Fuses & Circuit Breakers Audi A8 D2

Fuses & Circuit Breakers 14 illustrations ~792 words

IDENTIFICATION

CAUTIONBefore disconnecting battery, get radio code from customer. When battery is disconnected, vehicle computer and memory systems may lose memory data. Driveability problems may exist until computer systems have completed a relearn cycle.

Note. After reconnecting the battery be sure to reactivate the radio, clock, power windows and engine according to instructions in the Owner's Manual.

ENGINE IDENTIFICATION

For A8 models with the 3.7L V8 or 4.2L V8 engine and Engine Codes AEW and ABZ the engine code letters and serial number are stamped on the left side of the cylinder block (arrow), directly above the power steering pump. (Scheme 1) In addition, an adhesive label with engine code letters and serial number is affixed to the toothed belt guard. The engine code letters are also listed on the vehicle data plate.

Scheme 1

Scheme 1: ENGINE IDENTIFICATION
Scheme 1: ENGINE IDENTIFICATION

FUSE & RELAY PANELS IDENTIFICATION

  1. «PASSENGER COMPARTMENT FUSE PANEL»(/audi/a8/d2-1994-1999/remont/fuses-circuit-breakers/#fuses-circuit-breakers) .
  2. «CENTRAL ELECTRIC PANEL»(/audi/a8/d2-1994-1999/remont/fuses-circuit-breakers/#fuses-circuit-breakers__central-electric-panel) .
  3. «PASSENGERS FOOTWELL FIFTEEN FOLD RELAY PANEL»(/audi/a8/d2-1994-1999/remont/fuses-circuit-breakers/#fuses-circuit-breakers__passengers-footwell-fifteen-fold-relay-panel) .
  4. «PASSENGERS FOOTWELL AUXILIARY ELEVEN FOLD FUSE & RELAY PANEL»(/audi/a8/d2-1994-1999/remont/fuses-circuit-breakers/#fuses-circuit-breakers__passengers-footwell-auxiliary-eleven-fold-fuse) .
  5. «DRIVERS FOOTWELL AUXILIARY TEN FOLD RELAY PANEL»(/audi/a8/d2-1994-1999/remont/fuses-circuit-breakers/#fuses-circuit-breakers__drivers-footwell-auxiliary-ten-fold-relay) .
  6. «LUGGAGE BOOT RELAY & FUSE CARRIER»(/audi/a8/d2-1994-1999/remont/fuses-circuit-breakers/#fuses-circuit-breakers__luggage-boot-relay-fuse-carrier) .
  7. «PLENUM E-BOX RELAY & FUSE PANEL»(/audi/a8/d2-1994-1999/remont/fuses-circuit-breakers/#fuses-circuit-breakers__plenum-e-box-relay-fuse-panel) .
  8. «COOLANT FAN THIRD SPEED RELAY»(/audi/a8/d2-1994-1999/remont/fuses-circuit-breakers/#fuses-circuit-breakers__coolant-fan-third-speed-relay) .

Fuse Color & Amp Rating Identification

Fuse ColorAmp Rating
Black1
Lilac3
Light Brown (Beige)5
Brown7.5
Red10
Blue15
Yellow20
Transparent (White)25
Green30
Orange40

FUSE COLOR/AMP RATING

Fuse Panel Location

Passenger compartment fuse panel is located behind cover in passenger footwell. (Scheme 2)

Scheme 2

Scheme 2: Fuse Panel Location
Scheme 2: Fuse Panel Location

Fuse Panel Identification

For fuse position within panel (Scheme 3) For fuse position number, amp rating and description of circuits protected, see FUSE IDENTIFICATION (FUSE PANEL) table.

Scheme 3

Scheme 3: Fuse Panel Identification
Scheme 3: Fuse Panel Identification
Fuse No.Amp RatingCircuits Protected
Fuse Carrier Station No. 1 (Black)
15Lamp Control Module, Left Parking Light, Left Front Side Marker Light
25Lamp Control Module, Right Parking Light, Right Front Side Marker Light, Tail Lights, Licence Plate Lights
315Lamp Control Module
415Lamp Control Module
510Left High Beam Headlight
610Fog Light Relay, High Beam Indicator Light, Right High Beam Headlight
715Emergency Flasher Switch
815Duel Horns
95Instrument Cluster, Solar Cell Separation Relay (1)
95Data Link Connector, Selector Lever Light Relay
1025Windshield Wiper Motor (1)
1025Windshield Wiper Washer Switch, Windshield Wiper Washer Intermittent Relay
Fuse Carrier Station No. 2 (Red)
110Outside Mirrors
2N/ANot Used
35A/C Control Head, Cigarette Lighter, Fog Light Relay, Glove Compartment Light, Instrument Cluster, Instrument Cluster Combination Processor, Tail Lights, Ashtray Light, Rear Ashtray Light, Multi-Function Transmission Range Switch
35Selector Lever Light Relay Protection Diode, Interior Lights System, Light Switch (2)
45First, Second and Third Speed Coolant Fan Control Relays
45Air Quality Sensor (2)
515Fog Light Switch, Rear Fog Light Switch
630Rear Window Defogger Switch
7N/ANot Used
810Emergency Flasher Switch
910Brake Light Switch, Vacuum Pump Valve, Transmission Control Module
105Washer Nozzle Heaters
Fuse Carrier Station No. 3 (Yellow)
115Data Link Connector, Instrument Cluster, Lamp Control Module, Steering Wheel Control Module, Radio, Headlight Beam Adjustment Motors, Headlight Beam Adjustment Control Module, Air Bag Malfunction Indicator Lamp, ABS Malfunction Indicator Lamp, Traction Control Indicator Lamp
210Telephone Transceiver (2)
315Cigarette Lighter
45Instrument Cluster Combination Processor
515A/C Control Head, Interior Temperature Sensor, Instrument Cluster, Solar Cell Separation Relay, Steering Wheel Control Module
610Multi-Function Transmission Range Switch, Shift Lock Solenoid
715Coolant Pump, Heat regulating Valves (1)
815Coolant Pump (1)
910Steering Wheel Control Module
10N/ANot Used
Fuse Carrier Station No. 4 (Blue)
115Fuel Pump
2N/ANot Used
320HO2 Sensors Before TWC, MAF Sensor
415HO2 Sensors After TWC
5N/ANot Used
6N/ANot Used
7N/ANot Used
8N/ANot Used
95ABS Control Module
1010Brake Light Switch (Quattro) (1)
1010ABS Control Module, Anti-Slip Control Switch (W/FWD)
Fuse Carrier Station No. 5 (Brown)
110Rear Fog Light Switch, Front Interior Light, Rear Reading Lights, Central Locking/Alarm System/Interior Light Delay Control Module
210Right & Left Power Windows Control Module, Mirror Adjustment Switch, Mirror Fold-Away Function Control Module, Memory Program Switch, Rear Headrest Adjustment Switch, Right & Left "B" Pillar Micro Switches, Front Heated Seat Switches
310Luggage Compartment Release Switch, Right & Left Make Up Mirror Lights, Entry/Floor Light Relay, Interior Monitoring Sensors Control Module, Driver's Side Interior Lock Switch, Mirror Memory Control Module, Memory Program Switch, Rear Fog Light Switch
410Central Locking/Alarm System/Interior Lights Delay Control Module, Rear Window Shade Switch, Automatic Dimmer Inside Mirror
515Central Locking/Alarm System/Interior Lights Delay Control Module, Interior Monitoring Sensors Control Module, Driver's Side Interior Lock Switch
620Power Sunroof Control Module
715Window Lockout Switch
7 (2)15Right & Left Heated Door Lock Control Module
810Memory Program Switch, Mirror Memory Control Module (1)
920Steering Column/Belt Height Control Module, Steering Column Adjustment Switch
920Steering Column Adjustment Control Module (2)
1020Front Heated Seat Switches, Rear Window Shade Control Module
(1) Model year 1997 only. (2) Model years 1998 and 1999 only.
(1)Model year 1997 only.
(2)Model years 1998 and 1999 only.

FUSE IDENTIFICATION (FUSE PANEL)

RELAY PANELS

Note. Relay carriers, (panels) may also have fuse positions on them.

CENTRAL ELECTRIC PANEL

Central Electrical Panel is located in the passengers footwell. (Scheme 4) For relay positions within panel (Scheme 5) For relay number, position number and circuits protected, see Relay Identification.

