Exterior Lights, Switches Audi Q5 I

CONTACT CORROSION

Contact corrosion can occur if incorrect fasteners (bolts, nuts, washers, etc.) are used.

For this reason, only fasteners with a special surface coating are used.

In addition, rubber or plastic parts and adhesive consist of non-conductive materials.

If there are doubts as to whether parts are suitable or not, use new parts.

Note. We only recommend original replacement parts as they have been tested and are compatible with aluminum. We recommend using genuine Audi accessories. Damage resulting from contact corrosion is not covered by warranty.

ACCESS/START AUTHORIZATION SWITCH, CONNECTOR ASSIGNMENT

Connector Mount

Scheme 1

3 - Not used

4 - Not used

5 - S-contact

6 - Terminal 15

7 - LIN

8 - Terminal 30

9 - Not used

10 - Not used

11 - Not used

12 - Not used

13 - RED2, terminal 15

14 - RED, terminal 15

15 - ZAS+

16 - Terminal 31

Scheme 2

1. Left Front Level Control System Sensor -G78- Installation location: on left front control arm Removing and installing, refer to «Removal and Installation»(/audi/q5/i-2008-2012/remont/suspension-front/#front-suspension)
2. Left Headlamp Beam Adjustment Motor -V48- Removing and installing, refer to «HEADLAMP BEAM ADJUSTMENT MOTORS -V48- / -V49»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__headlamp-beam-adjustment-motors-v48)
3. Right Headlamp Beam Adjustment Motor -V49- Removing and installing, refer to «HEADLAMP BEAM ADJUSTMENT MOTORS -V48- / -V49»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__headlamp-beam-adjustment-motors-v48)
4. Control Module Installation location: behind the air intake chamber Removing and installing, refer to «AUTOMATIC HEADLAMP VERTICAL AIM AND RANGE, CONTROL MODULES -J431- / -J745»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__automatic-headlamp-vertical-aim-and-range) Vehicles without cornering lamp Headlamp range control module -J431- Vehicles with cornering lamp (AFS) Cornering lamp and headlamp range control module -J745
5. Electrical Connector
6. Left Rear Level Control System Sensor -G76- Installation location: on the left rear control arm Removing and installing, refer to «Removal and Installation»(/audi/q5/i-2008-2012/remont/suspension-rear/#rear-suspension)

BI-XENON HEADLAMPS WITH CORNERING LIGHT OVERVIEW

Part 1 - Headlamp

Scheme 3

1. Screw 4.5 Nm
2. Turn Signal Bulb Left front turn signal bulb -M5- Right front turn signal bulb -M7- 12 V, 21 W (H21W) Bulb, replacing, refer to «FRONT TURN SIGNAL LAMP BULBS»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__front-turn-signal-lamp-bulbs)
3. Housing Cover For turn signal light For vehicles with cornering lamp (AFS)
4. Gasket Replace if damaged
5. Power Output Stage Vehicles with AFS only Left headlamp power output stage -J667- Right headlamp power output stage -J668- Removing and installing, refer to «HEADLAMP POWER OUTPUT STAGES -J667- / -J668»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__headlamp-power-output-stages-j667)
6. Retaining Plate Removing and installing, refer to «HEADLAMP POWER OUTPUT STAGES -J667- / -J668»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__headlamp-power-output-stages-j667)
7. Screw 1.4 Nm
8. Housing Cover For turn signal light For vehicles without cornering lamp (AFS)
9. Screw 1.4 Nm
10. Daytime Running Lamp and Parking Lamp LED Module Left daytime running lamp and parking lamp LED module -L176- Right daytime running lamp and parking lamp LED module -L177- Removing and installing, refer to «DAYTIME RUNNING LAMP AND PARKING LAMP LED MODULES L176 AND L177»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__daytime-running-lamp-and-parking-lamp)
11. Screw 1.4 Nm
12. HID Headlamp Control Module Left HID headlamp control module -J343- Right HID headlamp control module -J344- Removing and installing, refer to «HID LAMP CONTROL MODULE»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__hid-lamp-control-module)
13. Sealing Ring
14. Screw 4.5 Nm
15. Headlamp Housing Bracket
16. Screw 4.5 Nm
17. Nut Self-Locking Replace
18. Housing Cover For low beam
19. Gas-Discharge Lamp With integrated ignition coil Left HID headlamp bulb -L13- Right HID headlamp bulb -L14- 42 V, 35 W (D3S) Bulb, replacing, refer to «HID HEADLAMP BULBS»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__hid-headlamp-bulbs)
20. Adapter Lead For gas discharge lamp Not available as a replacement part
21. Headlamp Housing The daytime running lamps and parking lamps are LED lamps and are integrated in the headlamp housing. The LEDs cannot be replaced separately. The entire headlamp must be replaced. The front side marker lamp bulb is an LED and is integrated in the headlamp housing. The LED cannot be replaced separately. The entire headlamp must be replaced. Removing and installing, refer to «HEADLAMP HOUSING»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__headlamp-housing)

Part 2 - Repair Kits

Scheme 4

1. Headlamp Housing Removing and installing, refer to «HEADLAMP HOUSING»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__headlamp-housing)
2. Headlamp Range Control Positioning Motor Left headlamp beam adjustment motor -V48- Right headlamp beam adjustment motor -V49- Removing and installing, refer to «HEADLAMP BEAM ADJUSTMENT MOTORS -V48- / -V49»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__headlamp-beam-adjustment-motors-v48)
3. Sealing Ring Not available separately as a replacement part
4. Headlamp Range Control Positioning Motor Housing Cover The headlamp housing must be cut open to replace the positioning motor A housing cover can be ordered to seal the assembly opening. Removing and installing, refer to «HEADLAMP BEAM ADJUSTMENT MOTORS -V48- / -V49»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__headlamp-beam-adjustment-motors-v48)
5. Screw From the repair kit for the headlamp range control positioning motor cover 2 Nm

Scheme 5

1. Tail Lamp Removing and installing, refer to «BUMPER COVER TAIL LAMPS»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__bumper-cover-tail-lamps)
2. Brake and Tail Lamp Bulb Left brake/tail lamp bulb -M21- Right brake/tail lamp bulb -M22- 12 V, 16 W (W16W) Bulb, replacing, refer to «BUMPER COVER TAIL LAMP BULBS»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__bumper-cover-tail-lamp-bulbs)
3. Rear Side Marker Lamp Bulb Left rear side marker lamp bulb -M37- Right rear side marker lamp bulb -M38- Bulb, replacing, refer to «BUMPER COVER TAIL LAMP BULBS»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__bumper-cover-tail-lamp-bulbs)
4. Screw 0.9 Nm
5. Sensor for Rear Lid Closed Rear lid -closed- sensor 1 -G525- Rear lid -closed- sensor 2 -G526- Removing and installing, refer to «REAR LID CLOSED SENSOR»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__rear-lid-closed-sensor)
6. Screw 0.9 Nm
7. Central Connector For lamp sockets
8. Rear Fog Light Bulb Left rear fog lamp bulb -L46- Right rear fog lamp bulb -L47- 12 V, 16 W (W16W) Bulb, replacing, refer to «BUMPER COVER TAIL LAMP BULBS»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__bumper-cover-tail-lamp-bulbs)
9. Left Back-Up Light Left back-up lamp bulb -M16- Right back-up lamp bulb -M17- 12 V, 16 W (W16W) Bulb, replacing, refer to «BUMPER COVER TAIL LAMP BULBS»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__bumper-cover-tail-lamp-bulbs)
10. Rear Turn Signal Bulb Left rear turn signal bulb -M6- Right rear turn signal bulb -M8- 12V, 21 W Bulb, replacing, refer to «BUMPER COVER TAIL LAMP BULBS»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__bumper-cover-tail-lamp-bulbs)
11. Screw 2.5 Nm
12. Cap For screw In the bumper cover

Scheme 6

1. Mirror Glass
2. Mirror Adjusting Unit Mount
3. Exterior Rearview Mirror Housing
4. Exterior Rearview Mirror Turn Signal Bulb Driver exterior rearview mirror turn signal bulb -L131- Front passenger exterior rearview mirror turn signal bulb -L132- Removing and installing, refer to «EXTERIOR MIRROR TURN SIGNAL LAMPS»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__exterior-mirror-turn-signal-lamps)
5. Screw 0.9 Nm

Scheme 7

1. Air Inlet Grille
2. Screw 4.5 Nm
3. Fog Lamp Bulb Left front fog lamp -L22- Right front fog lamp -L23- 12 V, 55 W (H11) Removing and installing, refer to «FOG LAMP BULBS»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__fog-lamp-bulbs)
4. Fog Lamps Removing and installing, refer to «FOG LAMP»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__fog-lamp)
5. Screw 4.5 Nm

