Anti-lock brakes circuit for Audi RS3 8V facelift (2017-2021)

ABS CONTROL MODULE (ON ABS HYDRAULIC UNIT) ABS HYDRAULIC PUMP AUTO HOLD BUTTON AUTO HOLD INDICATOR LAMP BLK WIRE BLK/RED WIRE BLK/VIO WIRE BLK/WHT WIRE BLU/VIO WIRE BLU/WHT WIRE BRAKE PRESSURE SENSOR 1 BRN WIRE BRN/GRY WIRE CLUTCH POSITION SENSOR COMPUTER DATA LINES SYSTEM CONVERTIBLE SEDAN CONVERTIBLE TOP OPERATION SWITCH DRIVING DYNAMICS REGULATION HIGH PRESSURE SWITCH VALVE 1 DRIVING DYNAMICS REGULATION HIGH PRESSURE SWITCH VALVE 2 DRIVING DYNAMICS REGULATION SWITCH VALVE 1 DRIVING DYNAMICS REGULATION SWITCH VALVE 2 ELECTRO- MECHANICAL PARKING BRAKE BUTTON ELECTRO-MECHANICAL PARKING BRAKE INDICATOR LAMP FUSE 1 FUSE 17 FUSE 2 FUSE 34 FUSE 8 FUSE PANEL B FUSE PANEL C GRN WIRE GRN/BLU WIRE GRN/YEL WIRE GRY WIRE GRY/BLK WIRE GRY/RED WIRE GRY/VIO WIRE GRY/WHT WIRE HOT AT ALL TIMES HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED LEFT FRONT ABS INLET VALVE LEFT FRONT ABS OUTLET VALVE LEFT REAR ABS INLET VALVE LEFT REAR ABS OUTLET VALVE LONGITUDINAL ACCELERATION SENSOR ORG/BLU WIRE ORG/BRN WIRE PUSH BUTTON ILLUMINATION BULB RED WIRE RED/GRN WIRE RED/WHT WIRE RIGHT FRONT ABS INLET VALVE RIGHT FRONT ABS OUTLET VALVE RIGHT REAR ABS INLET VALVE RIGHT REAR ABS OUTLET VALVE ROTATION RATE SENSOR TRANSVERSE ACCELERATION SENSOR VACUUM SENSOR VIO/GRY WIRE WHT WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE

2.0L TURBO CNTC, DLRA 2.0L TURBO CZRA 2.5L TURBO ASR/ESP BUTTON ASR/ESP IND LAMP BLK WIRE BLK/RED WIRE BLK/VIO WIRE BLK/WHT WIRE BLU WIRE BLU/RED WIRE BRAKE FLUID LEVEL WARNING SWITCH BRAKE LAMP SWITCH BRAKE PEDAL SWITCH BRAKE SYSTEM IND LAMP BRN WIRE BRN/BLU WIRE CENTER INSTRUMENT PANEL SWITCH MODULE COMPUTER DATA LINES SYSTEM ENGINE/MOTOR CONTROL MODULE FUSE 3 FUSE 6 FUSE PANEL A FUSE PANEL B GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRY/BLK WIRE GRY/GRN WIRE GRY/RED WIRE GRY/WHT WIRE HOT AT ALL TIMES HOT W/ MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ENERGIZED INSTRUMENT CLUSTER CONTROL MODULE INSTRUMENT CLUSTER INSTRUMENT CLUSTER SYSTEM LEFT FRONT ABS WHEEL SPEED SENSOR LEFT PARKING BRAKE MOTOR LEFT REAR ABS WHEEL SPEED SENSOR NCA WIRE ORG/BLK WIRE ORG/BLU WIRE ORG/BRN WIRE ORG/GRN WIRE POWER STEERING CONTROL MODULE RED WIRE RIGHT FRONT ABS WHEEL SPEED SENSOR RIGHT FRONT BRAKE PAD WEAR SENSOR RIGHT PARKING BRAKE MOTOR RIGHT REAR ABS WHEEL SPEED SENSOR STEERING ANGLE SENSOR STEERING TORQUE SENSOR VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO/BRN WIRE WHT WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE
