General, Technical Data (Automatic Transmission 0b6) Audi Q5 I

CLEAN WORKING CONDITIONS

1. Always clean the connection locations and the area around them before loosening.
2. Clean the transmission and transmission components using cleaning solution -D 009 401 04-.
3. Use lint-free cloths when cleaning. Audi recommends the "WYPALL X70/WORKHORSE" cloth made by Kimberly-Clark Professional.
4. Seal all open lines and connections immediately with clean plugs or caps from the engine bung set VAS 6122.
5. Place removed parts on a clean surface and cover them. Use foil or lint-free cloths.
6. Carefully cover or plug unpacked components if repairs cannot be performed immediately.
7. Only install clean components: Remove the replacement parts from their packaging just prior to installing them.
8. Protect the disconnected connectors from dirt and moisture and only connect when they are dry.

CONTACT CORROSION

Contact corrosion can occur if incorrect fasteners are used on the vehicle (bolts, nuts, washers, etc.).

For this reason, only connecting elements with a special surface coating are installed.

In addition, rubber or plastic parts and adhesive are made of materials that do not conduct electricity.

If you are not sure about the suitability of parts, install new parts.

Note. Original replacement parts are recommended because they have been tested. It is recommended to use Audi accessories. Damage resulting from contact corrosion is not covered by the warranty.

Transmission

1. The 6-speed automatic transmission 0B6 AWD is equipped with 6 hydraulically activated forward gears. When the torque converter lock-up clutch is closed, these forward gears become manually driven gears through bypassing the torque converter slip.
2. A special feature of the 0B6 transmission is the position of the front final drive (front axle differential with flange shafts) in front of the torque converter. An even distribution of the weight between the front and rear axles is attained.

Torque Converter

The torque converter is equipped with a slip-controlled torque converter lock-up clutch. Due to the new design of this transmission, the torque converter is located behind the front final drive.

Mechatronic

The Mechatronic combines the following components as a complete synchronized unit

1. The hydraulic control, the transmission control module -J217
2. The multifunction transmission range switch -F125
3. The sensors and actuators

The Mechatronic unit is installed in the transmission in the area of the oil pan.

Transmission Control Module -J217

The control module is a part of the Mechatronic unit in the transmission.

Determining the driving situation and driving resistance dependent shift point occurs automatically.

Advantages

1. Usage-based shifting
2. Maximum engine output is always available
3. Individual adaptation of shift points in all driving situations
4. Gear shift points are infinitely variable

On Board Diagnostic (OBD)

Use "Guided Fault Finding" to determine the exact cause of damage before servicing the automatic transmission.

Use the vehicle diagnostic tester to perform "Guided Fault Finding"

Shift Point Changes on Inclines and Declines

When driving on inclines or declines, gears are automatically selected using additional shift characteristic maps. The selection is based on accelerator pedal position and vehicle speed.

1. The gear change map for extreme uphill stretches is matched to engine output
2. The gear change map for extreme downhill stretches is matched to the braking effect of the engine.
3. By selecting a gear directly using tiptronic, the driver can use the engine braking effect with a specific gear engaged, for example when driving downhill with a trailer.

REPAIR INFORMATION

Carefulness, cleanliness and the correct tools are required for transmission repairs to be successful. The usual basic safety precautions also, naturally apply when carrying out vehicle repairs.

Some general repair information that applies to several procedures throughout this repair information is summarized here. They apply to this repair information.

Guided Fault Finding, Vehicle Diagnosis and Test Instruments

Scheme 8

1. Determine the cause of the malfunction as accurately as possible using "Guided Fault Finding", "OBD" and "Test Instruments" before starting any repairs on the transmission use the vehicle diagnostic tester.

Oil, Environmental and Disposal Regulations

1. Handle ATF, axle oil and other fluids with care.
2. Dispose of drained ATF properly.
3. Follow the legal environmental and disposal regulations.
4. Follow the information provided on oil packaging.

Special Tools and Equipment

For a complete list of special tools used, refer to appropriate service information.

Transmission

1. Clean working conditions for the transmission, refer to «CLEAN WORKING CONDITIONS»(/audi/q5/i-2008-2012/remont/automatic-trans/#general-technical-data-automatic-transmission-0b6__clean-working-conditions) .
2. Do not run the engine or tow the vehicle when the center differential housing is removed or when there is no ATF.
3. After installing, the following fluid levels must be checked and topped off if necessary: ATF in transmission, refer to «ATF, CHECKING LEVEL AND CORRECTING»(/audi/q5/i-2008-2012/remont/automatic-trans/#controls-housing-automatic-transmission-0b6-awd__atf-checking-level-and-correcting) and gear oil in transmission, refer to «GENERAL INFORMATION»(/audi/q5/i-2008-2012/remont/axle-shafts/#final-drive-differential-automatic-transmission-0b6) . Capacities and specifications, refer to «GEAR OIL CAPACITIES»(/audi/q5/i-2008-2012/remont/automatic-trans/#general-technical-data-automatic-transmission-0b6__gear-oil-capacities) .

