upward; with head airbag observe procedure for head airbag --> Additional safety precautions for head airbag .

3 - Immediately place old airbag unit in transport container.

4 - Install new airbag unit into vehicle.

Additional safety precautions for side airbag

Note. Seat-occupied sensor mat is not installed in drivers seat. In vehicles with no seat heating, the seats are installed with dummy seat heating elements (heating element with no wire). The foam upholstery in the backrest must not be cut away in the vicinity of the side airbag. When installing, ensure seam for side airbag is straight. When installing, fit all upholstery staples in same positions as on removal. Use only genuine upholstery staples. When installing, all upholstery staples must be installed in the same positions as the original ones. If the seat cover fabric is damaged (tears, burn marks, etc.) in the vicinity of the side airbag, the cover must be replaced for safety reasons, as otherwise the side airbag will not inflate properly. No repairs may be performed on the backrest cover fabric near the side airbag (original fabric has special thread and exactly defined seams). Always replace backrest padding after side airbag has been triggered. All damaged components must be replaced after an accident. The original airbag unit can still be used if no signs of damage are found. The airbag units have an expiration date. If airbag units are replaced, the replacement must be entered in the service record. Airbag units must be replaced on expiration of 14 years. If side airbag units are replaced, remove airbag number sticker from the new unit and stick it over the old one on the seat pan. Never use upholstery needles or poke any other sharp objects through the seat cover fabric in the vicinity of the airbag and sensor mat.

Additional safety precautions for head airbag

1. The head airbags are subject to the same safety precautions as the drivers and front passengers airbags.
2. Before installing a visual check for damage on the trims must be carried out.
3. Trim repairs (upper A-pillar, upper B-pillar, upper C-pillar and D-pillar trim) are not permitted.
4. When installing, ensure that trims are installed securely.

1. The head airbag module may only be bent at the intended location (roof to A-pillar transition).
2. When carrying out repairs behind the head airbag always remove complete module.
3. Store removed head airbag module in transport container or on a clean, level surface (place on blanket or in luggage compartment).
4. After body repairs in the vicinity of the head airbag the body must be checked for welding splashes, deformation or abrasion (compare to opposite side).

1. Always hold head airbag module securely.
2. Always fold removed head airbag modules and grasp at gas generator (thumb in direction of E-connection).
3. Always keep one hand on the gas generator.
4. Do not twist, turn, knot, throw, pull, hang, pinch, press or clamp head airbag module.

1. Contamination such as oil, grease, paint and solvents is absorbed into fabric always replace module.

Additional safety precautions for roll-over protection

1. Testing, removing, installing and repair work may only be performed by qualified personnel.
2. Always disconnect power supply when working on the rollover protection.
3. The rollover protection must only be removed and installed when extended. The rollover protection can be extended using the vehicle diagnostic, testing and information system VAS 5051 A. Refer to guided fault-finding, body, general body repairs, 01 systems with self-diagnosis capability, Airbag 8.4E, Functions-Airbag 8.4E J234-Airbag Control Module, output DTM.
4. After pushing in, the rollover protection must have approx. 1-2 mm downward play.

1. There must be no one in the vicinity of the rollover protection when battery is being connected (approx. 1 m distance).
2. The rollover protection should be installed immediately after removing from its transport container.
3. Leaving the rollover protection unattended is not permitted.
4. The rollover protection must be stored horizontally when not installed.

1. The rollover protection must be neither dismantled nor repaired. Always use new components only.
2. Rollover protection which is dropped on a hard surface or is damaged (particularly at the solenoid switch) must not be installed.
3. All damaged components must be replaced after an accident. The rollover protection can be reused if no signs of damage to rollover protection are found. Perform a functional test on rollover protection, using vehicle diagnostic, testing and information system VAS 5051 A. Refer to guided fault-finding, body, general body repairs, 01 systems with self-diagnosis capability, Airbag 8.4E, Functions-Airbag 8.4E J234-Airbag Control Module, output DTM.
4. During control element test the flap for rollover protection must be clipped in and no items must be positioned on the flap.

1. No repair work must be carried out on convertible top compartment lid in area of cover and on flap for rollover protection.
2. Install necessary shims when installing.
3. During body repairs in area of rollover protection, always remove rollover protection.
4. After body repairs in the vicinity of rollover protection the body must be checked for welding splashes, deformation or abrasion (compare to opposite side).

Airbag units after an accident, replacing

Note. The control unit for the airbag can be used for up to three side/head airbag and/or belt tensioner deployments. The malfunction display "Control module defective" will appear after third deployment.

Airbag control module must be replaced

1. If driver/passenger airbag is deployed.
2. After three side and/or head airbag deployments
3. If housing is damaged
4. In the event of tunnel deformation within 200 mm radius of control unit

Always replace the following

1. All triggered airbag units

Additionally, if front passengers airbag has been triggered

1. Instrument panel
2. Supports for passengers airbag module which have been bent out of shape (must not be bent back into shape).
3. Both front airbag sensors on front end
4. Lateral acceleration sensor if floor pan around sensor has been deformed

Additionally, if drivers airbag has been triggered

1. Self-cancelling ring with slip ring.
2. Both front airbag sensors on front end
3. Lateral acceleration sensor if floor pan around sensor has been deformed

Additionally, if side airbag has been triggered

1. Lateral acceleration sensor on side where airbag has been triggered.
2. With folding backrests: Side padding.
3. Non-triggered lateral acceleration sensor if floor pan around sensor has been deformed.

Additionally, if head airbag has been triggered

1. Lateral acceleration sensor on side where airbag has been triggered.
2. A, B, C and D-pillar trim
3. Non-triggered lateral acceleration sensor if floor pan around sensor has been deformed

Additionally

1. All seat belts with triggered belt tensioners

A - Airbag control module triggered

1. Connect vehicle diagnostic, testing and information system VAS 5051 A and select vehicle system "15 - Airbag". For this purpose, the ignition must be switched on.

Front belt tensioner

1. Read measured value block, display group 001.

A triggered belt tensioner is indicated by the display "too great".

Rear belt tensioner (USA)

1. Read measured value block, display group 002.

A triggered belt tensioner is indicated by the display "too great".

B - Airbag control module replaced

1. Connect vehicle diagnostic, testing and information system VAS 5051 A and select vehicle system "15 - Airbag". For this purpose, the ignition must be switched on.
2. Interrogate DTC memory.

Scheme 58

A triggered belt tensioner is identified by the fault message "Belt tensioner igniter - Resistance value too great".

1. In addition, the following must also be replaced, if necessary (visual check): all faulty components

Accident not involving activation of airbag

1. If the Airbag Malfunction Indicator Lamp (MIL) K75 does not indicate a malfunction, it is not necessary to replace the airbag components. The seat belts should be checked separately.

After replacing the airbag units or the control module, affix stickers (only tear-off strips) to the registration card and return the registration card to the relevant Sales Department or to the Importer for registration. .

Storage and transportation of airbag units

1. The airbag unit is a class PT 1 pyrotechnic device. Storage and transport are subject to safety legislation relating to hazardous materials (explosives).

In Germany: Small quantities of materials and articles may be kept in lockable rooms without special storage permission. Dispatch and transportation is only permitted in officially approved transport containers.

1. Airbag units are not to be stored for more than 3 months.

Disposal of airbag units

1. In Germany airbag units must be rendered unusable prior to scrapping by means of electrical ignition, in accordance with accident prevention regulations, as pyrotechnic devices can cause injury if activated improperly (e.g. with a cutting torch during scrapping).
2. The airbag unit must only be electrically ignited when installed in the vehicle. Proceed as follows

1. Disconnect connector from airbag unit and connect wiring harness, Part No. 8D1 971 259, to airbag unit.
2. Install airbag unit.
3. Cut off connector at other end of wiring harness, Part No. 8D1 971 259, strip the ends of the two wires and slit cable sheath until ends of wires are at least 30 cm apart.

1. Ignite airbag with doors closed and windows open using wiring harness and external battery (outside vehicle).

1. Ensure adequate vehicle ventilation after triggering.
2. Airbags can be disposed of with commercial refuse after removal.
3. Always wash hands after touching airbags which have been ignited.
4. Observe safety rules for handling airbags --> «Safety precautions when working on airbag»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__safety-precautions-when-working-on-airbag) .

Scheme 59

1 - Drivers airbag unit

1. Removing and installing --> «Airbag unit (standard steering wheel), assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__airbag-unit-standard-steering-wheel-assembly)

2 - Drivers airbag unit (sports steering wheel)

1. Removing and installing --> «Steering wheel (sports steering wheel), assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__steering-wheel-sports-steering-wheel-assembly)

3 - Airbag Control Module J234

1. Removing and installing --> «Airbag Control Module -J234-, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__airbag-control-module-j234-assembly-overview)

4 - Key switch for switching off passenger side airbag E224

1. Not applicable for this market

5 - Passengers airbag unit

1. Removing and installing --> «Front passenger airbag, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__front-passenger-airbag-assembly-overview)

6 - Warning light for airbag off, passenger side K145 "PASSENGER AIRBAG OFF"

1. Not applicable for this market

7 - Head airbag (Sedan)

8 - Head airbag (Avant)

9 - Front side airbag

1. Removing and installing --> «Side airbag (electric seat), assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__side-airbag-electric-seat-assembly-overview)

10 - Lateral acceleration sensor on B-pillar

1. Removing and installing --> «Front side airbag crash sensor, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__front-side-airbag-crash-sensor-removing)

11 - Lateral acceleration sensor on C-pillar

12 - Rear side airbag (folding backrest)

13 - Rear side airbag (fixed backrest)

14 - Diagnostic connector

15 - Lateral acceleration sensor on front end

1. Removing and installing --> «Front airbag crash sensor, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__front-airbag-crash-sensor-removing-and)

Airbag Control Module -J234-, assembly overview

Scheme 60

1 - Airbag Control Module J234

1. Removing

1. Disconnect battery Ground (GND) strap.
2. Remove center console --> «Center console, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
3. Release catch - 4 - at connector - 3 -.
4. Pull connector - 3 - out of control unit - 1 -.

1. Remove bolts - 2 - (3x).
2. Detach control unit.

2 - Bolts (3x)

1. Tightening torque 7 Nm

3 - Connector

4 - Securing clip

Note. After connecting the battery observe the necessary measures. --> 27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL 27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL for ELECTRICAL EQUIPMENT, CABRIOLET If Airbag Malfunction Indicator Lamp (MIL) K75 signals a malfunction after assembly, use vehicle diagnostic, testing and information system VAS 5051 A to interrogate, erase and then again interrogate DTC memory. The control module must be recoded after replacement.

Refer to guided fault-finding, body, general body repairs, 01 systems with self-diagnosis capability, Airbag 8.4E, Functions-Airbag 8.4E J234-Airbag Control Module, output DTM.

Airbag unit (standard steering wheel), assembly overview

Scheme 61

1 - Torx bolts T30 (2x)

1. Tightening torque 7 Nm

2 - Steering wheel

3 - Connector for coil r

4 - Connector for airbag unit

5 - Airbag unit

1. Removing

1. Disconnect battery Ground (GND) strap.
2. Release steering column adjuster.
3. Pull steering wheel - 2 - outward and upward as far as possible.
4. Move steering wheel - 2 - to vertical position.

1. Remove Torx bolt T30 - 1 -.
2. Turn steering wheel half a turn back and unscrew second Torx bolt T 30 - 1 -.
3. Disconnect connector for airbag unit - 4 -.
4. Unplug connector for horn - 6 -.

1. Put airbag unit down - 5 - with impact cushion facing upward.

1. Installing

1. Installation is in reverse order of removal.
2. Ensure that connector and catch engage fully (i.e. audibly).
3. Ensure that no cable is on gas generator.
4. Ensure that airbag cable is not trapped. Lay airbag cable in a loop to the left.

1. Lay horn cable in a loop to the outside.
2. Tighten bolts - 1 - (2x) to a torque of 7 Nm.
3. Switch ignition on.

1. Connect battery Ground (GND) strap.

6 - Horn connector

7 - Multi-point socket head bolt

1. Tightening torque 50 Nm

8 - Connector for heated steering wheel

9 - Self-cancelling ring with slip ring

Note. After connecting the battery observe the necessary measures. --> 27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL 27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL for ELECTRICAL EQUIPMENT, CABRIOLET If Airbag Malfunction Indicator Lamp (MIL) K75 signals a malfunction after assembly, use vehicle diagnostic, testing and information system VAS 5051 A to interrogate, erase and then again interrogate DTC memory.

Steering wheel (standard steering wheel), assembly overview

1 - Torx bolts T30 (2x)

1. Tightening torque 7 Nm

2 - Steering wheel

1. Removing

1. Remove airbag unit (standard steering wheel) --> «Airbag unit (standard steering wheel), assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__airbag-unit-standard-steering-wheel-assembly) .
2. Center steering wheel (wheels in straight-ahead position).
3. Remove bolt - 7 -.
4. Disconnect connector for coil - 3 -.

1. Heated steering wheel: Disconnect connector for heated steering wheel - 8 -.
2. Remove steering wheel - 2 -.

1. Installing

1. Installation is in reverse order of removal.
2. Ensure that connector and catch engage fully (i.e. audibly).
3. Attach steering wheel in center position (wheels in straight-ahead position).
4. Replace bolt - 7 - and tighten to 50 Nm.

