Sunroof Audi A8 D3

Contact corrosion!

With the extensive use of aluminum construction, corrosion caused by contact between dissimilar metals may result if the wrong fastening components (screws, bolts, nuts, washers, rivets, plugs, grommets, adhesives, etc.) are installed.

For this reason, the manufacturer only installs fastening components that have a special surface coating, recognized by its greenish color, and only uses rubber parts, plastic parts and adhesives that are electrically non-conductive.

These parts, compatible for use with aluminum, are also available as replacement parts.

Use only Genuine Parts!

If there is any doubt about whether the old parts are suitable for re-use, always install new replacement parts.

Note. The following list refers to (Scheme 1).

1. Wind deflector Removing and installing. See «WIND DEFLECTOR, REMOVING AND INSTALLING»(/audi/a8/d3-2002-2005/remont/sun-rooft-topconvertible-top/#sunroof__wind-deflector-removing-and-installing) .
2. Frame To remove and install, remove molded headliner. See «POWER SUNSHADE FOR REAR GLASS, REMOVING AND INSTALLING»(/audi/a8/d3-2002-2005/remont/gauges-instrument-panels/#interior-trim__power-sunshade-for-rear-glass-removing) .
3. Face plate To adjust, tilt sunroof open and push trim on edge of panel seal upward. Tighten bolts -5- to 1 Nm (9 in. lb).
4. Link guide Removing and installing. See «LINK GUIDE WITH CABLE, REMOVING AND INSTALLING»(/audi/a8/d3-2002-2005/remont/sun-rooft-topconvertible-top/#sunroof__link-guide-with-cable-removing-and) .
5. Socket-head screw 1 Nm (9 in. lb)
6. Rear guide with cable To remove, remove sunroof. See «ALUMINUM AND SOLAR SUNROOF PANEL, REMOVING AND INSTALLING»(/audi/a8/d3-2002-2005/remont/sun-rooft-topconvertible-top/#sunroof) and detach guide profile -9-.
7. Rain channel To remove, remove link guide. See «LINK GUIDE WITH CABLE, REMOVING AND INSTALLING»(/audi/a8/d3-2002-2005/remont/sun-rooft-topconvertible-top/#sunroof__link-guide-with-cable-removing-and) . On vehicles with glass panel, disconnect catch strap on rain channel
8. Recessed screw 2 Nm (18 in. lb)
9. Guide profile To remove, remove link guide.
10. Guide tube
11. Sliding roof motor Removing and installing. See «SUNROOF MOTOR, REMOVING AND INSTALLING»(/audi/a8/d3-2002-2005/remont/sun-rooft-topconvertible-top/#sunroof) . Setting zero position. See «SUNROOF MOTOR ZERO POSITION, ADJUSTING»(/audi/a8/d3-2002-2005/remont/sun-rooft-topconvertible-top/#sunroof) .
12. Bolts (3x) 3 Nm (27 in. lb)

Removing

1. Slide sunroof open approx. 10 cm toward rear.
2. Spread retaining clips open to left and right (arrows) and slide sunroof open toward rear. NOTE: Illustration shows retaining clip from inside sunroof headliner.
3. Close sunroof.
4. Completely remove screws -1-, -2- and -3- from tilting mechanism on both sides. Tightening torque: 4.5 Nm (40 in. lb)
5. Remove sunroof panel upward.

Installing

Installation is the reverse of removal, noting the following

1. Adjust sunroof. See «SUNROOF PANEL HEIGHT, ADJUSTING»(/audi/a8/d3-2002-2005/remont/sun-rooft-topconvertible-top/#sunroof) .

Scheme 1

1. Slide sunroof open approx. 10 cm toward rear.
2. Spread retaining clips open to left and right (arrows) and open sunroof headliner toward rear. NOTE: Illustration shows retaining clip from inside sunroof headliner.
3. Close sunroof.
4. Stick adhesive tape over retaining clips at left and right to prevent clips from locking in sunroof panel when sunroof is tilted open. NOTE: When the sunroof is tilted open, the retaining clips on the sunroof headliner must not lock into the sunroof panel. If the clips lock into the panel, the sunroof will no longer close without damaging the mechanism.
5. Close sunroof, tilt open and slide sunroof headliner forward completely. Retaining clips can no longer snap into sunroof panel.
6. Push sunroof headliner over rain channel and remove from sunroof opening toward rear.

Note. If the sunroof headliner is to be installed without removing the sunroof panel, the retaining clips the sunroof headliner must be covered with adhesive tape.

Scheme 2

1. Tilt sunroof open.
2. Insert sunroof headliner through sunroof open push forward into guides and press over rain channel at rear.
3. Push sunroof headliner toward rear in opening
4. Remove adhesive tape.
5. Close sunroof.
6. Slide sunroof headliner forward until retaining engage into sunroof panel.

1. Push sunroof headliner completely toward rear.
2. Tilt sunroof open.
3. Pull out interior trim strip -1- at top of panel between glass and inner plate in direction of arrow -A-.
4. Unclip interior trim strip at front of panel -2- from bolt and push to rear (arrow -B-) out of clip.
5. Remove interior trim toward center of vehicle.
6. Completely remove screws (arrows) on both sides of tilting mechanism. Tightening torque: 4.5 Nm (40 in. lb)
7. Lift sunroof out.

Installation is the reverse of removal, noting the following

1. Adjust sunroof. See «SUNROOF PANEL HEIGHT, ADJUSTING»(/audi/a8/d3-2002-2005/remont/sun-rooft-topconvertible-top/#sunroof) .