HALOGEN HEADLAMPS OVERVIEW

Part 1 - Headlamp

Scheme 8

1. Screw 4.5 Nm
2. Front Turn Signal Lamp Left front turn signal lamp -M5- Right front turn signal lamp -M7- 12 V, 24 W - yellow Bulb, replacing, refer to «FRONT TURN SIGNAL LAMP BULBS -M5- / -M7»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__front-turn-signal-lamp-bulbs-m5)
3. Housing Cover For high beam/turn signal
4. High Beam Headlamp Bulb Left high beam headlamp -M30- Right high beam headlamp -M32- 12 V, 55 W (H7) Bulb, replacing, refer to «HIGH BEAM HEADLAMP BULBS -M30- / -M32»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__high-beam-headlamp-bulbs-m30)
5. Daytime Running Lamp Bulb Left daytime running lamp -L174- Right daytime running lamp -L175- 12V, 13 W Bulb, replacing, refer to «DAYTIME RUNNING LAMP BULBS»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__daytime-running-lamp-bulbs)
6. Screw 4.5 Nm
7. Headlamp Housing Bracket
8. Screw 4.5 Nm
9. Nut Self-Locking Replace
10. Bulb Socket For daytime running lamp bulb
11. Low Beam Headlamp Bulb Left low beam headlamp -M29- Right low beam headlamp -M31- 12 V, 55 W (H7) Bulb, replacing, refer to «LOW BEAM HEADLAMP BULBS -M29- / -M31»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__low-beam-headlamp-bulbs-m29)
12. Housing Cover For low beam/daytime running lights/parking light
13. Bulb Socket For the front side marker lamp bulb
14. Front Side Marker Lamp Bulb Left front side marker lamp -M33- Right front side marker lamp -M34- 12V, 5 W Bulb, replacing, refer to «FRONT SIDE MARKER LAMP BULBS»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches)
15. Parking Lamp/Daytime Running Lamp Bulb Left Parking Lamp -M1- Right Parking Lamp -M3- Left daytime running lamp Right daytime running lamp 12V, 13 W Bulb, replacing, refer to «SIDE MARKER LAMP BULBS -M1- / -M3- AND DAYTIME RUNNING LAMP BULBS -L174- / -L175»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__side-marker-lamp-bulbs-m1)
16. Headlamp Housing Removing and installing, refer to «HEADLAMP HOUSING»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches)

Part 2 - Repair Sets

Scheme 9

1. Headlamp Housing Removing and installing, refer to «HEADLAMP HOUSING»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches)
2. Headlamp Range Control Positioning Motor Left headlamp beam adjustment motor -V48- Right headlamp beam adjustment motor -V49- Removing and installing, refer to «HEADLAMP BEAM ADJUSTMENT MOTORS»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__headlamp-beam-adjustment-motors)
3. Sealing Ring Not available separately as a replacement part
4. Headlamp Range Control Positioning Motor Housing Cover The headlamp housing must be cut open to replace the positioning motor A housing cover can be ordered to seal the assembly opening. Removing and installing, refer to «HEADLAMP BEAM ADJUSTMENT MOTORS»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__headlamp-beam-adjustment-motors)
5. Screw From the repair kit for the headlamp range control positioning motor cover 2 Nm

Scheme 10

1. Bracket For the headlamp housing mount
2. Screw 8 Nm
3. Screw 8 Nm
4. Screw 4.5 Nm
5. Speed Nut
6. Screw 4.5 Nm
7. Screw 4.5 Nm
8. Mount For headlamp housing Removing and installing, refer to «HEADLAMP HOUSING MOUNT»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__headlamp-housing-mount)
9. Screw Tightening specification, refer to «Description and Operation»(/audi/q5/i-2008-2012/remont/airbag/#passenger-protection-airbags-seat-belts)
10. Front Airbag Crash Sensor Removing and installing, refer to «Removal and Installation»(/audi/q5/i-2008-2012/remont/airbag/#passenger-protection-airbags-seat-belts)
11. Screw 1.2 Nm
12. Headlamp Washer System Spray Nozzle

Scheme 11

1. Left License Plate Light Removing and installing, refer to «LICENSE PLATE LIGHTS»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__license-plate-lights)
2. Left License Plate Lamp -X4- 12V, 5 W Bulb, replacing, refer to «LICENSE PLATE LIGHTS»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__license-plate-lights)
3. Right License Plate Lamp -X5- 12V, 5 W Bulb, replacing, refer to «LICENSE PLATE LIGHTS»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__license-plate-lights)
4. Right License Plate Light Removing and installing, refer to «LICENSE PLATE LIGHTS»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__license-plate-lights)
5. High Mounted Brake Light High-mounted brake lamp bulb -M25- Removing and installing, refer to «HIGH-MOUNTED BRAKE LAMP BULB»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__high-mounted-brake-lamp-bulb)
6. Screw 2.5 Nm
7. Screw 2.5 Nm

Scheme 12

1. Right Front Center Parking Aid Sensor -G253- In the radiator grille Removing and installing, refer to «FRONT PARKING AID SENSORS»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__front-parking-aid-sensors)
2. Right Front Parking Aid Sensor -G252- In front bumper cover Removing and installing, refer to «FRONT PARKING AID SENSORS»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__front-parking-aid-sensors)
3. Parking Aid Button -E266- Only with 8-channel parking aid Vehicles with MMI Basic Assembly overview, refer to «CENTER CONSOLE LIGHTS AND SWITCHES OVERVIEW»(/audi/q5/i-2008-2012/remont/door-locks-anti-theft-systems/#interior-lights-switches) Vehicles with MMI comfort equipment Assembly overview, refer to «INSTRUMENT PANEL LIGHTS AND SWITCHES OVERVIEW»(/audi/q5/i-2008-2012/remont/door-locks-anti-theft-systems/#interior-lights-switches)
4. Rear Parking Aid Warning Buzzer -H15- On the back of the right D-pillar Removing and installing, refer to «REAR PARKING AID WARNING BUZZER»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__rear-parking-aid-warning-buzzer)
5. Screw
6. Expanding Clip
7. Electrical Connector
8. Parking Aid Control Module -J446- In luggage compartment at rear, right side, below side trim Removing and installing, refer to «PARKING AID CONTROL MODULE -J446»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__parking-aid-control-module-j446)
9. Nut 3 Nm
10. Nut 3 Nm
11. Right Rear Parking Aid Sensor -G206- In rear bumper cover Removing and installing, refer to «REAR PARKING AID SENSORS -G203- / -G204- / -G205- / -G206»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__rear-parking-aid-sensors-g203)
12. Right Rear Center Parking Aid Sensor -G205- In rear bumper cover Removing and installing, refer to «REAR PARKING AID SENSORS -G203- / -G204- / -G205- / -G206»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__rear-parking-aid-sensors-g203)
13. Left Rear Center Parking Aid Sensor -G204- In rear bumper cover Removing and installing, refer to «REAR PARKING AID SENSORS -G203- / -G204- / -G205- / -G206»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__rear-parking-aid-sensors-g203)
14. Left Rear Parking Aid Sensor -G203- In rear bumper cover Removing and installing, refer to «REAR PARKING AID SENSORS -G203- / -G204- / -G205- / -G206»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__rear-parking-aid-sensors-g203)
15. Screw
16. Front Parking Aid Warning Buzzer -H22- Only with 8-channel parking aid At the instrument panel carrier behind the driver side storage compartment Removing and installing, refer to «Front Parking Aid Warning Buzzer -H22-, 8-CHANNEL PARKING AID»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__front-parking-aid-warning-buzzer-h22)
17. Electrical Connector
18. Expanding Clip
19. Left Front Parking Aid Sensor -G255- In front bumper cover Removing and installing, refer to «FRONT PARKING AID SENSORS»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__front-parking-aid-sensors)
20. Left Front Center Parking Aid Sensor -G254- In the radiator grille Removing and installing, refer to «FRONT PARKING AID SENSORS»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__front-parking-aid-sensors)

STEERING COLUMN SWITCH MODULE AND ELECTRONIC IGNITION LOCK OVERVIEW

1. The steering column switch module consists of coil connector with slip ring, steering angle sensor -G85-, steering column switch (turn signal indicator switch, wiper switch, cruise control switch) and steering column electronic systems control module.
2. Fault finding is done in Guided Fault Finding with the Vehicle Diagnostic Tester.

Scheme 13

1. Screw 0.5 Nm
2. Transport Protection
3. Steering Column Electronics Control Module -J527- With airbag spiral spring/return spring with slip ring -F138-, steering angle sensor Removing and installing, refer to «STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__steering-column-electronic-systems-control-module) CAUTION: Risk of damaging coil connector. Coil connector with slip ring is not to be turned following removal. Connector assignment of Steering Column Electronic Systems Control Module, refer to «STEERING COLUMN ELECTRONICS CONTROL MODULE J527 CONNECTOR ASSIGNMENT»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__steering-column-electronics-control-module-j527)
4. Mount With turn signal switch -E2-, windshield wiper intermittent mode switch -E22- On vehicles with cruise control with cruise control switch -E45- Removing and installing, refer to «TURN SIGNAL SWITCH, CRUISE CONTROL SWITCH AND WINDSHIELD WIPER AND WASHER INTERMITTENT MODE SWITCH»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__turn-signal-switch-cruise-control-switch)
5. Clamping Ring
6. Screw 4 Nm
7. Steering Column
8. Access/Start Authorization Switch -E415- Removing and installing, refer to «ACCESS/START AUTHORIZATION SWITCH»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__accessstart-authorization-switch)
9. Divider For access/start authorization switch Removing and installing, refer to «ACCESS/START AUTHORIZATION SWITCH»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__accessstart-authorization-switch)
10. Ignition Key

Scheme 14

Tighten the bolt -2- on the access/start authorization switch -1- to 3 Nm.

STEERING COLUMN ELECTRONICS CONTROL MODULE J527 CONNECTOR ASSIGNMENT

1. The Steering Column Electronics Control Module -J527- is part of the complete system steering column switch module. and receives signals from steering column switch, for example.
2. Check the steering column electronic systems control module in "Guided Fault Finding" using the Vehicle Diagnostic Tester.

