Interior Trim: Overview Audi Q7 4L facelift

Scheme 1

1. Rear Floor Covering Removing and installing, refer to «REAR FLOOR COVERING»(ref-491662-S23540311712012073100000) . Insert tank access carpet frame, refer to «TANK ACCESS CARPET FRAME, INSERTING»(ref-491662-S13481783872012073100000) .
2. Front Floor Covering Removing and installing, refer to «FRONT FLOOR COVERING»(ref-491662-S02867690802012073100000) .
3. Push Button For the front floor covering on the body.

Scheme 2

1. Footrest Cover Removing and installing, refer to «FOOTREST COVER AND BRACKET»(ref-491662-S08057422432012073100000) .
2. Bolt Tightening specification - 3 Nm
3. Threaded Clip Insert it in the footrest.
4. Footrest Bracket Removing and installing, refer to «FOOTREST COVER AND BRACKET»(ref-491662-S08057422432012073100000) .
5. Nut 3 Nm Quantity: 3
6. Tab Is joined firmly with the footrest cover.

Scheme 3

1. Door Warning Light Removing and installing, refer to «FRONT DOOR LAMPS AND SWITCHES»(ref-491786-S10018000032012073100000) (Front Door Lamps and Switches).
2. Passenger Compartment Monitoring Switch -E183- /Alarm System -Off- Switch -E217- Removing and installing, refer to «FRONT DOOR LAMPS AND SWITCHES»(ref-491786-S10018000032012073100000) (Ultrasonic Interior Monitoring).
3. Vent Grille Only with 2 zone A/C system. Removing and installing, refer to «VENT GRILLE FOR AIR DUCT»(ref-491662-S01230302922012073100000) .
4. Retaining Clip For front door trim.
5. Insulation
6. Door Frame Trim Removing and installing, refer to «WINDOW FRAME TRIM»(ref-491662-S08985026952012073100000) .
7. Mount For door trim
8. Bolt Tightening specification - 2.5 Nm
9. Speaker Treble speaker. Removing and installing, refer to «Removal and Installation»(ref-491792-S01030181612012073100000) .
10. Air Guide Channel Only with 2 zone A/C system. Removing and installing, refer to «AIR DUCT»(ref-491662-S03440818302012073100000) .
11. Front Door Trim Removing and installing, refer to «DOOR TRIM»(ref-491662-S11279931992012073100000) .
12. Air Intake Grille Only with 2 zone A/C system Removing and installing, refer to «AIR INTAKE GRILLE FOR THE AIR DUCT»(ref-491662-S21966989192012073100000) .
13. Entry Lamp Removing and installing, refer to «FRONT DOOR LAMPS AND SWITCHES»(ref-491786-S10018000032012073100000) (Front Door Lamps and Switches).