3 - Connector for coil

4 - Connector for airbag unit

5 - Airbag unit

6 - Horn connector

7 - Multi-point socket head bolt

1. Tightening torque 50 Nm

8 - Connector for heated steering wheel

9 - Self-cancelling ring with slip ring

Airbag unit (sports steering wheel), assembly overview

Scheme 62

1 - Self-cancelling ring with slip ring

2 - Connector for airbag unit

3 - Torx bolts T30 (2x)

1. Tightening torque 7 Nm

4 - Connector for coil

5 - Steering wheel

6 - Multi-point socket head bolt

1. Tightening torque 50 Nm

7 - Airbag unit

1. Removing

1. Disconnect battery Ground (GND) strap.
2. Release steering column adjuster.
3. Pull steering wheel - 5 - outward and upward as far as possible.
4. Move steering wheel - 5 - to vertical position.

1. Remove Torx bolt T30 - 3 -.
2. Turn steering wheel half a turn back and unscrew second Torx bolt T 30 - 3 -.
3. Disconnect connector for airbag unit - 2 -.
4. Put airbag unit down - 7 - with impact cushion facing upward.

1. Installing

1. Installation is in reverse order of removal.
2. Ensure that connector and catch engage fully (i.e. audibly).
3. Ensure that no cable is on gas generator.
4. Ensure that airbag cable is not trapped. Lay airbag cable in a loop to the left.

1. Tighten bolts - 3 - (2x) to a torque of 7 Nm.
2. Switch ignition on.

1. Connect battery Ground (GND) strap.

Note. After connecting the battery observe the necessary measures. --> 27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL 27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL for ELECTRICAL EQUIPMENT, CABRIOLET If Airbag Malfunction Indicator Lamp (MIL) K75 signals a malfunction after assembly, use vehicle diagnostic, testing and information system VAS 5051 A to interrogate, erase and then again interrogate DTC memory.

Steering wheel (sports steering wheel), assembly overview

1 - Self-cancelling ring with slip ring

2 - Connector for airbag unit

3 - Torx bolts T30 (2x)

1. Tightening torque 7 Nm

4 - Connector for coil

5 - Steering wheel

1. Removing

1. Remove airbag unit (sports steering wheel) --> «Airbag unit (sports steering wheel), assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__airbag-unit-sports-steering-wheel-assembly) .
2. Center steering wheel (wheels in straight-ahead position).
3. Remove bolt - 6 -.
4. Disconnect connector for coil - 4 -.

1. Remove steering wheel - 5 -.

1. Installing

1. Installation is in reverse order of removal.
2. Ensure that connector and catch engage fully (i.e. audibly).
3. Attach steering wheel in center position (wheels in straight-ahead position).
4. Replace bolt - 6 - and tighten to 50 Nm.

6 - Multi-point socket head bolt

1. Tightening torque 50 Nm

7 - Airbag unit

Airbag unit (multi-function steering wheel), assembly overview

Scheme 63

1 - Torx bolts T30 (2x)

1. Tightening torque 7 Nm

2 - Steering wheel

3 - Connector for coil

4 - Connector for airbag unit

5 - Airbag unit

1. Removing

1. Disconnect battery Ground (GND) strap.
2. Release steering column adjuster.
3. Pull steering wheel - 2 - outward and upward as far as possible.
4. Move steering wheel - 2 - to vertical position.

1. Remove Torx bolt T30 - 1 -.
2. Turn steering wheel half a turn back and release second Torx bolt T 30 - 1 -.
3. Disconnect connector for airbag unit - 4 -.
4. Put airbag unit down - 5 - with impact cushion facing upward.

1. Installing

1. Installation is in reverse order of removal.
2. Ensure that connector and catch engage fully (i.e. audibly).
3. Ensure that no cable is on gas generator.
4. Ensure that airbag cable is not trapped. Lay airbag cable in a loop to the left.

1. Tighten bolts - 1 - (2x) to a torque of 7 Nm.
2. Switch ignition on.

1. Connect battery Ground (GND) strap.

6 - Multi-point socket head bolt

1. Tightening torque 50 Nm

7 - Supply cable

8 - Clip

9 - Connector for multi-function steering wheel

10 - Connector for heated steering wheel

11 - Self-cancelling ring with slip ring

Note. After connecting the battery observe the necessary measures. --> 27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL 27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL for ELECTRICAL EQUIPMENT, CABRIOLET If Airbag Malfunction Indicator Lamp (MIL) K75 signals a malfunction after assembly, use vehicle diagnostic, testing and information system VAS 5051 A to interrogate, erase and then again interrogate DTC memory.

Steering wheel (multi-function steering wheel), assembly overview

1 - Torx bolts T30 (2x)

1. Tightening torque 7 Nm

2 - Steering wheel

1. Removing

1. Remove airbag unit (multi-function steering wheel) --> Refer to --> «Airbag unit (multi-function steering wheel), assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__airbag-unit-multi-function-steering-wheel-assembly) .
2. Center steering wheel (wheels in straight-ahead position).
3. Remove bolt - 6 -.
4. Disconnect connector for coil - 3 -.

1. Disconnect multi-function cable connector - 9 -.
2. Heated steering wheel: Unplug connector for heated steering wheel - 10 -.
3. Remove steering wheel - 2 -.

1. Installing

1. Installation is in reverse order of removal.
2. Ensure that connector and catch engage fully (i.e. audibly).
3. Insert supply cable - 7 - in clip - 8 -.
4. Attach steering wheel in center position (wheels in straight-ahead position).

1. Replace bolt - 4 - and tighten to 50 Nm.

3 - Connector for coil

4 - Connector for airbag unit

5 - Airbag unit

6 - Multi-point socket head bolt

1. Tightening torque 50 Nm

7 - Supply cable

8 - Clip

9 - Connector for multi-function steering wheel

10 - Connector for heated steering wheel

11 - Self-cancelling ring with slip ring

Self-cancelling ring with slip ring (coil connector/ESP sensor), removing and installing

Special tools, testers and auxiliary items required

1. Screwdriver T8 T40056
2. Removing

1. Remove drivers airbag unit (standard steering wheel) --> «Airbag unit (standard steering wheel), assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__airbag-unit-standard-steering-wheel-assembly) .
2. Remove drivers airbag unit (sports steering wheel) --> «Airbag unit (sports steering wheel), assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__airbag-unit-sports-steering-wheel-assembly) .
3. Remove drivers airbag unit (multi-function steering wheel) --> «Airbag unit (multi-function steering wheel), assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__airbag-unit-multi-function-steering-wheel-assembly) .
4. Remove steering wheel (standard steering wheel) --> «Steering wheel (standard steering wheel), assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__steering-wheel-standard-steering-wheel-assembly) .

1. Remove steering wheel (sports steering wheel) --> «Steering wheel (sports steering wheel), assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__steering-wheel-sports-steering-wheel-assembly) .
2. Remove steering wheel (multi-function steering wheel) --> «Steering wheel (multi-function steering wheel), assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__steering-wheel-multi-function-steering-wheel-assembly) .
3. Pull steering column out and down as far as possible.

Scheme 64

1. Remove Torx bolts with screwdriver T8 T40056 - 3 - and - 5 - as well as hex socket head bolt - 4 -.
2. Tightening torque 1 Nm
3. Separate upper trim - 2 - for steering column switch from lower trim - 1 - and remove both sections.

To install, insert the upper trim into the hooks of the lower trim, press both sections together and screw in place.

Scheme 65

1. Disconnect connector - 1 -.
2. Carefully release locking tabs - arrows - and pull self-cancelling ring with slip ring off steering column switch.

1. Installing

1. Make sure that all 3 locking tabs and connector are correctly engaged.

Note. The steering must be in the center position (wheels in straight-ahead position) when the self-cancelling ring with slip ring are removed and installed. Self-cancelling ring with slip ring is secured as a new part in the center position with a cable tie or tear ring. The ESP sensor must be adjusted in vehicles with ESP sensor in self-cancelling ring with slip ring.

Refer to guided fault-finding, running gear, brake system, 01 systems_with self-diagnosis capability_ Bosch_5_7, anti-locking brake system_ABS_EDL_TCS_ESP, SYS45_ basic setting_ steering angle sensor.

Front passenger airbag, assembly overview

Scheme 66

1 - Passengers airbag unit

1. Removing

1. Disconnect battery Ground (GND) strap.
2. Remove glove compartment --> «Glove compartment, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
3. Disconnect connector behind airbag unit «Disconnecting airbag connector»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .

1. Remove brace - 7 -.
2. Remove supports - 2 - behind airbag unit.
3. Remove nut - 3 - (4x).
4. Remove airbag unit.

1. Put airbag unit down with impact cushion facing upward.

1. Installing

1. Install airbag unit.
2. Ensure connector behind airbag unit engages properly (audibly) «Disconnecting airbag connector»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
3. Switch ignition on.

1. Connect battery Ground (GND) strap.

2 - Support

1. Must be replaced after airbag triggering.
2. Remove front passengers airbag unit.
3. Remove bolts - 4 - (4x).

3 - Nut (4x)

1. Must be replaced after airbag triggering
2. Tightening torque 9 Nm

4 - Bolts (4x)

1. Must be replaced after airbag triggering
2. Tightening torque 9 Nm

5 - Connector

6 - Frame for airbag unit

1. Must be replaced after airbag triggering
2. Remove front passengers airbag unit.

7 - Brace

Scheme 67

Scheme 68

1. Press release - A - and disconnect connector in direction of - arrow -.

1 - Retainer for connector

Note. After connecting the battery observe the necessary measures. --> 27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL 27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL for ELECTRICAL EQUIPMENT, CABRIOLET If Airbag Malfunction Indicator Lamp (MIL) K75 signals a malfunction after assembly, use vehicle diagnostic, testing and information system VAS 5051 A to interrogate, erase and then interrogate again DTC memory.

Tools

Special tools, workshop equipment, testers, measuring instruments and other items required

Scheme 69

Engine and transmission holder VAS 6095

Scheme 70

Fixture for seat repair VAS 6136

Torque wrench V.A.G 1410

Side airbag (sports seat, standard seat), removing and installing

Scheme 71

1 - Side airbag, drivers/front passengers

1. Removing

1. Disconnect battery Ground (GND) strap.
2. Remove seat --> «Seat, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__seat-assembly-overview) .
3. Attach fixture for seat repair VAS 6136 to engine and transmission holder VAS 6095.
4. Attach front seat to fixture for seat repair VAS 6136.

1. Remove backrest adjuster --> «Backrest adjuster, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__backrest-adjuster-removing-and-installing) .
2. Remove seat height adjuster --> «Seat height adjuster, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
3. Remove side trim on sill panel side --> «Side trim on sill panel side, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__side-trim-on-sill-panel-side) .
4. Remove side trim on tunnel side --> «Side trim on tunnel side, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__side-trim-on-tunnel-side-removing) .

1. Remove backrest cover panel --> «Backrest cover panel, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
2. Remove backrest --> «Front seat backrest, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__front-seat-backrest-assembly-overview) .
3. Pry out staples - 9 - (2x).
4. Remove Velcro strips - 8 - (2x).

1. Disengage piping on side - 4 -.
2. Pry out piping at bottom - 5 - (3x).
3. Unfasten clip - 6 - at cable guide - 7 -.
4. Lift out airbag cable - 3 -.

1. Remove nuts - 2 - (2x) of side airbag - 1 -.
2. Remove side airbag - 1 -.
3. Remove clip -11- and carefully pull out airbag cable - 3 -.

1. Installing

1. Installation is in reverse order of removal.
2. Make sure airbag cable - 3 - is routed between backrest frame and plastic guide - 10 - and that airbag cable - 3 - is not stretched.
3. Secure clip -11-.
4. Switch ignition on.

1. Connect battery Ground (GND) strap.

2 - Nuts (2x)

1. Tightening torque 5 Nm
2. Always replace

3 - Airbag cable

4 - Side piping

5 - Bottom piping (3x)

6 - Clip

7 - Cable guide

8 - Velcro strips (2x)

9 - Staples (2x)

1. Commercially available.
2. Only use upholstery stapler.

10 - Plastic guide

11 - Clip

Note. After connecting the battery observe the necessary measures. --> 27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL 27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL for ELECTRICAL EQUIPMENT, CABRIOLET If Airbag Malfunction Indicator Lamp (MIL) K75 signals a malfunction after assembly, use vehicle diagnostic, testing and information system VAS 5051 A to interrogate, erase and then again interrogate DTC memory.

Side airbag (electric seat), assembly overview

Scheme 72

1 - Side airbag drivers/front passengers

1. Removing

1. Disconnect battery Ground (GND) strap.
2. Remove seat --> «Front seat, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__front-seat-assembly-overview) .
3. Attach fixture for seat repair VAS 6136 to engine and transmission holder VAS 6095.
4. Attach front seat to fixture for seat repair VAS 6136.

1. Remove backrest cover panel --> «Backrest cover panel, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
2. Release sealing collar - 4 -.
3. Remove wiring harness - 5 - upward.
4. Remove nuts - 2 - (2x) of side airbag - 1 -.

1. Pry off metal tab - 3 -.
2. Remove side airbag - 1 -.
3. Remove clip - 6 - and carefully remove wiring harness - 5 -.

1. Installing

1. Installation is in reverse order of removal.
2. Make sure wiring harness - 5 - runs between seat frame and plastic guide - 7 - and that cables are not subject to strain.
3. Fasten clip - 6 -.
4. Switch ignition on.

1. Connect battery Ground (GND) strap.

2 - Nuts (2x)

1. Tightening torque 5 Nm
2. Always replace

3 - Metal tab

4 - Sealing collar

5 - Wiring harness

6 - Clip

7 - Plastic guide

Note. After connecting the battery observe the necessary measures. --> 27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL 27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL for ELECTRICAL EQUIPMENT, CABRIOLET If Airbag Malfunction Indicator Lamp (MIL) K75 signals a malfunction after assembly, use vehicle diagnostic, testing and information system VAS 5051 A to interrogate, erase and then again interrogate DTC memory.