Scheme 15

1. A - Turn Signal/Cruise Control Connector Mount 1 - Cruise control lever ground 2 - Cruise control set 3 - ACC 4 - Cruise control Res (+) / Set (-) 5 - Voltage supply (terminal 15) 6 - Cruise control ground/turn signal ground 7 - Cruise control off 8 - Cruise control Res/Soft 9 - Radio (AIA) 10 - Headlamp flasher 11 - High beams 12 - Turn signal 13 - Ground turn signal
2. B - Spiral Spring/Airbag/Multifunction Steering Wheel/Signal Horn Connector Mount 1 - Ground 2 - Horn signal 3 - Airbag 1 + 4 - Airbag 1 - 5 - Airbag 2 + 6 - Airbag 2 - 7 - Tip down 8 - Terminal 30 9 - LIN 10 - Tip up 11 - Dimming (terminal 58s) 12 - Tip ground
3. C - Airbag Control Module Connector Mount 3 - Airbag 1 + 4 - Airbag 1 - 5 - Airbag 2 - 6 - Airbag 2 +
4. D - Electrical System Connector Mount 1 - Not used 2 - Not used 3 - Voltage supply terminal 30 4 - Powertrain CAN bus shielding 5 - Cruise control latched Off 6 - Not used 7 - Radio/radio button 8 - Comfort CAN bus Low 9 - Comfort CAN bus High 10 - Voltage supply terminal 31 11 - Powertrain CAN bus High 12 - Powertrain CAN bus Low 13 - Electronic ignition lock signal terminal 15 14 - Not used 15 - Not used 16 - Not used
5. E - Connector Mount Wiper System/DIS 1 - Windshield washer ground 2 - Windshield wiper switch 3 - Wash 4 - DIS signal 5 - Intermittent wipe potentiometer 6 - DIS ground

Scheme 16

1. Tail Lamp In the rear lid Removing and installing, refer to «TAIL LAMP»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__tail-lamp)
2. Nut Tightening specifications and sequence, refer to «TAIL LAMPS, TIGHTENING SPECIFICATION AND SEQUENCE»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches) .
3. Nut Tightening specifications and sequence, refer to «TAIL LAMPS, TIGHTENING SPECIFICATION AND SEQUENCE»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches) .
4. Rear Turn Signal Bulb Left rear turn signal lamp -M6- Right rear turn signal lamp -M8- 12V, 21 W Bulb, replacing, refer to «OUTER BULB HOLDER»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__outer-bulb-holder)
5. Brake and Tail Lamp Bulb Left brake/tail lamp bulb -M21- Right brake/tail lamp bulb -M22- 12V, 21 W Bulb, replacing «OUTER BULB HOLDER»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__outer-bulb-holder)
6. Cap Removing and installing, refer to «TAIL LAMP»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__tail-lamp)
7. Wrench For removing and installing the bulb sockets
8. Central Connector For lamp sockets
9. Brake and Tail Lamp Bulb Left brake/tail lamp bulb 2 -M58- Right brake/tail lamp bulb 2 -M59- 12V, 21 W Bulb, replacing, refer to «INNER BULB HOLDER»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__inner-bulb-holder)
10. Wiring Bushing
11. Gasket Self-Adhesive Replace if damaged
12. Nut Tightening specifications and sequence, refer to «TAIL LAMPS, TIGHTENING SPECIFICATION AND SEQUENCE»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches) .

Scheme 17

Tighten the nuts for the lamps in the rear lid to 3.5 Nm and in sequence -1, 2, 3-.

FASTENER TIGHTENING SPECIFICATIONS

HEADLAMPS, CHECKING AND ADJUSTING CONDITIONS

1. Tire pressure must be OK
2. Headlamp lenses must be clean and dry.
3. Headlamps lenses must not be damaged.
4. Headlamp reflectors and all bulbs must be OK.
5. Vehicle load must be created.

Vehicle load on driver's seat in otherwise unloaded vehicle (curb weight).

1. One person or 75 kg (167).

The curb weight is the weight of the operational vehicle with completely full fuel tank, including the weight of all equipment carried in operation.

1. Fuel tank: at least 90% full.
2. Equipment present: for example, spare wheel, tools, vehicle jack, fire extinguisher, etc.

If the fuel tank is not at least 90% full, the load must be created as follows.

Check fuel tank fill lever in instrument cluster tank gauge and compare with the following table. Place additional weight in the luggage compartment, if necessary.

Example: if the fuel tank is half full, an additional 37 kg (approximately 81 lbs.) must be placed in the luggage compartment.

Note. Use fuel containers filled with water as additional weight (a 5 liter fuel container filled with water weighs 5 kg (11 lbs.)).

Scheme 18

Scheme 19

1. Roll the vehicle several yards or move it back and forth several times to seat the springs.
2. Vehicle and headlamp adjusting unit must be on a level surface.
3. Parking brake must not be engaged so vehicle is not under stress.
4. Headlamp adjusting unit must be aligned to vehicle.
5. The headlamp adjuster must be distance -a- 30 to 70 cm in front of the headlamp and should not deviate more than dimension -b- = 3 cm from the headlamp center point.
6. Set the angle dimension on the headlamp adjusting unit.
7. The angle dimension -arrow- is stamped on the upper edge of the headlamp -1- in %.

Note. The headlamp must be adjusted according to the angle dimension stamped on the headlamp. The percentage indicator is based on a 10 meter projection distance. Fro example, an angle dimension of 1.0% corresponds to 10 cm.

HEADLAMPS, ADJUSTING

Procedure

Follow the complete test and adjustment requirements. Refer to HEADLAMPS, CHECKING AND ADJUSTING CONDITIONS .

Vehicles with Halogen Headlamps

Set the range position thumbwheel to the 0 position.

Vehicles with Gas Discharge Headlamps

Select the basic setting function in Guided Fault Finding or Guided Functions using the Vehicle Diagnostic Tester.

Select the function or path

Follow the instructions on the Vehicle Diagnostic Tester display.

All Vehicles

Scheme 20

Switch on low beams.

1. The horizontal light-dark border must touch the dividing line -1- on the adjusting unit test surface.
2. The point -2- between the left horizontal part and the right rising part of the light-dark border must run vertically through the central mark -3-. The bright core of the light beam must be to the right of the vertical.

Note. To determine the point -2- more easily, cover and uncover the left half of the headlamp several times. Then check low beam again. After correct headlamp adjustment, the center of the high beam light beam must be on the central marking -3-. The adjustment procedure for the test screen without the 15° adjustment line also applies to the previous test screen with the 15° adjustment line. To avoid incorrect adjustments, ignore the 15° adjustment line -arrow-.

To adjust the height of the headlamp, set the light-dark border just under the dividing line with the adjustment screw -1-.

Scheme 21

Then adjust the light-dark border, starting from the bottom, on the dividing line.

For side adjustment, turn adjusting screw -2-.

Note. The allocation on the right headlamp is reversed.

Vehicles with Gas Discharge Headlamps

After the headlamp is adjusted, complete the basic setting. Switch off the ignition and disconnect the diagnostic connector.

FOG LAMPS, ADJUSTING

Procedure

Scheme 22

Complete test and adjustment requirements. Refer to HEADLAMPS, CHECKING AND ADJUSTING CONDITIONS .

Turn on the fog lamps.

To adjust headlamp range, turn adjusting screw -arrow-.

1. Angle dimension: 20 cm (equals 2%).

Note. Side adjustment is not intended.

AUXILIARY HEADLAMPS, ADJUSTING

Retrofitted auxiliary headlamps must be checked and adjusted according to the guidelines used for other systems.

AUTOMATIC HEADLAMP VERTICAL AIM AND RANGE, CONTROL MODULES -J431- / -J745

If the control module was replaced, select the "Replace" function for the respective control module in "Guided Fault Finding" or "Guided Functions" using the Vehicle Diagnostic Tester.

Select the function or path

Follow the instructions on the Vehicle Diagnostic Tester display.

Removing

Scheme 23

Switch off ignition and remove ignition key.

Remove glove compartment. Refer to Removal and Installation .

Release the retaining clip -arrow- and remove the -1- from the retaining frame.

Disconnect the electrical connector -2-.

To disconnect electrical connector, press catch -1-, turn retaining bracket in the direction of the -arrow- and remove connector.

Scheme 24

Installing

1. Tightening specification, refer to «AUTOMATIC HEADLAMP VERTICAL AIM CONTROL OVERVIEW»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches) .

Install in reverse order of removal, observing the following

Install glove compartment. Refer to Removal and Installation .

Follow the prompts on the Vehicle Diagnostic Tester display in the case of a new headlamp range control module.

ADAPTIVE CORNERING LAMP MOTORS V318/V319

The dynamic adaptive cornering light position motor sits in the headlamp housing and cannot be replaced separately if it is faulty.

Headlamp housing, removing and installing. Refer to HEADLAMP HOUSING .

DAYTIME RUNNING LAMP AND PARKING LAMP LED MODULES L176 AND L177

Removing

Switch vehicle ignition off

Disconnect the battery ground (GND) cable from the battery. Refer to BATTERY, DISCONNECTING AND CONNECTING . Vehicles with high voltage system, refer to BATTERY AND AUXILIARY BATTERY, DISCONNECTING AND CONNECTING .

Right side of the vehicle: Remove the air filter housing.

1. For gasoline engine, refer to ] «[For engine(s) CAEB] Removal and Installation»(ref-515412-S12570427722012120300000) or to «[For engine(s) CALB] Removal and Installation»(/audi/q5/i-2008-2012/remont/fuel-system/#32l-fuel-injection-system-engine-codes-calb)

Open the clip -2- in the direction of the -arrow-.

Scheme 25

Move the housing cover -1- to the side and remove it.