Scheme 4

1. Door Pocket Removing and installing, refer to «DOOR POCKET»(ref-491662-S00485214612012073100000) .
2. Lock Washer To replace door pocket.
3. Washer
4. Bolt For door pocket Tightening specification - 2 Nm
5. Armrest Removing and installing, refer to «ARMREST»(ref-491662-S25551574432012073100000) .
6. Switch Mount For the window regulator switch. Removing and installing, refer to «SWITCH MOUNT»(ref-491662-S24388300352012073100000) .
7. Bolt Tightening specification - 2.5 Nm
8. Cover Removing and installing, refer to «ARMREST»(ref-491662-S25551574432012073100000) .
9. Driver Seat Memory Program Control Head Driver side: Driver memory seat control head -E97-. Front passenger side: Front passenger memory seat control head -E277-. Removing and installing, refer to «FRONT DOOR LAMPS AND SWITCHES»(ref-491786-S10018000032012073100000) (Front Door Lamps and Switches).
10. Trim Panel For door trim. Removing and installing, refer to «TRIM MOLDING»(ref-491662-S21800120872012073100000) .
11. Bolt Tightening specification - 2.5 Nm
12. Front Door Trim Removing and installing, refer to «DOOR TRIM»(ref-491662-S11279931992012073100000) .
13. Clip For trim panel.
14. Bolt For armrest. Tightening specification - 1.2 Nm
15. Bolt For inside door release mechanism. If present, for driver seat operating unit with memory function. Tightening specification - 1.2 Nm
16. Bolt Tightening specification - 2.5 Nm
17. Rear Lid Remote Control Lock Switch -E233- and Fuel Tank Lid Unlock Button -E319- Removing and installing, refer to «REAR LID REMOTE RELEASE BUTTON -E233- AND FUEL FILLER DOOR RELEASE BUTTON -E319»(ref-491786-S01210981032012073100000) (Front Door Lamps and Switches).
18. Trim/Mount For Rear Lid Remote Unlock Switch -E188- and Fuel Tank Lid Unlock Button -E319-. To remove, remove Rear Lid Remote Unlock Switch -E188- and Fuel Tank Lid Unlock Button -E319-.
19. Interior Door Mechanism Removing and installing, refer to «INSIDE DOOR RELEASE MECHANISM»(ref-491662-S00139856552012073100000) .
20. Lane Change Assistance Button -E530- Removing and installing, refer to «LANE CHANGE ASSISTANCE BUTTON -E530»(ref-491786-S11251002802012073100000) (Lane Change Assistance).
21. Mount For Lane Change Assistance Button -E530-. To remove, remove Lane Change Assistance Button -E530-.
22. Trim For vehicles without Lane Change Assistance Button -E530-.
23. Interior Locking Switch (Central Locking Button) Driver side: Driver interior locking switch -E150-. Front passenger side: Front passenger interior locking switch -E198-. Removing and installing, refer to «FRONT DOOR LAMPS AND SWITCHES»(ref-491786-S10018000032012073100000) (Front Door Lamps and Switches).
24. Mount For driver seat operating unit with memory function. Removing and installing, refer to «DRIVER AND FRONT PASSENGER MEMORY SEAT CONTROL HEADS -E97- / -E277- TRIM/MOUNT»(ref-491662-S31524539242012073100000) .
25. Trim On vehicles without driver seat operating unit with memory function. Removing and installing, refer to «DRIVER AND FRONT PASSENGER MEMORY SEAT CONTROL HEADS -E97- / -E277- TRIM/MOUNT»(ref-491662-S31524539242012073100000) .
26. Window Regulator Switch Driver side: Power window control head in driver door -E512-. Front passenger side: Front passenger door window regulator switch -E107-. Removing and installing, refer to «FRONT PASSENGER DOOR WINDOW REGULATOR SWITCH -E107»(ref-491786-S24866308132012073100000) (Front Door Lamps and Switches).
27. Mirror Adjustment Switch -E43- Removing and installing, refer to «MIRROR ADJUSTING SWITCH -E43»(ref-491786-S14532823862012073100000) (Front Door Lamps and Switches).
28. Lock Washer For BOSE sound system trim panel.
29. Trim Panel Only with BOSE sound system. Removing and installing, refer to «BOSE SOUND SYSTEM TRIM»(ref-491662-S22715482492012073100000) .

HEADLINER OVERVIEW

Note. Molded headliner for vehicles without sunroof is shown in illustration. On vehicles with sunroof, remove headliner from cover frame. Refer to HEADLINER .

Scheme 5

1. Headliner Removing and installing, refer to «HEADLINER»(ref-491662-S33353007812012073100000) .
2. Cover For the screen separator wall mount. Must be unclipped to remove and install headliner. Hangs after unclipping from the screen separator wall mount and cannot be removed. Remove and install the screen separator wall mount «SCREEN SEPARATOR WALL MOUNT»(ref-491662-S15703889022012073100000) .
3. Bolt 3 Nm Approximately 0.75 inch (19 mm) long NOTE: If 2 screws of different lengths are installed, shorter screw for securing sun visor must be installed at front of direction of travel.
4. Bolt 3 Nm
5. Passenger Side Sun Visor Some vehicles are equipped with a double sun visor. Removing and installing, refer to «SUN VISOR OVERVIEW»(ref-491662-S32086660852012073100000) .
6. Driver Side Sun Visor Some vehicles are equipped with a double sun visor. Removing and installing, refer to «SUN VISOR OVERVIEW»(ref-491662-S32086660852012073100000) .
7. Center Cover For interior light/front reading light.
8. Decorative Frame For center cover.
9. Diffusion Lens For interior light/front reading light.
10. Bolt Tightening torque, refer to «FASTENER TIGHTENING SPECIFICATIONS»(ref-491786-S34936084612012073100000) (Roof Trim Lamps and Switches).
11. Interior Light/Front Reading Light
12. Bolt 3 Nm
13. Sun Visor Center Bearing Removing and installing, refer to «SUN VISOR OVERVIEW»(ref-491662-S32086660852012073100000) .
14. Bolt 2 Nm
15. Front Roof Grab Handle Removing and installing, refer to «ROOF GRAB HANDLE»(ref-491662-S32344406362012073100000) .
16. Screw, Self-Locking 4 Nm Replace Threaded holes for screws must always be cleaned (for example, with thread cutter).
17. Rear Roof Grab Handle Rear roof grab handle is equipped with a coat hook. Removing and installing, refer to «ROOF GRAB HANDLE»(ref-491662-S32344406362012073100000) .
18. Left Rear Interior Light -W47- /Right Rear Interior Light -W48
19. Clip Quantity: 3 For headliner to assembly bridge.
20. Assembly Bridge For headliner to body.
21. Bolt 4 Nm
22. Rear Courtesy Light -W43

