Audi A8 D2 facelift (1999-2002) blk Wiring diagrams

This page contains all the electrical diagrams for the component. blk, in which he is found in the car Audi A8 D2 facelift (1999-2002). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

blk wiring diagram (41 of 61)

BLK WIRE BRN WIRE CIRCUIT BREAKER DRIVER SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH DRIVER SEAT LUMBAR SUPPORT CURVATURE ADJUSTING MOTOR DRIVER SEAT LUMBAR SUPPORT HEIGHT ADJUSTING MOTOR GRY WIRE HOT AT ALL TIMES LUMBAR CURV- ATURE LUMBAR HEIGHT MEMORY SYSTEMS RED WIRE RIGHT FRONT FOOTWELL E-BOX AUXILIARY FUSE, RELAY PANEL VIO WIRE WHT WIRE

Go to component -> Driver"s lumbar circuit -> BLK WIRE

blk wiring diagram (42 of 61)

BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLU WIRE BLU/RED WIRE BRN WIRE BRN/BLU WIRE DRIVER'S SIDE MIRROR FOLD- AWAY FUSE FUSE PANEL (RIGHT FRONT FOOTWELL) GRN WIRE HOT W/ LOAD REDUCTION RELAY ENERGIZED MIRROR ADJUSTMENT SWITCH PASSENGER'S SIDE MIRROR RED WIRE RED/BLU WIRE

Go to component -> Fold-back mirrors circuit -> BLK WIRE

blk wiring diagram (43 of 61)

BLK WIRE BLK/VIO WIRE BLU WIRE BRN WIRE DRIVER'S BACKREST HEATING ELEMENT DRIVER'S HEATED SEAT ADJUSTER DRIVER'S SEAT BACKREST SIDE BOLSTER HEATER DRIVER'S SEAT HEATING ELEMENT DRIVER'S SEAT SIDE BOLSTER HEATER DRIVERS HEATED SEAT TEMPER- ATURE SENSOR FUSE FUSE PANEL (AT RIGHT FRONT FOOTWELL) GRY WIRE HEATED STEERING WHEEL CIRCUIT HOT AT ALL TIMES HOT W/ LOAD REDUCTION RELAY ENERGIZED NCA WIRE PASSENGER'S BACKREST HEATING ELEMENT PASSENGER'S HEATED SEAT ADJUSTER PASSENGER'S SEAT BACKREST SIDE BOLSTER HEATER PASSENGER'S SEAT SIDE BOLSTER HEATER PASSENGERS HEATED SEAT TEMPER- ATURE SENSOR PASSENGERS SEAT HEATING ELEMENT RED WIRE SOLID STATE WHT WIRE YEL WIRE

Go to component -> Front seat heater circuit -> BLK WIRE

blk wiring diagram (44 of 61)

BLK WIRE BLK/RED WIRE BLK/VIO WIRE BLK/YEL WIRE BRN WIRE DRIVER'S HEATED SEAT ADJUSTER FUSE FUSE PANEL (AT RIGHT FRONT FOOTWELL) HEATED STEERING WHEEL HOT W/ LOAD REDUCTION RELAY ENERGIZED MULTI-FUNCTION STEERING WHEEL CONTROL MODULE RED WIRE STEERING WHEEL CONTROL UNIT W/ MULTI-FUNCTION STEERING WHEEL W/O MULTI-FUNCTION STEERING WHEEL

Go to component -> Heated steering wheel circuit -> BLK WIRE

blk wiring diagram (45 of 61)

BACK- REST BLK WIRE BLU WIRE BLU/GRY WIRE BRN WIRE CIRCUIT BREAKER COMBUSTION AIR BLOWER CAPACITOR FORE/ AFT FRONT HEIGHT FRONT PASSENGER SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH GRN WIRE GRY WIRE HEAD- REST HOT AT ALL TIMES LUMBAR CURV- ATURE LUMBAR HEIGHT NCA WIRE PASSENGER BACKREST STOP SWITCH PASSENGER SEAT ADJUSTMENT SWITCH PASSENGER SEAT BACKREST ADJUSTING MOTOR PASSENGER SEAT FORE/AFT ADJUSTING MOTOR PASSENGER SEAT FRONT HEIGHT ADJUSTING MOTOR PASSENGER SEAT HEADREST ADJUSTING MOTOR PASSENGER SEAT LUMBAR SUPPORT CURVATURE ADJUSTING MOTOR PASSENGER SEAT LUMBAR SUPPORT HEIGHT ADJUSTING MOTOR PASSENGER SEAT REAR HEIGHT ADJUSTING MOTOR PASSENGERS BELT HEIGHT ADJUSTMENT SWITCH REAR HEIGHT RED WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RIGHT FRONT FOOTWELL E-BOX AUXILIARY FUSE, RELAY PANEL RIGHT SEAT BELT MOTOR VIO WIRE WHT WIRE YEL WIRE