Remove the screws -2- and -4- and remove the LED module -3- from the mount.

Scheme 26

Squeeze the clips in the direction of the -arrows- and disconnect the LED module connector -1-.

Installing

1. Tightening specification, refer to «BI-XENON HEADLAMPS WITH CORNERING LIGHT OVERVIEW»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__bi-xenon-headlamps-with-cornering-light-overview) .

Install in reverse order of removal, observing the following

Close housing cover and secure with clip.

Right side of the vehicle: Install the air filter housing.

1. For gasoline engine, refer to «[For engine(s) CAEB] Removal and Installation»(ref-515412-S12570427722012120300000) or to «[For engine(s) CALB] Removal and Installation»(/audi/q5/i-2008-2012/remont/fuel-system/#32l-fuel-injection-system-engine-codes-calb)

Connect battery. Required actions, refer to BATTERY, DISCONNECTING AND CONNECTING . Take the necessary precautions for vehicles with a high voltage system and refer to BATTERY AND AUXILIARY BATTERY, DISCONNECTING AND CONNECTING

FRONT SIDE MARKER LAMP BULBS

The front side marker lamp bulb is an LED and is integrated in the headlamp housing. The LED cannot be replaced. The entire headlamp must be replaced.

Replace the headlamp housing, refer to HEADLAMP HOUSING .

FRONT TURN SIGNAL LAMP BULBS

Removing

Remove headlamp housings. Refer to HEADLAMP HOUSING .

Open the clip -2- in the direction of the -arrow-.

Move the housing cover -1- to the side and remove it.

Vehicles with cornering lamp (AFS): disconnect the connectors -1, 2 and 3- on the headlamp power output stages -4-.

Scheme 27

Turn the bulb -1- counterclockwise in the direction of the -arrow- and remove it from the housing.

Scheme 28

Unlock the retaining spring and disconnect the bulb connector.

Installing

Install in reverse order of removal, observing the following

Insert the new bulb into the headlamp without touching the bulb with bare hands.

Close housing cover and secure with clip.

Vehicles with cornering lamp (AFS): install the headlamp power output stage. Refer to HEADLAMP POWER OUTPUT STAGES -J667- / -J668 .

Install the headlamp housing. Refer to HEADLAMP HOUSING .

HEADLAMP HOUSING

Removing

Scheme 29

Switch vehicle ignition off

Disconnect the battery ground (GND) cable. Refer to BATTERY, DISCONNECTING AND CONNECTING .

Remove front bumper cover. Refer to Removal and Installation .

Disconnect the electrical connector -5-.

Free up the wiring harness -6- on the bracket by loosening the clips -arrows B- and cutting the cable ties -arrows A-.

Remove the headlamp washer fluid line -8- from the clips.

Disconnect the connector on the front airbag crash sensor. Refer to Removal and Installation .

Remove the screws -1, 3, 4 and 7- and remove the headlamp bracket -2- and housing.

If the headlamp housing is being replaced, then the mount on the bracket must be removed. Refer to HEADLAMP HOUSING MOUNT .

Installing

Scheme 30

1. Tightening specification. Refer to «BI-XENON HEADLAMPS WITH CORNERING LIGHT OVERVIEW»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__bi-xenon-headlamps-with-cornering-light-overview) .

Install in reverse order of removal, observing the following

Install the headlamp housing -3- and bracket onto the lock carrier and the fender.

Tighten the screws -1, 2, 4 and 5- by hand.

Scheme 31

1. The guide tab -arrow B- on the headlamp housing bracket -1- must fit into the opening on the lock carrier -3-.
2. The guides -2- and -4- must fit into the mounts -arrow A-.

Install the front bumper cover. Refer to Removal and Installation .

Align the headlamp housing gap -3- dimensions according to the body contours.

1. Gap dimension = even gap dimension.

Remove front bumper cover. Refer to Removal and Installation .

Tighten the screws -1, 2, 4 and 5-.

Install the front bumper cover. Refer to Removal and Installation .

Check gap dimensions again, repeat adjustment of gap dimensions if necessary, as described above.

Connect battery. Required actions, refer to BATTERY, DISCONNECTING AND CONNECTING . Take the necessary precautions for vehicles with a high voltage system and refer to BATTERY AND AUXILIARY BATTERY, DISCONNECTING AND CONNECTING

Adjust headlamps. Refer to HEADLAMPS, CHECKING AND ADJUSTING CONDITIONS .

HEADLAMP BEAM ADJUSTMENT MOTORS -V48- / -V49

Note. The headlamp housing must be cut at the designated location with a sharp box cutter to replace the adjustment motor. A housing cover can be ordered to seal the assembly opening.

Special tools and workshop equipment required

1. Protective gloves
2. Protective eyewear
3. Box cutter

Removing

Remove headlamp housings. Refer to HEADLAMP HOUSING .

Scheme 32

Cut the cover -5- out of the headlamp housing with a sharp box cutter.

Open the retainer -2-.

Move the housing cover -1- to the side and remove it.

Turn the headlamp range control positioning motor -4-.

1. Left headlamp: counterclockwise.
2. Right headlamp: clockwise.

Push the ball end of the positioning stem upward and out of the ball end mount by swiveling the control motor.

Remove the control motor.

Disconnect the electrical connector -3-.

Installing

1. Tightening specification, refer to «BI-XENON HEADLAMPS WITH CORNERING LIGHT OVERVIEW»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__bi-xenon-headlamps-with-cornering-light-overview) .

Install in reverse order of removal, observing the following

Connect the electrical connector when guiding in.

Start by inserting ball end of positioning stem from underneath in reflector socket. To do so, pull reflector to rear.

Position and lock the headlamp range control motor bayonet connection on the headlamp housing.

1. Left headlamp: clockwise.
2. Right headlamp: counterclockwise.

Close the opening in the headlamp with the housing cover -1- from the repair set.

Scheme 33

Tighten the bolts -arrows-.

Install the headlamp housing. Refer to HEADLAMP HOUSING .

HEADLAMP HOUSING REPAIR SET

1. In the case of broken headlamp mounting tabs, the entire headlamp must be replaced in vehicles to 3/22/2009. Refer to «HEADLAMP HOUSING»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches) .
2. Headlamp mounting tabs that have broken off can be replaced by installing the repair set in vehicles after 3/23/2009. Completely replacing the headlamp is not necessary.

Procedure

Scheme 34

Remove headlamp with broken mounting tab. Refer to HEADLAMP HOUSING .

Remove remains of broken mounting tab at headlamp housing.

Position the repair set mounting tab -2- on the headlamp housing -3- and secure it with the screws -1-.

Tightening Specifications

HEADLAMP POWER OUTPUT STAGES -J667- / -J668

Removing

Switch vehicle ignition off

Disconnect battery ground (GND) cable. Refer to BATTERY, DISCONNECTING AND CONNECTING .

Right side of the vehicle: Remove the air filter housing.

1. For gasoline engine, refer to «[For engine(s) CAEB] Removal and Installation»(ref-515412-S12570427722012120300000) or to «[For engine(s) CALB] Removal and Installation»(/audi/q5/i-2008-2012/remont/fuel-system/#32l-fuel-injection-system-engine-codes-calb)

Open the clip -2- in the direction of the -arrow-.

Move the housing cover -1- to the side and remove it.

Disconnect the connectors -1, 2 and 3- on the headlamp power output stage -4-.

Remove the bolts -arrows- and retaining plate -1-.

Scheme 35

Remove the headlamp power output stage -2- from the housing cover -4-.

Installing

1. Tightening specification, refer to «BI-XENON HEADLAMPS WITH CORNERING LIGHT OVERVIEW»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__bi-xenon-headlamps-with-cornering-light-overview) .

Install in reverse order of removal, observing the following

Check the seal -3- between the power output stage and housing cover.

Right side of the vehicle: Install the air filter housing.

1. For gasoline engine, refer to «[For engine(s) CAEB] Removal and Installation»(ref-515412-S12570427722012120300000) or to «[For engine(s) CALB] Removal and Installation»(/audi/q5/i-2008-2012/remont/fuel-system/#32l-fuel-injection-system-engine-codes-calb)

Connect battery. Required actions, refer to BATTERY, DISCONNECTING AND CONNECTING . Take the necessary precautions for vehicles with a high voltage system and refer to BATTERY AND AUXILIARY BATTERY, DISCONNECTING AND CONNECTING

HID HEADLAMP BULBS

Removing

Scheme 36

Switch vehicle ignition off

Disconnect the battery ground (GND) cable from the battery. Refer to BATTERY, DISCONNECTING AND CONNECTING . Vehicles with high voltage system, refer to BATTERY AND AUXILIARY BATTERY, DISCONNECTING AND CONNECTING .

To remove the expanding clips -arrows-, carefully push the pin -1- to dimension -x- until it audibly engages into the expanding clip -arrow A-.

1. Dimension -x- = 5 mm.

Remove the unlocked expanding clip -2- and the pin.

Lift the cover -3- on the lock carrier and engage it on the radiator grille.

Right side of the vehicle: Remove the air filter housing.

1. For gasoline engine, refer to «[For engine(s) CAEB] Removal and Installation»(ref-515412-S12570427722012120300000) or to «[For engine(s) CALB] Removal and Installation»(/audi/q5/i-2008-2012/remont/fuel-system/#32l-fuel-injection-system-engine-codes-calb)

Open the clip -2- in the direction of -arrow A-.

Scheme 37

Move the housing cover -1- to the side, in the direction of -arrow B- and remove it.

Remove the screws -2- and -4-.