Scheme 6

1. Center Console Overview, refer to «CENTER CONSOLE ASSEMBLY OVERVIEW»(ref-491666-S16096455912012073100000) . Removing and installing, refer to «CENTER CONSOLE»(ref-491666-S34044617022012073100000) .
2. Driver Side Instrument Panel Covers Overview, refer to «INSTRUMENT PANEL COVERS ON DRIVER SIDE ASSEMBLY OVERVIEW»(ref-491666-S02774107562012073100000) . Instrument panel cover, removing and installing, lower, driver side, refer to «LOWER DRIVER SIDE INSTRUMENT PANEL COVER»(ref-491666-S08641294672012073100000) . Instrument panel cover, removing and installing, upper, driver side, removing and installing, refer to «UPPER INSTRUMENT COVER, DRIVER SIDE KNEE BAR»(ref-491666-S08315381182012073100000) .
3. Instrument Panel Overview, refer to «INSTRUMENT PANEL COMPONENTS OVERVIEW»(ref-491662-S25940761262012073100000) . Removing and installing, refer to «INSTRUMENT PANEL»(ref-491662-S38254864582012073100000) .
4. Instrument Panel Central Tube Overview, refer to «INSTRUMENT PANEL CENTRAL TUBE OVERVIEW»(ref-491662-S00796807222012073100000) . Removing and installing, refer to «INSTRUMENT PANEL CENTRAL TUBE»(ref-491662-S18302611422012073100000) .
5. Glove Compartment and Front Passenger Side Instrument Panel Cover Overview, refer to «PASSENGER SIDE GLOVE COMPARTMENT AND INSTRUMENT PANEL COVER ASSEMBLY OVERVIEW»(ref-491666-S21722254032012073100000) . Removing and installing the glove compartment, refer to «GLOVE COMPARTMENT»(ref-491666-S20121688542012073100000) . Passenger side instrument panel cover, removing and installing, refer to «PASSENGER SIDE INSTRUMENT PANEL COVER»(ref-491666-S21688598562012073100000) .
6. Front Center Armrest Overview, refer to «FRONT CENTER ARMREST ASSEMBLY OVERVIEW»(ref-491666-S03136076322012073100000) . Removing and installing, refer to «FRONT CENTER ARMREST»(ref-491666-S42947847572012073100000) .

