Door window, adjusting Audi S4 B7

Door window, adjusting

Special tools, testers and auxiliary items required

1. Masking tape

Scheme 343

Window immersion depth, determining

1. Close convertible top.

1. Raise window.
2. Tape masking tape - arrows - overlapping on window with door open.
3. Close door completely.

1. Dimension - a - = 80 mm.
2. Dimension - b - = 40 mm.

Scheme 344

Note. Raise convertible top fabric - 1 - in place.

1. Apply a marking - arrow - to making tape at front and back directly below roof frame seal.
2. Open door.
3. Measure distance between marking and upper end of window.

1. Front immersion depth: max. 5 mm.
2. Rear immersion depth: max. 7 mm.

Scheme 345

Window immersion depth, adjusting

1. Lower window.
2. Remove front and rear rubber stops - arrow - at bottom of door.
3. Insert a thin 5 mm hex socket head wrench through opening on door.

1. Door seal - 1 - does not need to be removed to insert hex socket head wrench.

1. Adjust front and rear window immersion depth by evenly turning both lifting units.

1. Turn right = greater immersion depth.
2. 1 turn corresponds to approx. 1.2 mm.

1. Seal off openings with rubber plugs.
2. Raise window and measure change.
3. Ensure window is parallel to side window, adjust if necessary --> «Side window, adjusting»(/audi/s4/b7-2004-2008/remont/door-locks-anti-theft-systems/#body-exterior-cabriolet__side-window-adjusting) .

Scheme 346

1 - Lower A-pillar

2 - Screw

1. 32 Nm

3 - Screw

1. 32 Nm
2. Installed from vehicle interior.

4 - Bottom door hinge

1. Two-part
2. Mark hinge location before removal.

5 - Pop rivet

1. Qty. 2

6 - Backing

7 - Impact member mount

8 - Front door

9 - Screw

1. 32 Nm

Scheme 347

1. Bolt (installed from inside of vehicle) (32 Nm)
2. Upper door hinge
3. Cover cap
4. Screw (32 Nm)
5. Screw (32 Nm)

Scheme 348

Note. Panel gap dimensions can be checked with Adjusting Gauge 3371. Dimension - a - = 3.5 mm ± 0.5 mm. Dimension - b - = 3.5 mm ± 0.5 mm. Dimension - c - = 5.0 mm ± 1 mm.

Scheme 349

1 - Door handle mount

1. Removing --> «Door handle, removing and installing»(/audi/s4/b7-2004-2008/remont/door-locks-anti-theft-systems/#body-exterior-cabriolet__door-handle-removing-and-installing) .

2 - Door handle

1. Removing --> «Door handle, removing and installing»(/audi/s4/b7-2004-2008/remont/door-locks-anti-theft-systems/#body-exterior-cabriolet__door-handle-removing-and-installing) .

3 - Door handle trim

1. Removing --> «Door handle trim, removing and installing»(/audi/s4/b7-2004-2008/remont/door-locks-anti-theft-systems/#body-exterior-cabriolet__door-handle-trim-removing-and-installing) .

4 - Lock cylinder

1. Assembly overview --> «Lock cylinder - assembly overview»(/audi/s4/b7-2004-2008/remont/door-locks-anti-theft-systems/#body-exterior-cabriolet) .
2. Removing --> «Lock cylinder, removing and installing»(/audi/s4/b7-2004-2008/remont/door-locks-anti-theft-systems/#body-exterior-cabriolet__lock-cylinder-removing-and-installing) .

5 - Lock cylinder cover

1. To remove, remove lock cylinder and unclip cover.

6 - Screw

1. 20 Nm

7 - Operating rod

1. Clip into door lock «Engaging operating rod in door lock»(/audi/s4/b7-2004-2008/remont/door-locks-anti-theft-systems/#body-exterior-cabriolet)

8 - Door lock

1. Assembly overview up to model year 2005 --> «Door lock (up to model year 2005) - assembly overview»(/audi/s4/b7-2004-2008/remont/door-locks-anti-theft-systems/#body-exterior-cabriolet) .
2. Assembly overview from model year 2006 --> «Door lock (from model year 2006) - assembly overview»(/audi/s4/b7-2004-2008/remont/door-locks-anti-theft-systems/#body-exterior-cabriolet) .
3. Removing, up to model year 2005 --> «Door lock (up to model year 2005) - assembly overview»(/audi/s4/b7-2004-2008/remont/door-locks-anti-theft-systems/#body-exterior-cabriolet) .
4. Removing, from model year 2006 --> «Door lock (from model year 2006), removing and installing»(/audi/s4/b7-2004-2008/remont/door-locks-anti-theft-systems/#body-exterior-cabriolet__door-lock-from-model-year-2006) .

Scheme 350

1 - Cover cap

1. Pry out

2 - Securing bracket

1. Engages in groove on lock cylinder.

3 - Door handle

1. Removing --> «Door handle, removing and installing»(/audi/s4/b7-2004-2008/remont/door-locks-anti-theft-systems/#body-exterior-cabriolet__door-handle-removing-and-installing) .

4 - Lock cylinder

1. Removing --> «Lock cylinder, removing and installing»(/audi/s4/b7-2004-2008/remont/door-locks-anti-theft-systems/#body-exterior-cabriolet__lock-cylinder-removing-and-installing) .

5 - Lock cylinder cover cap

1. Removing --> «Lock cylinder cover cap, removing and installing»(/audi/s4/b7-2004-2008/remont/door-locks-anti-theft-systems/#body-exterior-cabriolet__lock-cylinder-cover-cap-removing-and) .
