Audi A8 D2 facelift (1999-2002) memory program switch Wiring diagrams

BACK- REST BLK WIRE BLK/BLU WIRE BLU WIRE BRN WIRE BRN/GRN WIRE CIRCUIT BREAKER 44 DRIVER'S SEAT ADJUSTMENT SWITCH FORE/ AFT FRONT HEIGHT FUSE FUSE PANEL (AT RIGHT FRONT FOOTWELL) GRN WIRE GRN/YEL WIRE HEAD- REST HOT AT ALL TIMES HOT W/ LOAD REDUCTION RELAY ENERGIZED MEMORY PROGRAM SWITCH REAR HEIGHT RED WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RIGHT FRONT FOOTWELL E-BOX AUXILIARY FUSE, RELAY PANEL VIO/BLK WIRE WHT WIRE WHT/BLK WIRE WHT/GRN WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE

A/C CONTROL HEAD ANTI-SLIP CONTROL SWITCH ASHTRAY LIGHT BLK WIRE BLK/BLU WIRE BLU WIRE BOARD COMPUTER FUNCTION SELECTOR SWITCH II BRN WIRE BRN/YEL WIRE CENTER INSTRUMENT PANEL VENT ILLUMINATION CIGARETTE LIGHTER COIN HOLDER ILLUMINATION COMBINATION PROCESSOR CUP HOLDER ILLUMINATION EMERGENCY FLASHER SWITCH FOG LIGHT SWITCH FUSE FUSE FUSE FUSE PANEL (AT RIGHT FRONT FOOT- WELL) GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/GRN WIRE GRY/RED WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE HEATED DRIVER'S SEAT ADJUSTER HEATED PASSENGER'S SEAT ADJUSTER HOT AT ALL TIMES HOT W/ LOAD REDUCTION RELAY ENERGIZED INSTRUMENT CLUSTER LEFT INSTRUMENT PANEL VENT ILLUMINATION LIGHT SWITCH MEMORY PROGRAM SWITCH MIRROR SELECTOR SWITCH OFF HEAD PARK PARKING AID BUTTON PASSENGER SIDE AIRBAG KEY SWITCH RADIO REAR FOG LIGHT SWITCH REAR WINDOW SHADE SWITCH RED/BLU WIRE RED/GRN WIRE RIGHT FRONT MAP/READING LIGHT AND LEFT FRONT READING LIGHT RIGHT INSTRUMENT PANEL VENT ILLUMINATION STORAGE TRAY ILLUMINATION TIPTRONIC SWITCH