Scheme 38

Loosen the screws -3- three turns.

Push the headlamp housing -1- forward all the way in the direction of the -arrow-.

Disconnect the electrical connector -1-.

Scheme 39

Turn the circlip -2- in the direction of the -arrows- and remove the HID lamp -3- from the housing.

Installing

1. Tightening specification, refer to «BI-XENON HEADLAMPS WITH CORNERING LIGHT OVERVIEW»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__bi-xenon-headlamps-with-cornering-light-overview) .

Install in reverse order of removal, observing the following

Connect the connector and insert the new HID bulb in the housing. Do not touch the glass bulb with bare hands.

1. Installation position: the electrical connection faces down.

Secure HID lamp with circlip.

Close housing cover and secure with clip.

Right side of the vehicle: Install the air filter housing.

1. For gasoline engine, refer to «[For engine(s) CAEB] Removal and Installation»(ref-515412-S12570427722012120300000) or to «[For engine(s) CALB] Removal and Installation»(/audi/q5/i-2008-2012/remont/fuel-system/#32l-fuel-injection-system-engine-codes-calb)

Install the lock carrier cover on the radiator grille. Refer to Removal and Installation .

Connect battery. Required actions, refer to BATTERY, DISCONNECTING AND CONNECTING . Take the necessary precautions for vehicles with a high voltage system and refer to BATTERY AND AUXILIARY BATTERY, DISCONNECTING AND CONNECTING

HID LAMP CONTROL MODULE

Removing

Switch vehicle ignition off

Disconnect the battery ground (GND) cable from the battery. Refer to BATTERY, DISCONNECTING AND CONNECTING . Vehicles with high voltage system, refer to BATTERY AND AUXILIARY BATTERY, DISCONNECTING AND CONNECTING .

Right side of the vehicle: Remove the air filter housing.

1. For gasoline engine, refer to «[For engine(s) CAEB] Removal and Installation»(ref-515412-S12570427722012120300000) or to «[For engine(s) CALB] Removal and Installation»(/audi/q5/i-2008-2012/remont/fuel-system/#32l-fuel-injection-system-engine-codes-calb)

Remove the bolts -arrows-.

Scheme 40

Remove control module -4- from headlamp housing.

Disconnect the adapter wire -3- and connector -1- on the HID headlamp control module.

Remove the HID headlamp control module.

Installing

1. Tightening specification, refer to «BI-XENON HEADLAMPS WITH CORNERING LIGHT OVERVIEW»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__bi-xenon-headlamps-with-cornering-light-overview) .

Install in reverse order of removal, observing the following

Check seal -2- between gas discharge headlamp control module and headlamp housing for damage.

Right side of the vehicle: Install the air filter housing.

1. For gasoline engine, refer to «[For engine(s) CAEB] Removal and Installation»(ref-515412-S12570427722012120300000) or to «[For engine(s) CALB] Removal and Installation»(/audi/q5/i-2008-2012/remont/fuel-system/#32l-fuel-injection-system-engine-codes-calb)

Connect battery. Required actions, refer to BATTERY, DISCONNECTING AND CONNECTING . Take the necessary precautions for vehicles with a high voltage system and refer to BATTERY AND AUXILIARY BATTERY, DISCONNECTING AND CONNECTING

LOW BEAM REFLECTOR MOTORS

The lower beam cover sits in the headlamp housing and cannot be replaced separately if it is faulty.

Headlamp housing, removing and installing, refer to HEADLAMP HOUSING .

EXTERIOR MIRROR TURN SIGNAL LAMPS

Special tools and workshop equipment required

1. Hook 3438
2. Protective gloves

Removing

Scheme 41

Switch off ignition and remove ignition key.

Remove the rearview mirror, refer to -1- Removal and Installation .

Pull the outside mirror housing -2- far just enough in the direction of -arrow A- until the tabs in the cover disengage.

Scheme 42

Using the Hook 3438, release the left and right retaining tabs -1- in the direction of -arrow B- and remove the outside mirror housing from the cover.

Press the mirror adjusting unit down and pull the exterior rearview mirror housing -2- upward slightly.

Scheme 43

Disconnect the lane change assistance warning lamp connector on the front side of the mirror adjusting unit mount, if applicable.

Disconnect the connector -1- and remove the outside mirror housing.

Remove bolt -2-.

Scheme 44

Remove the turn signal bulb housing -3- from the outside mirror housing -1- in the direction of -arrow B-, by pulling the bulb housing out of the guide in the direction of -arrow A-.

Installing

Scheme 45

1. Tightening specifications, refer to «EXTERIOR REARVIEW MIRROR TURN SIGNALS OVERVIEW»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches) and «Removal and Installation»(/audi/q5/i-2008-2012/remont/mirrors/#exterior-equipment) .

Install in reverse order of removal, observing the following

Note. The entire exterior mirror turn signal must be replaced if an LED is faulty.

Insert the tip of the turn signal in the slit in the exterior rearview mirror housing -1- -arrow-.

Place the turn signal bulb housing -3- into the outside mirror housing; make sure the groove fits into the guide -2-.

Install the rearview mirror. Refer to Removal and Installation .

FOG LAMP

Removing

Scheme 46

Switch off ignition and remove ignition key.

Turn light switch into the "0" position.

Using a screwdriver -1- release the hooks in the direction of -arrow A-.

Remove the intake air grille -2- on the bumper cover in the direction of -arrow B-.

Remove screws -1- and -2-.

Scheme 47

Remove the headlamp housing -3- from the bumper cover while guiding the retaining tab -arrow- out of the mount.

Disconnect the electrical connector.

Installing

1. Tightening specification, refer to «FOG LAMPS OVERVIEW»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches) .

Install in reverse order of removal, observing the following

Adjusting fog lamps. Refer to HEADLAMPS, CHECKING AND ADJUSTING CONDITIONS .

FOG LAMP BULBS

Removing

Scheme 48

Remove fog lamp. Refer to FOG LAMP .

Rotate the bulb -1- counterclockwise in the direction of the -arrow- and remove it from the fog lamp housing -2-.

Installing

Install in reverse order of removal, observing the following

Insert the new bulb into the housing without touching the bulb with bare hands.

Rotate the bulb clockwise to secure.

Install fog lamp. Refer to FOG LAMP .

DAYTIME RUNNING LAMP BULBS

Removing

Switch off ignition and remove ignition key.

Turn light switch into the "0" position.

To remove the expanding clips -arrows-, carefully push the pin -1- to dimension -x- until it audibly engages into the expanding clip -arrow A-.

1. Dimension -x- = 5 mm.

Remove the unlocked expanding clip -2- and the pin.

Lift the cover -3- on the lock carrier and engage it on the radiator grille.

Right side of the vehicle: Remove the air filter housing.

1. For gasoline engine, refer to «[For engine(s) CAEB] Removal and Installation»(ref-515412-S12570427722012120300000) or to «[For engine(s) CALB] Removal and Installation»(/audi/q5/i-2008-2012/remont/fuel-system/#32l-fuel-injection-system-engine-codes-calb)

Open the clip -2- -arrow A-.

Move the housing cover -1- to the side -arrow B- and remove it.

Remove the screws -2- and -4-.

Loosen the screws -3- three turns.

Push the headlamp housing -1- forward all the way in the direction of the -arrow-.

Turn the bulb wrench -1- counterclockwise, in the direction of the -arrow- and remove it from the housing.

Scheme 49

Release the spring -4- and disconnect the bulb connector -2-.

Note. Do not remove the wrench -5- from the connector -3-.

Installing

Install in reverse order of removal, observing the following

Insert the new bulb into the headlamp without touching the bulb with bare hands.

Close housing cover and secure with clip.

Right side of the vehicle: Install the air filter housing.

1. For gasoline engine, refer to «[For engine(s) CAEB] Removal and Installation»(ref-515412-S12570427722012120300000) or to «[For engine(s) CALB] Removal and Installation»(/audi/q5/i-2008-2012/remont/fuel-system/#32l-fuel-injection-system-engine-codes-calb)

Install the lock carrier cover on the radiator grille. Refer to Removal and Installation .

Removing

Switch off ignition and remove ignition key.

Turn light switch into the "0" position.

To remove the expanding clips -arrows-, carefully push the pin -1- to dimension -x- until it audibly engages into the expanding clip -arrow A-.

1. Dimension -x- = 5 mm.

Remove the unlocked expanding clip -2- and the pin.

Lift the cover -3- on the lock carrier and engage it on the radiator grille.

Right side of the vehicle: Remove the air filter housing.

1. For gasoline engine, refer to «[For engine(s) CAEB] Removal and Installation»(ref-515412-S12570427722012120300000) or to «[For engine(s) CALB] Removal and Installation»(/audi/q5/i-2008-2012/remont/fuel-system/#32l-fuel-injection-system-engine-codes-calb)

Open the clip -2- in the direction of -arrow A-.

Move the housing cover -1- to the side -arrow B- and remove it.

Remove the screws -2- and -4-.

Loosen the screws -3- three turns.

Push the headlamp housing -1- forward all the way in the direction of the -arrow-.

Remove the bulb wrench -1- from the housing in the direction of the -arrow-.

Scheme 50

Remove the bulb -2- from the socket -3-.

Installing

Install in reverse order of removal, observing the following

Insert the new bulb into the headlamp without touching the bulb with bare hands.

Close housing cover and secure with clip.

Right side of the vehicle: Install the air filter housing.