Front airbag crash sensor, removing and installing

Scheme 73

1 - Front airbag crash sensor

1. Removing

1. Disconnect battery Ground (GND) strap.
2. Depending on engine version, remove air duct, if necessary.
3. Release tab at yellow connector - 3 - and disconnect connector.
4. Remove two bolts - 2 - on crash sensor - 1 -.

1. Installing

1. Switch ignition on.

1. Connect battery Ground (GND) strap.

2 - Bolts (2x)

1. Tightening torque 9 Nm

3 - Connector

4 - Lock carrier

Note. After connecting the battery observe the necessary measures. --> 27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL 27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL for ELECTRICAL EQUIPMENT, CABRIOLET If Airbag Malfunction Indicator Lamp (MIL) K75 signals a malfunction after assembly, use vehicle diagnostic, testing and information system VAS 5051 A to interrogate, erase and then again interrogate DTC memory.

Front side airbag crash sensor, removing and installing

Scheme 74

1. Removing

1. Disconnect battery Ground (GND) strap.
2. Remove side trim --> «Left side trim, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
3. Remove belt reel of front seat belt --> «Front 3-point seat belt with belt tensioner, assembly overivew»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
4. Remove belt reel insulation --> «Insulation, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .

1. Remove bolts - 2 - (2x).

1. Tightening torque 9 Nm

1. Disconnect connector on crash sensor - 1 - and remove crash sensor - 1 -.

1. Installing

1. Install crash sensor - 1 - in reverse order of removal.
2. Switch ignition on.

1. Connect battery Ground (GND) strap.

Note. After connecting the battery observe the necessary measures. --> 27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL 27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL for ELECTRICAL EQUIPMENT, CABRIOLET If Airbag Malfunction Indicator Lamp (MIL) K75 signals a malfunction after assembly, use vehicle diagnostic, testing and information system VAS 5051 A to interrogate, erase and then again interrogate DTC memory.

Scheme 75

1 - Rollover protection

1. Removing

1. Remove rear bench seat --> «Rear seat bench, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
2. Remove rear seat backrest --> «Rear seat backrest, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
3. Remove trim for ski bag --> «Removing and installing trim for through-load bag»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__removing-and-installing-trim-for-through-load) .
4. Close convertible top and fold convertible top compartment upward.

1. Unclip clips - 3 - (2x) on back panel trim - 2 -.
2. Fold back panel trim - 2 - aside in direction of - arrow -.

2 - Luggage compartment back panel trim

3 - Clips (2x)

Scheme 76

1 - Rollover bar

1. Remove bolts - 2 - (2x).
2. Fold convertible top compartment downward.

2 - Bolts (2x)

Scheme 77

1 - Rollover protection

1. Actuate convertible top far enough to allow access to convertible top compartment.
2. Extend rollover protection - 1 - Refer to guided fault-finding, body, general body repairs, 01 systems with self-diagnosis capability, Airbag 8.4E, Functions-Airbag 8.4E J234-Airbag Control Module, output DTM.
3. Unclip clips - 3 - (2x) on back panel trim - 2 -.
4. Fold back panel trim - 2 - aside in direction of arrow.

2 - Luggage compartment back panel trim

3 - Clips (2x)

Scheme 78

1 - Rollover protection

1. Check if and where shims are installed on rollover protection - 1 -.
2. Mark the points where the shims were removed.
3. Remove bolts - 2 - (4x).

2 - Bolts (4x)

Scheme 79

1 - Rollover protection

1. Press catch - 3 - and detach connector for solenoid valve - 2 -.
2. Pull out rollover protection - 1 -.
3. Installing

1. If installed, install shims in same places on rollover protection - 1 -.
2. Retract rollover protection - 1 - «Retracting rollover protection»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
3. Ensure that connector for solenoid valve - 2 - engages audibly.
4. Install rollover protection - 1 - in reverse order of removal.

1. Check function of rollover protection with control element test. Refer to guided fault-finding, body, general body repairs, 01 systems with self-diagnosis capability, Airbag 8.4E, Functions-Airbag 8.4E J234-Airbag Control Module, output DTM.

2 - Connector for solenoid valve

3 - Release

Scheme 80

1. Press release lever - 1 - in direction of - arrow -.
2. Retract rollover protection.

Scheme 81

1. Extend rollover bar. Refer to guided fault-finding, body, general body repairs, 01 systems with self-diagnosis capability, Airbag 8.4E, Functions-Airbag 8.4E J234-Airbag Control Module, output DTM.
2. Remove bolts - 2 - (4x). Tightening torque 5 Nm
3. Remove impact bar - 1 - upward.
4. When installing, push the back of the impact bar under the guide.

1. Installing

1. Installation is in reverse order of removal.

Scheme 82

1 - Removing and installing door trim --> Door trim, assembly overview

2 - Removing and installing trim panel --> Trim, removing and installing

3 - Removing and installing armrest --> Armrest, removing and installing

4 - Removing and installing window regulator switch module --> Switch panel for window regulator, removing and installing

5 - Removing and installing interior door handle --> Interior door handle, removing and installing

6 - Removing and installing central locking switch --> Central locking switch, removing and installing

7 - Removing and installing mirror adjustment switch --> Mirror adjustment switch, removing and installing

8 - Removing and installing bass speaker trim --> Bass speaker trim, removing and installing

9 - Removing and installing memory seat switch panel --> Switch panel for memory seat, removing and installing

10 - Removing and installing courtesy light --> Door warning light and courtesy light, removing and installing

11 - Removing and installing switch panel for tailgate release and/or anti-theft alarm --> Switch panel for tailgate release and/or deactivation of anti-theft alarm, assembly overview

12 - Removing and installing door warning light --> Door warning light and courtesy light, removing and installing

Scheme 83

1 - Door trim

1. Removing

1. Remove triangular treble speaker trim --> «Treble speaker, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__treble-speaker-removing-and-installing) .
2. Remove trim panel - 6 - --> «Trim, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
3. Remove bolts - 5 - (2x).
4. Using a screwdriver, pry out switch panel of window regulator - 3 - from below through hole.

1. Remove bolt - 4 -.
2. Remove bolt - 7 -.
3. Unclip door trim - 1 - starting at bottom.
4. Detach door trim - 1 - upward.

1. Disconnect connector to window regulator control unit «Disconnecting connector at window regulator control unit»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet)
2. Disengage Bowden cable for interior door handle --> «Disengaging Bowden cable for interior door handle»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet)

1. Installing

1. Make sure expanding nut - 10 - is clipped into door shell - 9 -.
2. Make sure all clips - 8 - (8x) are in position on inside of door trim. Replace damaged clips - 8 - «Replacing door trim securing clip»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet)
3. Make sure all clips - 2 - (6x) are clipped in on inside of door trim - 1 -.
4. Install door trim - 1 - in reverse order of removal.

2 - Clips (6x)

3 - Window regulator switch panel

4 - Bolt

5 - Bolts (2x)

6 - Trim strip

7 - Bolt

8 - Clips (8x)

9 - Door shell

10 - Expanding nut

Scheme 84

1. Pull Bowden cable - 2 - out of guide - 1 -.
2. Detach hook - 3 -.

Note. When installing, make sure hook - 3 - is facing upward.

Scheme 85

1. Detach catch - 2 -.
2. Disconnect connector - 3 - from control unit - 1 - in direction of - arrow -.

Scheme 86

1. Press retainer tab - 2 - and pull out clip - 1 - in direction of arrow.

Scheme 87

1. Carefully pry out trim - 1 - at front end in direction of - arrow -.
2. Unclip trim panel - 1 -.

Scheme 88

1 - Door shell

2 - Insulation

1. Removing

1. When removing insulation - 2 - , ensure that insulation - 2 - is not damaged.

1. Installing

1. Make sure adhesive bead - 3 - is not dirty or damaged.
2. Ensure that insulation - 2 - is not damaged.
3. Press adhesive bead - 3 - tightly all around door shell - 1 -.

3 - Adhesive bead

Scheme 89

1 - Cable to mirror adjustment switch

2 - Cable to central locking system switch

3 - Cable to switch panel for window regulator

4 - Cable to display of anti-theft alarm

5 - Cable to door warning light

6 - Cable to anti-theft alarm deactivation switch

7 - Cable to courtesy light

8 - Cable to tailgate release switch

9 - Cable to window regulator control unit connector

10 - Cable to memory seat switch panel

Armrest, removing and installing

1. Remove door trim --> «Door trim, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .

Scheme 90

1. Remove bolts - 2 - (2x).
2. Disconnect connector - 3 -.
3. Remove bolts - 4 - (8x).
4. Unclip armrest at retainer tab - 1 -.

Note. Figure shows armrest without cover.

Scheme 91

1. Remove armrest - 1 -.
2. Detach cover on underside of armrest - 1 -.
3. Unplug connector - 2 -.

Central locking switch, removing and installing

1. Remove door trim --> «Door trim, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .

Scheme 92

1. Disconnect connector - 1 -.
2. Using a screwdriver, pry out central locking switch - 2 -.

Mirror adjustment switch, removing and installing

Note. Figure shows armrest without cover.

1. Remove door trim --> «Door trim, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
2. Remove armrest --> «Armrest, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__armrest-removing-and-installing) .

Scheme 93

1. Using a screwdriver, pry out mirror adjustment switch - 1 -.
2. Disconnect connector at mirror adjustment switch - 2 -.

1. Installing

1. Installation is in reverse order of removal.

Interior door handle, removing and installing

1. Removing

1. Remove door trim --> «Door trim, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
2. Remove central locking switch --> «Central locking switch, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__central-locking-switch-removing-and-installing) .

Scheme 94

1. Remove bolt - 1 -.
2. Press retaining tabs - 2 - (2x) and remove interior door handle - 3 - to front.

1. Installing

1. Installation is in reverse order of removal.

Scheme 95

1. Using a screwdriver, pry out switch panel of window regulator - 1 - from below through hole.
2. Disconnect connector.

1. Installing

1. Installation is in reverse order of removal.

Scheme 96

1. Using a screwdriver, pry out switch panel for memory seat - 1 -.
2. Disconnect connector.

1. Installing

1. Installation is in reverse order of removal.

Scheme 97

1 - Switch panel for tailgate release and deactivation of anti-theft alarm

2 - Switch panel for tailgate release or deactivation of anti-theft alarm

3 - Dummy cover

1. Removing

1. Using a screwdriver, carefully pry out switch panel.
2. Disconnect connector(s) from switch panel

1. Installing

1. Install switch module in reverse order of removal.

Door warning light and courtesy light, removing and installing

1. Remove door trim --> «Door trim, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .

Scheme 98

1. Using a screwdriver, pry door warning light - 1 - out from below and pull door warning light - 1 - out with cable.
2. Disconnect connector on door warning light - 1 -.
3. Using a screwdriver, pry out courtesy light - 2 - at front and pull courtesy light - 2 - out with cable.
4. Disconnect connector on courtesy light - 2 -.

Treble speaker, removing and installing

1. Removing

Scheme 99

1. Unclip grille - 2 -.
2. Remove bolt - 3 -.
3. Remove triangular trim of treble speaker - 1 - upward.
4. Disconnect connector from triangular treble speaker trim - 1 -.

1. Installing

1. Unclip grille - 2 - from triangular treble speaker trim - 1 -.
2. Install triangular treble speaker trim - 1 - in reverse order of removal.

Bass speaker trim, removing and installing

1. Remove door trim --> «Door trim, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .

Scheme 100

1. Using a screwdriver, pry out circlips - 1 - (14x).
2. On deactivation of anti-theft alarm: Disconnect connector - 2 -.
3. On tailgate release: Detach connector - 3 -.
4. Disconnect memory seat connector - 4 -.

1. Remove bass speaker trim.

1. Installing

1. Installation is in reverse order of removal.

Scheme 101

1 - Side trim

1. Removing

1. Remove rear bench seat --> «Rear seat bench, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
2. Remove rear seat backrest --> «Rear seat backrest, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
3. Remove decorative panel --> «Decorative panel, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
4. Unclip center piece - 4 -.

1. Remove bolt - 5 -.
2. Reach into side trim - 1 - and unclip side trim - 1 - at clips - 2 - , - 7 - and - 6 -.
3. Remove side trim - 1 -.

1. If side trim - 1 - is to be replaced

1. Remove anchorage point for outer floor panel --> «Front anchorage point for outer floor panel»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__front-anchorage-point-for-outer-floor) .

1. Installing

Note. After installation ensure that seal is pulled correctly over side trim.

1. Pull back clip - 6 - to loosen clip - 6 -.
2. Install side trim - 1 - in reverse order of removal.

2 - Clip

3 - Decorative panel

4 - Center piece

5 - Bolt

6 - Clip

7 - Clip

Scheme 102

1. Carefully pry off decorative panel - 1 - in direction of - arrow -.
2. Unclip decorative panel - 1 -.

1. Installing

1. Installation is in reverse order of removal.

Scheme 103

1 - Insulation with loudspeaker installed

2 - Insulation with loudspeaker not installed

3 - Insulation

4 - Belt reel insulation

1. Removing

1. Remove rear bench seat --> «Rear seat bench, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
2. Remove rear seat backrest --> «Rear seat backrest, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
3. Remove decorative panel --> «Rear side trim, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
4. For belt reel insulation: Remove belt reel of front seat belt --> «Front 3-point seat belt with belt tensioner, assembly overivew»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .

1. For all insulation: When removing insulation, ensure that insulation does not become damaged.
2. Remove insulation.

1. Installing

1. Press insulation evenly and firmly onto body.
2. For belt reel insulation: Install belt reel --> «Front 3-point seat belt with belt tensioner, assembly overivew»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .

Scheme 104

1 - Instrument panel

1. Removing --> «Instrument panel, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__instrument-panel-removing-and-installing)

2 - Left instrument panel vent

1. Removing

3 - Left instrument panel speaker

1. Removing

4 - Instrument cluster -->

1. «90 INSTRUMENTS»(/audi/s4/b7-2004-2008/remont/cruise-control-systems/#electrical-equipment)
2. 90 INSTRUMENTS for ELECTRICAL EQUIPMENT, CABRIOLET

5 - Upper trim for steering column switch

1. Removing

6 - Sunlight Photo Sensor G107

1. Removing

7 - Center instrument panel speaker

1. Removing

8 - Trim for center defroster vent

1. Removing

9 - Center instrument panel vent

1. Removing

10 - Front passengers airbag unit

1. Removing --> «Front passenger airbag, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__front-passenger-airbag-assembly-overview)

11 - Right instrument panel speaker

1. Removing

12 - Right instrument panel vent

1. Removing

13 - Instrument panel cover, right

1. Removing

14 - Right instrument panel trim

1. Removing

15 - Glove compartment

1. Removing --> «Glove compartment, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet)

16 - Center console

1. Removing --> «Center console, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet)

17 - Front ashtray

1. Removing --> «Front ashtray, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet)

18 - Removing instrument panel center section --> Center section of instrument panel, assembly overview

1. Removing --> «Center section of instrument panel, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet)

19 - Drivers storage compartment

1. Removing --> «Drivers storage compartment (without knee protection), removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet)

20 - Left instrument panel trim

1. Removing

21 - Light switch and adjuster for headlight range control

1. Removing

22 - Instrument panel cover, left

1. Removing

Instrument panel, removing and installing

Special tools and workshop equipment required

Scheme 105

1. Front end hook 3370
2. Hook 3438
3. Screwdriver T8 T40056

1. Removing

1. Disconnect battery Ground (GND) strap at battery.
2. Remove drivers airbag unit (standard steering wheel) --> «Airbag unit (standard steering wheel), assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__airbag-unit-standard-steering-wheel-assembly) .
3. Remove drivers airbag unit (sports steering wheel) --> «Airbag unit (sports steering wheel), assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__airbag-unit-sports-steering-wheel-assembly) .
4. Remove drivers airbag unit (multi-function steering wheel) --> «Airbag unit (multi-function steering wheel), assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__airbag-unit-multi-function-steering-wheel-assembly) .

1. Remove steering wheel (standard steering wheel) --> «Steering wheel (standard steering wheel), assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__steering-wheel-standard-steering-wheel-assembly) .
2. Remove steering wheel (sports steering wheel) --> «Steering wheel (sports steering wheel), assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__steering-wheel-sports-steering-wheel-assembly) .
3. Remove steering wheel (multi-function steering wheel) --> «Steering wheel (multi-function steering wheel), assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__steering-wheel-multi-function-steering-wheel-assembly) .
4. Remove drivers storage compartment --> «Drivers storage compartment (without knee protection), removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .

1. Remove instrument cluster. --> «90 INSTRUMENTS»(/audi/s4/b7-2004-2008/remont/cruise-control-systems/#electrical-equipment) 90 INSTRUMENTS for ELECTRICAL EQUIPMENT, CABRIOLET
2. Remove glove compartment --> «Glove compartment, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
3. Remove front passengers airbag unit --> «Front passenger airbag, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__front-passenger-airbag-assembly-overview) .
4. Remove center console --> «Center console, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .

1. Remove instrument panel center section --> «Center section of instrument panel, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .

1. Detach left instrument panel cover - arrow - using front end hook 3370.

Scheme 106

1. Unscrew bolts - 1 - (2x). Tightening torque 4 Nm

Scheme 107

1. Disconnect connector - arrow - at left and right vent temperature sensors G150 and G151.

Note. The illustration shows right vent temperature sensor -G151- on passenger side.

Scheme 108

1. Disconnect connector for instrument panel vent light.

Note. The illustration shows instrument panel vent on passenger side. The center instrument panel vents must be pulled out to detach connector for light.

1. Move rear air flaps of instrument panel vent into central position by turning adjustment wheel - 1 -.

Scheme 109

1. Guide tool 3438 in position - 2 - or - 3 - into instrument panel vent.
2. Hook tool 3438 by slightly moving it into recesses - 4 - at rear end of instrument panel vent.

Scheme 110

1. Detach instrument panel vent carefully to rear alternating between left and right using special tool 3438.

Scheme 111

1. Carefully pry out loudspeaker trim - 1 -.
2. Remove bolts - 2 -.
3. Take out speaker and disconnect connectors.

Removing and installing tray, switch and cup holder

1. Remove tray «Removing and installing storage tray»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
2. Remove cup holder «Removing and installing cup holder»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
3. Position a small flat-bladed screwdriver on top at the switch.

Scheme 112

1. Carefully pry appropriate switch out of switch mount - arrows -.
2. Disconnect connectors.

Scheme 113

1. Press light switch - arrow 1 - and turn clockwise at same time - arrow 2 -.
2. Keep switch in this position...

Scheme 114

1. ... and pull light switch out of switch housing - 3 -.
2. Disconnect connector.

Scheme 115

1. Press headlight range control adjuster out of switch housing.
2. Disconnect connector.

Scheme 116

1. Remove bolts - 1 - (3x). Tightening torque 3 Nm
2. Remove trim - 2 - for instrument panel.

Scheme 117

1. Remove bolts - 1 - (2x). Tightening torque 4 Nm

Removing upper steering column switch trim

Drivers airbag unit and steering wheel removed

1. Pull steering column out and downward as far as possible.

Scheme 118

1. Remove bolts - 1 - (2x). Tightening torque 3 Nm
2. Remove Torx bolts - 3 - with screwdriver T8 T40056. Tightening torque 0.6 Nm
3. Unclip surround from instrument panel downward - arrow -.
4. Remove upper steering column switch trim - 2 -.

Scheme 119

1. Carefully pry off cover - A -.
2. Remove bolt - B -.
3. Remove photo sensor.
4. Disconnect cable connector.

Scheme 120

1. Remove defroster vent bolt - 1 -. Tightening torque 0.8 Nm

Removing center instrument panel speaker

Center defroster vent removed

Scheme 121

1. Remove bolts - 1 - (2x). Tightening torque 2 Nm
2. Swivel out speaker and disconnect connector.

Scheme 122

1. Remove bolt - 1 - and detach trim - 2 - to rear. Tightening torque 3 Nm

Note. When installing trim for instrument panel cover, replace fasteners - 3 -.

Removing right instrument panel cover

1. Remove right instrument panel cover - arrow - using front end hook 3370.

Scheme 123

1. Remove bolts - 1 - (2x). Tightening torque 4 Nm

Scheme 124

1. Unscrew bolts - 1 - (4x). Tightening torque 4 Nm
2. Pull out instrument panel toward the rear.

1. Installing

Scheme 125

1. Check that felt pad - 2 - is present on left and right of clip - 1 -.
2. Insert instrument panel into clip pressing it down slightly at the same time.
3. Test that the instrument panel is located correctly in the clip at the front by pulling up lightly.
4. Carry out remainder of installation in reverse order of removal.

Scheme 126

1. Pop rivet tool VAS 5072
2. Removing

1. Remove instrument panel --> «Instrument panel, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__instrument-panel-removing-and-installing) .
2. Remove damaged left or right vent temperature sensor G150 or G151.

Scheme 127

1. Using a sharp knife, cut off weld points - 2 - (4x) flush with air duct.

Scheme 128

1. Remove damaged air duct.
2. Drill 5 mm holes at - 2 - (3x).

1. Installing

1. Install new air duct, ensuring that no parts remain inside it.
2. Install blind rivets supplied with air duct at - 2 - (3x).
3. Screw in bolt - 3 - supplied with air duct.

Scheme 129

1 - Angle bracket, left

1. For central tube

2 - Bolts (3x)

1. Tightening torque 23 Nm

3 - Bolt

1. Tightening torque 9 Nm

4 - Sealing washer

5 - Bolt

1. Tightening torque 6 Nm

6 - Central tube

7 - Bolts (2x)

1. Tightening torque 9 Nm

8 - Bolts (3x)

1. Tightening torque 23 Nm

9 - Angle bracket, right

1. For central tube

10 - Angle bracket

11 - Bolt

1. Tightening torque 9 Nm

12 - Nut

1. Tightening torque 35 Nm

13 - Bolts (2x)

1. Tightening torque 8 Nm

14 - Bracket

1. For air conditioner unit

15 - Bolts (2x)

1. Tightening torque 9 Nm

16 - Brace

17 - Bolts (2x)

1. Tightening torque 9 Nm

18 - Bolts (2x)

1. Tightening torque 9 Nm

19 - Support

20 - Bolts (4x)

1. Tightening torque 5 Nm

21 - Adapter center section

22 - Support

23 - Bolts (2x)

1. Tightening torque 9 Nm

24 - Bolt

1. Tightening torque 8 Nm

25 - Bolts (2x)

1. Tightening torque 9 Nm

26 - Bolt

1. Tightening torque 8 Nm

27 - Nut

1. Tightening torque 35 Nm

Scheme 130

1. Pry bar 80-200
2. Removing

1. Remove instrument panel --> «Instrument panel, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__instrument-panel-removing-and-installing) .
2. Remove instrument panel center section --> «Center section of instrument panel, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .

Scheme 131

1. Remove bolts - 1 - (2x) from fuse carrier - 2 -. Tightening torque 3 Nm
2. Lay the fuse carrier with attached wiring downward.
3. Disconnect wiring harness from instrument panel subframe and set aside.

Scheme 132

1. Unscrew bolts - 1 - (2x) of 3-position relay carrier - 2 -. Tightening torque 3 Nm
2. Remove nuts - 3 - (2x) of 6-position relay carrier - 4 - on vehicles electrical system control unit. Tightening torque 2.4 Nm
3. Lay the relay carrier with attached wiring downward.
4. Disconnect wiring harness behind relay carriers from central tube and set aside.

Scheme 133

1. Remove bolt - 2 - of pedal bracket. Tightening torque 23 Nm
2. Remove bolts - 1 - (4x). Tightening torque 22 Nm
3. Lay steering column down in drivers footwell.

Scheme 134

1. Remove bolts - 1 - (4x) of left support. Tightening torque 9 Nm
2. Remove bolt - 2 -. Tightening torque 8 Nm

Note. If support does not have to be removed, simply loosen bolt - 3 - and swing support downward.

1. Loosen or remove bolt - 3 - (front attachment of support to air conditioner unit). Tightening torque 8 Nm
2. Remove support or swing downward.

Scheme 135

1. Remove bolts - 1 - (4x). Tightening torque 9 Nm
2. Lay wiring aside - 2 -.
3. Remove right support.

Scheme 136

1. Remove bolts - 1 - (2x) of air conditioner unit bracket. Tightening torque 9 Nm

Scheme 137

1. Using a screwdriver pry off both trim caps - 3 -.
2. Loosen the hex nuts - 4 - a few turns.
3. Remove wiper arms - 2 - from the pivot shaft by tilting them slightly.
4. Remove hex nuts completely and remove wiper arms.

1. Remove retaining clips - 1 - and remove air cowl grille - 5 -.

Scheme 138

1. Remove cover for electronics box (plenum chamber) - arrow -.

Scheme 139

1. Using a screwdriver, carefully lever off retainer - arrow - and place engine control module with connected wiring on one side.
2. Unclip retaining clip.
3. If present, place transmission control module with connected wiring on one side.

Scheme 140

1. Remove bolts - 2 - (2x) of connector point. Tightening torque 3 Nm
2. In plenum chamber, remove bolt - 1 - from instrument panel central tube. Tightening torque 6 Nm

Scheme 141

1. Remove nuts - 1 - (2x) on left. Tightening torque 35 Nm
2. Remove bolt - 3 - at top. Tightening torque 6 Nm
3. Remove Ground (GND) wires - 2 -.

Scheme 142

1. Remove nut - 2 - on right. Tightening torque 35 Nm
2. Remove bolt - 3 - at top. Tightening torque 6 Nm
3. Remove Ground (GND) wires - 1 -.
4. Pull instrument panel central tube a few mm forward.

Scheme 143

1. Using a small screwdriver pull out pins - 2 - (2x) upwards as far possible.
2. Set electrical wiring harness aside behind vent.
3. Remove air duct - arrow - upward.
4. Remove Ground (GND) wires - 1 -.

Scheme 144

1. Disconnect wiring harness behind instrument panel central tube from instrument panel central tube - arrows -...

Scheme 145

1. ... Pry bar 80-200
2. Remove instrument panel central tube.

Scheme 146

1 - Upper A-pillar trim

1. Removing

1. Remove windshield trim --> «Windshield trim, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
2. Unclip lower A-pillar trim in upper area.
3. Pry out upper A-pillar trim - 1 - at clips - 2 - (3x).
4. Detach upper A-pillar trim - 1 -.

1. Removing

1. When installing, ensure that rubber door surround is in full contact with upper A-pillar trim - 1 -.
2. Install upper A-pillar trim - 1 - in reverse order of removal.

