Front heated seats circuit, w/ ventilation for Audi RS7 II (2019-2024)

BLK/YEL WIRE BRN WIRE COMPUTER DATA LINES SYSTEM COUPLING STATION IN LEFT FRONT SEAT DRIVER BACKREST HEATING ELEMENT DRIVER SEAT BOLSTER HEATER DRIVER SEAT COUPLING POINT DRIVER SEAT HEATING ELEMENT FRONT INFORMATION DISPLAY CONTROL HEAD FUSE 1 FUSE 10 FUSE PANEL D (LEFT KICK PANEL) FUSE PANEL E (LEFT KICK PANEL) GRN WIRE HOT AT ALL TIMES HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED LEFT FRONT SEAT TEMPERATURE SENSOR LEFT SEAT HEATING BUTTON ORG/BRN WIRE PNK WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRY WIRE RED/VIO WIRE RED/YEL WIRE RIGHT SEAT HEATING BUTTON VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO/BLU WIRE WHT WIRE WHT/VIO WIRE WHT/YEL WIRE YEL WIRE

BLK/YEL WIRE BRN WIRE BRN/YEL WIRE COUPLING STATION IN RIGHT FRONT SEAT DRIVER SEAT BACKREST COUPLING POINT DRIVER SEAT COUPLING POINT FRONT PASSENGER BACKREST HEATING ELEMENT FRONT PASSENGER SEAT BACKREST COUPLING POINT FRONT PASSENGER SEAT BOLSTER HEATER FRONT PASSENGER SEAT COUPLING POINT FRONT PASSENGER SEAT HEATING ELEMENT GRN WIRE LEFT FRONT SEAT BACKREST FAN 1 LEFT FRONT SEAT CUSHION FAN 1 RED WIRE RED/BLK WIRE RED/VIO WIRE RED/YEL WIRE RIGHT FRONT SEAT BACKREST FAN 1 RIGHT FRONT SEAT CUSHION FAN 1 RIGHT FRONT SEAT TEMPERATURE SENSOR SEAT OCCUPANT DETECTION SYSTEM CONTROL MODULE VIO/BLU WIRE VIO/WHT WIRE W/ MEMORY W/O MEMORY WHT WIRE WHT/VIO WIRE YEL WIRE
