Audi A8 D5 (2017-2022) brn Wiring diagrams
This page contains all the electrical diagrams for the component. brn, in which he is found in the car Audi A8 D5 (2017-2022). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram brn (121 of 235)
ANTI-THEFT ALARM SYSTEM SENSOR
BLK WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
CENTER COUPLING POINT ON ROOF
COMFORT SEAT
COUPLING STATION IN RIGHT FRONT SEAT
DRIVER ASSISTANCE SYSTEMS FRONT CAMERA
DRIVER VANITY MIRROR LAMP CONTACT SWITCH
FRONT PASSENGER BACKREST HEATING ELEMENT
FRONT PASSENGER SEAT BACKREST BOLSTER HEATER
FRONT PASSENGER SEAT BOLSTER HEATER
FRONT PASSENGER SEAT COUPLING POINT
FRONT PASSENGER SEAT HEATING ELEMENT
FRONT ROOF MODULE
INTERIOR REAR VIEW MIRROR
LEFT AMBIENT ROOF LAMP
LEFT ILLUMINATED VANITY MIRROR
PASSENGER OCCUPANT DETECTION SYSTEM CONTROL MODULE
RAIN/LIGHT RECOGNITION SENSOR
REAR INTERIOR LAMP
RIGHT AMBIENT ROOF LAMP
RIGHT FRONT SEAT HEATED BACKREST
RIGHT FRONT SEAT HEATING ELEMENT
RIGHT ILLUMINATED VANITY MIRROR
SPORT SEAT
SUNROOF CONTROL MODULE
WHT WIRE
Go to component -> Ground distribution circuit (11 of 12) -> BRN WIRE
Wiring diagram brn (122 of 235)
ANTENNA AMPLIFIER
ANTENNA AMPLIFIER SHIELD
BLK WIRE
BOTTOM COUPLING POINT ON RIGHT A-PILLAR
BRN WIRE
DATA BUS ON BOARD DIAGNOSTIC INTERFACE
DRIVER ASSISTANCE SYSTEM,
DVD PLAYER
EMERGENCY CALL MODULE ANTENNA
EMERGENCY CALL MODULE ANTENNA SHIELD
EMERGENCY CALL MODULE, COMMUNICATION UNIT CONTROL MODULE
EMERGENCY CALL MODULE, COMMUNICATION UNIT CONTROL MODULE SHIELD
FRONT A/C DISPLAY CONTROL HEAD 1
FRONT A/C DISPLAY CONTROL HEAD 2
FRONT A/C DISPLAY CONTROL HEAD 3
FRONT A/C DISPLAY CONTROL HEAD 4
FRONT INFORMATION DISPLAY CONTROL HEAD
FRONT INFORMATION DISPLAY CONTROL HEAD 2
INFORMATION ELECTRONICS CONTROL MODULE 1
INFORMATION ELECTRONICS CONTROL MODULE 1 SHIELD
INSTRUMENT CLUSTER CONTROL MODULE
NCA WIRE
ROOF ANTENNA
ROOF ANTENNA SHIELD
TV ANTENNA AMPLIFIER 1
TV ANTENNA AMPLIFIER 1 SHIELD
TV TUNER
USB DISTRIBUTOR
VEHICLE INTERIOR CARBON DIOXIDE CONCENTRATION SENSOR
WINDSHIELD PROJECTION HEAD UP DISPLAY CONTROL MODULE
Go to component -> Ground distribution circuit (12 of 12) -> BRN WIRE
Wiring diagram brn (123 of 235)
ALARM HORN
BATTERY MONITORING CONTROL MODULE
BLK WIRE
BRN WIRE
BRN/VIO WIRE
COOLANT RECIRCULATION PUMP
DRIVER SIDE WINDSHIELD WIPER ARM THERMAL RESISTOR 1
EXTERIOR AIR QUALITY, HUMIDITY SENSOR