1. For gasoline engine, refer to «[For engine(s) CAEB] Removal and Installation»(ref-515412-S12570427722012120300000) or to «[For engine(s) CALB] Removal and Installation»(/audi/q5/i-2008-2012/remont/fuel-system/#32l-fuel-injection-system-engine-codes-calb)

Install the lock carrier cover on the radiator grille. Refer to Removal and Installation .

FRONT TURN SIGNAL LAMP BULBS -M5- / -M7

Removing

Switch off ignition and remove ignition key.

Turn light switch into the "0" position.

Right side of the vehicle: Remove the air filter housing.

1. For gasoline engine, refer to «[For engine(s) CAEB] Removal and Installation»(ref-515412-S12570427722012120300000) or to «[For engine(s) CALB] Removal and Installation»(/audi/q5/i-2008-2012/remont/fuel-system/#32l-fuel-injection-system-engine-codes-calb)

Open the clip -2- in the direction of the -arrow-.

Scheme 51

Move the housing cover -1- to the side and remove it.

Turn the bulb -1- counterclockwise in the direction of the -arrow- and remove it from the housing.

Scheme 52

Open the spring -4- and disconnect the connector -3- on the bulb -2-.

Installing

Install in reverse order of removal, observing the following

Insert the new bulb into the headlamp without touching the bulb with bare hands.

Close housing cover and secure with clip.

Right side of the vehicle: Install the air filter housing.

1. For gasoline engine, refer to «[For engine(s) CAEB] Removal and Installation»(ref-515412-S12570427722012120300000) or to «[For engine(s) CALB] Removal and Installation»(/audi/q5/i-2008-2012/remont/fuel-system/#32l-fuel-injection-system-engine-codes-calb)

HEADLAMP BEAM ADJUSTMENT MOTORS

Note. The headlamp housing must be cut at the designated location with a sharp box cutter to replace the headlamp range control positioning motor. A housing cover can be ordered to seal the assembly opening.

Special tools and workshop equipment required

1. Protective gloves
2. Protective eyewear
3. Box cutter

Removing

Scheme 53

Remove headlamp housings. Refer to HEADLAMP HOUSING .

Cut the cover -5- out of the headlamp housing with a sharp box cutter.

Open the retainer -2-.

Move the housing cover -1- to the side and remove it.

Turn the headlamp range control positioning motor -4-.

1. Left headlamp: counterclockwise.
2. Right headlamp: clockwise.

Push the ball end of the positioning stem upward and out of the ball end mount by swiveling the control motor.

Remove the control motor.

Disconnect the electrical connector -3-.

Installing

1. Tightening specification, refer to «HALOGEN HEADLAMPS OVERVIEW»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__halogen-headlamps-overview) .

Install in reverse order of removal, observing the following

Connect the electrical connector when guiding in.

Start by inserting ball end of positioning stem from underneath in reflector socket. To do so, pull reflector to rear.

Position and lock the headlamp range control motor bayonet connection on the headlamp housing.

1. Left headlamp: clockwise.
2. Right headlamp: counterclockwise.

Close the opening in the headlamp with the housing cover -1- from the repair set.

Tighten the bolts -arrows-.

Install the headlamp housing. Refer to HEADLAMP HOUSING .

Removing

Switch off ignition and remove ignition key.

Turn light switch into the "0" position.

Remove front bumper cover. Refer to Removal and Installation .

Disconnect the electrical connector -5-.

Free up the wiring harness -6- on the bracket by loosening the clips -arrows B- and cutting the cable ties -arrows A-.

Remove the headlamp washer fluid line -8- from the clamps, if applicable.

Disconnect the connector on the front airbag crash sensor. Refer to Removal and Installation .

Remove the screws -1, 3, 4 and 7- and remove the headlamp bracket -2- and housing.

If the headlamp housing is being replaced, then the mount on the bracket must be removed. Refer to HEADLAMP HOUSING MOUNT .

Installing

1. Tightening specification, refer to «HALOGEN HEADLAMPS OVERVIEW»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__halogen-headlamps-overview) .

Install in reverse order of removal, observing the following

Install the headlamp housing -3- and bracket onto the lock carrier and the fender.

Tighten the screw -1, 2, 4 and 5- by hand.

1. The guide tab -arrow B- on the headlamp housing bracket -1- must fit into the opening on the lock carrier -3-.
2. The guides -2- and -4- must fit into the mounts -arrow A-.

Install the front bumper cover. Refer to Removal and Installation .

Align the headlamp housing gap -3- dimensions according to the body contours.

1. Gap dimension = even gap dimension.

Remove front bumper cover. Refer to Removal and Installation .

Tighten the screws -1, 2, 4 and 5-.

Install the front bumper cover. Refer to Removal and Installation .

Check gap dimensions again, repeat adjustment of gap dimensions if necessary, as described above.

Adjust headlamps. Refer to HEADLAMPS, CHECKING AND ADJUSTING CONDITIONS .

1. In the case of broken headlamp mounting tabs, the entire headlamp must be replaced in vehicles up to 3/22/2009. Refer to «HEADLAMP HOUSING»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches) .
2. Headlamp mounting tabs that have broken off can be replaced by installing the repair set in vehicles after 3/23/2009. Completely replacing the headlamp is not necessary.

Procedure

Remove headlamp with broken mounting tab. Refer to HEADLAMP HOUSING .

Remove remains of broken mounting tab at headlamp housing.

Position the repair set mounting tab -2- on the headlamp housing -3- and secure it with the screws -1-.

Tightening Specifications

HIGH BEAM HEADLAMP BULBS -M30- / -M32

Removing

Switch off ignition and remove ignition key.

Turn light switch into the "0" position.

Right side of the vehicle: Remove the air filter housing.

1. For gasoline engine, refer to «[For engine(s) CAEB] Removal and Installation»(ref-515412-S12570427722012120300000) or to «[For engine(s) CALB] Removal and Installation»(/audi/q5/i-2008-2012/remont/fuel-system/#32l-fuel-injection-system-engine-codes-calb)

Open the clip -2- in the direction of the -arrow-.

Move the housing cover -1- to the side and remove it.

Remove the bulb -2- from the spring clips -arrows-.

Scheme 54

Disconnect the electrical connector -1- on the bulb.

Installing

Install in reverse order of removal, observing the following

Insert the new bulb into the housing without touching the bulb with bare hands.

Push the bulb past the resistance of the spring clips into the housing and connect the connector.

Close housing cover and secure with clip.

Right side of the vehicle: Install the air filter housing.

1. For gasoline engine, refer to «[For engine(s) CAEB] Removal and Installation»(ref-515412-S12570427722012120300000) or to «[For engine(s) CALB] Removal and Installation»(/audi/q5/i-2008-2012/remont/fuel-system/#32l-fuel-injection-system-engine-codes-calb)

LOW BEAM HEADLAMP BULBS -M29- / -M31

Removing

Switch off ignition and remove ignition key.

Turn light switch into the "0" position.

To remove the expanding clips -arrows-, carefully push the pin -1- to dimension -x- until it audibly engages into the expanding clip -arrow A-.

1. Dimension -x- = 5 mm.

Remove the unlocked expanding clip -2- and the pin.

Lift the cover -3- on the lock carrier and engage it on the radiator grille.

Right side of the vehicle: Remove the air filter housing.

1. For gasoline engine, refer to «[For engine(s) CAEB] Removal and Installation»(ref-515412-S12570427722012120300000) or to «[For engine(s) CALB] Removal and Installation»(/audi/q5/i-2008-2012/remont/fuel-system/#32l-fuel-injection-system-engine-codes-calb)

Open the clip -2- in the direction of -arrow A-.

Move the housing cover -1- to the side, in the direction of -arrow B-, and remove it.

Remove the screws -2- and -4-.

Loosen the screws -3- three turns.

Push the headlamp housing -1- forward all the way in the direction of the -arrow-.

Remove the bulb -1- from the spring clips -arrows-.

Scheme 55

Disconnect the electrical connector -2- on the bulb.

Installing

1. Tightening specification, refer to «HALOGEN HEADLAMPS OVERVIEW»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__halogen-headlamps-overview) .

Install in reverse order of removal, observing the following

Insert the new bulb into the housing without touching the bulb with bare hands.

Push the bulb past the resistance of the spring clips into the housing and connect the connector.

Close housing cover and secure with clip.

Right side of the vehicle: Install the air filter housing.

1. For gasoline engine, refer to «[For engine(s) CAEB] Removal and Installation»(ref-515412-S12570427722012120300000) or to «[For engine(s) CALB] Removal and Installation»(/audi/q5/i-2008-2012/remont/fuel-system/#32l-fuel-injection-system-engine-codes-calb)

Install the lock carrier cover on the radiator grille. Refer to Removal and Installation .

SIDE MARKER LAMP BULBS -M1- / -M3- AND DAYTIME RUNNING LAMP BULBS -L174- / -L175

Removing

Switch off ignition and remove ignition key.

Turn light switch into the "0" position.

To remove the expanding clips -arrows-, carefully push the pin -1- to dimension -x- until it audibly engages into the expanding clip -arrow A-.

1. Dimension -x- = 5 mm.

Remove the unlocked expanding clip -2- and the pin.

Lift the cover -3- on the lock carrier and engage it on the radiator grille.

Right side of the vehicle: Remove the air filter housing.

1. For gasoline engine, refer to «[For engine(s) CAEB] Removal and Installation»(ref-515412-S12570427722012120300000) or to «[For engine(s) CALB] Removal and Installation»(/audi/q5/i-2008-2012/remont/fuel-system/#32l-fuel-injection-system-engine-codes-calb)

Open the clip -2- in the direction of -arrow A-.