Scheme 7

1. Parking Brake Release Handle
2. Light Switch Removing and installing «[For engine(s) CATA, BHK, CJWC, CJWB, BAR] Removal and Installation»(ref-491789-S27438983732012073100000)
3. Left Side Instrument Panel Vent Removing and installing, refer to «SIDE PANEL VENT»(ref-491662-S21755351372012073100000) .
4. Bolt Tightening specification - 1.4 Nm
5. Side Instrument Panel Cover Removing and installing, refer to «PANEL SIDE COVER»(ref-491662-S25276955052012073100000) .
6. Bolt Tightening specification - 1.4 Nm
7. Guide For parking brake release handle.
8. Bolt Tightening specification - 1.4 Nm
9. Bolt Tightening specification - 0.6 Nm
10. Bolt Tightening specification - 0.6 Nm
11. Upper Center Air Duct Depending on equipment with Indirect Ventilation Flap Motor -V213-.
12. Center Air Duct
13. Installation Frame For the center instrument panel vent, CD changer -R41-, Climatronic control module -J255- (also called A/C control head). Removing and installing, refer to «INSTALLATION FRAME»(ref-491662-S34890774772012073100000) .
14. Clips
15. Clips
16. Bolt Tightening specification - 1.4 Nm
17. Sunlight Photo Sensor -G107- Removing and installing, refer to «[For engine(s) CATA, BHK, CJWC, CJWB, BAR] Removal and Installation»(ref-491706-S39074348772012073100000) .
18. Indirect Ventilation Trim With defroster vent. Removing and installing, refer to «INDIRECT VENTILATION TRIM»(ref-491662-S14002926032012073100000) .
19. Spreader Pin
20. Bolt Tightening specification - 1.8 Nm
21. Speaker Removing and installing, refer to «Removal and Installation»(ref-491792-S01030181612012073100000) .
22. Threaded Clip
23. Instrument Panel WARNING: Follow all safety precautions when working on pyrotechnic components. Removing and installing, refer to «INSTRUMENT PANEL»(ref-491662-S38254864582012073100000) .
24. Right Side Instrument Panel Vent Removing and installing, refer to «SIDE PANEL VENT»(ref-491662-S21755351372012073100000) .
25. Front Passenger Airbag Unit Bracket
26. Front Passenger Airbag Unit WARNING: Follow all safety precautions when working on pyrotechnic components. Removing and installing, refer to «FRONT PASSENGER AIRBAG UNIT»(ref-491782-S17490142402012073100000) .
27. Nut Replace Tightening specification - 7 Nm
28. Trim For Access/Start Authorization Switch -E415-.
29. Center Instrument Panel Vent Removing and installing, refer to «CENTER INSTRUMENT PANEL VENT»(ref-491662-S29415196612012073100000) . With the switch unit with the Front passenger airbag -disabled- indicator lamp -K145-. The switch strip inside the center instrument panel vent must be replaced completely if the Front passenger airbag disabled indicator lamp -K145- LED is faulty. Refer to «FRONT PASSENGER AIRBAG DISABLED INDICATOR LAMP -K145»(ref-491786-S24443361372012073100000) .
30. CD Changer -R41- Removing and installing, refer to «Removal and Installation»(ref-491792-S01030181612012073100000) .
31. Climatronic Control Module -J255- Removing and installing, refer to «[For engine(s) CATA, BHK, CJWC, CJWB, BAR] Removal and Installation»(ref-491706-S39074348772012073100000) .
32. Access/Start Authorization Switch -E415- Removing and installing, refer to «[For engine(s) CATA, BHK, CJWC, CJWB, BAR] Removal and Installation»(ref-491789-S27438983732012073100000) .
33. Bolt Tightening specification - 1.4 Nm
34. Gap Cover
35. Bolt Tightening specification - 1.4 Nm
36. Instrument Cluster Removing and installing, refer to «[For engine(s) CATA, BHK, CJWC, CJWB, BAR] Removal and Installation»(ref-491730-S22769762732012073100000) .

Scheme 8

1. Central Tube Left Angle Bracket Before removal, mark the installation location on the A-pillar for reinstallation.
2. Bolt Tightening specification - 23 Nm
3. Bolt Tightening specification - 23 Nm
4. Balancing Element
5. A/C Unit Bracket
6. A/C Unit Bracket
7. Bolt Tightening specification - 10 Nm
8. Bolt Tightening specification - 1.5 Nm
9. Bolt Tightening specification - 10 Nm
10. Bolt Tightening specification - 23 Nm
11. Right Central Tube Angle Bracket Before removal, mark the installation location on the A-pillar for reinstallation.
12. Bolt Tightening specification - 23 Nm
13. Right Front Passenger Airbag Unit Bracket
14. Nut Replace Tightening specification - 7 Nm
15. Left Bracket For Front Passenger Airbag Unit
16. Bolt Tightening specification - 23 Nm
17. Bolt Tightening specification - 10 Nm
18. Bolt Tightening specification - 23 Nm
19. Instrument Panel Central Tube Before removing, mark installation location on -item 1- and -item 11- for reinstallation. Removing and installing, refer to «INSTRUMENT PANEL CENTRAL TUBE»(ref-491662-S18302611422012073100000) .
20. Bolt Tightening specification - 23 Nm
21. Bolt Self-locking Replace Tightening specification - 23 Nm
22. Bolt Tightening specification - 23 Nm