Note. The following list refers to see scheme 9.

1. Sunroof headliner Glass panel removed Press gliding piece -2- out of guide on one side toward center of vehicle and lift out sunroof headliner.
2. Gliding piece Pull out of clips of sunroof headliner -1-.
3. Rain channel To remove, remove link guide. See «LINK GUIDE WITH CABLE, REMOVING AND INSTALLING»(/audi/a8/d3-2002-2005/remont/sun-rooft-topconvertible-top/#sunroof__link-guide-with-cable-removing-and) . Disconnect catch strap on rain channel.
4. Catch strap No replacement part available Push catch strap through eyelet at rain channel -3- from below and attach spring as shown. Attach spring at sunroof headliner -1-.

Wind deflector, removing and installing

1. Run sunroof completely toward rear.
2. Slide wind deflector -1- toward rear as indicated by arrow and push out of bracket.
3. Push wind deflector toward center of vehicle until stop -2- below sunroof opening is free.
4. Remove wind deflector and spring -3- from sunroof opening toward top.
5. When installing, make sure spring engages completely in frame.

1. Sunroof removed

1. Pull out seal -1- and remove adhesive residue.
2. Coat metal flange -2- on inside only using adhesive D 002 100.

Note. The panel seal must not be cut. Compensate for slight material excess by compressing the seal equally on both sides.

1. Remove panel seal -2- from sunroof panel -3-. see scheme 12
2. Push new panel seal into sunroof panel -3- starting at rear of panel edge in center.

Note. Coat edge of panel with soapy water to facilitate installation of seal.

Note. The sunroof must be closed to remove or install the sunroof motor (cable mechanism and sunroof motor must be in zero position).

Note. The following list refers to see scheme 13.

1. Cover For interior light Unclip in downward direction
2. Cover For sunroof motor Remove bolt -8- and pull out of clips toward front.
3. Torx(R) bolts (3x) 3 Nm (27 in. lb)
4. Harness connector At sunroof motor Disconnect harness connector.
5. Sliding roof motor
6. Harness connector For interior light Disconnect harness connector.
7. Harness connector For sunroof motor Disconnect harness connector.
8. Bolts (2x)

1. Motor is removed
2. Harness connectors connected

1. Move rotary control to "roof closed" position. Sunroof motor runs to zero position and switches off automatically.
2. Install motor in this position with sunroof closed.

Link guide with cable, removing and installing

1. Sunroof removed
2. Sunroof motor removed

1. Slide link guide evenly on both sides toward into guide rail.
2. Remove screws at guide profile.
3. Tightening torque: 2 Nm (18 in. lb)
4. Remove guide profile.
5. Slide link guide forward and out of guide rails.
6. Remove screws on left and right trim panels remove trim.
7. Rain channel -1- is attached to link guide -2- left and right with clips. Pry clips off before removing. see scheme 15
8. Raise rain channel -1- in link guide -2- and pull in direction of arrow.
9. On vehicles with glass panel, disconnect catch strap on rain channel.
10. Remove link guide and cable.

Installation is the reverse of removal, noting the following

Note. Install rain channel first before installing the link guides.

1. Position rain channels in frame in direction of arrow and push in toward rear.

Rear window regulator, removing and installing

1. Bring rear guide to center position and press off in direction of arrow.
2. When installing, insert rear guide into center position of link guide and lightly tap into place using hammer.

Link guide zero position, checking and adjusting

1. Sunroof motor removed

1. Slide link guide -2- from rear to front on both sides.
2. Using 4 mm hex wrench, secure link guide and rear guide -1- together with cable in zero position. NOTE: To eliminate play, leave the hex wrench inserted at the left and right and push the rear guide and the link guide to the rear until against stop.
3. Install sunroof motor in zero position.

Adjust height at front and rear as shown to avoid wind noise.

Scheme 3

1. Check height adjustment at center of front and rear edges of roof opening. vorn = front Front edge of roof panel should not be higher than the roof opening along any point. The rear edge of the roof panel should not be lower than the rear edge of the roof opening along any point. To adjust height, always close sunroof from the open position.

Note. If the car is equipped with a glass panel, the height of the panel must be measured from the top of the panel seal. In this case, the weather seal of the panel should not be higher at the front or lower at the rear than the roof at any point. -A- = front

1. To adjust front height, loosen screws -1- and -2-. Tightening torque: 4.5 Nm (40 in. lb)

Rear height adjustment

1. To adjust rear height, loosen screws -2- and -3-. Tightening torque: 4.5 Nm (40 in. lb)
2. Adjust height as shown in illustrations. See «SUNROOF PANEL HEIGHT, ADJUSTING»(/audi/a8/d3-2002-2005/remont/sun-rooft-topconvertible-top/#sunroof) .

Water drain hoses, cleaning

Note. For cleaning, a locally manufactured cleaning probe made from a speedometer inner cable approx. 2300 mm (7.5 ft) long is recommended. This is simultaneously rotated and passed all the way through the drain hoses.

Scheme 4

Front water drain hoses

The front water drain hoses are routed through the A-pillars and exit above the lower hinge of the front door (arrow). They can be cleaned from the sunroof opening.

Rear water drain hoses

The rear water drain hoses are routed through the D-pillars and exit behind the wheelhousing on the right side with battery vent house -1- (arrow). They can be cleaned from the lower end of the hose.
