3.0L - Ignition/glow Plug System - Engine Code(s): Cata: Overview Audi Q7 4L facelift

Scheme 17

1. Sensor Wheel For the Engine Speed (RPM) sensor -G28- Removing and installing , refer to «Description and Operation»(ref-491740-S01219978642012073100000)
2. Glow Plug 12 Nm Cylinder bank 1 (right): Glow plug 1 -Q10-, Glow plug 2 -Q11-, Glow plug 3 -Q12- Cylinder bank 2 (left): Glow plug 4 -Q13-, Glow plug 5 -Q14-, Glow plug 6 -Q15- Removing and installing , refer to «GLOW PLUGS»(ref-491753-S35893852242012073100000)
3. Electrical Harness Connector
4. Bolt 9 Nm
5. Camshaft Position (CMP) Sensor -G40- Removing and installing , refer to «Camshaft Position Sensor -G40»(ref-491753-S33550451572012073100000)
6. O-ring Replace
7. Engine Speed (RPM) Sensor -G28- Removing and installing , refer to «Engine Speed Sensor -G28»(ref-491753-S23450910602012073100000)
8. Bolt 9 Nm