Scheme 9

1. Luggage Compartment Floor
2. Cargo Tray Not installed on all vehicles.
3. Tie-Down Eye For vehicles with retaining tracks. Is inserted in retaining tracks.
4. Bolt 6 Nm
5. Right Retaining Track Removing and installing, refer to «TIE-DOWN EYE RETAINING RAIL»(ref-491662-S31053082012012073100000) .
6. Bolt 6 Nm
7. Tie-Down Eye Removing and installing, refer to «TIE-DOWN EYE WITH THE GAP COVER»(ref-491662-S09854563692012073100000) .
8. Right Gap Cover For vehicles with tie-down eyes. Removing and Installing, refer to «TIE-DOWN EYE WITH THE GAP COVER»(ref-491662-S09854563692012073100000) .
9. Rear Cross Panel Trim Removing and installing, refer to «REAR CROSS PANEL TRIM OVERVIEW»(ref-491662-S08045001362012073100000) .
10. Luggage Compartment Floor To remove, the luggage compartment side trim must be removed first. Removing and installing, refer to «LUGGAGE COMPARTMENT FLOOR OR FLOOR SUPPORT»(ref-491662-S23417498612012073100000) .
11. Left Gap Cover For vehicles with tie-down eyes. Removing and installing, refer to «TIE-DOWN EYE WITH THE GAP COVER»(ref-491662-S09854563692012073100000) .
12. Left Retaining Rack Removing and installing, refer to «TIE-DOWN EYE RETAINING RAIL»(ref-491662-S31053082012012073100000) .
13. Right Gap Cover For vehicles with retaining tracks. Removing and installing, refer to «GAP COVER»(ref-491662-S25908762282012073100000) .
14. Right Luggage Compartment Floor Support For vehicles with 3rd row seating Removing and installing, refer to «LUGGAGE COMPARTMENT FLOOR OR FLOOR SUPPORT»(ref-491662-S23417498612012073100000) .
15. Left Luggage Compartment Floor Support For vehicles with 3rd row seating. Removing and installing, refer to «LUGGAGE COMPARTMENT FLOOR OR FLOOR SUPPORT»(ref-491662-S23417498612012073100000) .
16. Left Gap Cover For vehicles with retaining tracks. Removing and installing, refer to «GAP COVER»(ref-491662-S25908762282012073100000) .
17. Bolt 2.5 Nm
18. Handle For the luggage compartment floor. Removing and installing, refer to «LUGGAGE COMPARTMENT FLOOR HANDLE»(ref-491662-S11509967382012073100000) .

Scheme 10

1. Luggage Compartment Side Trim Removing and installing, refer to «LUGGAGE COMPARTMENT SIDE TRIM»(ref-491662-S24854250592012073100000) . When installing, the tab -arrow- must be inserted in the D-pillar trim LUGGAGE COMPARTMENT SIDE TRIM PANEL OVERVIEW .
2. Clips Replace if damaged.
3. D-pillar Trim Must be installed before installation of the luggage compartment side trim.
4. C-pillar Trim Before removing, the luggage compartment side trim must be removed. Removing and installing, refer to «C-PILLAR TRIM OVERVIEW»(ref-491662-S16909371472012073100000) .
5. Bracket Must be installed before installation of the luggage compartment side trim.
6. Bolt 2.5 Nm

Scheme 11

1. A-pillar Lower Trim Removing and installing, refer to «A-PILLAR LOWER TRIM»(ref-491662-S16971173442012073100000) .
2. Hood Release Lever For hood. Removing and installing, refer to «A-PILLAR LOWER TRIM»(ref-491662-S16971173442012073100000) .
3. Bolt Driver side only. 2.0 Nm
4. Retaining Clip Only passenger side.
5. Clips Quantity: 2 Replace if damaged or deformed.
6. Sill Panel Strip Must be removed in the transition area to the lower A-pillar trim from the sill.
7. Bolt 2.5 Nm For the sill panel on the sill.
8. Front Trim
9. Mount For operating lever.

A-PILLAR TRIM, UPPER OVERVIEW

Scheme 12

1. Upper A-pillar Trim Removing and installing, refer to «A-PILLAR UPPER TRIM»(ref-491662-S20827532692012073100000) .
2. Cover With the >>Airbag<< symbol. Carefully unclip. Hangs from trim and cannot be detached.
3. Screw, Self-Locking 3 Nm Always replace if removed. Threaded screw holes must always be cleaned (for example, with thread cutter).
4. Adapter Tab -arrow A- must be inserted in recess -arrow B- in body (A-pillar).
5. Head Curtain Airbag
6. Clips Quantity: 2 Replace if damaged or deformed.