Move the housing cover -1- to the side in the direction of -arrow B- and remove it.

Remove the screws -2- and -4-.

Loosen the screws -3- three turns.

Push the headlamp housing -1- forward all the way in the direction of the -arrow-.

Turn the bulb -1- counterclockwise in the direction of the -arrow- and remove it from the housing.

Scheme 56

Open the spring -4- and disconnect the connector -3- on the bulb -2-.

Installing

Install in reverse order of removal, observing the following

Insert the new bulb into the headlamp without touching the bulb with bare hands.

Close housing cover and secure with clip.

Right side of the vehicle: Install the air filter housing.

1. For gasoline engine, refer to «[For engine(s) CAEB] Removal and Installation»(ref-515412-S12570427722012120300000) or to «[For engine(s) CALB] Removal and Installation»(/audi/q5/i-2008-2012/remont/fuel-system/#32l-fuel-injection-system-engine-codes-calb)

Install the lock carrier cover on the radiator grille. Refer to Removal and Installation .

HEADLAMP HOUSING MOUNT

Removing

Scheme 57

Switch off ignition and remove ignition key.

Remove the headlamp housing. Halogen headlamps, refer to HEADLAMP HOUSING , HID headlamps refer to HEADLAMP HOUSING .

Remove the screws -3, 5 and 7- and remove the headlamp bracket -4-.

Loosen the screw -2- three turns and remove the mount -6- from the headlamp housing -1-.

Installing

1. Tightening specification refer to «HEADLAMP HOUSING BRACKET AND MOUNT OVERVIEW»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches) , «HALOGEN HEADLAMPS OVERVIEW»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__halogen-headlamps-overview) , «BI-XENON HEADLAMPS WITH CORNERING LIGHT OVERVIEW»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__bi-xenon-headlamps-with-cornering-light-overview) .

Push the headlamp housing all the way into the housing mount.

1. The headlamp housing must slide into the mount gently without using force.

Install the headlamp housing -3- and bracket onto the lock carrier and the fender.

Tighten the screw -1, 2, 4 and 5- by hand.

1. The guide tab -arrow B- on the headlamp housing bracket -1- must fit into the opening on the lock carrier -3-.
2. The guides -2- and -4- must fit into the mounts -arrow A-.

Install the front bumper cover. Refer to Removal and Installation .

Align the headlamp housing gap -1- dimensions according to the body contours.

Scheme 58

1. Gap dimension = even gap dimension.

Tighten the screws -2 through 7- while aligning the headlamp housing so that it sits flush with the out edge of the fender.

Remove front bumper cover. Refer to Removal and Installation .

Tighten the screws -1, 2, 4 and 5-.

Install the front bumper cover. Refer to Removal and Installation .

Check gap dimensions again, repeat adjustment of gap dimensions if necessary, as described above.

Adjust headlamps. Refer to HEADLAMPS, CHECKING AND ADJUSTING CONDITIONS .

HIGH-MOUNTED BRAKE LAMP BULB

Removing

Scheme 59

Do not press brake pedal.

Remove the roof spoiler. Refer to Removal and Installation .

Remove the screws -2- and -3-.

Remove the high-mounted brake lamp -1- from the roof spoiler in the direction of the -arrow-.

Installing

1. Tightening specification, refer to «HIGH-MOUNT BRAKE LIGHT AND LICENSE PLATE LIGHTS OVERVIEW»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches) .

Install in reverse order of removal, observing the following

Install the roof spoiler. Refer to Removal and Installation .

LICENSE PLATE LIGHTS

Removing

Scheme 60

Turn light switch into the "0" position.

Remove the marker lamps -2- from the rear lid by positioning a screwdriver -1- at the slit and sliding it in the direction of the -arrow-.

Remove the bulb -3- from the clamping socket.

Installing

Install in reverse order.

PARKING AID CONTROL MODULE -J446

Removing

If the control module was replaced, select the "Replace" function for the respective control module in "Guided Fault Finding" or "Guided Functions" using the Vehicle Diagnostic Tester.

Select the function or path

Follow the instructions on the Vehicle Diagnostic Tester display.

Switch off ignition and remove ignition key.

Open the right luggage compartment side trim cover.

Scheme 61

Disconnect electrical connectors -2 through 4-.

Remove the nuts -arrows-.

Remove the parking aid control module -J446- -1-.

Installing

1. Tightening specification, refer to «PARKING AID OVERVIEW»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches) .

Install in reverse order of removal, observing the following

Follow the prompts on the vehicle diagnostic tester display in the case of a new parking aid control module.

FRONT PARKING AID WARNING BUZZER -H22-, 8-CHANNEL PARKING AID

Removing

Scheme 62

Switch off ignition and remove ignition key.

Remove the driver side instrument panel cover. Refer to Removal and Installation .

Remove the screws -1- and -3-.

Remove the Front Parking Aid Warning Buzzer -H22- -2- and expansion clips.

Disconnect the electrical connector -4-.

Installing

Install in reverse order of removal, observing the following

Install the driver side instrument panel cover Removal and Installation .

REAR PARKING AID WARNING BUZZER

Removing

Scheme 63

Switch off ignition and remove ignition key.

Remove the D-pillar trim panel. Refer to Removal and Installation .

Remove screws -1- and -2-.

Remove the rear parking aid warning buzzer -H15- -3- and expansion clips.

Disconnect the electrical connector -4-.

Installing

Install in reverse order of removal, observing the following

Install the D-pillar trim panel. Refer to Removal and Installation .

FRONT PARKING AID SENSORS

Removing

Outer Sensors

Using a screwdriver -1- release the hooks in the direction of -arrow A-.

Remove the intake air grille -2- on the bumper cover in the direction of -arrow B-.

Reach through the opening in the bumper cover and expand both tabs in the direction of the -arrows- while pushing the sensor -2- from the outside toward the inside at the same time.

Scheme 64

Disconnect the electrical connector -1- on the sensor.

Inner Sensor

Scheme 65

Remove front bumper cover. Refer to Removal and Installation .

Press both retainer tabs to the side in the direction of the -arrows- and press the sensor -2- through from the outside towards the inside.

Disconnect the electrical connector -1- on the sensor.

Installing

Install in reverse order of removal, observing the following

Inner Sensor

Install the front bumper cover. Refer to Removal and Installation .

REAR PARKING AID SENSORS -G203- / -G204- / -G205- / -G206

Removing

Scheme 66

Switch off ignition and remove ignition key.

Right Side of Vehicle - Vehicles with 4-Cylinder Engine

Remove the pin -arrow- and expanding clips -1-.

Remove the nuts -2, 3 and 5-.

Remove the rear floor panel trim -4-.

Continuation for All Sensors

Reach behind bumper cover from below.

Press both retainer tabs to the side in the direction of the -arrows- and press the sensor -2- through from the outside towards the inside.

Disconnect the electrical connector -1- on the sensor.

Installing

Install in reverse order of removal.

STEERING COLUMN SWITCH MODULE

Removing

Switch off ignition and remove ignition key.

Adjust steering wheel downward and to rear as far as possible, use entire adjustment range of steering column adjustment for this.

Remove the driver airbag. Refer to Removal and Installation .

Remove steering wheel. Refer to Removal and Installation .

Remove steering column trim. Refer to Removal and Installation .

Remove bolt -1-.

Scheme 67

Disconnect the electrical connector -2-.

Disconnect the electrical connector -3-.

Press catch -1- in the direction of the -arrow- until the harness connector -2- disengages.

Scheme 68

Remove the steering column switch module carefully.

Installing

1. Tightening specification, refer to «STEERING COLUMN SWITCH MODULE AND ELECTRONIC IGNITION LOCK OVERVIEW»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches__steering-column-switch-module-and-electronic) .

Install in reverse order of removal, observing the following

Install steering column trim. Refer to Removal and Installation .

Install steering wheel. Refer to Removal and Installation .

Install the driver airbag. Refer to Removal and Installation .

STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE

The airbag spiral spring/return spring with slip ring -F138- and the steering angle sensor -G85- are integrated in the steering column electronics control module -J527-.

Special tools and workshop equipment required

1. Feeler gauge

Removing

If the control module was replaced, select the "Replace" function for the respective control module in "Guided Fault Finding" or "Guided Functions" using the Vehicle Diagnostic Tester.

Select the function or path

Follow the instructions on the Vehicle Diagnostic Tester display.

Switch off ignition and remove ignition key.

Adjust steering wheel downward and to rear as far as possible, use entire adjustment range of steering column adjustment for this.

Remove the driver airbag. Refer to Removal and Installation .

Remove steering wheel. Refer to Removal and Installation .

Remove steering column trim. Refer to Removal and Installation .

Remove bolt -1-.

Scheme 69

Release the retaining hooks in the direction of the -arrows- carefully and remove the airbag spiral spring/return spring with slip ring -2- from the steering column switch module -3-.

Release the electrical connectors on the airbag spiral spring/return spring with slip ring -3- by positioning the screwdriver at the retaining hooks -2- and -4- as illustrated and carefully releasing the connectors -1- and -5- in the direction of -arrow A-.

Scheme 70

Remove the airbag spiral spring/return spring with slip ring on the steering column switch module.

Installing

Install in reverse order of removal, observing the following

Make sure all retaining hooks and connectors are engaged securely.

Install steering column trim. Refer to Removal and Installation .

Install steering wheel. Refer to Removal and Installation .

Install the driver airbag. Refer to Removal and Installation .

Follow the prompts on the vehicle diagnostic tester display in the case of a new steering column electronics control module.