2 - Clips (3x)

Scheme 147

1 - Sill panel trim

2 - Clips (3x)

3 - Clip

4 - Lower A-pillar trim

1. Removing

1. Unclip sill panel trim - 1 - at clips - 2 - (3x).
2. Lift front sill panel trim - 1 -.
3. Unclip lower A-pillar trim - 4 - at clip - 5 -.
4. Press retainer tab on clip - 3 - and remove lower A-pillar trim - 4 -.

1. Installing

1. When installing, ensure that rubber door surround is in full contact with lower A-pillar trim - 1 -.
2. Install lower A-pillar trim - 1 - in reverse order of removal.

5 - Clip

Scheme 148

1 - Floor mat

1. Removing

1. Remove front seats --> «Front seat, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__front-seat-assembly-overview) .
2. Remove rear seat backrest --> «Rear seat backrest, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
3. Remove rear bench seat --> «Rear seat bench, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
4. Remove sill panel trims --> «Sill panel trim, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__sill-panel-trim-removing-and-installing) .

1. Remove lower A-pillar trims --> «Lower A-pillar trim, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
2. Remove foot rest --> «Removing and installing foot rest»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__removing-and-installing-foot-rest) .
3. Remove foot rest holder --> «Foot rest holder, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__foot-rest-holder-removing-and-installing) .
4. Remove center console --> «Center console, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .

1. Detach wiring harness under center console.
2. Remove bolts (2x) at air ducts - 2 - (2x) and remove both air ducts - 2 - (2x).
3. Unscrew bolts - 3 - (2x).
4. Fold floor mat - 1 - length ways and remove floor mat - 1 - from vehicle.

1. Installing

Note. Floor covering is liable to tear slightly at cut-outs. Install floor mat carefully.

1. Install floor mat - 1 - in reverse order of removal.

2 - Air ducts (2x)

3 - Bolts (2x)

Sill panel trim, removing and installing

1. Removing

Scheme 149

1. Unclip side trim - 1 - in bottom area.
2. Unclip sill panel trim - 2 - at clips - 3 - (3x).
3. Remove sill panel trim - 2 -.

1. Installing

1. After installation ensure that seal is pulled correctly over sill panel trim - 2 -.
2. Install sill panel trim - 2 - in reverse order of removal.

Removing and installing foot rest

1. Removing

1. Remove drivers storage compartment --> «Drivers storage compartment (without knee protection), removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) , USA vehicles --> «Drivers storage compartment (vehicles with knee bolster), assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet)
2. Remove lower A-pillar trim --> «Lower A-pillar trim, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .

Scheme 150

1. Remove bolt - 1 -.
2. Push foot rest - 2 - upward and remove foot rest - 2 -.

1. Installing

1. Install foot rest - 2 - in reverse order of removal.

Foot rest holder, removing and installing

1. Removing

1. Remove foot rest.

1. Fold back floor covering in area of foot rest holder - 4 -.
2. Remove nuts - 5 - (3x).

1. Tightening torque 4 Nm

1. Remove foot rest holder - 4 -.

1. Installing

1. Ensure that - 3 - is installed to foot rest holder - 4 -.

Scheme 151

1. Remove sun visor - 4 - from mount - 1 - and fold sun visor - 4 - aside.
2. Using a screwdriver, pry out trim cap - 3 -.
3. Remove bolt - 2 -.

1. Tightening torque 4 Nm

1. Remove sun visor - 4 -.

1. Installing

1. Installation is in reverse order of removal.

Sun visor mount, removing and installing

1. Removing

Scheme 152

1. Using a screwdriver, pry out trim cap - 3 -.
2. Remove bolts - 2 - (2x).

1. Tightening torque 4 Nm

1. Remove mount - 1 -.

1. Installing

1. Installation is in reverse order of removal.

Scheme 153

1. Remove bolt - 2 -.
2. Remove center sun visor - 1 -.

1. Installing

1. Installation is in reverse order of removal.

Scheme 154

1 - Bolt

1. Tightening torque 7 Nm

2 - Clips (2x)

3 - Nut

4 - Tabs (2x)

5 - Windshield trim

1. Removing

1. Remove interior light/reading light --> «Lower A-pillar trim, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) and --> «Lower A-pillar trim, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) and --> «Interior light/reading light, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__interior-lightreading-light-removing-and-installing) .
2. Remove make-up mirror light --> «Lower A-pillar trim, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) and --> «Lower A-pillar trim, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) and --> «Removing and installing make-up mirror light»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
3. Remove sun visors --> «Lower A-pillar trim, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) and --> «Lower A-pillar trim, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) and --> «Sun visor, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
4. Remove sun visor mounts --> «Lower A-pillar trim, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) and --> «Lower A-pillar trim, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) and --> «Sun visor mount, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__sun-visor-mount-removing-and-installing) .

1. Remove center sun visor --> «Lower A-pillar trim, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) and --> «Lower A-pillar trim, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) and --> «Center sun visor, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
2. Remove nut - 3 -.
3. Pry out windshield trim - 5 - at clips - 2 - (2x) and tabs - 4 - (2x).
4. Carefully remove windshield trim - 5 - downward.

1. Installing

1. Install windshield trim - 5 - in reverse order of removal.

Scheme 155

1. Using a screwdriver, pry out make-up mirror light - 2 - in direction of - arrow -.
2. Disconnect connector - 1 -.
3. Remove make-up mirror light - 2 -.

1. Installing

1. Installation is in reverse order of removal.

Interior light/reading light, removing and installing

Special tools and workshop equipment required

1. Pry bar 80-200
2. Removing

Scheme 156

1. Using Pry bar 80-200 , carefully pry out interior light at rear edge. Watch for the two retaining tabs - arrows -.
2. Disconnect connectors.

1. Installing

1. Installation is in reverse order of removal.

Scheme 157

1 - Tailgate trim

1. Removing

1. Remove warning triangle.
2. Remove bolts - 3 - (3x).
3. Remove warning triangle holder - 6 -.
4. Remove lock cover - 2 -.

1. Remove bolt - 5 - in handle - 4 -.
2. Vehicles with emergency release handle: Remove emergency release handle «Removing emergency release handle»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet)
3. Unclip tailgate trim - 1 - at clips - 7 - (12x).
4. Remove tailgate trim - 1 -.

1. Installing

1. Install tailgate trim in reverse order of removal.

2 - Lock cover

3 - Bolts (3x)

4 - Handle

5 - Bolt

6 - Bracket for warning triangle.

7 - Clips (12 x)

Scheme 158

1. Unclip cover - 1 -.
2. Remove bolt - 3 -.
3. Remove handle - 2 -.

Scheme 159

1. Using a screwdriver, pry out luggage compartment light - 1 - in direction of - arrow -.
2. Disconnect connector - 2 -.

1. Installing

1. Installation is in reverse order of removal.

Scheme 160

1 - Rear cross panel trim

1. Removing

1. Remove luggage compartment floor covering from luggage compartment
2. Remove luggage compartment light --> «Luggage compartment light, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
3. Unclip rear cross panel trim - 1 - upward from clips - 2 - (4x).

1. Installing

Note. After installation ensure that seal is pulled correctly over trim.

1. Install rear cross panel trim in reverse order of removal.

2 - Clips (4x)

Scheme 161

1 - Right side trim

1. Removing

1. Remove luggage compartment floor covering.
2. Remove rear panel trim --> «Rear cross panel trim, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
3. Remove luggage compartment light --> «Luggage compartment light, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
4. Unclip clip - 2 -.

1. Detach right side trim - 1 - in direction of - arrow -.

1. Installing

Note. After installation ensure that seal is pulled correctly over trim.

1. Install trim in reverse order of removal.

2 - Clip

Scheme 162

1 - Left side trim

1. Removing

1. Remove luggage compartment floor covering.
2. Remove rear panel trim --> «Rear cross panel trim, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
3. Unclip clip - 2 -.
4. Detach left side trim - 1 - in direction of - arrow -.

1. Installing

Note. After installation ensure that seal is pulled correctly over trim.

1. Install trim in reverse order of removal.

2 - Clip

Scheme 163

1 - Back panel trim

1. Removing

1. Remove right side trim --> «Right side trim, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
2. Remove left side trim --> «Left side trim, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
3. Remove luggage compartment floor covering.
4. If installed, remove frame for ski bag --> «Removing and installing trim for through-load bag»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__removing-and-installing-trim-for-through-load) .

1. Ensure that convertible top is closed and convertible top compartment folded up.
2. Unclip back panel trim - 1 - at clips - 2 - (6x).

2 - Clips (6x)

Scheme 164

1 - Clips (2x)

2 - Back panel trim

1. Fold convertible top compartment down.
2. Open convertible top.
3. Unclip back panel trim - 2 - at clips - 1 - (2x).
4. Lift out back panel trim - 2 -.

1. Removing

1. Install back panel trim - 2 - in reverse order of removal.

Floor covering holder, removing and installing

1. Remove floor covering - 2 -.

Scheme 165

1. Unclip holder - 1 - from fastener - 3 -.

Scheme 166

1 - Rear trim

1. Removing

1. Open convertible top.
2. Fold convertible top compartment down.
3. Unclip clips - 2 - (4x).
4. Fold away seal and pull out rear trim - 1 -.

1. Installing

1. After installation ensure that seal is installed correctly.
2. Install rear trim - 1 - in reverse order of removal.

2 - Clips (4x)

Scheme 167

1 - Side trim

1. Removing

1. Open convertible top.
2. Fold convertible top compartment down.
3. Unclip clips - 3 - (3x).
4. Remove stop buffer - 2 -.

1. Fold seal aside and pull out side trim - 1 -.

1. Installing

Note. After installation ensure that seal is pulled correctly over trim.

1. Install side trim - 1 - in reverse order of removal.

2 - Stop buffer

3 - Clips (3x)

Scheme 168

1 - Flap

1. Removing

1. Remove bolts - 3 - (2x) on mountings - 2 - (2x).
2. Push flap - 1 - forward and detach flap - 1 - downward.

1. Installing

1. Install flap in reverse order of removal.

2 - Mounting (2x)

3 - Bolts (2x)

Scheme 169

1 - Variable convertible top compartment

1. Removing
2. Move convertible top into such a position that convertible top compartment is open.
3. Lift up side lining in convertible top compartment.
4. Remove bolts left and right - 2 - (2x).

1. Close convertible top.
2. Open luggage compartment lid.
3. Remove lid of convertible top compartment --> «Convertible top compartment lid, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
4. Remove handle mount trim --> «Handle mount trim, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .

1. Detach Bowden cables from clips.
2. Using a large, flat screwdriver - 6 - , work along between convertible top compartment side section - 4 - and console - 3 - and carefully detach convertible top compartment from console - 5 - (secured with adhesive tape)
3. Disconnect connector to microswitch - 7 - on right side.
4. Detach Bowden cables from clips.

1. Close luggage compartment lid.
2. Move convertible top back into position "Convertible top compartment open".
3. Second mechanic is required to lift out.
4. Position handle mount trim on variable convertible top compartment.

1. Remove luggage compartment side trim on left --> «Left side trim, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) and right --> «Right side trim, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .

Note. The variable convertible top compartment must be lifted at sides of frame section, do not hold convertible top compartment in center and extend mechanism. Lift out variable convertible top compartment - 1 - at both sides on side sections - 4 -. Make sure Bowden cables do not catch.

2 - Bolts (2x)

1. Tightening torque 2 Nm

3 - Convertible top compartment side lining

4 - Convertible top compartment side section

5 - Flat screwdriver

6 - Console

7 - Microswitch connector

Scheme 170

1 - Convertible top compartment lid

Note. The variable convertible top compartment must be in the lowest position. The hinges - 2 - must not be unscrewed to remove convertible top compartment lid - 1 -. Arrow faces in direction of travel.

1. Removing
2. Bend convertible top compartment lid - 1 - back on one side on hinge and detach convertible top compartment lid - 1 - from hinges.
3. Fold convertible top compartment lid - 1 - downward.
4. Detach lid on hooks - 4 - (2x) by pushing forward.

2 - Hinge (2x)

1. Bend convertible top compartment lid - 1 - back on one side on hinge and detach convertible top compartment lid - 1 - from hinges.
2. Remove bolt - 3 -.
3. Detach hinge - 2 - from body.

3 - Bolt (2x)

4 - Hook

5 - Variable convertible top compartment

Scheme 171

1 - Handle mount trim

Note. Convertible top must be closed.

1. Removing
2. Pry out cover - 2 - using a small flat screwdriver.
3. Remove bolt - 3 -.

1. Turn handle.
2. Pry out cover - 2 - on other side, using a small flat screwdriver.
3. Remove second bolt - 3 -.
4. Remove bolts - 4 - from underneath.

1. Unclip handle mount trim - 1 - from clips - 5 - (2x).
2. Pry out clamp - 6 - (always replace clamp - 6 -).
3. Detach Bowden cable - 7 - from handle.

2 - Cover (2x)

3 - Bolts (2x)

1. Tightening torque 9 Nm

4 - Bolts (2x)

1. Tightening torque 7 Nm

5 - Clips (2x)

6 - Fastener

1. Always replace

7 - Bowden cable

Handle for variable convertible top compartment, removing and installing

1. Removing

1. Remove handle mount trim --> «Handle mount trim, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .

Note. Illustration shown from rear for greater clarity.

Scheme 172

1. Using a small flat screwdriver, pry out fuse - 2 - (always replace fuse - 2 -).
2. Press out pin - 3 -.
3. Remove handle - 1 -.

1 - Handle

2 - Fuse

Always replace

3 - Pin

4 - Bowden cable

1. Installing

1. Installation is in reverse order of removal.

Microswitch for variable convertible top compartment, removing and installing

1. Remove variable convertible top compartment --> «Variable convertible top compartment, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .

Scheme 173

1. Pull carpet - 1 - back (convertible top compartment lining) on right side until both bolts - 2 - are accessible.

1. Bond carpet with D 001 200.

1. Remove bolts - 2 - (2x).

1. Tightening torque 4 Nm

1. Detach convertible top compartment center section - 3 - from right side section - 4 -.

Scheme 174

1. Pull side sections - 1 - and - 2 - apart.
2. Remove bolts - 3 - (4x) from inner lid.

1. Tightening torque 2 Nm

1. Detach inner lid - 1 -.
2. Carefully drill off microswitch weld on outside.

Scheme 175

1. Remove microswitch - 1 -.

1. Installing

1. Attach new microswitch - 1 - using soldering iron on outside.
2. Installation is in reverse order of removal.

Removing

1. Remove variable convertible top compartment --> «Variable convertible top compartment, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .

1. Pull carpet - 1 - back (convertible top compartment lining) on side to be changed until both bolts - 2 - are accessible.

1. Bond carpet with D 001 200.

1. Remove bolts - 2 - (2x).

1. Tightening torque 4 Nm

1. Detach convertible top compartment center section - 3 - from right side section - 4 -.

1. Pull side sections - 1 - and - 2 - apart.
2. Remove bolts - 3 - (4x) from inner lid.

1. Tightening torque 2 Nm

1. Detach inner lid - 1 -.

Scheme 176

1. Remove bolts - 1 - (4x) on both sides.

1. Tightening torque 2 Nm

Scheme 177

1. Pull sections - 1 - and - 4 - apart upward.
2. Pry guide rails - 3 - out of catch of section - 1 -.
3. Separate sections - 1 - and - 4 -.
4. Release holder - 1 - at rear.

Scheme 178

1. Pry out holder - 1 - using a flat screwdriver..
2. Always replace holder - 1 -.
3. Remove toothed segment - 2 -.
4. Detach Bowden cable - 3 -.

Installing

Toothed segment with Bowden cable for right side

Scheme 179

1. Engage Bowden cable - 2 - in long groove and lay Bowden cable - 2 - in groove - 3 -.
2. Groove - 4 - not used.

Toothed segment with Bowden cable for left side

Scheme 180

1. Engage Bowden cable - 2 - in long groove and lay Bowden cable - 2 - in groove - 4 -.
2. Engage Bowden cable for right side in short groove and lay Bowden cable - 5 - in groove - 3 - (Bowden cables routed in opposite directions).

All models continued

1. Press toothed segment - 2 - onto guide.
2. Engage new holder - 1 -.
3. Toothed segment - 2 - must be horizontal on installation.

1. On assembly, section - 4 - must be positioned with guide rails - 3 - on rubber buffers at bottom.
2. Ensure that microswitch on right side is not crushed. For this pull section - 4 - slightly upward.
3. Press section - 4 - back down again.
4. The toothed segment - 5 - must be horizontal when folding together. Fold sections in lowest position together.

1. In folded position, push guide rail outer section - 3 - upward and engage it in tabs.
2. Carry out remainder of installation in reverse order of removal.

Rack of variable convertible top compartment, removing and installing

1. Remove variable convertible top compartment --> «Variable convertible top compartment, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .

1. Pull carpet - 1 - back (convertible top compartment lining) on side to be changed until both bolts - 2 - are accessible.

1. Bond carpet with D 001 200.

1. Remove bolts - 2 - (2x).

1. Tightening torque 4 Nm

1. Detach convertible top compartment center section from side section - 4 - on right.

1. Pull apart side sections - 1 - and - 2 -.
2. Remove bolts - 3 - (4x) from inner lid.

1. Tightening torque 2 Nm

1. Detach inner lid - 1 -.

1. Remove bolts - 1 - (4x) on both sides.

1. Tightening torque 2 Nm

1. Pull sections - 1 - and - 4 - apart upward.
2. Pry guide rails - 3 - out of catch of section - 1 -.
3. Separate sections - 1 - and - 4 -.

Scheme 181

1. Remove bolts - 2 - (3x).

1. Tightening torque 2.5 Nm

1. Remove rack - 1 -.

Guide rail of variable convertible top compartment, removing and installing

1. Remove variable convertible top compartment --> «Variable convertible top compartment, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .

1. Pull carpet - 1 - back (convertible top compartment lining) on side to be changed until both bolts - 2 - are accessible.

1. Bond carpet with D 001 200.

1. Remove bolts - 2 - (2x).

1. Tightening torque 4 Nm

1. Detach convertible top compartment center section - 3 - from side section - 4 - on right.

1. Pull side sections - 1 - and - 2 - apart.
2. Remove bolts - 3 - (4x) from inner lid.

1. Tightening torque 2 Nm

1. Detach inner lid - 1 -.

1. Remove bolts - 1 - (4x) on both sides.

1. Tightening torque 2 Nm

1. Pull sections - 1 - and - 4 - apart upward.
2. Pry guide rail - 3 - out of catch of section - 1 -.
3. Separate sections - 1 - and - 4 -.

Scheme 182

1. Remove bolts - 2 - on left and right.

1. Tightening torque 1 Nm

1. Push guide rail - 1 - downward and out of locking tabs.
2. Remove guide rail - 1 -.

1. Installing

1. Installation is in reverse order of removal.

Scheme 183

1 - Console

1. Remove variable convertible top compartment --> «Variable convertible top compartment, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
2. Remove nuts - 2 - (4x).
3. Lift console - 1 - upward out of body.

2 - Nuts (4x)

Special tools, workshop equipment, testers, measuring instruments and other items required

Engine and transmission holder VAS 6095

Fixture for seat repair VAS 6136

Seat, assembly overview

Special tools and workshop equipment required

Scheme 184

Torque wrench V.A.G 1331

Scheme 185

1 - Front rail cover

1. Removing

1. Pull handle for forward and backward adjustment and move front seat - 4 - to rearmost position.
2. Remove securing clip - 2 - (2x).
3. Remove rail cover - 1 - (2x).
4. Remove bolts - 3 - (2x).

2 - Securing clip (2x)

3 - Bolt (2x)

1. Tightening torque 50 Nm

4 - Front seat

Scheme 186

1 - Rear rail cover

1. Removing

1. Pull handle for forward and backward adjustment and move front seat - 4 - forward as far as possible.
2. Remove securing clips - 2 - (4x).
3. Remove rail cover - 1 - (2x).
4. Remove bolt - 3 - (2x).

2 - Securing clip (4x)

3 - Bolt (2x)

1. Tightening torque 50 Nm

4 - Front seat

Scheme 187

1 - Belt mount

Note. Height adjustable seat: Raise seat.

Removing

1. Remove cover - 2 - pull upward.
2. Remove belt mount - 1 - pull down in direction of - arrow -.

2 - Cover

Scheme 188

1 - Front seat

2 - Buckle interrogation connector (black)

3 - Heated seat connector (green)

4 - Power supply connector (red)

5 - Airbag connector (yellow)

6 - Connector point cover

1. Removing

1. Tilt front seat - 1 - back.
2. Remove connection point cover - 6 - upward.
3. Press tab on airbag connector - 5 - inboard side and remove airbag connector - 5 -.
4. Press tab on power supply connector - 4 - inboard side and remove power supply connector - 4 -.

1. Press tab on seat heating connector - 3 - inboard side and remove seat heating connector - 3 -.
2. For vehicles with buckle interrogation: Press in tab on buckle interrogation connector - 2 - inboard side and remove buckle interrogation connector - 2 -.
3. Connect airbag adapter --> «Airbag adapter VAS 6036 , connecting»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__airbag-adapter-vas-6036-connecting) .
4. With assistance from a second mechanic, lift front seat - 1 - out of vehicle.

Airbag adapter VAS 6036 , connecting

Special tools and workshop equipment required

Scheme 189

Airbag adapter VAS 6036

Note. The mechanic must electrostatically discharge him/herself before disconnecting ignition and ground (GND) wires (briefly touch closing wedge for door or body).

Scheme 190

1 - Airbag connector (yellow)

1. Attach airbag connector (yellow) - 1 - to airbag adapter connector - 2 -.
2. If present: Connect the airbag adapter power supply connector (red) - 3 - to the seat connector power supply connector (red) - 4 -.

2 - Airbag adapter connector (yellow)

3 - Airbag adapter power supply connector (red)

4 - Airbag adapter power supply connector (red)

Scheme 191

Disconnecting plug for side airbag

1. Press tab - 3 - for side airbag connector - 2 - from Airbag connector - 1 - and disconnect connector.

Note. When connecting the battery observe the necessary measures. --> 27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL 27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL for ELECTRICAL EQUIPMENT, CABRIOLET If Airbag Malfunction Indicator Lamp (MIL) K75 signals a malfunction after assembly, use vehicle diagnostic, testing and information system VAS 5051 A to interrogate, erase and then again interrogate DTC memory.

Front seat backrest, assembly overview

Special tools and workshop equipment required

1. Torque wrench V.A.G 1331

Scheme 192

1 - Backrest

1. Removing

1. Remove seat --> «Seat, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__seat-assembly-overview) .
2. Attach fixture for seat repair VAS 6136 to engine and transmission holder VAS 6095.
3. Attach front seat to future for seat repair VAS 6136.
4. Remove backrest adjuster --> «Backrest adjuster, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__backrest-adjuster-removing-and-installing) .

1. Remove seat height adjuster --> «Seat height adjuster, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
2. Remove side trim on sill panel side --> «Side trim on sill panel side, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__side-trim-on-sill-panel-side) .
3. Remove side trim on tunnel side --> «Side trim on tunnel side, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__side-trim-on-tunnel-side-removing) .
4. Disconnect connectors - 7 - (3x).

1. Remove cables at mounting rails.
2. Remove bolts -2- (4x).
3. Tilt backrest - 1 - forward onto seat.
4. Press cushion aside and carefully pull wiring harness out of seat pan - 8 -.

1. Remove backrest - 1 -.

1. Installing

1. Replace bolts - 2 - (4x).
2. Before inserting bolts - 2 - (4x) recut the thread in the backrest frame.
3. Install backrest - 1 - in reverse order of removal.

2 - Bolts (4x)

1. Tightening torque 20 Nm

3 - Backrest adjuster

4 - Plastic rivet (2x)

5 - Seat height adjuster

6 - Side trim, sill panel side

7 - Connector (3x)

8 - Seat pan

9 - Side trim, tunnel side

10 - Plastic rivet (2x)

Side trim on sill panel side, removing and installing

1 - Backrest

2 - Bolts (4x)

3 - Backrest adjuster

4 - Plastic rivet (2x)

1. Always replace

5 - Seat height adjuster

6 - Side trim, sill panel side

1. Removing

1. Remove seat --> «Seat, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__seat-assembly-overview) .
2. Attach fixture for seat repair VAS 6136 to engine and transmission holder VAS 6095.
3. Attach front seat to fixture for seat repair VAS 6136.
4. Remove backrest adjuster --> «Backrest adjuster, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__backrest-adjuster-removing-and-installing) .

1. Remove seat height adjuster --> «Seat height adjuster, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
2. Apply screwdriver to head of plastic rivet - 4 -.
3. Twist screwdriver and pry out plastic rivet - 4 -.
4. Release second plastic rivet - 4 -.

1. Remove side trim on sill panel side - 6 -.

1. Installing

1. Install side trim on sill panel side - 6 - in reverse order of removal.

7 - Connector (3x)

8 - Seat pan

9 - Side trim, tunnel side

10 - Plastic rivet (2x)

Scheme 193

1 - Seat height adjuster

1. Removing

1. Remove seat --> «Seat, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__seat-assembly-overview) .
2. Attach fixture for seat repair VAS 6136 to engine and transmission holder VAS 6095.
3. Attach front seat to fixture for seat repair VAS 6136.
4. Make improvised tool --> «Making improvised tool for removing seat height adjuster»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet)

1. Pull seat height adjuster - 1 - slightly off seat.
2. Insert improvised tool - 2 - in mount - 4 -.
3. Pull improvised tool - 2 - in direction of arrow - A - to press spring - 3 - outward.
4. Remove seat height adjuster - 1 - in direction of arrow - B -.

1. Installing

1. Make sure clip is attached to lever of seat height adjuster. Observe installation position --> «Installation position of clip»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet)
2. Install seat height adjuster - 1 - in reverse order of removal.

2 - Improvised tool

3 - Spring

4 - Mount

Scheme 194

1. Bend screwdriver - 1 - with a width - 2 - of 3.5 mm to form dimensions - A - 20 mm and - B - max. 15 mm.

Scheme 195

1. Make sure springs - 2 - (2x) of clip - 3 - are positioned on outside of lever - 1 -.

Backrest adjuster, removing and installing

Special tools and workshop equipment required

Scheme 196

1. Assembly tool 3399
2. Removing

Scheme 197

1. Turn backrest adjuster - 1 - until detent is visible from rear - arrow A -. Use light, if necessary.
2. Hook in assembly tool 3399 - 2 - and lever in direction of arrow - B -.
3. Turn backrest adjuster - 1 - an additional 120° turn.
4. Hook in special tool 3399 - 2 - and lever in direction of arrow - B -.

1. Detach backrest adjuster - 1 -.

1. Installing

Note. After installing backrest adjuster, replace if it is too loose.