B-PILLAR TRIM OVERVIEW

Scheme 13

1. B-pillar Trim Removing and installing, refer to «B-PILLAR TRIM»(ref-491662-S13857068462012073100000) .
2. Head Curtain Airbag
3. Headliner
4. Retaining Pin On The Seat Belt Height Adjuster
5. Mount On The Sliding Piece Of The B-pillar Trim
6. Belt Webbing
7. Clips Quantity: 2 Replace if damaged or deformed.
8. Vent
9. Spring Clamp For vent B-PILLAR TRIM OVERVIEW .
10. Front Belt Guide

Scheme 14

1. C-pillar Trim Removing and installing, refer to «C-PILLAR TRIM»(ref-491662-S40452942822012073100000) .
2. Cover With the >>Airbag<< symbol. Carefully unclip. Hangs from trim and cannot be detached.
3. Seat Belt
4. Screw, Self-Locking 3 Nm Always replace if removed. Threaded screw holes must always be cleaned (for example, with thread cutter).
5. Screw, Self-Locking 3 Nm Always replace if removed. Threaded screw holes must always be cleaned (for example, with thread cutter).
6. Vent
7. Spring Clamp For vent C-PILLAR TRIM OVERVIEW .
8. Mount On The Sliding Piece Of The C-pillar Trim
9. Retaining Pin On The Seat Belt Height Adjuster

Scheme 15

1. D-pillar Trim For vehicles without a seat belt on the D-pillar. Removing and installing, refer to «D-PILLAR TRIM»(ref-491662-S13901197492012073100000) .
2. Screw, Self-Locking 3 Nm Always replace if removed. Threaded screw holes must always be cleaned (for example, with thread cutter).
3. Nut 3 Nm For bracket to body, refer to item 4 .
4. Bracket
5. Cover With the >>Airbag<< symbol. Carefully unclip. hangs from trim and cannot be detached.
6. Clips Replace clamps if damaged or deformed.
7. D-pillar Trim For vehicles with seat belt on D-pillar Removing and installing, refer to «D-PILLAR TRIM»(ref-491662-S13901197492012073100000) .
8. Belt Extraction Panel Clip in the D-pillar trim, refer to item 7 . Removing and installing, refer to «SEAT BELT EXTRACTION PANEL»(ref-491662-S00854989952012073100000) .

Scheme 16

1. Bar Piece Removing and installing, refer to «BAR PIECE»(ref-491662-S41707392552012073100000) .
2. Clips Insert in body.
3. Upper A-pillar Trim
4. A-pillar Lower Trim Must be installed before bar piece is installed.

Scheme 17

1. Rear Cross Panel Trim Removing and installing, refer to «REAR CROSS PANEL TRIM»(ref-491662-S14503272812012073100000) .
2. Clips Quantity: 4 Replace if damaged.
3. Insulation Install between the rear cross panel trim and striker pin.
4. Bolt 3.5 Nm

Scheme 18

1. Door Warning Light Removing and installing, refer to «DOOR WARNING LAMP AND REAR ENTRY LAMP»(ref-491786-S05505115432012073100000) .
2. Rear Door Trim Removing and installing, refer to «DOOR TRIM PANEL»(ref-491662-S17606038512012073100000) .
3. Retaining Clip For rear door trim.
4. Insulation
5. Door Frame Trim Removing and installing, refer to «WINDOW FRAME TRIM»(ref-491662-S31637474832012073100000) .
6. Bolt Tightening specification - 2 Nm
7. Speaker Treble speaker Removing and installing, refer to «Removal and Installation»(ref-491792-S01030181612012073100000) .
8. Antennas In Interior For Access and Start Authorization Driver side: Access/start authorization antenna 3 in vehicle interior -R154- Front passenger side: Access/start authorization antenna 2 in vehicle interior -R139- Removing and installing, refer to «ACCESS/START AUTHORIZATION ANTENNA 1 IN VEHICLE INTERIOR -R138»(ref-491786-S22671575472012073100000) (Access/Start Authorization System).
9. Speaker Trim Removing and installing, refer to «SPEAKER TRIM»(ref-491662-S33797772312012073100000) .
10. Entry Lamp Removing and installing, refer to «DOOR WARNING LAMP AND REAR ENTRY LAMP»(ref-491786-S05505115432012073100000) .

