Front/Center Console Control Head E461 , removing and installing Audi A8 D3 рестайлинг 2

Front/Center Console Control Head E461 , removing and installing

Removing

1. Open glove box.
2. Remove decorative panel with right switch strip --> «70 - INTERIOR TRIM»(/audi/a8/d3-2-2007-2010/remont/gauges-instrument-panels/#body-interior) .

Scheme 21

1. Remove bolts - arrows - (1 Nm) on rear side.
2. Remove Front/Center Console Control Head E461 - 2 - from panel - 1 -.

Installing

1. Install in reverse order.

General information

The components of the systems Radio R / Navigation System with CD Drive Control Module J401 / Media Player, Position 1 R118 / Digital Sound System Control Module J525 / Data Bus On Board Diagnostic Interface J533 are combined with one another in a "ring". This "ring" represents the optical MOST-Bus.

The connection to the other BUS systems in the vehicle are performed by the Data Bus On Board Diagnostic Interface J533.

The "central control module" is the Front Information Display Control Head Control Module J523. The transfer of signals representing the instrument cluster display occurs via the MOST-Bus to Data Bus On Board Diagnostic Interface J533 and from there via CAN-Bus (instrument cluster) to the instrument cluster.

Fault finding is performed via "Guided Fault Finding" using.

Additional information 971303New Data Bus Systems , 993303A8L Infotainment.

Information on optical MOST-Bus

In addition to the CAN-Bus systems, an optical data bus system has been implemented.

Data exchange of the systems Radio R / Digital Sound System Control Module J525 / CD Changer R41 / Navigation System with CD Drive Control Module J401 / Data Bus On Board Diagnostic Interface J533 occurs via the MOST-Bus.

A fiber optic cable is utilized as the "connecting cable".

Fiber optic cables are routed inside corrugated tubes for protection.

Ensure that harness connector end faces are not soiled.

If harness connectors are disconnected: Install Protective Cap For Cable Connector VAS 6223/9 - 1 -.

Fiber optic cables cannot be repaired, they must be replaced completely.

Observe the minimum bending radius of 25 mm when routing fiber optic cables. Fiber optic cables must not be pinched or bent.

Repairing fiber optic cables --> 97 - WIRING .

Additional information 971303New Data Bus Systems.

The individual Communication systems have extensive On Board Diagnostic (OBD) capabilities.

In the event that malfunctions occur in any Communication system, troubleshooting is performed using the in the "Guided Fault Finding" operating mode.

In addition to the CAN-Bus systems, a fiber optic data bus system has been implemented.

Data exchange of Radio R / Digital Sound System Control Module J525 / TV Tuner R78 / Media Player, Position 1 R118 / Media Player, Position 2 R119 / Telephone Transceiver R36 , Navigation System with CD Drive Control Module J401 / Chip Card Reader Control Module J676 / Data Bus On Board Diagnostic Interface J533 systems occurs via the fiber optic MOST-Bus.

A fiber optic cable is utilized as the "connecting cable".

Fiber optic cables are routed inside corrugated tubes for protection.

Ensure that harness connector end faces are not soiled.

If harness connectors are disconnected: Install Protective Cap For Cable Connector VAS6223/9 - 1 -.

Fiber optic cables cannot be repaired, they must be replaced completely.

Observe the minimum bending radius of 25 mm when routing fiber optic cables. Do not pinch or bend fiber optic cables.

Servicing fiber optic cables --> 97 - WIRING .

Additional information 971303New Data Bus Systems.