Scheme 4

Scheme 4: CENTRAL ELECTRIC PANEL
Scheme 4: CENTRAL ELECTRIC PANEL

Scheme 5

Scheme 5
Scheme 5

Relay Identification

PositionRelay No.Circuit Protected
1J59Load Reduction Relay
2J4Duel Horn Relay
3J39Headlight Washer System Relay
4J207Staring Interlock Relay
5J31Wiper/Washer Intermittent Relay
6J17Fuel Pump Relay

CENTRAL ELECTRIC PANEL

PASSENGERS FOOTWELL FIFTEEN FOLD RELAY PANEL

Relay panel is located in the passengers footwell. (Scheme 4) For relay positions within panel (Scheme 6) For relay number, position number and circuits protected, see FIFTEEN FOLD RELAY PANEL table.

Scheme 6

Scheme 6: PASSENGERS FOOTWELL FIFTEEN FOLD RELAY PANEL
Scheme 6: PASSENGERS FOOTWELL FIFTEEN FOLD RELAY PANEL
PositionRelay No.Circuit Protected
1J123Front Lamp Control Module
2N/ANot Used
3N/ANot Used
4J31Wiper/Washer Intermittent Relay
5J348Relay For Entry & Floor Light
6J123Front Lamp Control Module
7J309Soar Separation Relay
8J89Daytime Running Lights Change-Over Relay Staring Interlock Relay
9J31Wiper/Washer Intermittent Relay
10J351Control Module For Mirror Fold-Away Function
11J2Emergency Flasher Relay
12J236Servotronic Control Module
13J307Selector Lever Light Relay
14J44A/C Clutch Relay
15J351Control Module For Mirror Fold-Away Function

FIFTEEN FOLD RELAY PANEL

PASSENGERS FOOTWELL AUXILIARY ELEVEN FOLD FUSE & RELAY PANEL

Relay Panel is located in the passengers footwell. (Scheme 4) For relay positions within panel (Scheme 7) For relay number, position number and circuits protected, see RELAY IDENTIFICATION. For fuse number, position number, amperage and circuits protected, see FUSE IDENTIFICATION.

Scheme 7

Scheme 7: PASSENGERS FOOTWELL AUXILIARY ELEVEN FOLD FUSE & RELAY PANEL
Scheme 7: PASSENGERS FOOTWELL AUXILIARY ELEVEN FOLD FUSE & RELAY PANEL

Relay Identification (Auxiliary Eleven Fold Panel)

PositionRelay No.Circuit Protected
1J5Fog Light Relay
2N/ANot Used
5J90Daytime Running Lights Switch-On Relay
6N/ANot Used
8N/ANot Used
9N/ANot Used
10N/ANot Used
11N/ANot Used

AUXILIARY ELEVEN FOLD FUSE & RELAY PANEL

Fuse Identification (Auxiliary Eleven Fold Panel)

Position No.Fuse No.Amp RatingCircuit Protected
3S8030Power Seat Circuit Breaker
4S4430Power Seat (Memory) Circuit Breaker
7S2540Blower Fan

FUSE IDENTIFICATION (AUXILIARY ELEVEN FOLD FUSE & RELAY PANEL)

DRIVERS FOOTWELL AUXILIARY TEN FOLD RELAY PANEL

Relay panel is located under drivers footwell. Relay panel is behind driver's storage shelf. For relay panel location (Scheme 8) To identify Auxiliary Ten Fold Relay Panel (Scheme 9) For relay and fuse positions within panel (Scheme 10) For relay number, position number and circuits protected, see RELAY IDENTIFICATION. For fuse number, position number, amperage and circuits protected, see FUSE IDENTIFICATION

Scheme 8

Scheme 8: DRIVERS FOOTWELL AUXILIARY TEN FOLD RELAY PANEL
Scheme 8: DRIVERS FOOTWELL AUXILIARY TEN FOLD RELAY PANEL

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Relay Identification (Auxiliary Ten Fold Relay Panel)

PositionRelay No.Circuit Protected
1J59Load Reduction Relay
2J4Duel Horn Relay
3J26Coolant Fan Control Relay (First Speed)
3 (1)J453Control Module For Multi-Function Steering Wheel
4J101Second Speed Coolant Fan Control Relay
4 (1)J453Control Module For Multi-Function Steering Wheel
5N/ANot Used
6J1Turn Signal Relay
9N/ANot Used
10N/ANot Used
(1) Model years 1998 and 1999 only.
(1)Model years 1998 and 1999 only.