Side trim on tunnel side, removing and installing

1 - Backrest

2 - Bolts (4x)

3 - Backrest adjuster

4 - Plastic rivet (2x)

5 - Seat height adjuster

6 - Side trim, sill panel side

7 - Connector (3x)

8 - Seat pan

9 - Side trim, tunnel side

1. Removing

1. Remove seat --> «Seat, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__seat-assembly-overview) .
2. Attach fixture for seat repair VAS 6136 to engine and transmission holder VAS 6095.
3. Attach front seat to fixture for seat repair VAS 6136.
4. Apply screwdriver to head of plastic rivet - 10 -.

1. Twist screwdriver and pry out plastic rivet - 10 -.
2. Release second plastic rivet - 10 -.
3. Remove side trim on tunnel side - 9 -.

1. Installing

1. Install side trim on tunnel side - 9 - in reverse order of removal.

10 - Plastic rivet (2x)

1. Always replace

Seat height adjuster unit, removing and installing

Special tools, workshop equipment, testers, measuring instruments and other items required

Torque wrench V.A.G 1410

Scheme 198

1 - Seat height adjuster lever

2 - Seat height adjuster unit

1. Removing

1. Remove seat --> «Seat, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__seat-assembly-overview) .
2. Attach fixture for seat repair VAS 6136 to engine and transmission holder VAS 6095.
3. Attach front seat to fixture for seat repair VAS 6136.
4. Remove backrest adjuster --> «Backrest adjuster, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__backrest-adjuster-removing-and-installing) .

1. Remove seat height adjuster --> «Seat height adjuster, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
2. Remove side trim on sill panel side --> «Side trim on sill panel side, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__side-trim-on-sill-panel-side) .
3. Remove bolt - 3 -.
4. Remove bolts - 5 - (2x).

1. Remove seat height adjuster unit - 2 - and retainer - 4 -.

1. Installing

1. Install seat height adjuster unit - 2 - in reverse order of removal.
2. Make sure retainer - 4 - makes contact with seat pan - arrow -.
3. Make sure clip is attached to lever of seat height adjuster - 2 -. Observe installation position --> «Installation position of clip»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet)

3 - Bolt

1. Tightening torque 8 Nm

4 - Retainer

5 - Bolts (2x)

1. Tightening torque 8 Nm

Scheme 199

1 - Bowden cable of seat height adjuster unit

1. Removing

1. Remove seat --> «Seat, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__seat-assembly-overview) .
2. Attach fixture for seat repair VAS 6136 to engine and transmission holder VAS 6095.
3. Attach front seat to fixture for seat repair VAS 6136.
4. Remove side trim on sill panel side --> «Side trim on sill panel side, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__side-trim-on-sill-panel-side) .

1. Remove side trim on tunnel side --> «Side trim on tunnel side, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__side-trim-on-tunnel-side-removing) .
2. Remove backrest --> «Front seat backrest, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__front-seat-backrest-assembly-overview) .
3. Remove Bowden cable - 1 - from holder - 2 -.
4. Remove tab - 4 - from pin - 3 -.

1. Remove Bowden cable - 1 - from holder - 5 -.
2. Remove Bowden cable at hook - 7 - from holder - 6 -.

1. Installing

1. Install Bowden cable of seat height adjuster unit - 1 - in reverse order of removal.

2 - Holder

3 - Pin

4 - Tab

5 - Holder

6 - Holder

7 - Hook

Scheme 200

1 - Lever

2 - Pins (2x)

3 - Easy-entry facility (manual)

1. Removing

1. Move front seat forward as far as possible.
2. Remove seat --> «Seat, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__seat-assembly-overview) .
3. Drill out rivet - 4 - at runner - 5 - and take out metal holders (2x) on inside of runner - 5 -.
4. Press lever - 1 - until pins - 2 - (2x) are in runner - 5 - and pull runner - 5 - to rear in direction of - arrow -.

1. Remove easy-entry facility - 3 -.

1. Installing

1. Guide easy-entry facility into runner «Guiding easy-entry facility into runner»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet)
2. Installing easy-entry facility - 3 - in reverse order of removal.

4 - Rivet

5 - Runner

6 - Handle for length adjustment

Scheme 201

1. Guide easy-entry facility - 2 - into runner - 3 -.
2. Press lever - 1 - and slide easy-entry facility - 2 - forward.

Scheme 202

1 - Handle

2 - Storage compartment

1. Removing

1. Remove seat --> «Seat, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__seat-assembly-overview) .
2. Attach fixture for seat repair VAS 6136 to engine and transmission holder VAS 6095.
3. Attach front seat to fixture for seat repair VAS 6136.
4. Pull handle - 1 - out storage compartment - 2 -.

1. Remove bolts - 3 - (2x).
2. Remove bolts - 4 - (2x).
3. Remove storage compartment - 2 -.

1. Installing

1. Install storage compartment - 2 - in reverse order of removal.

3 - Bolts (2x)

4 - Bolts (2x)

Scheme 203

1 - Front seat

2 - Clips (3x)

3 - Holders (2x)

4 - Backrest cover panel

1. Removing

1. Unclip clips - 3 - (3x) by inserting a flat screwdriver in clip and turning screwdriver clockwise until clip is released.
2. Remove backrest cover panel - 4 - upward from holders - 3 - (2x).

1. Installing

1. Replace damaged clips - 2 - (3x).
2. Install backrest cover panel - 4 - in reverse order of removal.

Scheme 204

1 - Front seat

2 - Clips (2x)

3 - Outer frame

1. Removing

1. Remove backrest cover panel --> «Backrest cover panel, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
2. Pry out staples - 8 - (4x) on left and right.
3. Remove velcro strips - 7 - (4x) on left and right.
4. Disengage piping on side - 9 - (2x).

1. Pry out piping at bottom - 6 - (3x).
2. Pry out clips - 4 - (3x).
3. Pry out clips - 2 - (2x).
4. Remove outer frame - 3 - from backrest frame.

1. Installing

1. Lock outer frame - 3 - at holders - 5 - (2x) in backrest frame.
2. Install outer frame - 3 - in reverse order of removal.

4 - Clips (3x)

5 - Holders (2x)

6 - Bottom piping (3x)

7 - Velcro strips (4x)

8 - Staples (4x)

1. Commercially available.
2. Only use upholstery stapler.

9 - Side piping (2x)

Easy-entry facility handle, removing and installing

1. Removing

Scheme 205

1. Press handle - 1 - upward.
2. Use screwdriver to pry tab - 3 - out of metal pin - 2 - and at the same time detach handle - 1 -.

1. Installing

1. Install easy-entry facility handle - 1 - in reverse order of removal.

Note. In order to be able to press in the handle, the metal pin in the cover plate aperture must be pushed upward with a screwdriver.

Removing and installing easy-entry facility trim

1. Removing

Scheme 206

1. Use flat screwdriver to pry out trim - 1 -.

1. Installing

1. Install easy-entry facility trim - 1 - in reverse order of removal.

Scheme 207

1 - Holder

2 - Holder

3 - Bowden cable adjusters (2x)

4 - Bowden cables for backrest lock (2x)

1. Removing

1. Remove seat --> «Seat, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__seat-assembly-overview) .
2. Attach fixture for seat repair VAS 6136 to engine and transmission holder VAS 6095.
3. Attach front seat to fixture for seat repair VAS 6136.
4. Remove backrest --> «Front seat backrest, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__front-seat-backrest-assembly-overview) .

1. Remove backrest cover panel --> «Backrest cover panel, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
2. Pry out staples - 10 - (4x) on left and right.
3. Remove velcro strips - 9 - (4x) on left and right.
4. Detach piping on side - 5 - (2x).

1. Pry out piping at bottom - 8 - (3x).
2. Use pliers to disengage tabs -7- (2x) at bottom left and right.
3. Use screwdriver to pry Bowden cables out of mounts -6- (2x) on left and right.
4. Remove Bowden cables -4- (2x) upward.

1. Push cover - 11 - upward in direction of - arrow -.
2. Detach Bowden cables at holders -1- and -2-.

1. Installing

1. Install Bowden cables for backrest lock in reverse order of removal.
2. Set Bowden cables -4- (2x) with adjusters -3- (2x). Make sure pins at bottom left and right are released simultaneously on actuating easy-entry facility handle - 12 -.

5 - Side piping (2x)

6 - Mounts (2x)

7 - Tabs (2x)

8 - Bottom piping (3x)

9 - Velcro strips (4x) on left and right

10 - Staples (4x) on left and right

1. Commercially available.
2. Only use upholstery stapler.

11 - Cover

12 - Handle of easy-entry facility

Scheme 208

1 - Mount

2 - Backrest frame

3 - Clip

4 - Side airbag guide

1. Removing

1. Remove seat --> «Seat, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__seat-assembly-overview) .
2. Remove backrest cover panel --> «Backrest cover panel, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
3. Remove side airbag --> «Side airbag (sports seat, standard seat), removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__side-airbag-sports-seat-standard-seat) .
4. Press clip -3- together from inside of backrest frame - 2 -.

1. Pry out mount -1- from inside.
2. Remove side airbag guide -4-.

1. Installing

1. Install in reverse order of removal.

Head restraint with slide-in locking mechanism, removing and installing

1. Removing

Scheme 209

1. Press button - 2 -.
2. Remove head restraint - 1 -.

Scheme 210

1. Use screwdriver to pry rear footwell light - 1 - out of backrest cover panel on one side.
2. Disconnect rear footwell light connector - 2 -.

Special tools, workshop equipment, testers, measuring instruments and other items required

Airbag adapter VAS 6036

Front seat, assembly overview

Note. Before disconnecting the battery: obtain the radio code.

Scheme 211

1 - Front seat

1. Removing

1. Remove front seat rail covers --> «Front seat rail cover, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
2. Remove rear seat rail covers --> «Rear seat rail cover, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
3. Move front seat - 1 - up and back as far as possible.
4. Remove front bolts - 2 - (2x).

1. Move seat forward.
2. Remove rear bolts - 2 - (2x).

1. Tilt front seat - 1 - back.
2. Disconnect connectors --> «Connectors, disconnecting»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
3. Connect airbag adapter --> «Airbag adapter VAS 6036 , connecting»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .

1. Installing

1. Installation is in reverse order of removal.

2 - Bolts (4x)

1. Tightening torque 40 Nm

Front seat with faulty forward and backward seat adjustment motor or defective control unit, removing and installing

Note. If possible: Move seat up. For greater clarity, the illustration shows the seat pan without padding or backrest.

Scheme 212

1 - Bolts (4x)

1. Tightening torque 17 Nm

2 - Motor retaining plate

3 - Bolts (2x)

1. Tightening torque 19 Nm

4 - Upper seat pan support

1. Removing

1. Remove bolts - 3 - (2x).
2. Fold seat forwards.
3. Remove bolts - 1 - (4x).
4. Remove backrest with top support of seat pan.

1. For faulty control unit

1. Disconnect connector at forward and backward seat adjustment motor.
2. Move the forward and backward seat adjustment motor with an external power source until the bolts are visible.
3. Remove bolts.
4. Remove control unit --> «Control unit, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__control-unit-removing-and-installing) .

1. For faulty forward and backward seat adjustment motor

1. Disconnect connector - 3 -.
2. Remove bolts - 4 - (2x) from forward and backward seat adjustment motor.
3. Disengage forward and backward seat adjustment motor - 2 - from the two shafts - 1 - and - 5 -.
4. Move both seat rails using a power screwdriver via the long shaft -5-, until the concealed bolts are visible.

1. Remove bolts.
2. Replace the lower seat support with forward and backward seat adjustment motor.

Scheme 213

1 - Front seat

2 - Seat rail covers (2x)

1. Removing

1. Move front seat - 1 - back as far as possible.
2. Remove securing clips - 3 - (2x).
3. Remove seat rail covers - 2 - (2x).

1. Installing

1. Install in reverse order of removal.

3 - Securing clips (2x)

Scheme 214

1 - Front seat

2 - Securing clips (4x)

3 - Seat rail covers (3x)

1. Removing

1. Move front seat - 1 - forward as far as possible.
2. Remove securing clips - 2 - (4x).
3. Remove seat rail covers - 3 - (3x).

1. Installing

1. Installation is in reverse order of removal.

Connectors, disconnecting

Note. The mechanic must electrostatically discharge him/herself before disconnecting ignition and ground (GND) wires (briefly touch closing wedge for door or body).

Scheme 215

1 - Front seat

2 - Buckle interrogation connector (black)

3 - Seat heating connector (green)

4 - Power supply connector (red)

5 - Airbag connector (yellow)

6 - Connector point cover

1. Removing

1. Tilt front seat - 1 - back.
2. Remove connection point cover - 6 - upward.
3. Press tab on airbag connector - 5 - inboard side and remove airbag connector - 5 -.
4. Connect airbag adapter --> «Airbag adapter VAS 6036 , connecting»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .

1. Press tab on power supply connector - 4 - inboard side and remove power supply connector - 4 -.
2. Press tab on seat heating connector - 3 - inboard side and remove seat heating connector - 3 -.
3. For vehicles with buckle interrogation: Press in tab on buckle interrogation connector - 2 - inboard side and remove buckle interrogation connector - 2 -.

Scheme 216

Note. The mechanic must electrostatically discharge him/herself before disconnecting ignition and ground (GND) wires (briefly touch closing wedge for door or body).

1 - Seat connector power supply connector (red)

2 - Airbag adapter power supply connector (red)

3 - Airbag adapter connector (yellow)

4 - Airbag connector (yellow)

1. Disconnect ignition and Ground (GND) wires.
2. Connect airbag connector - 4 - to airbag adapter connector - 3 -.
3. If present: Connect the airbag adapter power supply connector - 2 - to the seat connector power supply connector - 1 -.

Connector assignment for connection point

Note. Arrow points in direction of travel.

