Battery, Starter, Generator, Cruise Control Audi Q5 I

CONTACT CORROSION

Contact corrosion can occur if incorrect fasteners (bolts, nuts, washers, etc.) are used.

For this reason, only fasteners with a special surface coating are used.

In addition, rubber or plastic parts and adhesive consist of non-conductive materials.

If there are doubts as to whether parts are suitable or not, use new parts.

Note. We only recommend original replacement parts as they have been tested and are compatible with aluminum. We recommend using genuine Audi accessories. Damage resulting from contact corrosion is not covered by warranty.

The following descriptions can be found in Generator, Checking

1. Battery post/terminal
2. Battery with visual indicator
3. Battery with visual indicator, checking
4. Battery with visual indicator, checking the color display (battery electrolyte level)
5. Battery with visual indicator, electrolyte level checking
6. Battery with visual indicator, visual checking
7. Central venting system
8. Lead-acid battery warnings and safety precautions
9. Safety procedures and precautions

BATTERY INTERRUPT IGNITER -N253

Replace the battery interrupt igniter -N253- if it is faulty or has deployed. Refer to Removal and Installation .

BATTERY, WITH HIGH VOLTAGE SYSTEM

1. Observe notes on contact corrosion. Refer to «CONTACT CORROSION»(/audi/q5/i-2008-2012/remont/charging-system/#battery-starter-generator-cruise-control__contact-corrosion) .
2. Read and follow the High Voltage Electrical System General Warnings. .

MAINTENANCE-FREE BATTERY

The following descriptions can be found in Battery, Starter, Generator, Cruise Control

1. Battery with visual indicator
2. Battery with visual indicator, checking
3. Central venting system
4. Battery Post/Terminal
5. Visual check of the battery
6. Check the color display (battery electrolyte level), battery with "visual indicator"
7. Battery electrolyte level, checking

Scheme 37

1. Battery In the luggage compartment of the spare wheel well Removing and installing, refer to «BATTERY»(/audi/q5/i-2008-2012/remont/charging-system/#battery-starter-generator-cruise-control__battery-engine-codes-caeb-calb)
2. Negative Terminal Cover Varies by equipment level Allocation
3. Positive Terminal Cover
4. Nut 5 Nm
5. Electrical Wire For the relay/fuse panel, under the instrument panel on the left side Tightening specification, refer to «ENGINE COMPARTMENT E-BOX, WIRE JUNCTION, FUSE HOLDER AND BATTERY OVERVIEW Tightening Specifications for the Fuse Panel A»(/audi/q5/i-2008-2012/remont/wiring-system-data-link-connectors-pwr-dist-grnd-dist/#wiring)
6. Fuse Panel A -SA- Disconnecting and connecting, refer to «BATTERY»(/audi/q5/i-2008-2012/remont/charging-system/#battery-starter-generator-cruise-control__battery-engine-codes-caeb-calb) Removing and installing, refer to «FUSE PANEL A IN LUGGAGE COMPARTMENT»(/audi/q5/i-2008-2012/remont/wiring-system-data-link-connectors-pwr-dist-grnd-dist/#wiring__fuse-panel-a-in-luggage-compartment)
7. Nut Tightening specification, refer to «ENGINE COMPARTMENT E-BOX, WIRE JUNCTION, FUSE HOLDER AND BATTERY OVERVIEW Tightening Specifications for the Fuse Panel A»(/audi/q5/i-2008-2012/remont/wiring-system-data-link-connectors-pwr-dist-grnd-dist/#wiring)
8. Positive Cable to the Engine
9. Screw
10. Nut 5 Nm
11. Electrical Wire For the battery monitoring control module -J367- Follow the sequence when connecting the ground cable. Refer to «BATTERY, DISCONNECTING AND CONNECTING»(/audi/q5/i-2008-2012/remont/charging-system/#battery-starter-generator-cruise-control__battery-disconnecting-and-connecting)
12. Ground Wire with Battery Monitoring Control Module -J367- Disconnecting and connecting, refer to «BATTERY, DISCONNECTING AND CONNECTING»(/audi/q5/i-2008-2012/remont/charging-system/#battery-starter-generator-cruise-control__battery-disconnecting-and-connecting) Removing and installing, refer to «BATTERY MONITORING CONTROL MODULE»(/audi/q5/i-2008-2012/remont/charging-system/#battery-starter-generator-cruise-control__battery-monitoring-control-module)
13. Screw
14. Nut 18 Nm
15. Central Venting System Hose
16. Screw Quantity: 2 18 Nm
17. Retaining Bracket

BATTERY, PREPARING FOR CHARGING

Procedure

Before the battery charger can be connected, the following preparations are necessary

Note. It is recommended that the battery is charged when installed and connected. This is the only way to ensure the charging current is incorporated into the capacity calculation for the battery monitoring control module -J367-.

Switch off ignition, switch off all electrical consumers and remove ignition key.

Remove the cover -2- while pressing on -arrow A-.

Scheme 38

Release the tab -arrow B- and open the cover -1-.

Connect the battery charger red charging clamp "+" to the positive terminal clamp -1- and the black charging clamp "-" to the negative "-" terminal clamp -2-.

Scheme 39

Connect the battery charger electrical system connector and switch the charger on Generator, Checking .

Keep the rear lid open while charging.