Scheme 22

1 - Multimedia Control Head E380

1. In center console, bottom
2. Connector assignment --> «Multimedia Control Head E380 , harness connectors»(/audi/a8/d3-2-2007-2010/remont/accessories-control-systems/#communication__multimedia-control-head-e380-harness)
3. Removing and installing --> «Multimedia Control Head E380 , removing and installing»(/audi/a8/d3-2-2007-2010/remont/accessories-control-systems/#communication__multimedia-control-head-e380-removing)

2 - Front Information Display Control Head J685

1. In center of instrument panel
2. Removing and installing --> «Front Information Display Control Head J685 , removing and installing»(/audi/a8/d3-2-2007-2010/remont/accessories-control-systems/#communication__front-information-display-control-head-j685)

3 - Front Information Display Control Head Control Module J523

1. Behind glove compartment
2. Connector assignment --> «Front Information Display Control Head Control Module J523 , harness connectors»(/audi/a8/d3-2-2007-2010/remont/accessories-control-systems/#communication__front-information-display-control-head-control)
3. Removing and installing --> «Front Information Display Control Head Control Module J523 , removing and installing»(/audi/a8/d3-2-2007-2010/remont/accessories-control-systems/#communication__front-information-display-control-head-control)

4 - Instrument Cluster Control Module J285 (instrument cluster)

1. In instrument panel
2. Removing and installing --> «90 - INSTRUMENTS»(/audi/a8/d3-2-2007-2010/remont/cruise-control-systems/#electrical-equipment)

5 - Radio R

1. Behind luggage compartment left side trim
2. Optional with Speech Input Control Module J507
3. Connector assignment Radio R --> «Radio R , harness connectors»(/audi/a8/d3-2-2007-2010/remont/accessories-control-systems/#communication__radio-r-harness-connectors)
4. Removing and installing Radio R --> «Radio R , removing and installing»(/audi/a8/d3-2-2007-2010/remont/accessories-control-systems/#communication__radio-r-removing-and-installing)

6 - Media Player, Position 1 R118 / Media Player, Position 2 R119

1. In glove compartment

CD Changer R41

1. Connector assignment --> «CD Changer R41 / CD-Player R89 / CD-ROM Drive R92 , connector assignments»(/audi/a8/d3-2-2007-2010/remont/accessories-control-systems/#communication__cd-changer-r41-cd-player-r89)
2. Removing and installing --> «CD Changer R41 , removing and installing»(/audi/a8/d3-2-2007-2010/remont/accessories-control-systems/#communication__cd-changer-r41-removing-and)

7 - Satellite Radio R146

1. Behind luggage compartment left side trim
2. Connector assignment --> «Satellite Radio R146 , connector assignments»(/audi/a8/d3-2-2007-2010/remont/accessories-control-systems/#communication__satellite-radio-r146-connector-assignments)
3. Removing and installing, up to model year 05 --> «Satellite Radio R146 - up to model year 05, removing and installing»(/audi/a8/d3-2-2007-2010/remont/accessories-control-systems/#communication__satellite-radio-r146-up-to)
4. Removing and installing, as of model year 06 --> «Satellite Radio R146 - as of model year 06, removing and installing»(/audi/a8/d3-2-2007-2010/remont/accessories-control-systems/#communication__satellite-radio-r146-as-of)

1. Removing and installing with RSE light --> «Satellite Radio R146 - RSE light, removing and installing»(/audi/a8/d3-2-2007-2010/remont/accessories-control-systems/#communication__satellite-radio-r146-rse-light)

8 - Navigation System with CD Drive Control Module J401

1. Behind luggage compartment left side trim
2. Connector assignment --> «Navigation System with CD Drive Control Module J401 , connector assignments»(/audi/a8/d3-2-2007-2010/remont/accessories-control-systems/#communication__navigation-system-with-cd-drive-control)
3. Removing and installing --> «Navigation System with CD Drive Control Module J401 , removing and installing»(/audi/a8/d3-2-2007-2010/remont/accessories-control-systems/#communication__navigation-system-with-cd-drive-control)

9 - Digital Sound System Control Module J525

1. Behind luggage compartment left side trim
2. BOSE connector assignment --> «Digital Sound System Control Module J525 - BOSE, connector assignments»(/audi/a8/d3-2-2007-2010/remont/accessories-control-systems/#communication__digital-sound-system-control-module-j525)
3. Removing and installing BOSE, up to model year 05 --> «Digital Sound System Control Module J525 - up to model year 05, removing and installing»(/audi/a8/d3-2-2007-2010/remont/accessories-control-systems/#communication__digital-sound-system-control-module-j525)
4. Removing and installing BOSE, as of model year 06 --> «Digital Sound System Control Module J525 BOSE - as of model year 06, removing and installing»(/audi/a8/d3-2-2007-2010/remont/accessories-control-systems/#communication__digital-sound-system-control-module-j525)