Scheme 217

1. 1 Side airbag
2. 2 Power supply
3. 3 Seat heating
4. 4 Buckle interrogation

Connector for side airbag, disconnecting

1. Press retainer tab - 3 - of airbag connector - 2 - out of airbag adapter connector - 1 - and disconnect airbag connector - 2 -.

Note. After connecting the battery observe the necessary measures. --> 27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL 27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL for ELECTRICAL EQUIPMENT, CABRIOLET If airbag malfunction warning light K75 signals a malfunction after assembly, use vehicle diagnostic, testing and information system VAS 5051 A to interrogate, erase and then again interrogate DTC memory.

Scheme 218

1 - Backrest

1. Removing

1. Remove seat --> «Seat, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__seat-assembly-overview) .
2. Attach fixture for seat repair VAS 6136 to engine and transmission holder VAS 6095.
3. Attach front seat to fixture for seat repair VAS 6136.
4. Remove side trim, outboard side --> «Side trim on sill panel side, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__side-trim-on-sill-panel-side) .

1. Remove side trim, inboard side --> «Side trim, inboard side, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__side-trim-inboard-side-assembly-overview) .

2 - Wiring harness

3 - Bolts (4x)

1. Tightening torque 20 Nm

4 - Plastic washer

5 - Bracket

6 - Bolt

7 - Clip

8 - Seat pan

Scheme 219

1 - Cable ties (2x)

1. Open cable ties - 1 - (2x).
2. Detach rubber straps - 2 - (2x).
3. Disconnect connectors - 5 - (4x).
4. Remove cable tie - 3 - on wiring harness.

1. Detach adhesive strips on mounting rails - 4 - (5x).

2 - Rubber straps (2x)

3 - Cable tie

4 - Mounting rails (5x)

5 - Connectors (4x)

1 - Backrest

1. Removing

1. Remove bolt - 6 -.
2. Twist clip - 7 - upward.
3. Remove bolts - 3 - (4x).
4. Tilt backrest - 1 - forwards onto seat.

1. Move padding to one side and carefully lift wiring harness - 2 - out of seat pan - 8 -.
2. Remove backrest - 1 -.

1. Installing

1. To instal clip - 5 - : Secure bolt - 6 - firmly to plastic washer - 4 -.
2. Always use new bolts - 3 - (4x).
3. Before inserting bolts - 3 - (4x) recut the thread in the backrest frame.
4. For memory seat: After installing seat in vehicle perform basic setting of backrest and seat.

2 - Wiring harness

3 - Bolts (4x)

1. Tightening torque 20 Nm

4 - Plastic packing plate

5 - Bracket

6 - Bolt

7 - Clip

8 - Seat pan

Scheme 220

1 - Backrest

2 - Bolts (4x)

3 - Rear side trim, outboard side

4 - Front side trim, outboard side

1. Removing

1. Remove seat --> «Seat, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__seat-assembly-overview) .
2. Remove bolts - 2 - (4x).
3. Remove rear side trim - 3 - upward.
4. Remove front side trim - 4 - forward.

1. Disconnect connectors - 5 - (3x).

5 - Connector (3x)

6 - Side trim, inboard side

7 - Bolts (2x)

8 - Rubber strap of backrest cover

Side trim, inboard side, assembly overview

1 - Backrest

2 - Bolts (4x)

3 - Rear side trim, outboard side

4 - Front side trim, outboard side

5 - Connector (3x)

6 - Side trim, inboard side

1. Removing

1. Remove seat --> «Seat, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__seat-assembly-overview) .
2. Disengage rubber strap of backrest cover - 8 -.
3. Remove bolts - 7 - (2x).
4. Remove side trim - 6 - upward.

7 - Bolts (2x)

8 - Rubber strap of backrest cover

Easy-entry facility, removing and installing

1. Removing

Scheme 221

1. Press handle - 1 - upward.
2. Release tab - 2 - in direction of - arrow - using a screwdriver and, at the same time, pull off handle - 1 -.

Scheme 222

1. Unclip cover plate - 1 -.
2. Disconnect connector - 3 -.
3. Remove cover plate - 1 -.

1. Installing

Note. In order to be able to press in the handle, the metal pin in the cover plate aperture must be pushed upward with a screwdriver.

1. Install easy-entry facility in reverse order of removal. Make sure handle - 2 - engages.

Bowden cable for backrest lock, assembly overview

Note. For the sake of illustration, the seat is depicted without seat pan in the illustration.

Scheme 223

1 - Adjustment devices for Bowden cable (2x)

2 - Bowden cable for backrest lock (2x)

1. Removing

1. Remove seat --> «Seat, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__seat-assembly-overview) .
2. Attach fixture for seat repair VAS 6136 to engine and transmission holder VAS 6095.
3. Attach front seat to fixture for seat repair VAS 6136.
4. Remove backrest panel --> «Backrest cover panel, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .

1. Operate the Easy Entry handle of entry assistance and fold backrest forward.
2. Disengage eyelets - 4 - (2x) at bottom left and right, using pliers.
3. Using a screwdriver, pry out left and right retainers - 3 - (2x).
4. Remove Bowden cables - 2 - (2x) upward.

1. Slide seat cover upward in direction of - arrow -.
2. Disengage Bowden cables at brackets - 5 - and - 6 -.

1. Installing

Note. For vehicles up to 05.02, VIN: 8H 3K 002 450: To prevent malfunctions of headrest and seatback adjustment, apply a cable tie - 7 -.

1. Install Bowden cable for backrest lock in reverse order of removal.
2. Adjust Bowden cables - 1 - (2x) using adjustment devices - 2 - (2x). Ensure that the lower pins at left and right are released simultaneously when the Easy Entry handle of entry assistance is operated.

3 - Retainers (2x)

4 - Eyelets (2x)

5 - Bracket

6 - Bracket

7 - Cable tie

Scheme 224

1 - Cable tie

2 - Connector

3 - Circlip

4 - Microswitch for seatback release

1. Removing

1. Remove seat --> «Seat, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__seat-assembly-overview) .
2. Attach fixture for seat repair VAS 6136 to engine and transmission holder VAS 6095.
3. Attach front seat to fixture for seat repair VAS 6136.
4. Remove door sill side seat trim --> «Side trim on sill panel side, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__side-trim-on-sill-panel-side) .

1. Remove tunnel side seat trim --> «Side trim, inboard side, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__side-trim-inboard-side-assembly-overview) .
2. Remove backrest --> «Front seat backrest, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__front-seat-backrest-assembly-overview) .
3. Remove backrest panel --> «Backrest cover panel, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
4. Remove backrest frame --> «Backrest frame, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__backrest-frame-assembly-overview) .

1. Remove backrest cover and cushion --> «Backrest cover and padding (sports seat, standard seat), removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__backrest-cover-and-padding-sports-seat) .
2. Use a screwdriver to pry out circlip - 3 -.
3. Press together catches - 5 - (2x) and remove microswitch - 4 -.
4. Disconnect connector - 2 -.

1. Installing

1. Press in microswitch - 4 - until the catches - 5 - (2x) engage.
2. Connect connector - 2 -.
3. Install backrest cover and cushion g --> «Backrest cover and padding (sports seat, standard seat), removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__backrest-cover-and-padding-sports-seat) .
4. Install backrest --> «Front seat backrest, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__front-seat-backrest-assembly-overview) .

1. Install seat --> «Seat, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__seat-assembly-overview) .
2. Adjust microswitch for seatback release --> «Microswitch for seatback release, adjusting»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__microswitch-for-seatback-release-adjusting) .
3. Insert the circlip - 3 -.
4. Install backrest frame --> «Backrest frame, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__backrest-frame-assembly-overview) .

1. Install backrest panel --> «Backrest cover panel, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .

5 - Catches (2x)

Microswitch for seatback release, adjusting

Note. For vehicles up to 05.02, VIN: 8H 3K 002 450: To prevent malfunctions of headrest and seatback adjustment, apply a cable tie - 1 -.

1 - Cable tie

2 - Connector

3 - Circlip

4 - Microswitch for seatback release

1. Adjusting and checking function

1. Remove backrest panel --> «Backrest cover panel, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
2. Use a screwdriver to pry out circlip - 3 -.
3. Slide microswitch - 4 - only far enough so that backrest is switched off when release lever is lifted 1/3.
4. Check backrest function at adjustment switch

1. Backrest is not activated when backrest release lever is lifted to 1/3.
2. Backrest is activated when release lever is in rest position.
3. Correct the position of microswitch - 4 - as necessary and check its function again.

5 - Catches (2x)

Scheme 225

1 - Cable tie

2 - Connector

3 - Circlip

4 - Microswitch for headrest

1. Removing

1. Remove backrest panel --> «Backrest cover panel, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
2. Use a screwdriver to pry out circlip - 3 -.
3. Press together catches - 5 - (2x) and remove microswitch - 4 -.
4. Disconnect connector - 2 -.

1. Installing

1. Press in microswitch - 4 - until the catches - 5 - (2x) engage.
2. Connect connector - 2 -.
3. Install seat --> «Seat, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__seat-assembly-overview) .
4. Adjust microswitch for headrest --> «Microswitch for headrest, adjusting»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__microswitch-for-headrest-adjusting) .

1. Insert the circlip - 3 -.
2. Install backrest panel --> «Backrest cover panel, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .

5 - Catches (2x)

Microswitch for headrest, adjusting

Note. For vehicles up to 05.02, VIN: 8H 3K 002 450: To prevent malfunctions of headrest and seatback adjustment, apply a cable tie - 1 -.

1 - Cable tie

2 - Connector

3 - Circlip

4 - Circlip

1. Adjusting and checking function

1. Remove backrest panel --> «Backrest cover panel, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .
2. Use a screwdriver to pry out circlip - 3 -.
3. Slide microswitch - 4 - only far enough so that headrest is moved downward and switched off when release lever is lifted 1/3.
4. Check function of headrest at adjustment switch

1. Headrest is not activated when backrest release lever is lifted to 1/3.
2. Headrest is activated when release lever is in rest position.
3. Correct the position of microswitch - 4 - as necessary and check its function again.

5 - Catches (2x)

Backrest (standard seat), replacing

Note. Sports backrest only is available as replacement part. Convert the sports backrest for the standard seat.

Scheme 226

1 - Sports backrest

1. Conversion

1. Detach wire clips - 2 - (2x) from sports seat backrest - 1 -.
2. Paint layer must be replicated and, if necessary, the protection measures against corrosion must be performed.

2 - Wire clips (2x)

Seat pan (standard seat), replacing

Note. Sports seat pan only is available as replacement part. Convert the sports seat pan for the standard seat.

Scheme 227

1 - Sports seat pan

1. Conversion

1. Detach wire clips - 2 - (2x) from sports seat pan - 1 -.
2. Paint layer must be replicated and, if necessary, the protection measures against corrosion must be performed.

2 - Wire clips (2x)

Scheme 228

1 - Guide for side airbag

1. Removing

1. Remove seat --> «Seat, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__seat-assembly-overview) .
2. Attach fixture for seat repair VAS 6136 to engine and transmission holder VAS 6095.
3. Attach front seat to fixture for seat repair VAS 6136.
4. Remove backrest cover panel --> «Backrest cover panel, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet) .

1. Remove side airbag --> «Side airbag (electric seat), assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__side-airbag-electric-seat-assembly-overview) .
2. Press clip - 3 - together and remove clip - 3 -.
3. Pry out the retainer - 2 - from inside.
4. Detach the side airbag guide - 1 -.

1. Installing

1. Installation is in reverse order of removal.

2 - Retainer

3 - Clip

Seat adjustment switch, removing and installing

1. Removing

Scheme 229

1. Remove seat --> «Seat, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__seat-assembly-overview) .
2. Remove seat side trim, outboard side --> «Side trim on sill panel side, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__side-trim-on-sill-panel-side) .
3. Remove bolts - 5 - (5x). Tightening torque 1.5 Nm
4. Detach seat adjustment switch - 2 -.

1. Remove the connection board with connectors - 1 -.

1. Installing

1. Installation is in reverse order of removal.

Switch for 4-way lumbar support, removing and installing

1. Removing

1. Remove seat --> «Seat, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__seat-assembly-overview) .
2. Remove seat side trim, outboard side --> «Side trim on sill panel side, removing and installing»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__side-trim-on-sill-panel-side) .
3. Remove bolts - 4 - (2x). Tightening torque 0.4 Nm
4. Detach switch for 4-way lumbar support - 3 -.

1. Installing

1. Installation is in reverse order of removal.

Control unit, removing and installing

Note. The control unit for the memory seat and the electric seat is under the drivers seat. If the control unit is defective, the top support of the seat pan and backrest must be removed --> Front seat with faulty forward and backward seat adjustment motor or defective control unit, removing and installing .

Scheme 230

1. Remove seat --> «Seat, assembly overview»(/audi/s4/b7-2004-2008/remont/gauges-instrument-panels/#body-interior-cabriolet__seat-assembly-overview) .
2. Remove bolts - 2 - (2x). Tightening torque 1.5 Nm
3. Turn control unit - 1 - over.

Scheme 231

1. Disengage retaining clip - 4 - and disconnect connector - 5 -.
2. Press retainer tabs - 3 - (2x) and disconnect connector - 2 -.
3. Remove control unit - 1 -.

1. Installing

1. Installation is in reverse order of removal.

Forward and backward seat adjustment motor, assembly overview

Note. If the motor is faulty, the top support of the seat pan must be replaced --> Front seat with faulty forward and backward seat adjustment motor or defective control unit, removing and installing .

Scheme 232

1 - Lumbar support adjustment motors (2x)

2 - Seat height adjustment motor
