Power Mirrors Audi A8 D2

Mirrors 24 illustrations ~1015 words

INSIDE DAY/NIGHT MIRROR

Adjust the inside mirror manually. When the ignition is switched on, the inside rear view mirror will "dim itself" electronically, depending on the intensity of outside light (for example, the light shining from the vehicle headlights behind you). When you move the selector lever into Reverse (R) or when you switch the interior lights on, the inside mirror will return to its original position (dimming effect off).

Automatic Day/Night Outside Mirrors

The outside mirrors are automatically dimmed together with the automatic inside day/night mirror. When the ignition is on, the mirrors dim automatically depending on the outside light, for example; light shining from the vehicle headlights behind you. When the interior lights are switched on, or when you shift into Reverse gear, the mirrors switch back to their original brightness (not dimmed).

Note. In order for the automatic mirror dimmer to work properly without any interference make sure the rear window shade is rolled up and/or the light shining on the inside mirror is not blocked by other objects.

With the ignition on, both outside mirrors can be adjusted using the rocker switch (C). (Scheme 1) Press the control in the appropriate direction to move the mirror surface. The adjuster control can be switched over to operate either the left or right-hand door mirrors by turning the knob.

The outside mirrors are automatically heated when the ignition is switched on.If the electrical adjustment of the mirror should not respond, it can be adjusted by hand by pushing on the edge of the mirror glass.

Scheme 1

Scheme 1: Automatic Day/Night Outside Mirrors

Folding Down Of The Outside Mirror (Passenger's Side)

When you move the selector lever into Reverse (R), the outside mirror on the passenger's side will tilt slightly downwards, provided you have switched to the right-hand outside mirror. This makes is possible to see the edge of the curb when parking your vehicle. The mirror will return to its original position as soon as you move the gearshift or selector lever out of Reverse (R) , or if you switch the remote control back to the driver's outside mirror.

Memory

The setting of the outside mirrors is automatically stored in the memory for the driver's seat adjustment together with the seat position. Adjust the mirrors as described then store this setting together with your seating position memory.

COMPONENT LOCATIONS

ComponentLocation
E-BoxIn Passenger Footwell. (Scheme 2)
Fuse PanelIn Passenger Side Footwell. (Scheme 3)
Automatic Dimming Interior Rear View MirrorMiddle Of Windshield
Control Module For Mirror Fold-Away Function (J351)Auxiliary Relay Panel, In Passenger Footwell E-Box, Relay Positions 10 & 15. (Scheme 5)
Mirror Memory Control Module (J267)Behind Driver's Side "B" Pillar Trim

COMPONENT LOCATIONS

Scheme 2

Scheme 2

Scheme 3

Scheme 3

Scheme 4

Scheme 4

Scheme 5

Scheme 5

PRELIMINARY INSPECTION

Verify customer complaint by operating suspected system. Visually inspect for obvious signs of mechanical and electrical damage. Inspect for blown fuses and damaged relays. Inspect for loose or corroded connections, damaged wiring harnesses and/or switches. Check for a broken or partially broken wire inside insulation, which could cause system malfunction but prove good in a continuity/voltage check with system disconnected. Ensure any aftermarket electronic equipment is properly installed. If fault is found, repair as necessary.

AUTOMATIC DIMMING INSIDE REAR VIEW MIRROR SYSTEM CHECK

  1. Hold photo sensor closed on front side (or tape).
  2. Illuminate photo sensor on back side using light source (flash light).
  3. The inside rear view mirror must dim within a short time.

Measurements At Switch For Mirror Adjustment (E168)

  1. Remove mirror adjustment switch and disconnect harness connector.
  2. Connect adapter harness (VAG 1598/13) to Test Box (VAG 1598), mirror adjustment switch harness connector and mirror adjustment switch.
  3. Check for continuity. (Scheme 6) If adapter harness (VAG 1598/13) to Test Box (VAG 1598) are not available, pin-outs can be checked directly at switch. See «WIRING DIAGRAMS»(/audi/a8/d2-1994-1999/remont/mirrors/#power-mirrors).
  4. See «CORRECTIVE MEASURES»(/audi/a8/d2-1994-1999/remont/mirrors/#power-mirrors).

