Audi A8 D2 facelift (1999-2002) left rear seat head rest adjustment switch wiring diagram
This page shows the only wiring diagram for the component.left rear seat head rest adjustment switch, which is found in the car Audi A8 D2 facelift (1999-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
left rear seat head rest adjustment switch wiring diagram (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
FUSE
FUSE PANEL (AT RIGHT FRONT FOOTWELL)
GRY WIRE
HOT AT ALL TIMES
HOT W/ LOAD REDUCTION RELAY ENERGIZED
LEFT REAR HEAD REST LOWER RELAY (ON LEFT REAR SEAT BACK)
LEFT REAR SEAT HEAD REST ADJUSTMENT MOTOR
LEFT REAR SEAT HEAD REST ADJUSTMENT SWITCH
REAR HEAD- REST ADJUSTMENT SWITCH
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
RELAY & FUSE PANEL
RIGHT REAR HEAD REST LOWER RELAY (ON RIGHT REAR SEAT BACK)
RIGHT REAR SEAT HEAD REST ADJUSTMENT MOTOR
RIGHT REAR SEAT HEAD REST ADJUSTMENT SWITCH
WHT WIRE
YEL WIRE
YEL/BLU WIRE
YEL/RED WIRE
Go to component -> Rear power headrest circuit -> LEFT REAR SEAT HEAD REST ADJUSTMENT SWITCH