FRONT PASSENGER DOOR CONTROL MODULE
FRONT PASSENGER DOOR LOCK UNIT
FRONT PASSENGER SIDE WINDSHIELD WIPER ARM THERMAL RESISTOR 1
FRONT PASSENGER THORAX AIR BAG IGNITER
FRONT PASSENGER VANITY MIRROR LAMP CONTACT SWITCH
HEADLAMP WASHER SYSTEM PUMP
HOOD CONTACT SWITCH 2
POWER STEERING CONTROL MODULE
REAR AXLE COUPLING POINT 1
REAR AXLE STEERING CONTROL MODULE
RIGHT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT
RIGHT FRONT DOOR COUPLING POINT
RIGHT FRONT EXTERIOR DOOR HANDLE TOUCH SENSOR
RIGHT FRONT HEADLAMP
RIGHT FRONT OBJECT DETECTION RADAR SENSOR CONTROL MODULE
RIGHT FRONT SEAT COUPLING STATION
RIGHT REAR SEAT BELT TENSIONER CONTROL MODULE
SUSPENSION STABILIZATION CONTROL MODULE 1
SUSPENSION STABILIZATION CONTROL MODULE 2
TERMINAL 30 WIRE JUNCTION
W/ ADAPTIVE CRUISE CONTROL
WINDSHIELD DEFOGGER CONTROL MODULE
WINDSHIELD WASHER PUMP CONTROL MODULE
WIPER MOTOR CONTROL MODULE
Go to component -> Ground distribution circuit (1 of 12) -> BRN WIRE
Wiring diagram brn (124 of 235)
AUXILIARY HEATER CONTROL MODULE
BRAKE LAMP SWITCH, BRAKE PEDAL SWITCH
BRN WIRE
CENTER WASHER NOZZLE HEATER
CLOSE RANGE COMMUNICATION CONTROL MODULE
COUPLING POINT IN PLENUM CHAMBER
COUPLING POINT IN THE LEFT FRONT DOOR
DIAGNOSTIC CONNECTION
DRIVER ASSISTANCE SYSTEMS CONTROL MODULE
DRIVER DOOR CLOSING AID MOTOR
DRIVER DOOR CONTROL MODULE
DRIVER DOOR LOCK UNIT
DRIVER DOOR STORAGE COMPARTMENT ILLUMINATION BULB
DRIVER SIDE EXTERIOR DOOR HANDLE ILLUMINATION LAMP
DRIVER SIDE EXTERIOR DOOR HANDLE SWITCH
DRIVER SIDE FRONT DOOR TRIM PANEL HEATING ELEMENT 2
HIGH-MOUNTED BRAKE LAMP BULB
LEFT DOOR STORAGE COMPARTMENT ILLUMINATION LAMP
LEFT FRONT DOOR AMBIENT LIGHTING BULB 1
LEFT FRONT DOOR CONTOUR ILLUMINATION LAMP
LEFT FRONT DOOR CONTOUR ILLUMINATION LAMP 2
LEFT FRONT DOOR COUPLING POINT
LEFT FRONT EXTERIOR DOOR HANDLE TOUCH SENSOR
LEFT WASHER NOZZLE HEATER
NIGHT VISION SYSTEM CONTROL MODULE
PEDESTRIAN PROTECTION TRIGGER 1
PEDESTRIAN PROTECTION TRIGGER 2
PRESSURE SIDE A/C PRESSURE/ TEMPERATURE SENSOR
RADIATOR FAN CONTROL MODULE
RADIATOR FAN CONTROL MODULE 2
RIGHT WASHER NOZZLE HEATER
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
W/ AMBIENT LIGHTING
Go to component -> Ground distribution circuit (2 of 12) -> BRN WIRE
Wiring diagram brn (125 of 235)
ADAPTIVE CRUISE CONTROL MODULE
AFTER-RUN COOLANT PUMP
BRN WIRE
CELLULAR TELEPHONE AMPLIFIER
COUPLING POINT ON LEFT FRONT BUMPER
