Login procedure (scan tool function 11) Audi A8 D2

On Board Diagnostic (OBD) - Abs/edl/asr 3 illustrations ~129 words

Note. In order to carry out this function, the dealer code in the VAG1551/VAG1552 scan tool must have been entered. This is the dealer code for your dealership.

See Operating manual for VAG1551 scan tool, information about OBD

Indicated on display

Scheme 345: Login procedure (scan tool function 11)

Scheme 345: Login procedure (scan tool function 11)

Press buttons -1- and -1- to select "Login Procedure" function 11.

Indicated on display

Scheme 346

Scheme 346

Press the -Q- button to confirm input.

Indicated on display

Scheme 347

Scheme 347

Enter the relevant code for the vehicle and press -Q- button to confirm input.
The code for logging in for zeroing of steering angle sensor -G85- is 40168.
For the codes for logging in to code the ABS Control Module (w/EDL) -J104-, see «TEST SEQUENCE»(/audi/a8/d2-1994-1999/remont/warning-system/#on-board-diagnostic-obd-absedlasr) .
