DESCRIPTION & OPERATION
The power window system consists of a control panel, 3 remote operating switches, window motor, wiring harness and connectors. Mechanical components include a regulator, carrier assembly and typical window hardware. (Scheme 1)
The power windows can be operated at all times when ignition is in the ON position. When ignition is off, the power windows can be operated only when both front doors are closed. The control panel located in the driver's armrest operates all windows. The rear windows will operate only when the safety switch in control panel is deactivated.
All closed windows will automatically open 6" (150 mm) when opening or closing convertible top.
Scheme 1
WINDOW MOTOR
Disconnect window motor harness connector. Connect battery voltage to connector terminals. Ensure motor works at both polarities.
Remove door trim. Remove window motor mounting screws. (Scheme 2) Disconnect harness connector. Pry motor out of carrier assembly. To install, reverse removal procedure. Tighten mounting screws to 40 INCH lbs. (4.5 N.m).
Scheme 2
WINDOW SWITCH
Use screwdriver to pry switch console from armrest. Remove wiring harness connectors. Carefully pry switch away from console at side tabs. (Scheme 3) Remove switch from console.
