Read measuring value block (scan tool function 08) Audi A8 D2

On Board Diagnostic (OBD) - Instrument Cluster & Headlights 4 illustrations ~140 words

Read measuring value block (scan tool function 08)

Indicated on display.

Scheme 44

Scheme 44: Read measuring value block (scan tool function 08)
Scheme 44: Read measuring value block (scan tool function 08)

Scheme 45

Scheme 45
Scheme 45

Scheme 46

Scheme 46
Scheme 46
  1. Press buttons 0 and 8. With function 08 "Read measuring value block" is selected. Indicated on display.
  2. Press Q button to confirm input. Indicated on display.
  3. Enter display group number from «TABLE OF SELECTABLE DISPLAY GROUP NUMBERS»(/audi/a8/d2-1994-1999/remont/gauges-instrument-panels/#on-board-diagnostic-obd-instrument-cluster-headlights) . Press Q button to confirm input.

The selected measuring value block is displayed in the standardized form.

Scheme 47

Scheme 47: Table of selectable display group numbers
Scheme 47: Table of selectable display group numbers

Note. The display always shows the actual values of the sensors. Because the values are filtered in the display of the instrument cluster, the actual values may be different. If the actual coolant temperature is between 80° C and 100° C, the instrument cluster will display 90° C. Other display groups are not available for the instrument cluster.
