Headlights circuit, w/ led & matrix beam for Audi RS3 8V facelift (2017-2021)

BLK WIRE BLK/GRN WIRE BLK/VIO WIRE BLU WIRE BLU/WHT WIRE BRN WIRE COMPUTER DATA LINES SYSTEM CORNERING LAMP, HEADLAMP RANGE CONTROL MODULE FUSE 11 FUSE 35 FUSE 36 FUSE 37 FUSE 8 FUSE PANEL C GRN WIRE GRN/GRY WIRE GRY/VIO WIRE HOT AT ALL TIMES HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED LEFT DAYTIME RUNNING LAMP, POSITION LAMP LED MODULE LEFT FRONT HEADLAMP LEFT FRONT LEVEL CONTROL SYSTEM SENSOR LEFT FRONT TURN SIGNAL BULB LEFT HEADLAMP BEAM ADJUSTMENT MOTOR LEFT HEADLAMP FAN LEFT HIGH BEAM HEADLAMP BULB LEFT LED HEADLAMP POWER OUTPUT MODULE 1 LEFT LIGHT CONTROL MODULE LEFT LOW BEAM HEADLAMP BULB LEFT REAR LEVEL CONTROL SYSTEM SENSOR LEFT STATIONARY CORNERING LAMP LIGHT SWITCH ORG/BRN WIRE ORG/GRN WIRE ORG/GRY WIRE RAIN/LIGHT RECOGNITION SENSOR, HUMIDITY SENSOR RED/BLK WIRE RED/BLU WIRE RED/GRY WIRE RED/VIO WIRE VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO/GRN WIRE WHT WIRE WHT/BLK WIRE WHT/GRY WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE

ABS CONTROL MODULE AUTOMATIC DIMMING INTERIOR REAR VIEW MIRROR AUTOMATIC HIGH BEAM ASSIST CONTROL MODULE BLK/VIO WIRE BLU/WHT WIRE BRN WIRE COMPUTER DATA LINES SYSTEM ELECTRO- MECHANICAL PARKING BRAKE BUTTON GRN/BLU WIRE GRN/GRY WIRE GRY WIRE INSTRUMENT CLUSTER INSTRUMENT CLUSTER CONTROL MODULE LEFT FRONT FOG LAMP BULB LIGHT RECOGNITION SENSOR ORG/BLU WIRE ORG/BRN WIRE ORG/GRN WIRE ORG/GRY WIRE RED/VIO WIRE RIGHT DAYTIME RUNNING LAMP, POSITION LAMP LED MODULE RIGHT FRONT FOG LAMP BULB RIGHT FRONT HEADLAMP RIGHT FRONT TURN SIGNAL BULB RIGHT HEADLAMP BEAM ADJUSTMENT MOTOR RIGHT HEADLAMP FAN RIGHT HIGH BEAM HEADLAMP BULB RIGHT LED HEADLAMP POWER OUTPUT MODULE 1 RIGHT LIGHT CONTROL MODULE RIGHT LOW BEAM HEADLAMP BULB RIGHT STATIONARY CORNERING LAMP VIO/GRY WIRE WHT/BLK WIRE WHT/GRY WIRE WHT/YEL WIRE YEL WIRE