EMERGENCY CALL MODULE, COMMUNICATION UNIT CONTROL MODULE
ENGINE HOOD CONTACT SWITCH
ENGINE/MOTOR CONTROL MODULE
HIGH PRESSURE SENSOR
HIGH TONE HORN
IGNITION COIL 1 W/ POWER OUTPUT STAGE
IGNITION COIL 2 W/ POWER OUTPUT STAGE
IGNITION COIL 3 W/ POWER OUTPUT STAGE
IGNITION COIL 4 W/ POWER OUTPUT STAGE
IGNITION COIL 5 W/ POWER OUTPUT STAGE
IGNITION COIL 6 W/ POWER OUTPUT STAGE
LASER DISTANCE REGULATION CONTROL MODULE
LEFT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT
LEFT FRONT HEADLAMP
LEFT FRONT OBJECT DETECTION RADAR SENSOR CONTROL MODULE
LOW PRESSURE SIDE A/C PRESSURE/ TEMPERATURE SENSOR
LOW TONE HORN
RIGHT REAR BRAKE PAD WEAR SENSOR
RIGHT TAIL LAMP
TV TUNER
W/ LED TAIL LAMP ASSEMBLY W/O LED TAIL LAMP ASSEMBLY
Go to component -> Ground distribution circuit (3 of 12) -> BRN WIRE
Wiring diagram brn (126 of 235)
A/C SYSTEM PARTICULATE MATTER CONCENTRATION SENSOR
ACCESS/START AUTHORIZATION BUTTON
ACTIVE STEERING CONTROL MODULE
BRN WIRE
CENTER CONSOLE CONTOUR ILLUMINATION LAMP 1
CENTER CONSOLE CONTOUR ILLUMINATION LAMP 2
CENTER CONSOLE CONTOUR ILLUMINATION LAMP 3
CENTER CONSOLE CONTOUR ILLUMINATION LAMP 4
CENTER COUPLING POINT IN INTERIOR
CIGARETTE LIGHTER
CLOSE RANGE COMMUNICATION CONTROL MODULE 2
DRIVER VOLUME CONTROL
ELECTRONIC STEERING COLUMN LOCK CONTROL MODULE
FRAGRANCE DIFFUSER SYSTEM CONTROL MODULE
FRESH AIR BLOWER CONTROL MODULE
FRONT CENTER CONSOLE AMBIENT LIGHTING BULB 1
FRONT CENTER CONSOLE AMBIENT LIGHTING BULB 2
FRONT CENTER CONSOLE AMBIENT LIGHTING BULB 3
FRONT CENTER CONSOLE AMBIENT LIGHTING BULB 4
FRONT PASSENGER AIR BAG UNIT
GLOVE COMPARTMENT LAMP SWITCH
INSTRUMENT PANEL AMBIENT LIGHTING LAMP 1
INSTRUMENT PANEL AMBIENT LIGHTING LAMP 2
INSTRUMENT PANEL AMBIENT LIGHTING LAMP 3
INSTRUMENT PANEL CONTOUR ILLUMINATION LAMP 1
INSTRUMENT PANEL CONTOUR ILLUMINATION LAMP 2
INSTRUMENT PANEL CONTOUR ILLUMINATION LAMP 3
IONIZER CONTROL MODULE
LEFT FRONT FOOTWELL ILLUMINATION BULB
LIGHT SWITCH
MOBILE DEVICE CHARGER 1
PARKING BRAKE BUTTON
POWER ADJUSTABLE STEERING COLUMN CONTROL MODULE
REAR CENTER CONSOLE REAR CIGARETTE LIGHTER
RIGHT FRONT FOOTWELL ILLUMINATION BULB
SELECTOR LEVER
STEERING COLUMN ELECTRONICS CONTROL MODULE
VALET PARKING LOCK BUTTON
W/ AMBIENT LIGHTING
Go to component -> Ground distribution circuit (4 of 12) -> BRN WIRE
Wiring diagram brn (127 of 235)
AUXILIARY DISPLAY CONTROL HEAD 1
BRN WIRE
CENTER CONSOLE CONTOUR ILLUMINATION LAMP 5
