Front A/C Controls, Removing and Installing

Special tools, testers and auxiliary items required

1. Torque wrench V.A.G 1783/

Removing

1. Place selector lever in position "S".
2. Switch off ignition.

Front ashtray, removing

1. Open front ashtray.

Scheme 56

1. Operate button - arrow -.
2. Pull out ashtray insert - 1 -.

Scheme 57

1. Remove bolt - 1 -.
2. Pull front ashtray - 2 - out of center console.
3. Disconnect electrical connector.

Remove center console panel with multimedia control unit.

Scheme 58

1. Pull center console panel with multimedia control unit - 1 - upward and off.

2 - Pins

3 - Spring clamp

4 - Center Console

1. Disconnect electrical connectors.
2. Remove center console panel with multimedia control unit.

Removing front A/C controls

Scheme 59

1. Remove bolts - 1 - (qty. 2).
2. Pull front A/C controls - 3 - out of center console - 2 -.
3. Disconnect electrical connectors.
4. Remove front A/C controls.

Installing

Installation is reverse of removal. Observe the following when doing so

Follow the sequence of installation when installing center console panel with multimedia control unit, front A/C controls and front ashtray

1. Connect electrical harness connectors.
2. Insert front A/C controls into center console, but do not tighten bolts.
3. Connect electrical harness connectors to multimedia control unit.
4. Clip center console panel with multimedia control unit into center console.

1. Align at center the center console panel with multimedia control unit.
2. Tighten bolts of front A/C controls to the specified tightening torque.
3. Install front ashtray --> «Front Ashtray, Removing and Installing»(/audi/a8/d3-2005-2007/remont/gauges-instrument-panels/#body-interior__front-ashtray-removing-and-installing) .

Tightening torques

Front A/C controls to center console: 4 Nm

Refer to the respective information for all other tightening torques.