BATTERY, PREPARING FOR SUPPORT MODE

Procedure

Remove the cover -2- while pressing on -arrow A-.

Release the tab -arrow B- and open the cover -1-.

Connect the battery charger red charging clamp "+" to the positive terminal clamp -1- and the black charging clamp "-" to the negative "-" terminal clamp -2-.

Connect the battery charger electrical system connector and switch the charger on Generator, Checking .

BATTERY AND AUXILIARY BATTERY OVERVIEW

Battery -A

Scheme 40

1. Battery -A- In the luggage compartment in the spare wheel well Removing and installing, refer to «BATTERY»(/audi/q5/i-2008-2012/remont/charging-system/#battery-starter-generator-cruise-control__battery-engine-codes-chja)
2. Positive Terminal Cover
3. Negative Terminal Cover Equipment level Allocation
4. Screw
5. Nut 5 Nm
6. Fuse Panel A -SA- Disconnecting and connecting, refer to «BATTERY»(/audi/q5/i-2008-2012/remont/charging-system/#battery-starter-generator-cruise-control__battery-engine-codes-chja) Removing and installing, refer to «FUSE PANEL A IN LUGGAGE COMPARTMENT, VEHICLES WITH HIGH VOLTAGE SYSTEM»(/audi/q5/i-2008-2012/remont/wiring-system-data-link-connectors-pwr-dist-grnd-dist/#wiring__fuse-panel-a-in-luggage-compartment)
7. Electrical Wire For the relay/fuse panel, under the instrument panel on the left side Tightening specification, refer to «FUSE PANEL A IN LUGGAGE COMPARTMENT, VEHICLES WITH HIGH VOLTAGE SYSTEM»(/audi/q5/i-2008-2012/remont/wiring-system-data-link-connectors-pwr-dist-grnd-dist/#wiring__fuse-panel-a-in-luggage-compartment)
8. Screw 3.5 Nm
9. Electrical Wire
10. Nut Tightening specification, refer to «FUSE PANEL A IN LUGGAGE COMPARTMENT, VEHICLES WITH HIGH VOLTAGE SYSTEM»(/audi/q5/i-2008-2012/remont/wiring-system-data-link-connectors-pwr-dist-grnd-dist/#wiring__fuse-panel-a-in-luggage-compartment)
11. Positive Cable to the Engine
12. Nut 5 Nm
13. Electrical Wire For the battery monitoring control module -J367- Follow the sequence when connecting the ground cable. Refer to «BATTERY AND AUXILIARY BATTERY, DISCONNECTING AND CONNECTING»(/audi/q5/i-2008-2012/remont/charging-system/#battery-starter-generator-cruise-control__battery-and-auxiliary-battery-disconnecting-and)
14. Ground Wire with Battery Monitoring Control Module -J367- Disconnecting and connecting, refer to «BATTERY AND AUXILIARY BATTERY, DISCONNECTING AND CONNECTING»(/audi/q5/i-2008-2012/remont/charging-system/#battery-starter-generator-cruise-control__battery-and-auxiliary-battery-disconnecting-and) Removing and installing, refer to «BATTERY MONITORING CONTROL MODULE -J367- FOR BATTERY»(/audi/q5/i-2008-2012/remont/charging-system/#battery-starter-generator-cruise-control__battery-monitoring-control-module-j367-for)
15. Nut 20 Nm
16. Screw
17. Central Venting System Hose
18. Screw 18 Nm Quantity: 2
19. Retaining Bracket

Auxiliary Battery -A1

Scheme 41

1. Central Venting System Hose
2. Screw 9 Nm
3. Battery Bracket
4. Ground Wire with Battery Monitoring Control Module 2 -J934- Removing and installing, refer to «BATTERY MONITORING CONTROL MODULE -J367- FOR BATTERY»(/audi/q5/i-2008-2012/remont/charging-system/#battery-starter-generator-cruise-control__battery-monitoring-control-module-j367-for)
5. Nut 20 Nm
6. Screw
7. Nut 5 Nm
8. Electrical Wire for the Battery Monitoring Control Module 2 -J934
9. Screw 4.5 Nm
10. Negative Pole
11. Screw 4.5 Nm
12. Positive Cable
13. Electrical Wire
14. Auxiliary Battery -A1- Removing and installing
15. Screw 9 Nm
16. Battery Bracket

Scheme 42

1. Bolts 23 Nm
2. Generator Removing and installing: Vehicles with 2.0L TFSI engine, refer to «GENERATOR»(/audi/q5/i-2008-2012/remont/charging-system/#battery-starter-generator-cruise-control__generator-engine-codes-caeb-chja) Vehicles with 3.2L FSI engine, refer to «GENERATOR»(/audi/q5/i-2008-2012/remont/charging-system/#battery-starter-generator-cruise-control__generator-engine-codes-calb)
3. Bushing During removal this bushing may come out. During reinstallation ensure that the bushing is fully seated against the bracket before final torque is achieved.
4. Electrical Connector
5. Nut 16 Nm
6. Cap
7. Terminal 30/B+

Scheme 43

1. Screw 23 Nm Quantity: 2
2. Generator Removing and installing: Vehicles with 2.0L TFSI engine, refer to «GENERATOR»(/audi/q5/i-2008-2012/remont/charging-system/#battery-starter-generator-cruise-control__generator-engine-codes-caeb-chja) Vehicles with 3.2L FSI engine, refer to «GENERATOR»(/audi/q5/i-2008-2012/remont/charging-system/#battery-starter-generator-cruise-control__generator-engine-codes-calb)
3. Electrical Connector
4. Terminal 30/B+
5. Cap
6. Nut 16 Nm

GENERATOR, SERVICING

Observe notes on contact corrosion, refer to CONTACT CORROSION .