TURN SIGNAL SWITCH, CRUISE CONTROL SWITCH AND WINDSHIELD WIPER AND WASHER INTERMITTENT MODE SWITCH

Removing

Remove the steering column switch module. Refer to STEERING COLUMN SWITCH MODULE .

Remove the steering column electronics control module -J527-. Refer to STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE .

Remove the turn signal switch -E2-, cruise control switch -E45- and windshield wiper intermittent mode switch -E22-.

Installing

Install in reverse order of removal, observing the following

Install the steering column electronic systems control module. Refer to STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE .

Install the steering column switch module. Refer to STEERING COLUMN SWITCH MODULE .

ACCESS/START AUTHORIZATION SWITCH

Note. Induction coil for immobilizer is secured to access/start authorization switch -E415- and cannot be replaced separately. If induction coil is malfunctioning, access/start authorization switch must be replaced. The immobilizer does not need to be adapted if the access/start authorization switch is replaced. Lock in access/start authorization switch is not coded mechanically. Keys must therefore not be replaced when access/start authorization switch is replaced; present keys continue to match.

Special tools and workshop equipment required

1. Special Pliers VAS 6339

Removing

Scheme 71

Remove the driver side instrument panel cover. Refer to Removal and Installation .

Remove the right impact bar. Refer to Removal and Installation .

Remove the instrument vent in the center. Refer to Removal and Installation .

Insert the VAS 6339 through the trim flaps.

Position the tips of the VAS 6339 on both holes -arrows A- on the switch for the -2- access/start authorization switch -E415-.

Press the VAS 6339 handles together, in the direction of the -B arrows-, to spread the tips of the pliers and release the trim retaining tabs.

Hold the VAS 6339 pressed with one hand and remove the trim -1- with the other hand, in the direction of -arrow C-.

Note. Only use the VAS 6339 to release. Remove the trim by hand.

Remove bolt -4-.

Scheme 72

Remove the access/start authorization switch -1- from the instrument panel and into the passenger compartment.

Note. If necessary, push the wiring harness on the central tube to the side.

Disconnect electrical harness connector -2- by sliding retainer -3- up in the direction of the -arrow- and pressing the release inward.

Installing

1. Tightening specification, refer to «ACCESS/START AUTHORIZATION SWITCH TIGHTENING SPECIFICATION»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches) .

Install in reverse order of removal, observing the following

Install the center instrument vent. Refer to Removal and Installation .

Install the right impact bar. Refer to Removal and Installation .

Install the driver side instrument panel cover. Refer to Removal and Installation .

TAIL LAMP

Removing

Scheme 73

Switch off ignition and remove ignition key.

Turn light switch into the "0" position.

Remove the outer cap on the opening -2- in the direction of the -arrow-.

Note. Disregard item -1-.

Insert a screwdriver -2- into the opening and pry out the cap -1- from the inside in the direction of the -arrow-.

Scheme 74

Disconnect the connector mount -5- on the bracket by pressing the retainer -6- in the direction of the -arrow- and remove the mount.

Scheme 75

Disconnect the electrical connector -7-.

Remove the nuts -2 through 4- and remove the tail lamps -1-.

Installing

Scheme 76

1. Tightening specification, refer to «TAIL LAMPS OVERVIEW»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches) .

Install in reverse order of removal, observing the following

1. Wiring grommets -2- must seat correctly in their mount -3-.
2. Self-adhesive seal -1- between rear lid and rear light housing must seal correctly.

Tighten the nuts for the lamps in the rear lid. Refer to ACCESS/START AUTHORIZATION SWITCH TIGHTENING SPECIFICATION .

OUTER BULB HOLDER

Removing

Remove the outer cap on the opening -2- in the direction of the -arrow-.

Remove the key -1- from the mount in the cap and position is on the bulb holder.

Turn the bulb holder -1- and -2- with the key -3- counterclockwise, in the direction of the -arrow-.

Scheme 77

Remove the bulb holder from the tail lamps and remove the bulbs.

Installing

Install in reverse order of removal, observing the following

Insert the new bulb into the socket without touching the bulb with bare hands.

INNER BULB HOLDER

Removing

Switch off ignition and remove ignition key.

Turn light switch into the "0" position.

Insert a screwdriver -2- into the opening and pry out the cap -1- from the inside, in the direction of the -arrow-.

Turn the socket -1- counterclockwise, in the direction of the -arrow-.

Scheme 78

Remove socket from rear light housing.

Remove lamp from socket.

Installing

Install in reverse order of removal, observing the following

Insert new bulb into socket, do not touch glass cone with bare hands when doing so.

Secure socket by turning clockwise.

BUMPER COVER TAIL LAMPS

Removing

Scheme 79

Switch off ignition and remove ignition key.

Turn light switch into the "0" position.

Note. To protect the paint in the area around the cap, tape it off with a soft cloth.

Push the cap -1- on the outer side, in the direction of the -arrow- toward the inside.

Remove the cap and let it hang.

Remove bolt -1-.

Scheme 80

Remove the tail lamp -2- from the bumper cover.

Disconnect the connector -3- on the central connector.

Installing

Install in reverse order of removal, observing the following

1. Tightening specification, refer to «BUMPER COVER TAIL LAMPS OVERVIEW»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches) .

Tighten screw.

Press cover cap into bumper cover until it engages audibly.

BUMPER COVER TAIL LAMP BULBS

Removing

Remove the tail lamps. Refer to BUMPER COVER TAIL LAMPS .

Turn the socket counterclockwise, in the direction of the -arrow- and remove it from the housing.

Scheme 81

Remove the bulb from socket -3-.

Remove the bulbs from the sockets -1, 2, 4 and 5-, as necessary.

Installing

Install in reverse order of removal, observing the following

Insert the new bulb in the socket without touching the bulb with bare hands.

Secure socket by turning clockwise.

Install the tail lamps. Refer to BUMPER COVER TAIL LAMPS .

REAR LID CLOSED SENSOR

Removing

Scheme 82

Switch off ignition and remove ignition key.

Remove the rear lid trim panel. Refer to Removal and Installation .

Remove screws -arrows- and remove rear lid closed sensor -1-.

Installing

1. Tightening specification, refer to «BUMPER COVER TAIL LAMPS OVERVIEW»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches) .

Install in reverse order of removal, observing the following

Install the rear lid trim panel. Refer to Removal and Installation .

SPECIAL TOOLS

Hook 3438

Scheme 83

Feeler gauge

Special pliers VAS 6339

Scheme 84

See also:
• Removal and Installation
• Removal and Installation
• Description and Operation
• CENTER CONSOLE LIGHTS AND SWITCHES OVERVIEW
• Removal and Installation
• BATTERY, DISCONNECTING AND CONNECTING
• BATTERY AND AUXILIARY BATTERY, DISCONNECTING AND CONNECTING
• [For engine(s) CALB] Removal and Installation
• Removal and Installation
• General Information
• Removal and Installation
• Removal and Installation
• Removal and Installation
• HEADLAMP BEAM ADJUSTMENT MOTORS -V48- / -V49
• AUTOMATIC HEADLAMP VERTICAL AIM AND RANGE, CONTROL MODULES -J431- / -J745
• FRONT TURN SIGNAL LAMP BULBS
• HEADLAMP POWER OUTPUT STAGES -J667- / -J668
• DAYTIME RUNNING LAMP AND PARKING LAMP LED MODULES L176 AND L177
• HID LAMP CONTROL MODULE
• HID HEADLAMP BULBS
• HEADLAMP HOUSING
• BUMPER COVER TAIL LAMPS
• BUMPER COVER TAIL LAMP BULBS
• REAR LID CLOSED SENSOR
• EXTERIOR MIRROR TURN SIGNAL LAMPS
• FOG LAMP BULBS
• FOG LAMP
• FRONT TURN SIGNAL LAMP BULBS -M5- / -M7
• HIGH BEAM HEADLAMP BULBS -M30- / -M32
• DAYTIME RUNNING LAMP BULBS
• LOW BEAM HEADLAMP BULBS -M29- / -M31
• FRONT SIDE MARKER LAMP BULBS
• SIDE MARKER LAMP BULBS -M1- / -M3- AND DAYTIME RUNNING LAMP BULBS -L174- / -L175
• HEADLAMP BEAM ADJUSTMENT MOTORS
• HEADLAMP HOUSING MOUNT
• LICENSE PLATE LIGHTS
• HIGH-MOUNTED BRAKE LAMP BULB
• FRONT PARKING AID SENSORS
• REAR PARKING AID WARNING BUZZER
• PARKING AID CONTROL MODULE -J446
• REAR PARKING AID SENSORS -G203- / -G204- / -G205- / -G206
• Front Parking Aid Warning Buzzer -H22-, 8-CHANNEL PARKING AID
• STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE
• STEERING COLUMN ELECTRONICS CONTROL MODULE J527 CONNECTOR ASSIGNMENT
• TURN SIGNAL SWITCH, CRUISE CONTROL SWITCH AND WINDSHIELD WIPER AND WASHER INTERMITTENT MODE SWITCH
• ACCESS/START AUTHORIZATION SWITCH
• TAIL LAMP
• OUTER BULB HOLDER
• INNER BULB HOLDER
• HEADLAMPS, CHECKING AND ADJUSTING CONDITIONS
• BI-XENON HEADLAMPS WITH CORNERING LIGHT OVERVIEW
• HALOGEN HEADLAMPS OVERVIEW
• STEERING COLUMN SWITCH MODULE AND ELECTRONIC IGNITION LOCK OVERVIEW
• STEERING COLUMN SWITCH MODULE