Scheme 6

Scheme 6

Measurements At Mirror Memory Control Module (J267)

  1. Remove mirror memory control module harness connector.
  2. Connect adapter harness (VAG 1598/4) to Test box (VAG 1598), mirror memory control module harness connector and mirror memory control module.
  3. Check for continuity. (Scheme 7) If adapter harness (VAG 1598/4) to Test Box (VAG 1598) are not available, pin-outs can be checked directly at control module. See «WIRING DIAGRAMS»(/audi/a8/d2-1994-1999/remont/mirrors/#power-mirrors).
  4. See «CORRECTIVE MEASURES»(/audi/a8/d2-1994-1999/remont/mirrors/#power-mirrors).

Scheme 7

Scheme 7

Scheme 8

Scheme 8: CORRECTIVE MEASURES

Removal

  1. Unclip cable tunnel cover.
  2. Remove connector and mark.
  3. Press inside rear view mirror off the retaining plate by pushing down at a angle clamping springs in base of mirror. (Scheme 9)

Scheme 9

Scheme 9

Installation

Note. Cable channel should not be used for turning

When installing mirror, rotate mirror 60-90 degrees, install onto installation point and turn in direction of arrows until locking springs engage. (Scheme 10)

Scheme 10

Scheme 10: Installation

ELECTRIC MIRROR ADJUSTING UNIT

Note. On vehicles equipped with mirror memory, electric adjusting unit cannot be replaced individually.

Removal & Installation

  1. Switch ignition off.
  2. Remove mirror lens. See «MIRROR LENS»(/audi/a8/d2-1994-1999/remont/mirrors/#power-mirrors).
  3. Remove screws. (Scheme 11)
  4. Remove electric adjusting unit.
  5. Remove cover from electric adjusting unit. (Scheme 12)
  6. Cut electrical wiring close to soldered connections. (Scheme 13)

Scheme 11

Scheme 11

Scheme 12

Scheme 12

Scheme 13

Scheme 13

Attach electrical wires to plug housing included with replacement parts. (Scheme 14)

  1. Harness connector wire 1 (Red).
  2. Harness connector wire 2 (Brown/White).
  3. Harness connector wire 3 (White). NOTE: Arrow points to chamfer on harness connector housing.To install, reverse removal procedures, See «TORQUE SPECIFICATIONS»(/audi/a8/d2-1994-1999/remont/mirrors/#power-mirrors__torque-specifications) .

Scheme 14

Scheme 14

HOUSING FOR OUTSIDE REAR VIEW MIRROR

  1. Remove mirror lens. See «MIRROR LENS»(/audi/a8/d2-1994-1999/remont/mirrors/#power-mirrors).
  2. Remove 2 screws on driver's side and one on passenger's side. (Scheme 15)
  3. Push catches back and remove cover.
  4. Remove 3 screws on driver's side and 2 on passenger's side.
  5. Lift housing up and out.

Scheme 15

Scheme 15
  1. Unglue mirror housing.
  2. Using Pry Lever (82-200), carefully pry out lens at button first, then at top. (Scheme 16)
  3. Disconnect harness connectors.

Scheme 16

Scheme 16
CAUTIONSafety gloves must be worn when installing the mirror lens.
  1. Attach harness connectors.
  2. Friction finger on mirror lens must also be inserted into friction spring in housing during installation. (Scheme 17)
  3. Press on mirror lens.

Scheme 17

Scheme 17
  1. Unclip trim from door component carrier. (Scheme 18)
  2. Remove seal.
  3. Run door window to lowest position.
  4. Remove bolt together with washer. (Scheme 19)
  5. Lift out rear view mirror behind opening seal and the window guide.
  6. Lift off seal simultaneously.
  7. Disconnect harness connectors.
  8. To install, reverse removal procedures. See «TORQUE SPECIFICATIONS»(/audi/a8/d2-1994-1999/remont/mirrors/#power-mirrors__torque-specifications). NOTE: Align rear view mirror to window guide when installing.

Scheme 18

Scheme 18

Scheme 19

Scheme 19

TORQUE SPECIFICATIONS

ApplicationINCH Lbs. (N.m)
Electric Mirror Adjusting Unit Screws9 (1)
Outside Rear View Mirror Bolts71 (8)

TORQUE SPECIFICATIONS

Scheme 20

Scheme 20: WIRING DIAGRAMS

Scheme 21

Scheme 21

Scheme 22

Scheme 22

Scheme 23

Scheme 23

Scheme 24

Scheme 24