The following descriptions can be found in Generator, Checking

1. Bosch generator from 2007, assembly overview
2. Bosch generators from 2001, carbon brushes, checking
3. Bosch generator from 2007, voltage regulator, removing and installing
4. Valeo generator from 2001, assembly overview
5. Valeo generator from 2007, carbon brushes, checking
6. Valeo generator from 2007, voltage regulator, removing and installing
7. Ribbed belt pulley with freewheel, removing and installing
8. Ribbed belt pulley without freewheel, removing and Installing

STARTER OVERVIEW

Observe notes on contact corrosion, refer to CONTACT CORROSION .

Scheme 44

1. Screw Tightening specification, refer to «Description and Operation»(ref-515388-S32919833812012120300000)
2. Spacer Sleeve Only on 4-cylinder engines
3. Starter Removal and installation, refer to «STARTER»(/audi/q5/i-2008-2012/remont/charging-system/#battery-starter-generator-cruise-control__starter-engine-codes-calb) .
4. Terminal 30/B+
5. Nut 15 Nm
6. Electrical Connector
7. Screw Tightening specification, refer to «Description and Operation»(ref-515388-S32919833812012120300000)

FASTENER TIGHTENING SPECIFICATIONS

Procedure

Before the battery charger can be connected, the following preparations are necessary

Note. It is recommended that the battery is charged when installed and connected. This is the only way to ensure the charging current is incorporated into the capacity calculation for the battery monitoring control module -J367-.

Switch off ignition

Switch off all electrical consumers and remove ignition key.

Remove the cover -2- while pressing on -arrow A-.

Release the tab -arrow B- and open the cover -1-.

Connect the battery charger red charging clamp "+" to the positive terminal clamp -1- and the black charging clamp "-" to the negative "-" terminal clamp -2-.

Connect the battery charger electrical system connector and switch the charger on. Refer to Generator, Checking .

Keep the rear lid open while charging.

Procedure

Remove the cover -2- while pressing on -arrow A-.

Release the tab -arrow B- and open the cover -1-.

Connect the battery charger red charging "+" clamp to the positive terminal clamp -1- and the black charging "-" clamp to the negative "-" terminal clamp -2-.

Connect the battery charger electrical system connector and switch the charger on. Refer to Generator, Checking .

AUXILIARY BATTERY -A1-, PREPARING FOR CHARGING

Remove the luggage compartment left side trim panel cover.

Connect the red charging clamp "+" for the battery charger to the positive pole for the auxiliary battery -A1- -2- and connect the black charging clamp "-" to the nut -1- for the ground cable.

Scheme 45

Connect the battery charger electrical system connector and switch the charger on Generator, Checking .

BATTERY, TESTING

The following descriptions can be found in Diagnosis and Testing

1. Battery check using Vehicle Diagnostic Tester systems
2. Measure the no load voltage - vehicles with battery monitoring control module -J367- or energy management control module -J644

BATTERY, CHARGING

The following descriptions can be found in Generator, Checking

1. Charge battery using Battery Charger VAS 5903 or Midtronics INC-940.
2. Exhaustively discharged battery
3. Battery support mode with Battery Charger VAS 5903 or Midtronics INC-940.

GENERATOR, TESTING

The generator is tested in "Guided Fault Finding" under "Body/Electrical Equipment/26 - Starter, voltage supply/electrical components/C generator, testing," using the Vehicle Diagnostic Tester. Refer to vehicle diagnosis, testing and information system.

BATTERY - ENGINE CODE(S): CAEB, CALB, CGXD & CPMA

Scheme 46

Switch off ignition and remove ignition key.

Remove the luggage compartment floor -3-.

Remove the dirt tray, if applicable.

Remove the bass box -2- if applicable. Refer to Removal and Installation .

Fold back the carpet -1- over the flap.

Remove the battery cover. Refer to Removal and Installation .

Connect the battery charger for battery support mode. Refer to General Information .

Remove the vehicle tools, if applicable, -2- and the bracket.

Scheme 47

Open the cover -7- over the battery negative "-" terminal.

Loosen nut -6- a few turns and remove the battery ground (GND) cable clamp from battery terminal.

Disconnect the central gas vent hose -8-.

Remove the bolts -arrows- on the battery mounting bracket -1-.

Remove the battery -5- slightly from the battery mount.

Open the cover -4- over the battery positive terminal.

Loosen the nut -3- several turns and remove the positive cable clamp with fuse panel A -SA- from the battery terminal.

Remove battery from luggage compartment.

INSTALLING

1. Tightening specification, refer to «BATTERY OVERVIEW»(/audi/q5/i-2008-2012/remont/charging-system/#battery-starter-generator-cruise-control) .