CENTER CONSOLE CONTOUR ILLUMINATION LAMP 6
CENTER REAR SEAT COUPLING STATION
CENTER TAIL LAMP
DATA BUS ON BOARD DIAGNOSTIC INTERFACE
DRIVETRAIN CONTROL MODULE
DVD CHANGER
EXHAUST DOOR CONTROL UNIT
EXHAUST DOOR CONTROL UNIT 2
FRONT A/C DISPLAY CONTROL HEAD 5
FRONT A/C DISPLAY CONTROL HEAD 6
GARAGE DOOR OPENER CONTROL MODULE
LANE CHANGE ASSISTANCE CONTROL MODULE
LANE CHANGE ASSISTANCE CONTROL MODULE 2
LEFT REAR BUMPER COUPLING POINT
LEFT TAIL LAMP
LEFT TAIL LAMP 2
MOBILE DEVICE CHARGER 2
PASSENGER SIDE REAR MULTI- CONTOUR SEAT SWITCH
POWER REAR LID OPENING CONTROL MODULE
REAR A/C DISPLAY CONTROL HEAD
REAR CENTER CONSOLE AMBIENT LIGHTING BULB 1
REAR CENTER CONSOLE AMBIENT LIGHTING BULB 2
REAR CENTER CONSOLE STORAGE COMPARTMENT ILLUMINATION BULB
REAR FRESH AIR BLOWER CONTROL MODULE
REAR SEAT COUPLING STATION
REAR WINDOW DEFOGGER RELAY
RELAY & FUSE PANEL 3
RIGHT CENTER ARMREST ILLUMINATION BULB
RIGHT REAR CENTER ARMREST HEATING ELEMENT
RIGHT TAIL LAMP 2
TELEPHONE BASEPLATE
TERMINAL 15 POWER SUPPLY RELAY
TO FRONT PASSENGER SEAT COUPLING POINT (DIAGRAM 10 OF 12)
USB CONNECTION 1
W/ AMBIENT LIGHTING
W/ SHORT REAR CENTER CONSOLE W/ LONG REAR CENTER CONSOLE
Go to component -> Ground distribution circuit (5 of 12) -> BRN WIRE
Wiring diagram brn (128 of 235)
ABS CONTROL MODULE
AIR BAG CONTROL MODULE
BRN WIRE
CELLULAR TELEPHONE AMPLIFIER 2
COMFORT SYSTEM CENTRAL CONTROL MODULE
COOLER
DIFFERENTIAL LOCK CONTROL MODULE
DIGITAL SOUND SYSTEM CONTROL MODULE
DRIVER SIDE SECOND ROW CENTER AIR BAG IGNITER OCCUPANT CONTACT PROTECTION
LEFT "C" PILLAR)
LEFT LUGGAGE COMPARTMENT LAMP
LEFT REAR SEAT BELT TENSIONER CONTROL MODULE
LEVEL CONTROL SYSTEM COMPRESSOR ELECTRONICS
REAR LID CLOSING AID
REAR LID CONTROL HEAD
REAR LID CONTROL MODULE
REAR LID HANDLE RELEASE BUTTON
REAR LID LOCK UNIT
REAR SUNROOF CONTROL MODULE
REAR VIEW CAMERA SYSTEM CONTROL MODULE
REAR WINDOW DEFOGGER
RIGHT LUGGAGE COMPARTMENT LAMP
ROOF ANTENNA
TIRE PRESSURE MONITORING CONTROL MODULE
W/ LONG WHEEL BASE
Go to component -> Ground distribution circuit (6 of 12) -> BRN WIRE
Wiring diagram brn (129 of 235)
BLK WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
COMFORT SEAT
COUPLING POINT IN LEFT REAR SEAT
COUPLING POINT IN THE LEFT REAR DOOR
COUPLING STATION IN LEFT FRONT SEAT
DRIVER BACKREST HEATING ELEMENT
DRIVER SEAT BACKREST BOLSTER HEATER
DRIVER SEAT BOLSTER HEATER
DRIVER SEAT COUPLING POINT
DRIVER SEAT HEATING ELEMENT