O-rings, Shaft Seals, Seals

1. O-rings, shaft seals and seals must be replaced.
2. After removing gaskets, examine contact surface on housing/shaft for burrs resulting from removal or for other signs of damage.
3. Thoroughly clean housing joint surfaces before assembling.
4. To install, thinly coat shaft seals along outer circumference and on sealing lip with ATF.
5. Coat O-rings with ATF before inserting to prevent crushing rings during installation.
6. Always only use approved ATF. Other types of lubrication cause faults to occur in the transmission hydraulics.
7. The open side of the shaft seals point toward the fluid to be sealed in.
8. Press in new shaft seal, so that the sealing lip does not run on the same point as the sealing lip of the old shaft seal (use insertion depth tolerances).
9. After installing, the following fluid levels must be checked and topped off if necessary: ATF in transmission «ATF, CHECKING LEVEL AND CORRECTING»(/audi/q5/i-2008-2012/remont/automatic-trans/#controls-housing-automatic-transmission-0b6-awd__atf-checking-level-and-correcting) or gear oil in transmission «GENERAL INFORMATION»(/audi/q5/i-2008-2012/remont/axle-shafts/#final-drive-differential-automatic-transmission-0b6) . Capacities and specifications, refer to «GEAR OIL CAPACITIES»(/audi/q5/i-2008-2012/remont/automatic-trans/#general-technical-data-automatic-transmission-0b6__gear-oil-capacities) .

Bolts and Nuts

1. Loosen the bolts opposite the tightening sequence.
2. Nuts and bolts which secure covers and housings should be tightened in steps according to the specified tightening sequence and method.
3. Nuts and bolts which secure covers and housings should be loosened and tightened crosswise in stages if no tightening sequence is specified.
4. Replace the self-locking nuts and bolts.
5. Use a wire brush to clean the threads of bolts that were screwed in with locking compound. Next, use locking compound AMV 185 101 A1 to install the bolts.
6. Threaded holes into which self-locking bolts or bolts coated with locking fluid are screwed, must be cleaned (for example tap). Otherwise there is a risk that the bolts will shear the next time they are removed.
7. The tightening specifications stated apply to non-oiled nuts and bolts.

Fasteners

1. Do not overstretch the circlips.
2. Replace damaged or stretched circlips.
3. The circlips must fit completely inside the groove.

Bearings

1. Install needle bearings with lettered side (thicker metal) racing the fitting tool.
2. Insert bearing with axle oil or ATF, depending on installation location.
3. Do not interchange the outer or inner races for the same size bearings.
4. Always replace the tapered roller bearings on one shaft together and use new bearings from a single manufacturer.

Adjusting Shims

1. Measure the adjusting shims at several locations with a micrometer. Tolerance variations make it possible to find the exact shim thickness required.
2. Check for burrs and damage. Only install perfect shims.

SAFETY PRECAUTIONS

Observe the following to avoid personal injury and vehicle damage

To prevent personal injury and damage or destruction of electrical and electronic components, observe the following

1. Connect and disconnect test equipment only when the ignition is turned off.

Disconnect the battery. Refer to [For engine(s) CAEB, CALB] Removal and Installation .

If testing equipment must be used during a road test, observe the following

TOWING

Note. Tow-starting the engine, for example when the battery is too weak or the starter is faulty, is not possible.

TRANSMISSION IDENTIFICATION

Code Letters, Location on Transmission

Scheme 9

1. Transmission code letters are located on the data plate under the transmission. Location of the type plate depending on the build version -arrow 1- or -arrow 2-.
2. An identical type plate is located on the left side of the transmission but is not accessible with the transmission installed.

Transmission Code and Transmission Serial Number

Scheme 10

Example

1. 1- Transmission serial number
2. 2- Parts list number
3. 3- Manufacturer transmission code: 6HP-28
4. 4- Transmission code example: KRL

Note. The transmission code is also listed on the vehicle data plate.

Scheme 11

1. 6-Speed Automatic Transmission 0B6 AWD
2. Driveshaft
3. Rear Final Drive

CODE LETTERS, TRANSMISSION ALLOCATIONS, RATIOS AND EQUIPMENT

GEAR OIL CAPACITIES

ATF area in the Transmission

ATF, DRAINING OR FILLING AFTER REPAIR

Front Final Drive

GENERAL INFORMATION

Transfer Case

GENERAL INFORMATION

See also:
• ATF, CHECKING LEVEL AND CORRECTING
• GENERAL INFORMATION
• [For engine(s) CAEB, CALB] Removal and Installation
• ATF, DRAINING OR FILLING AFTER REPAIR
• CLEAN WORKING CONDITIONS
• GEAR OIL CAPACITIES