Note. Only maintenance-free batteries conforming to standards TL 82506 (as of December 1997) and VW 75073 (as of August 2001) may be installed. Batteries from the Audi Parts Program have a bottom strip-adapter for adapting to different grip channels. For information on how to use the base strip adapter, if applicable, see the battery operating instructions.

Insert the battery in the battery mount so the base strip engages in the battery mount retaining strip -arrow-.

Scheme 48

1. It should no longer be possible to move the battery.

Position battery bracket -1-.

1. Lug at battery bracket must engage in recess at battery base strip.

Tighten the battery bracket screws -arrows-.

Connect central venting system hose -8- while observing notes. Refer to Generator, Checking .

With the ignition and electrical consumers switched off, connect the battery -5- in the following sequence

Connect positive cable terminal clamp -3- by hand to battery positive terminal "+" and tighten nut.

Disconnect the connector -3- on the battery monitoring control module -J367- -1-.

Scheme 49

Connect the battery ground (GND) cable clamp by hand to battery negative "-" terminal and tighten the nut -1-.

Connect the electrical connector on the battery monitoring control module -J367-.

Check battery after installation for secure seating. Refer to General Information .

Install the battery cover. Refer to Removal and Installation .

After replacing, adapt the battery in the Guided Fault Finding or Guided Functions mode using the Vehicle Diagnostic Tester

Continue following the instructions on the vehicle diagnostic tester display in the case of a new battery.

When the battery is connected, the following steps must be performed

1. Activate the power window regulator one-touch up/down function.
2. Check DTC memories of all control modules and erase the "undervoltage" DTC, if necessary, using the Vehicle Diagnostic Tester.

Note. After connecting the power supply, the ABS warning lamp may only go out after the vehicle has been driven a few yards.

BATTERY, DISCONNECTING AND CONNECTING

Disconnecting

Switch off ignition and remove ignition key.

Remove the luggage compartment floor -3-.

Remove the dirt tray, if applicable.

Remove the bass box -2- if applicable. Refer to Removal and Installation .

Fold back the carpet -1- over the flap.

Unlock the retaining tabs -arrows- and open the cover -1-.

Scheme 50

Open the cover -1- over the battery negative "-" terminal.

Scheme 51

Loosen the nut on the clamp several turns and remove the ground cable -arrow- from the battery terminal.

Connecting

1. Tightening specification, refer to «BATTERY OVERVIEW»(/audi/q5/i-2008-2012/remont/charging-system/#battery-starter-generator-cruise-control) .

Disconnect the connector -3- on the battery monitoring control module -J367- -1-.

Connect the ground wire terminal clamp, by hand, to battery negative - terminal and tighten the nut -1-.

Connect the electrical connector on the battery monitoring control module -J367-.

When the battery is connected, the following steps must be performed

1. Activate the power window regulator one-touch up/down function.
2. Check DTC memories of all control modules and erase the "undervoltage" DTC if necessary, using the Vehicle Diagnostic Tester.

Note. After connecting the power supply, the ABS warning lamp may only go out after the vehicle has been driven a few yards.

Install the bass box, if applicable. Refer to Removal and Installation .

BATTERY MONITORING CONTROL MODULE

Removing

Switch off ignition and remove ignition key.

Remove the luggage compartment floor -3-.

Remove the dirt tray, if applicable.

Remove the bass box -2- if applicable. Refer to Removal and Installation .

Fold back the carpet -1- over the flap.

Unlock the retaining tabs -arrows- and open the cover -1-.

Remove the vehicle tools, if applicable.

Open the cover -2- over the battery negative "-" terminal.

Scheme 52

Loosen the nut several turns and remove the battery ground (GND) cable -3- from the battery terminal.

Disconnect the electrical connector -4-.

Remove nut -1- and ground cable -6- with the battery monitoring control module -J367- -5-.

Installing

1. Tightening specification. Refer to «BATTERY OVERVIEW»(/audi/q5/i-2008-2012/remont/charging-system/#battery-starter-generator-cruise-control) .

Install in reverse order of removal, observing the following

Connect battery BATTERY, DISCONNECTING AND CONNECTING .

Install the bass box, if applicable. Refer to Removal and Installation .

BATTERY AND AUXILIARY BATTERY, DISCONNECTING AND CONNECTING

Disconnecting

Remove the luggage compartment floor panel. Refer to Interior Trim .

Remove the nut -1- from the ground point, remove the ground wire -2-.

Scheme 53

Remove the luggage compartment left side trim panel cover.

Scheme 54

Loosen the nut -5- a few turns and disconnect the ground cable from the battery negative pole -2-.

Note. Ignore -1, 3 and 4-.

Connecting

1. Tightening specification, refer to «BATTERY AND AUXILIARY BATTERY OVERVIEW»(/audi/q5/i-2008-2012/remont/charging-system/#battery-starter-generator-cruise-control__battery-and-auxiliary-battery-overview) .

Attach the battery ground (GND) cable terminal -2- by hand to the battery negative pole "-" when attaching the auxiliary battery -A1-, and then tighten the nut -5-.

Tighten the ground cable -1- to the ground point.

When the batteries are connected, the following steps must be performed

1. Activate the power window regulator one-touch up/down function. Refer to the owner's manual.
2. Check DTC memories of all control modules and erase "undervoltage" DTC if necessary using the Vehicle Diagnostic Tester.