Scheme 19

1. Door Pocket Removing and installing, refer to «POCKET»(ref-491662-S31436851772012073100000) .
2. Lock Washer To replace door pocket.
3. Armrest Removing and installing, refer to «ARMREST»(ref-491662-S27264482202012073100000) .
4. Window Regulator Switch Left: Left rear power window switch in left rear door -E52- Right: Right rear window switch in right rear door -E54- Removing and installing, refer to «POWER WINDOW SWITCHES IN REAR DOORS -E52- / -E54»(ref-491786-S16848278892012073100000) .
5. Window Regulator/Ashtray Switch Mount Removing and installing, refer to «SWITCH MOUNT»(ref-491662-S36995440792012073100000) .
6. Ashtray Removing and installing, refer to «ASHTRAY»(ref-491662-S03867118012012073100000) .
7. Trim Panel For door trim. Removing and installing, refer to «TRIM MOLDING»(ref-491662-S01036414172012073100000) .
8. Bolt Tightening specification - 2.5 Nm
9. Rear Door Trim Removing and installing, refer to «DOOR TRIM PANEL»(ref-491662-S17606038512012073100000) .
10. Clip For trim panel.
11. Bolt For armrest. Tightening specification - 2.5 Nm
12. Bolt For inside door release mechanism. Tightening specification - 1.2 Nm
13. Interior Door Mechanism Removing and installing, refer to «INSIDE DOOR RELEASE MECHANISM»(ref-491662-S15373342282012073100000) .
14. Bolt Tightening specification - 2.5 Nm
15. Trim
16. Pull Handle Removing and installing, refer to «PULL HANDLE»(ref-491662-S38235987462012073100000) .
17. Bolt Tightening specification - 2.5 Nm
18. Cover For pull handle.
19. Lock Washer For BOSE sound system trim panel.
20. Trim Panel Only with BOSE sound system. Removing and installing, refer to «BOSE SOUND SYSTEM TRIM»(ref-491662-S12284193462012073100000) .

Scheme 20

1. Rear Door Trim
2. Bolt Tightening specification - 1.2 Nm
3. Sun Shade Removing and installing, refer to «SUN SHADE»(ref-491662-S39998815392012073100000) .
4. Bolt Tightening specification - 1.2 Nm
5. Guide Strip Removing and installing, refer to «SUN SHADE»(ref-491662-S39998815392012073100000) .

Scheme 21

Tighten the screws -1- on the sun shade mount to 1.2 Nm.

REAR LID TRIM PANEL OVERVIEW

Note. Component designation relates to direction of travel.

Scheme 22

1. Upper Center Rear Lid Trim Clipped in with 4 or 5 clips when installing the sun shade on the rear lid. Removing and installing, refer to «REAR LID TRIM»(ref-491662-S19163478602012073100000) .
2. Upper Left Rear Lid Trim Is secured to the rear lid with two clamps and one screw. Removing and installing, refer to «REAR LID TRIM»(ref-491662-S19163478602012073100000) .
3. Bolt 1.5 Nm
4. Lower Rear Lid Trim Can only be removed after removing upper trim. Removing and installing, refer to «REAR LID TRIM»(ref-491662-S19163478602012073100000) .
5. Cover For the inner left tail lamp. Unclip with Trim Removal Wedge 3409. There is a lower trim screw located behind cover.
6. Left Luggage Compartment Lights Unclip with Trim Removal Wedge 3409.
7. Cover For luggage compartment emergency release.
8. Rear Lid Lock Trim Inserted in lower trim.
9. Bolt 1.5 Nm 2 screws are only accessible after removing warning triangle. 2 screws are located under the inner tail lamp covers.
10. Right Luggage Compartment Lights Is not installed on all vehicles.
11. Rear Lid Lock Button In Luggage Compartment -E406- Is not installed on all vehicles. Retrofitting rear lid lock button in luggage compartment opening in lower rear lid trim, refer to «REAR LID LOCK BUTTON IN LUGGAGE COMPARTMENT E406, RETROFITTING»(ref-491662-S20446553312012073100000) .
12. Cover For the inner right tail lamp. Unclip with Trim Removal Wedge 3409. There is a lower trim screw located behind cover.
13. Clips Quantity: 6 Inserted in lower trim. Replace if damaged or deformed.
14. Upper Right Rear Lid Trim Is secured to the rear lid with two clamps and one screw. Removing and installing, refer to «REAR LID TRIM»(ref-491662-S19163478602012073100000) .
15. Bolt 1.5 Nm
16. Clips Quantity: 2 Insert in upper right trim. Replace if damaged or deformed.
17. Clips Quantity: 5 Insert in upper center trim. Replace if damaged or deformed.
18. Clips Quantity: 2 Insert in upper left trim. Replace if damaged or deformed.
19. Clip
20. Sun Shade Mount Vehicles with Removing and installing, refer to «REAR LID TRIM»(ref-491662-S19163478602012073100000) .
21. Bolt 1.6 Nm
22. Cover For the sun shade mount.