DRIVER SIDE REAR DOOR CLOSING AID MOTOR
DRIVER SIDE REAR DOOR CONTROL MODULE
DRIVER SIDE REAR DOOR LOCK UNIT
DRIVER SIDE REAR DOOR TRIM PANEL HEATING ELEMENT 2
DRIVER SIDE REAR EXTERIOR DOOR HANDLE ILLUMINATION LAMP
DRIVER SIDE REAR EXTERIOR DOOR HANDLE SWITCH
DRIVER SIDE REAR SEAT ADJUSTMENT CONTROL MODULE
LEFT FRONT SEAT BELT
LEFT FRONT SEAT HEATED BACKREST
LEFT FRONT SEAT HEATING ELEMENT
LEFT REAR BACKREST FAN 1
LEFT REAR BACKREST HEATING ELEMENT
LEFT REAR DOOR AMBIENT LIGHTING BULB 1
LEFT REAR DOOR AMBIENT LIGHTING BULB 2
LEFT REAR DOOR CONTOUR ILLUMINATION LAMP
LEFT REAR DOOR CONTOUR ILLUMINATION LAMP 2
LEFT REAR DOOR COUPLING POINT
LEFT REAR DOOR STORAGE COMPARTMENT ILLUMINATION CONTROL MODULE
LEFT REAR DOOR STORAGE COMPARTMENT ILLUMINATION LAMP
LEFT REAR EXTERIOR DOOR HANDLE TOUCH SENSOR
LEFT REAR SEAT BACKREST BOLSTER HEATING ELEMENT
LEFT REAR SEAT BOLSTER HEATER
LEFT REAR SEAT COUPLING STATION
LEFT REAR SEAT CUSHION FAN 1
SPORT SEAT
W/ AMBIENT LIGHTING
W/ VENTILATION W/O VENTILATION
WHT WIRE
Go to component -> Ground distribution circuit (8 of 12) -> BRN WIRE
Wiring diagram brn (130 of 235)
BLK WIRE
BRN WIRE
BRN/YEL WIRE
COUPLING POINT IN THE RIGHT REAR DOOR
FRONT PASSENGER SEAT BELT SWITCH
FRONT PASSENGER SEAT COUPLING POINT
FRONT PASSENGER SIDE SILL PANEL STRIP AMBIENT LIGHTING LAMP
FUEL DELIVERY UNIT
FUEL DELIVERY UNIT COUPLING POINT
FUEL DELIVERY UNIT SHIELD
FUEL PUMP CONTROL MODULE
NCA WIRE
PASSENGER SIDE REAR DOOR CLOSING AID MOTOR
PASSENGER SIDE REAR DOOR CONTROL MODULE
PASSENGER SIDE REAR DOOR LOCK UNIT
PASSENGER SIDE REAR DOOR TRIM PANEL HEATING ELEMENT 2
PASSENGER SIDE REAR EXTERIOR DOOR HANDLE ILLUMINATION LAMP
PASSENGER SIDE REAR EXTERIOR DOOR HANDLE SWITCH
PASSENGER SIDE REAR SILL PANEL STRIP AMBIENT LIGHTING LAMP
RIGHT FRONT SEAT BELT
RIGHT FRONT SEAT COUPLING STATION
RIGHT REAR AIR VENT ILLUMINATION BULB
RIGHT REAR DOOR AMBIENT LIGHTING BULB 1
RIGHT REAR DOOR AMBIENT LIGHTING BULB 2
RIGHT REAR DOOR CONTOUR ILLUMINATION LAMP
RIGHT REAR DOOR CONTOUR ILLUMINATION LAMP 2
RIGHT REAR DOOR COUPLING POINT
RIGHT REAR DOOR STORAGE COMPARTMENT ILLUMINATION CONTROL MODULE
RIGHT REAR DOOR STORAGE COMPARTMENT ILLUMINATION LAMP
RIGHT REAR EXTERIOR DOOR HANDLE TOUCH SENSOR
RIGHT REAR INFORMATION DISPLAY CONTROL HEAD CONTROL MODULE
W/ AMBIENT LIGHTING
W/ AUXILIARY LAMPS
Go to component -> Ground distribution circuit (9 of 12) -> BRN WIRE