Note. After connecting the power supply, the ABS warning lamp may only go out after the vehicle has been driven a few yards.

BATTERY MONITORING CONTROL MODULE -J367- FOR BATTERY

Removing

Remove the luggage compartment floor panel. Refer to Removal and Installation .

Remove the air guide inlet for the traction battery. Refer to Removal and Installation .

Open the cover -1- over the battery negative "-" terminal.

Scheme 55

Loosen the nut several turns and remove the ground cable -2- from the battery terminal.

Disconnect the electrical connector -3-.

Remove nut -6- and ground cable -5- with the battery monitoring control module -J367- -4-.

Note. For a better overview, the installation location is shown with the battery cooling module illustration removed.

Installing

1. Tightening specification, refer to «BATTERY AND AUXILIARY BATTERY OVERVIEW»(/audi/q5/i-2008-2012/remont/charging-system/#battery-starter-generator-cruise-control__battery-and-auxiliary-battery-overview)

Install in reverse order of removal. Note the following

Install the air guide inlet for the traction battery. Refer to Removal and Installation .

Install the luggage compartment floor panel. Refer to Interior Trim .

BATTERY - ENGINE CODE(S): CHJA

Removing

Bring the battery cooling module into the service position. Refer to Battery Cooling Module Overview .

Remove the bass box, if applicable. Refer to Removal and Installation .

Connect the battery charger for battery support mode, refer to Removal and Installation .

Open the cover -6- over the battery negative "-" terminal.

Scheme 56

Loosen nut -5- a few turns and remove ground cable terminal clamp from battery terminal.

Disconnect the central gas vent hose -7-.

Open the cover -3- over the battery positive terminal.

Loosen the nut -2- several turns and remove the positive wire terminal clamp with fuse panel A -SA- from the battery terminal.

Remove the bolt -arrow- on the battery mounting bracket -1-.

Remove battery -4- from the luggage compartment.

Installing

1. Tightening specification, refer to «BATTERY AND AUXILIARY BATTERY OVERVIEW»(/audi/q5/i-2008-2012/remont/charging-system/#battery-starter-generator-cruise-control__battery-and-auxiliary-battery-overview) .

Note. Only maintenance-free batteries conforming to standards "TL 82506" (as of December 1997) and "VW 75073" (as of August 2001) may be installed. Batteries from the Audi Parts Program have a bottom strip-adapter for adapting to different grip channels. For information on how to use the base strip adapter, if applicable, see the battery operating instructions.

Insert the battery in the battery mount so the base strip engages in the battery mount retaining strip -arrow-.

1. It should no longer be possible to move the battery.

Position battery bracket -1-.

1. Lug at battery bracket must engage in recess at battery base strip.

Tighten the battery bracket bolt -arrow-.

Connect central venting system hose -7- while observing notes Generator, Checking .

Switch off the ignition and all electrical consumers.

Connect the battery -5- in the following sequence

Connect positive cable terminal clamp -3- by hand to battery positive terminal "+" and tighten nut.

Disconnect the connector -3- on the battery monitoring control module -J367- -1-.

Connect the ground wire terminal clamp "1" by hand to the battery negative "-" terminal and tighten the nut.

Connect the electrical connector on the battery monitoring control module -J367-.

Check battery after installation for secure seating Generator, Checking .

Install the battery cooling module. Refer to Battery Cooling Module Overview .

After replacing, adapt the battery in the "Guided Fault Finding" or "Guided Functions" mode using the Vehicle Diagnostic Tester.

Continue following the instructions on the vehicle diagnostic tester display in the case of a new battery.

When the battery is connected, the following steps must be performed

1. Activate the power window regulator one-touch up/down function. Refer to the owner's manual.
2. Check DTC memories of all control modules and erase "undervoltage" DTC if necessary, using the Vehicle Diagnostic Tester.

Note. After connecting the power supply, the ABS warning lamp may only go out after the vehicle has been driven a few yards.

BATTERY MONITORING CONTROL MODULE -J934- FOR AUXILIARY BATTERY -A1

Removing

Remove the luggage compartment left side trim panel cover.

Disconnect the electrical connector -1-.

Remove the nut -3-.

Loosen the nut -4- a few turns and remove the battery ground (GND) cable terminal and battery monitoring control module 2 -J934- -2- from the battery negative pole.

Note. For a better overview, the installation location is shown with the battery cooling module illustration removed.

Installing

1. Tightening specification, refer to «BATTERY AND AUXILIARY BATTERY OVERVIEW»(/audi/q5/i-2008-2012/remont/charging-system/#battery-starter-generator-cruise-control__battery-and-auxiliary-battery-overview) .

Install in reverse order.

GENERATOR - ENGINE CODE(S): CAEB, CHJA & CPMA

Special tools and workshop equipment required

1. Locking tool T40098

Removing

Scheme 57

Turn off the ignition.

Disconnect the ground cable from the battery. Refer to BATTERY, DISCONNECTING AND CONNECTING . Take the necessary precautions for vehicles with a high voltage system and refer to BATTERY AND AUXILIARY BATTERY, DISCONNECTING AND CONNECTING .

Turn the tensioning element clockwise -arrow- to release the tension on the ribbed belt and lock it with the locking tool T40098.

Remove ribbed belt.

Remove upper and lower bolts -arrows- and pivot generator toward front.