Go to component -> Passenger seat circuit -> BLK WIRE

blk wiring diagram (46 of 61)

BLK WIRE BLK/BLU WIRE BLU WIRE BRN WIRE BRN/BLU WIRE BRN/RED WIRE C.B. 37 FUSE FUSE PANEL HOT AT ALL TIMES HOT IN RUN LEFT FRONT WINDOW SWITCH LEFT WINDOW MOTOR POWER SUNROOF CONTROL MODULE RED/BLK WIRE RED/WHT WIRE RELAY PANEL RIGHT FRONT FOOTWELL E-BOX AUXILIARY FUSE, VIO WIRE VIO/BLK (OR WHT/YEL) WIRE WHT WIRE WHT/YEL WIRE WINDOW MOTOR YEL WIRE

Go to component -> Power windows circuit (1 of 2) -> BLK WIRE

blk wiring diagram (47 of 61)

BLK WIRE BLU WIRE BRN WIRE FUSE FUSE 38 FUSE PANEL (AT RIGHT FRONT FOOTWELL) GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ LOAD REDUCTION RELAY ENERGIZED LEFT REAR BACKREST HEATING ELEMENT LEFT REAR HEATED SEAT REGULATING SWITCH LEFT REAR HEATED SEAT SWITCH LEFT REAR SEAT HEATING ELEMENT LEFT REAR SEAT TEMPER- ATURE SENSOR RED WIRE RELAY & FUSE PANEL (IN PLENUM CHAMBER E-BOX) RIGHT REAR BACKREST HEATING ELEMENT RIGHT REAR HEATED SEAT SWITCH RIGHT REAR RIGHT REAR SEAT TEMPER- ATURE SENSOR SEAT HEATING ELEMENT RIGHT REAR SEAT HEAT HEATED SEAT SWITCH SOLID STATE WHT WIRE YEL WIRE

Go to component -> Rear heated seats circuit -> BLK WIRE

blk wiring diagram (48 of 61)

BLK WIRE BLU WIRE BRN WIRE FUSE GRY WIRE HOT AT ALL TIMES LEFT REAR SEAT LUMBAR SUPPORT CURVATURE ADJUSTING MOTOR LEFT REAR SEAT LUMBAR SUPPORT HEIGHT ADJUSTING MOTOR LUMBAR CURV- ATURE LUMBAR HEIGHT REAR LEFT SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH REAR RIGHT SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH RED WIRE RELAY & FUSE PANEL RIGHT REAR SEAT LUMBAR SUPPORT CURVATURE ADJUSTING MOTOR RIGHT REAR SEAT LUMBAR SUPPORT HEIGHT ADJUSTING MOTOR VIO WIRE WHT WIRE

Go to component -> Rear lumbar circuit -> BLK WIRE

blk wiring diagram (49 of 61)

BLK WIRE BLU WIRE BRN WIRE FUSE FUSE PANEL (AT RIGHT FRONT FOOTWELL) GRY WIRE HOT AT ALL TIMES HOT W/ LOAD REDUCTION RELAY ENERGIZED LEFT REAR HEAD REST LOWER RELAY (ON LEFT REAR SEAT BACK) LEFT REAR SEAT HEAD REST ADJUSTMENT MOTOR LEFT REAR SEAT HEAD REST ADJUSTMENT SWITCH REAR HEAD- REST ADJUSTMENT SWITCH RED WIRE RED/BLU WIRE RED/WHT WIRE RELAY & FUSE PANEL RIGHT REAR HEAD REST LOWER RELAY (ON RIGHT REAR SEAT BACK) RIGHT REAR SEAT HEAD REST ADJUSTMENT MOTOR RIGHT REAR SEAT HEAD REST ADJUSTMENT SWITCH WHT WIRE YEL WIRE YEL/BLU WIRE YEL/RED WIRE

Go to component -> Rear power headrest circuit -> BLK WIRE

blk wiring diagram (50 of 61)

BLK WIRE BRN WIRE FUSE FUSE PANEL (RIGHT FRONT FOOTWELL) HOT AT ALL TIMES NCA WIRE POWER SUNROOF CONTROL MODULE (ABOVE INTERIOR LIGHT ASSEMBLY, FORWARD OF SUNROOF) RED WIRE SOLID STATE SUN-ROOF MOTOR SUNROOF REGULATOR WHT WIRE YEL WIRE

Go to component -> Sunroof circuit -> BLK WIRE
