Noise insulation, removing
Auxiliary heating with bolted exhaust system
Scheme 24
- On vehicles with auxiliary heater, remove parking/auxiliary heater exhaust pipe screws - arrows - on noise insulation.
Auxiliary heating with inserted exhaust system
- After installing noise insulation, check location of exhaust pipe - A - ; a seal - B - must be installed between exhaust pipe and noise insulation.
Scheme 25
- Exhaust pipe must project below seal and the escape of exhaust from the pipe - A - must not be impaired.
Noise insulation, removing
Scheme 26
- Remove screws or quick-release connectors - 1 - and - 2 - and remove noise insulation.
- Assembly is done in reverse order