Scheme 58

Disconnect the electrical connector -1-.

Scheme 59

Remove terminal 30/B+ -2-.

Remove the generator.

Installing

Scheme 60

1. Tightening specifications, refer to «GENERATOR WITHOUT BUSHINGS OVERVIEW»(/audi/q5/i-2008-2012/remont/charging-system/#battery-starter-generator-cruise-control) .

Install in reverse order of removal. Note the following

Position the ribbed belt over pulleys in the specified sequence.

1. Vibration damper
2. Coolant pump
3. Ribbed belt tensioner
4. Generator
5. Power steering pump
6. A/C Compressor

Note. When installing the ribbed belt, make sure it is seated correctly on the belt pulley.

Connect battery. Required actions, refer to BATTERY, DISCONNECTING AND CONNECTING .

Start the engine and check the ribbed belt routing.

GENERATOR - ENGINE CODE(S): CALB

Removing

Scheme 61

Switch the ignition off.

Disconnect the battery ground (GND) cable from the battery. Refer to BATTERY, DISCONNECTING AND CONNECTING .

Remove the front noise insulation. Refer to -1- Removal and Installation .

Remove the bolt -1- and nut -3-.

Scheme 62

Remove the right lock carrier brace -2-.

Scheme 63

Pivot tensioner in the direction of the -arrow- to release tension on ribbed belt.

Detach ribbed belt from generator pulley.

Release tensioner.

Note. Observe safety precautions when working on the automatic transmission .

Remove the bolt -arrow- for the ATF lines.

Disconnect the electrical connector on the oil level thermal sensor -G266- and free up the wiring harness on the generator.

Scheme 64

Remove the bolts -arrows- and remove generator.

Disconnect electrical connector -1-.

Remove terminal 30/B+ -item 2-.

Remove the generator downward between the ATF lines and the lock carrier.

Installing

1. Tightening specifications, refer to «GENERATOR WITHOUT BUSHINGS OVERVIEW»(/audi/q5/i-2008-2012/remont/charging-system/#battery-starter-generator-cruise-control) .

Install in reverse order of removal. Note the following

Secure the ATF lines. Refer to REMOVAL AND INSTALLATION .

Install the lock carrier right brace. Refer to Removal and Installation .

Position ribbed belt over pulleys in stated sequence.

Scheme 65

1. Generator
2. Idler pulley
3. Coolant pump
4. Power steering pump
5. A/C Compressor
6. Tensioner for ribbed belt
7. Crankshaft

Note. When installing the ribbed belt, make sure it is seated correctly on the belt pulley.

Connect battery. Required actions, refer to BATTERY, DISCONNECTING AND CONNECTING . Take the necessary precautions for vehicles with a high voltage system and refer to BATTERY AND AUXILIARY BATTERY, DISCONNECTING AND CONNECTING

Start the engine and make sure the belt it running correctly.

STARTER - ENGINE CODE(S): CAEB, CHJA & CPMA

Removing

Turn off the ignition.

Disconnect the ground cable from the battery. Refer to BATTERY, DISCONNECTING AND CONNECTING . Vehicles with high voltage system, refer to BATTERY AND AUXILIARY BATTERY, DISCONNECTING AND CONNECTING .

Remove the strut tower. Refer to Removal and Installation .

Remove the right engine mount. Refer to Removal and Installation .

Remove the front exhaust pipe. Refer to Removal and Installation .

Disconnect the catalytic converter and move it to the side. Refer to Removal and Installation .

Remove the bolts -1- and -2- and the turbocharger support.

Scheme 66

Remove the nut -1- and free up the ground wire on the engine support.

Scheme 67

Remove the bolts -arrows- and the right engine support.

Remove the bolt -1- for the wiring bracket -2-.

Scheme 68

Disconnect the electrical connector -3- by sliding the retainer back and pressing the release down.

Scheme 69

Remove the terminal 30/B+ wire -2- from the starter.

Remove the bolts -1- and -4- and the starter.

Note. 1- can be reached from above.

Installing

Scheme 70

1. Tightening specifications, refer to «STARTER OVERVIEW»(/audi/q5/i-2008-2012/remont/charging-system/#battery-starter-generator-cruise-control__starter-overview) .

Install in reverse order of removal. Note the following

Install the engine support and the right engine mount. Refer to Removal and Installation .

Install the turbocharger support. Refer to Removal and Installation .

Install the catalytic converter and front exhaust pipe. Refer to Removal and Installation .

Install the strut tower. Refer tor Removal and Installation .

Connect battery. Required actions, refer to BATTERY, DISCONNECTING AND CONNECTING . Take the necessary precautions for vehicles with a high voltage system and refer to BATTERY AND AUXILIARY BATTERY, DISCONNECTING AND CONNECTING

STARTER - ENGINE CODE(S): CALB

Removing

Scheme 71

Switch off the ignition.

Disconnect the battery ground (GND) cable from the battery. Refer to BATTERY, DISCONNECTING AND CONNECTING .

Loosen the clamping sleeve -1-, push it toward the rear and tie up the left front muffler.

Remove the right engine mount. Refer to Removal and Installation .

Scheme 72

Remove the nut -1- and free up the ground wire on the engine support.

Remove the bolts -arrows- and the right engine support.

Disconnect the electrical connector -3- by sliding the retainer back and pressing the release down.