Scheme 23

1. Roof Panel Trim Removing and installing, refer to «ROOF PANEL TRIM»(ref-491662-S07973389952012073100000) .
2. Clamps Quantity: 3 Replace if damaged or deformed.
3. Assembly Bridge/Headliner For securing the roof panel trim.
4. Door Seal Lip
5. D-pillar Trim

Scheme 24

1. Sill Panel Strip Removing and installing, refer to «SILL PANEL»(ref-491662-S17995221372012073100000) . When installing, pins -arrow- must be inserted in hole in body SILL PANEL TRIM OVERVIEW .
2. Bolt 2.5 Nm
3. Clips Check for damage, replace if necessary.
4. Rear Trim Remove with Trim Removal Wedge 3409.
5. Front Trim Remove with Trim Removal Wedge 3409.
6. Body B-pillar
7. A-pillar Lower Trim Must be installed before installing sill panel strip.

SUN VISOR OVERVIEW

Note. Double sun visor is shown in illustration

Scheme 25

1. Sun Visor Some vehicles are equipped with a double sun visor. Removing and installing, refer to «SUN VISOR»(ref-491662-S20621828312012073100000) .
2. Cover
3. Bolt 3 Nm Approximately 0.75 inch (19 mm) long. NOTE: If 2 screws of different lengths are installed, shorter screw for securing sun visor must be installed at front of direction of travel.
4. Bolt 3 Nm
5. Sun Visor Center Bearing
6. Cover For sun visor center bracket.
7. Bolt 3 Nm

Scheme 26

1. D-pillar Trim Overview, refer to «D-PILLAR TRIM OVERVIEW»(ref-491662-S34647417892012073100000) .
2. C-pillar Trim Overview, refer to «C-PILLAR TRIM OVERVIEW»(ref-491662-S16909371472012073100000) .
3. B-pillar Trim Overview, refer to «B-PILLAR TRIM OVERVIEW»(ref-491662-S40312755462012073100000) .
4. Upper A-pillar Trim Overview, refer to «A-PILLAR TRIM, UPPER OVERVIEW»(ref-491662-S16988700942012073100000) .
5. Bar Piece Overview, refer to «BAR PIECE OVERVIEW»(ref-491662-S30677773682012073100000) .
6. A-pillar Lower Trim Overview, refer to «A-PILLAR TRIM, LOWER OVERVIEW»(ref-491662-S18033992822012073100000) .
7. Sill Panel Strip Overview, refer to «SILL PANEL TRIM OVERVIEW»(ref-491662-S27267798432012073100000) .
8. Wheel Housing Trim Overview, refer to «WHEEL HOUSING LINER OVERVIEW»(ref-491662-S39335141212012073100000) .
9. Luggage Compartment Side Trim Overview, refer to «LUGGAGE COMPARTMENT SIDE TRIM PANEL OVERVIEW»(ref-491662-S08214814832012073100000) .

Scheme 27

1. Wheel Housing Trim Removing and installing, refer to «WHEEL HOUSING TRIM»(ref-491662-S31232676982012073100000) . Detaching the wheel housing trim from the C-pillar and attaching it (not removing), refer to «WHEEL HOUSING TRIM, DETACHING FROM C-PILLAR (NOT REMOVING)»(ref-491662-S05476517782012073100000) . With opening -arrow- for guiding seat belt through.
2. Bolt 55 Nm For belt anchor/seat belt to body.
3. Seat Belt Guide through opening -arrow- in wheel housing trim.
4. C-pillar Trim Must be installed before removing wheel housing trim.
5. Clips Quantity: 4 Replace if damaged or deformed. Insert in wheel housing trim.
6. Sill Panel Strip Must be installed before removing wheel housing trim.
7. Support Piece