RELAY IDENTIFICATION (AUXILIARY TEN FOLD RELAY PANEL)

Fuse Identification (Auxiliary Ten Fold Relay Panel)

Position No.Fuse No.Amp RatingCircuit Protected
7S4330Power Window Circuit Breaker (Front)
8S3730Power Window Circuit Breaker (Rear)

FUSE IDENTIFICATION (AUXILIARY TEN FOLD RELAY PANEL)

LUGGAGE BOOT RELAY & FUSE CARRIER

Note. No relays where located for luggage boot relay and fuse carrier. Only fuses are installed.

Luggage boot relay and fuse carrier is located inside luggage boot, right side panel. (Scheme 11) For relay and fuse positions within panel (Scheme 12) For relay number, position number and circuits protected. See LUGGAGE BOOT RELAY & FUSE CARRIER table. For fuse color/amp identification. See FUSE COLOR & AMP RATING IDENTIFICATION table.

Scheme 11

Scheme 11: LUGGAGE BOOT RELAY & FUSE CARRIER
Scheme 11: LUGGAGE BOOT RELAY & FUSE CARRIER

Scheme 12

Scheme 12
Scheme 12

Fuse Identification (Luggage Boot Relay & Fuse Carrier)

Fuse & Relay PositionFuse NumberAmp RatingCircuits Protected
1TV2 ConnectorN/ATerminal 30 B+ Distribution To Luggage Boot Relay & Fuse Carrier
2S5350ABS Control Module
2S12350ABS Control Module, Quattro (1)
3S3820Heated Seats, Right & Left Rear Seat Regulating Switch
6 (1) , (2)S9220Radio, Amplifier, Right & Left Rear Woofers, Power Antenna
7S9220Radio
7 (1)S5425ABS Valve
15S4520Power Seat Fuse
(1) Model years 1998 and 1999 only. (2) Manufacturer also shows Fuse No. 119 15 amp (Telephone) for 1998 and 1999 location No.6. (3) Model year 1997 only.
(1)Model years 1998 and 1999 only.
(2)Manufacturer also shows Fuse No. 119 15 amp (Telephone) for 1998 and 1999 location No.6.
(3)Model year 1997 only.

LUGGAGE BOOT RELAY & FUSE CARRIER

PLENUM E-BOX RELAY & FUSE PANEL

Plenum E-Box Relay and Fuse Panel is located to the left of ECM in plenum. (Scheme 13) For fuse and relay positions within relay and fuse panel (Scheme 14) For relay number, position number and circuits protected, see RELAY IDENTIFICATION. For fuse position number, fuse number, amperage rating and circuits protected, see FUSE IDENTIFICATION.

Scheme 13

Scheme 13: PLENUM E-BOX RELAY & FUSE PANEL
Scheme 13: PLENUM E-BOX RELAY & FUSE PANEL

Relay Identification (Plenum E-Box)

PositionRelay No.Circuit Protected
1N/ANot Used
3N/ANot Used
4J271Engine Control Module, Power Supply Relay
5N/ANot Used
8N/ANot Used

RELAY IDENTIFICATION (PLENUM E-BOX RELAY & FUSE PANEL)

Fuse Identification (Plenum E-Box)

Position No.Fuse No.Amp RatingCircuit Protected
2bS11315Transmission Control Module
6S11715EVAP Canister Purge Regulator Valve, Intake Change Over Valve, Fuel Injector Air Control Valve & EVAP Leak Detection Pump
7S11615ECM & Fuel Injectors
9S11520ECM & Ignition Coil Terminal No. 15

FUSE IDENTIFICATION (PLENUM E-BOX RELAY & FUSE PANEL)

COOLANT FAN THIRD SPEED RELAY

Coolant fan third speed relay is located next to drivers footwell auxiliary ten fold relay panel. see scheme 15

Scheme 14

Scheme 14: COOLANT FAN THIRD SPEED RELAY
Scheme 14: COOLANT FAN THIRD SPEED RELAY