Disconnect electrical wire -2- from starter.

Remove the bolt -1- and the rear extension from the transmission.

Remove the bolt -4- and remove the starter.

Note. 1- is reached from above.

Installing

1. Tightening specifications, refer to «STARTER OVERVIEW»(/audi/q5/i-2008-2012/remont/charging-system/#battery-starter-generator-cruise-control__starter-overview) .

Install in reverse order of removal. Note the following

Install the engine support and the right engine mount. Refer to Removal and Installation .

Align the exhaust system so that there is no tension. Refer to Removal and Installation .

Connect battery. Required actions, refer to BATTERY, DISCONNECTING AND CONNECTING . Take the necessary precautions for vehicles with a high voltage system and refer to BATTERY AND AUXILIARY BATTERY, DISCONNECTING AND CONNECTING

STARTER, 2.0L TDI AND MANUAL TRANSMISSION

Removing

Scheme 73

Switch the ignition off.

Disconnect the battery ground (GND) cable from the battery. Refer to BATTERY, DISCONNECTING AND CONNECTING . Vehicles with high voltage system, refer to BATTERY AND AUXILIARY BATTERY, DISCONNECTING AND CONNECTING .

Remove the strut tower. Refer to Removal and Installation .

Remove the right engine mount. Refer to [For engine(s) CAEB] Removal and Installation .

Remove the bolts -1- and -2- and the turbocharger support.

Remove the front exhaust pipe, refer to [For engine(s) CAEB] Removal and Installation .

Scheme 74

Disconnect the particulate filter and move it to the side. Refer to [For engine(s) CAEB] Removal and Installation .

Remove the nut -1- and free up the ground wire on the engine support.

Remove the bolts -arrows- and the right engine support.

Remove the bolt -1- for the wiring bracket -2-.

Disconnect the electrical connector -3- by sliding the retainer back and pressing the release down.

Scheme 75

Remove the terminal 30/B+ wire -2- from the starter.

Remove the bolts -1- and -4- and the starter.

Note. 1- can be reached from above.

Installing

1. Tightening specifications, refer to «STARTER OVERVIEW»(/audi/q5/i-2008-2012/remont/charging-system/#battery-starter-generator-cruise-control__starter-overview) .

Install in reverse order of removal. Note the following

Install the engine support and the right engine mount [For engine(s) CAEB] Removal and Installation .

Install the turbocharger support [For engine(s) CAEB] Removal and Installation .

Install the particulate filter and the front exhaust pipe [For engine(s) CALB] Removal and Installation .

Install the strut tower Removal and Installation .

Connect battery. Required actions, refer to BATTERY, DISCONNECTING AND CONNECTING . Take the necessary precautions for vehicles with a high voltage system and refer to BATTERY AND AUXILIARY BATTERY, DISCONNECTING AND CONNECTING

STARTER, 3.0L TDI

Removing

Switch the ignition off.

Disconnect the battery ground (GND) cable from the battery. Refer to BATTERY, DISCONNECTING AND CONNECTING . Vehicles with high voltage system, refer to BATTERY AND AUXILIARY BATTERY, DISCONNECTING AND CONNECTING .

Remove the front exhaust pipe. Refer to [For engine(s) CAEB] Removal and Installation .

Remove the generator. Refer to GENERATOR, 3.0L TDI WITHOUT AUXILIARY HEATER .

Remove the right engine mount. Refer to [For engine(s) CAEB] Removal and Installation .

Remove screws -1- and -2-.

Scheme 76

Press the lower right coolant pipe to the side.

Note. Disregard item -3-.

Remove the nut -1- and free up the ground wire on the engine support.

Scheme 77

Remove the bolts -arrows- and the right engine support.

Note. The engine support is illustrated without the heat shield.

Disconnect the electrical connector -3- by sliding the retainer back and pressing the release down.

Remove the terminal 30/B+ wire -2- from the starter.

Remove the bolts -1- and -4- and the starter.

Note. 1- can be reached from above.

Installing

1. Tightening specifications, refer to «STARTER OVERVIEW»(/audi/q5/i-2008-2012/remont/charging-system/#battery-starter-generator-cruise-control__starter-overview) .

Install in reverse order of removal. Note the following

Install the engine support and the right engine mount. Refer to [For engine(s) CAEB] Removal and Installation .

Install the lower right coolant pipe. Refer to [For engine(s) CAEB] Removal and Installation .

Install the generator. Refer to GENERATOR, 3.0L TDI WITHOUT AUXILIARY HEATER .

Install the front exhaust pipe. Refer to [For engine(s) CAEB] Removal and Installation .

Connect battery. Required actions, refer to BATTERY, DISCONNECTING AND CONNECTING . Take the necessary precautions for vehicles with a high voltage system and refer to BATTERY AND AUXILIARY BATTERY, DISCONNECTING AND CONNECTING

GENERATOR, 3.0L TDI WITHOUT AUXILIARY HEATER

Special tools and workshop equipment required

1. Torx T60 Socket T40087

Removing

Scheme 78

Switch the ignition off.

Disconnect the battery ground (GND) cable from the battery. Refer to BATTERY, DISCONNECTING AND CONNECTING . Vehicles with high voltage system, refer to BATTERY AND AUXILIARY BATTERY, DISCONNECTING AND CONNECTING .