1. BOSE 6000 connector assignment --> «Digital Sound System Control Module J525 - BOSE 6000, connector assignments»(/audi/a8/d3-2-2007-2010/remont/accessories-control-systems/#communication__digital-sound-system-control-module-j525)
2. Removing and installing 6000 --> «Digital Sound System Control Module J525 BOSE 6000, removing and installing»(/audi/a8/d3-2-2007-2010/remont/accessories-control-systems/#communication__digital-sound-system-control-module-j525)

10 - Multifunction Steering Wheel

1. Removing and installing buttons --> «Multi-function buttons, removing and installing»(/audi/a8/d3-2-2007-2010/remont/accessories-control-systems/#communication__multi-function-buttons-removing-and-installing)

11 - Steering Column Electronic Systems Control Module J527

1. On steering column at steering column switches
2. Removing and installing --> «94 - LIGHTS, SWITCHES - EXTERIOR»(/audi/a8/d3-2-2007-2010/remont/cruise-control-systems/#electrical-equipment)

12 - Data Bus On Board Diagnostic Interface J533

1. Behind glove compartment
2. Connector assignment --> «Harness connectors on Data Bus On Board Diagnostic Interface J533»(/audi/a8/d3-2-2007-2010/remont/accessories-control-systems/#communication__harness-connectors-on-data-bus-on)
3. Removing and installing --> «Data Bus On Board Diagnostic Interface J533 , removing and installing»(/audi/a8/d3-2-2007-2010/remont/accessories-control-systems/#communication__data-bus-on-board-diagnostic-interface)

The Microphone Unit (in front roof module) R164 in the Front Interior Light W1 consists of a maximum of three microphones.

As of calendar week 22/04, only two microphones were installed.

For this, one microphone is connected directly to Telephone Transceiver R36. The other microphones are connected to the Digital Sound System Control Module J525.

Microphone Unit (in front roof module) R164

A - Driving direction

B - Front Interior Light W1

C - Microphone 1 (black/gray) to Digital Sound System Control Module J525 or Telephone Transceiver R36

D - Microphone 2 (white) to Digital Sound System Control Module J525 (left-side steering only) up to calendar week 21/04

E - Telephone Transceiver R36

F - Digital Sound System Control Module J525

G - Microphone 4 (red) to Digital Sound System Control Module J525 (right-side steering only) up to calendar week 21/04

H - Microphone 3 (blue/green) to Digital Sound System Control Module J525 or Telephone Transceiver R36

Microphone Unit (in front roof module) R164 , removing and installing --> Microphone Unit (in front roof module) R164 , removing and installing .

Standard

(...) applicable to vehicles with right-side steering

BOSE

(...) applicable to vehicles with right-side steering

Standard

(...) applicable to vehicles with right-side steering

BOSE

(...) applicable to vehicles with right-side steering

Radio system is a component of the MMI Infotainment system. A "radio unit" is no longer installed, rather the Radio R consists of a radio tuner with additional connector positions in the left rear luggage compartment.

Operation is performed via the Multimedia Control Head E380. Data transfer to the Digital Sound System Control Module J525 occurs via the optical MOST-Bus.

Signals of rear window antenna reach the Radio R via the Antenna Amplifier R24 with integrated Antenna Selection Control Module J515.

For regions with digital radio reception, a Digital Radio (DAB) R147 can also be installed.

Fault finding is performed via "Guided Fault Finding" using.

Repairs on antenna wires --> 97 - WIRING .

The individual Communication systems have extensive On Board Diagnostic (OBD) capabilities.

In the event that malfunctions occur in any Communication system, troubleshooting is performed using the in the "Guided Fault Finding" operating mode.
