Engine Controls - Specifications Audi Cabriolet I

Specifications 4 illustrations ~355 words

INTRODUCTION

Use this article to quickly find specifications related to servicing and on-vehicle adjustments. This article may be used for quick reference when you are familiar with proper adjustment procedures and only need a specification.

CAPACITIES

CAUTIONWhen battery is disconnected, radio will go into anti-theft protection mode. Obtain radio anti-theft protection code from owner prior to servicing vehicle.
ApplicationAmp Hr. Rating
2.8L63

BATTERY SPECIFICATIONS

ApplicationQuantity
Crankcase (Includes Filter)5.3 Qts. (5.0L)
Cooling System (Includes Heater)11.6 Qts. (11.0L)
A/T (Dexron II)3.2 Qts. (3.0L)
A/T Final Drive (G 50 Synthetic SAE 75W 90)1.1 Qts. (1.0L)
M/T (G 50 Synthetic SAE 75W 90)2.5 Qts. (2.35L)
Differential (G 50 Synthetic SAE 75W 90)1.1 Qts. (1.0L)

FLUID CAPACITIES

SERVICE INTERVALS & SPECIFICATIONS

ComponentInterval (Miles)
Air Filter30,000
Cam Timing Belt90,000
Coolant60,000
Fuel Filter15,000
Oil & Filter7500
Spark Plugs30,000

REPLACEMENT INTERVALS

DRIVE BELT INSPECTION

  1. Using a crayon or other marker, mark direction of belt travel before removing belt (if reusing belt). If reinstalled in opposite direction, damage to belt will occur.
  2. Remove drive belt guard. Using a 10-mm wrench, rotate drive belt tensioner clockwise and remove drive belt. Hold tensioner in place with Holding Mandrel (V.A.G. 3204). (Scheme 1)
  3. Ensure belt has no splits, cracks or other damage. To install drive belt, reverse removal procedure. Place drive belt over drive rollers and idling roller first and onto tensioning roller last. Using a 10-mm wrench, remove holding mandrel and allow tensioning roller to move against belt. Install drive belt guard.

Scheme 1

Scheme 1

ENGINE COMPRESSION

ApplicationSpecification
Compression Ratio10.3:1
Normal Compression Pressure128-199 psi (9-14 kg/cm 2 )
Minimum Compression Pressure109 psi (7.7 kg/cm 2 )
Maximum Variation Between Cylinders44 psi (3.1 kg/cm 2 )

COMPRESSION SPECIFICATIONS

VALVE CLEARANCE

Note. Cabriolet is equipped with hydraulic lifters. No adjustments are required.

IGNITION COIL(S)

ApplicationPrimarySecondary
2.8L.5-1.29000-14,000

IGNITION COIL RESISTANCE - Ohms @ 68°F (20°C)

HIGH TENSION WIRE RESISTANCE

Information is not available from manufacturer.

SPARK PLUGS

ApplicationAudiNGK
2.8L101 000 033 AABKUR6ET-10

SPARK PLUG TYPE

ApplicationGapIn. (mm)TorqueFt. Lbs. (N.m)
2.8L.035-.043 (.9-1.1)15 (20)

SPARK PLUG SPECIFICATIONS

FIRING ORDER

Note. For firing order (Scheme 2)

Scheme 2

Scheme 2: FIRING ORDER

IGNITION TIMING

Note. Ignition timing, idle speed and mixture are controlled by the PCM, and are not adjustable.

Basic Setting

  1. Lock camshafts at TDC No. 3 cylinder using Timing Fixture (V.A.G. 3243). Locating plates are used to position camshafts. Each locating plate has a large hole and a small hole. When installing timing fixture, ensure large holes on locating plates face each other. (Scheme 3)
  2. Lock crankshaft at TDC No. 3 cylinder with Crank Locating Pin (V.A.G. 3242) inserted through threaded hole in block where reference sensor usually is, and into locating notch in crankshaft. (Scheme 4) Fit and tension cam drive belt. Remove timing fixture and locating pin.

Scheme 3

Scheme 3

Scheme 4

Scheme 4

FUEL PUMP

FunctionValue
System (Pump) Pressure55-61 psi (3.8-4.2 kg/cm 2 )
Residual Pressure (1)
Engine Cold32 psi (2.2 kg/cm 2 )
Engine Hot44 psi (3.0 kg/cm 2 )
Fuel Injector/Injection Rate (2)2.9-3.4 oz. (85-100 ml)
Idle Speed700-800 RPM
CO Content0.3-1.2% Of Volume
(1) After 10 minutes. (2) Per 30 seconds of operation.
(1)After 10 minutes.
(2)Per 30 seconds of operation.

FUEL PUMP PERFORMANCE

INJECTOR RESISTANCE

Injector resistance is 15-17 ohms.

IDLE SPEED & MIXTURE

Idle speed and mixture are controlled by PCM, and are nonadjustable.