Remove the engine cover in the direction of the -arrows-.

Remove the air duct -arrow-.

Scheme 79

Disconnect the mass airflow sensor -G70- connector -1-.

Scheme 80

Remove the bolt -3- and free up the exhaust pressure sensor 1 -G450- -4- on the air guide pipe.

Free up the exhaust gas temperature sensor 4 -G648- -2- connector on the air pipe.

Remove the air guide hose with the mass airflow sensor -G70- by releasing the hose clamp -5- and opening the clips -arrows-.

Disconnect the vacuum line -1-.

Scheme 81

Remove the air filter housing and on the rear side, disconnect the electrical connector -2- on the air filter bypass door valve -N275-.

Remove the screws -2- and -3-.

Scheme 82

Remove the air guide pipe from the air guide hose by loosening the hose clamp -1-.

Remove the right front wheel.

Loosen the front section of the right front wheel housing liner and press it back. Refer to Removal and Installation .

Remove the front noise insulation -1-. Refer to Removal and Installation .

Remove the bolt -1- and nut -3-.

Remove the right lock carrier brace -2-.

Vehicles with DSG Transmission

Scheme 83

Note. Note the rules for cleanliness when working on the DSG transmission .

Remove the bolt -arrow- for the automatic transmission fluid (ATF) lines.

All Vehicles

Scheme 84

Disconnect the -4- right electrohydraulic engine mount solenoid valve -N145- connector.

Remove the mount -5- for the connector on the bracket -3-.

Remove the nut -1- and remove the bracket and wiring harness from the subframe.

Cut the cable tie -6- and move the bracket and heat shield to the side.

Remove the nut -2- and disconnect the ground wire on the longitudinal member.

Remove the air guide hose from the right air guide pipe and lay it aside by loosening the hose clamp -arrow-.

Scheme 85

Scheme 86

Using a torx T60 socket T40087, move the tensioning element clockwise -arrow- to release the tension on the ribbed belt.

Remove the ribbed belt from the generator ribbed belt pulley.

Loosen the generator bolts -arrows- approximately 6 turns.

Scheme 87

Using a hammer, carefully hit bolt heads to loosen generator mount bushings.

Remove the bolts completely.

Remove generator from bracket.

Scheme 88

Remove the cap and then remove the terminal 30/B+ -1- nut.

Disconnect the electrical connector -2-.

Remove the generator -1- to the right between the wiring harness -2- and the automatic transmission fluid (ATF) lines -3- -arrow-, as illustrated.

Scheme 89

Installing

1. Tightening specification, refer to «GENERATOR WITH BUSHINGS OVERVIEW»(/audi/q5/i-2008-2012/remont/charging-system/#battery-starter-generator-cruise-control) .

Install in reverse order of removal. Note the following

Note. Tight sleeves for generator mount must be made smooth-running, otherwise clamping force of sleeve is too little despite correct torque. During removal the bushing may come out a little. During reinstallation ensure that the bushing is fully seated against the bracket before final torque is achieved.

Drive retaining bolt bushings back slightly for easier generator installation.

Install the right air guide pipe. Refer to [For engine(s) CAEB] Removal and Installation .

Place ribbed belt over ribbed belt pulleys.

Scheme 90

1. Generator
2. Idler pulley
3. Idler pulley
4. Coolant pump
5. Idler pulley (varies depending on construction version)
6. Power steering pump
7. A/C Compressor
8. Ribbed belt tensioner
9. Vibration damper

Note. When installing the ribbed belt, make sure it is seated correctly on the belt pulley.

Connect battery. Required actions, refer to BATTERY, DISCONNECTING AND CONNECTING . Take the necessary precautions for vehicles with a high voltage system and refer to BATTERY AND AUXILIARY BATTERY, DISCONNECTING AND CONNECTING

Start the engine and make sure the belt it running correctly.

SPECIAL TOOLS

Special tools and workshop equipment required

Scheme 91

Scheme 92

1. Locking Tool T40098
2. Torx Socket T60 T40087

See also:
• Generator, Checking
• Removal and Installation
• Battery, Starter, Generator, Cruise Control
• ENGINE COMPARTMENT E-BOX, WIRE JUNCTION, FUSE HOLDER AND BATTERY OVERVIEW Tightening Specifications for the Fuse Panel A
• FUSE PANEL A IN LUGGAGE COMPARTMENT
• Removal and Installation
• Removal and Installation
• Removal and Installation
• Battery Cooling Module Overview
• Removal and Installation
• REMOVAL AND INSTALLATION
• Removal and Installation
• Removal and Installation
• Removal and Installation
• Removal and Installation
• CONTACT CORROSION
• BATTERY
• BATTERY, DISCONNECTING AND CONNECTING
• BATTERY MONITORING CONTROL MODULE
• BATTERY
• BATTERY AND AUXILIARY BATTERY, DISCONNECTING AND CONNECTING
• BATTERY MONITORING CONTROL MODULE -J367- FOR BATTERY
• GENERATOR
• GENERATOR
• STARTER
• BATTERY OVERVIEW
• BATTERY AND AUXILIARY BATTERY OVERVIEW
• STARTER OVERVIEW
• GENERATOR, 3.0L TDI WITHOUT AUXILIARY HEATER
