Audi A6 C8 (2018-2023) brn Wiring diagrams
This page contains all the electrical diagrams for the component. brn, in which he is found in the car Audi A6 C8 (2018-2023). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram brn (101 of 196)
BLK WIRE
BRN WIRE
COUPLING POINT IN RIGHT REAR SEAT
COUPLING POINT IN THE RIGHT REAR DOOR
DUAL SEAT BELT LATCH
FUEL DELIVERY UNIT
FUEL DELIVERY UNIT SHIELD
FUEL PUMP CONTROL MODULE
LEFT REAR SEAT BELT TENSIONER CONTROL MODULE
LEFT TAIL LAMP
NCA WIRE
PASSENGER SIDE REAR DOOR CLOSING AID MOTOR
PASSENGER SIDE REAR DOOR CONTROL MODULE
PASSENGER SIDE REAR DOOR LOCK UNIT
PASSENGER SIDE REAR EXTERIOR DOOR HANDLE ILLUMINATION LAMP
PASSENGER SIDE REAR SIDE SILL PANEL STRIP AMBIENT LIGHTING LAMP
PASSENGER SIDE SECOND ROW SEAT BELT
REAR A/C DISPLAY CONTROL HEAD
REAR LID CONTROL MODULE
REAR WINDOW DEFOGGER
RIGHT LUGGAGE COMPARTMENT LAMP
RIGHT REAR AIR VENT ILLUMINATION BULB
RIGHT REAR BACKREST HEATING ELEMENT
RIGHT REAR BENCH SEAT HEATING ELEMENT
RIGHT REAR BRAKE PAD WEAR SENSOR
RIGHT REAR DOOR AMBIENT LIGHTING BULB 1
RIGHT REAR DOOR CONTOUR ILLUMINATION LAMP
RIGHT REAR DOOR CONTOUR ILLUMINATION LAMP 2
RIGHT REAR DOOR COUPLING POINT
RIGHT REAR EXTERIOR DOOR HANDLE TOUCH SENSOR
RIGHT REAR SEAT BELT TENSIONER CONTROL MODULE
RIGHT REAR SEAT COUPLING STATION
TV TUNER
W/ AMBIENT LIGHTING
W/ AUXILIARY LAMPS
Go to component: -> Ground distribution circuit (10 of 10) -> BRN WIRE
Wiring diagram brn (102 of 196)
ABS CONTROL MODULE
AUTOMATIC TRANSMISSION COUPLING POINT
BRN WIRE
CLOSE RANGE COMMUNICATION CONTROL MODULE
COUPLING POINT IN THE LEFT FRONT DOOR
COUPLING POINT ON ROOF
DIAGNOSTIC CONNECTION
DRIVER ASSISTANCE SYSTEMS CONTROL MODULE
DRIVER ASSISTANCE SYSTEMS FRONT CAMERA
DRIVER DOOR CLOSING AID MOTOR
DRIVER DOOR CONTROL MODULE
DRIVER DOOR LOCK UNIT
DRIVER EXTERIOR DOOR HANDLE TOUCH SENSOR
DRIVER SIDE DOOR AMBIENT LIGHTING LAMP
DRIVER SIDE EXTERIOR DOOR HANDLE ILLUMINATION LAMP
DRIVER VANITY MIRROR LAMP CONTACT SWITCH
HOOD CONTACT SWITCH 2
INTERIOR REAR VIEW MIRROR
LEFT DOOR STORAGE COMPARTMENT ILLUMINATION LAMP
LEFT FRONT DOOR CONTOUR ILLUMINATION LAMP
LEFT FRONT DOOR COUPLING POINT
NIGHT VISION SYSTEM CONTROL MODULE
RAIN/LIGHT RECOGNITION SENSOR
RELAY & FUSE CARRIER 2
TERMINAL 15 POWER SUPPLY RELAY
TRANSMISSION CONTROL MODULE
TRANSMISSION ELECTRIC PUMP 2
TRANSMISSION ELECTRIC PUMP 3
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
W/ AMBIENT LIGHTING
W/ AUXILIARY LAMPS
Go to component: -> Ground distribution circuit (1 of 10) -> BRN WIRE
Wiring diagram brn (103 of 196)
2.0L
3.0L TURBO, 2.9L
3.0L TURBO, 2.9L TURBO
ADAPTIVE CRUISE CONTROL MODULE
AFTER-RUN COOLANT PUMP
ANTENNA AMPLIFIER
BLK WIRE
BOTTOM COUPLING POINT ON RIGHT A-PILLAR
BRAKE BOOSTER CONTROL MODULE
BRN WIRE
CHARGE AIR COOLING PUMP
COOLANT RECIRCULATION PUMP
ENGINE HOOD CONTACT SWITCH
ENGINE/MOTOR CONTROL MODULE
HIGH PRESSURE SENSOR
HIGH TONE HORN
HIGH-MOUNTED BRAKE LAMP BULB
IGNITION COIL 1 W/ POWER OUTPUT STAGE
IGNITION COIL 2 W/ POWER OUTPUT STAGE
IGNITION COIL 3 W/ POWER OUTPUT STAGE
IGNITION COIL 4 W/ POWER OUTPUT STAGE
IGNITION COIL 5 W/ POWER OUTPUT STAGE
IGNITION COIL 6 W/ POWER OUTPUT STAGE
INFORMATION ELECTRONICS CONTROL MODULE 1
LASER DISTANCE REGULATION CONTROL MODULE
LEFT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT
LEFT FRONT HEADLAMP
LEFT FRONT OBJECT DETECTION RADAR SENSOR CONTROL MODULE
LOW TONE HORN
RIGHT FRONT HEADLAMP
RIGHT FRONT OBJECT DETECTION RADAR SENSOR CONTROL MODULE
SUPPRESSOR
TERMINAL 30 WIRE JUNCTION SUPPRESSOR
Go to component: -> Ground distribution circuit (2 of 10) -> BRN WIRE
Wiring diagram brn (104 of 196)
2.0L TURBO
ACTIVE STEERING CONTROL MODULE
ALL WHEEL DRIVE CLUTCH ACTUATOR 2
ALL- WHEEL DRIVE CONTROL MODULE
AUTOMATIC TRANSMISSION COUPLING POINT
AUXILIARY HEATER HEATING ELEMENT
BLK WIRE
BRN WIRE
CELLULAR TELEPHONE AMPLIFIER
COMFORT SYSTEM CENTRAL CONTROL MODULE
COOLANT RECIRCULATION PUMP
DIFFERENTIAL LOCK CONTROL MODULE
EMERGENCY CALL MODULE, COMMUNICATION UNIT CONTROL MODULE
FRESH AIR BLOWER CONTROL MODULE
FRONT PASSENGER AIR BAG UNIT
GLOVE COMPARTMENT LAMP SWITCH
GLOVE COMPARTMENT WIRING HARNESS COUPLING POINT
HIGH HEAT OUTPUT RELAY
LOW HEAT OUTPUT RELAY
POWER STEERING CONTROL MODULE
RADIATOR FAN CONTROL MODULE
RADIATOR FAN CONTROL MODULE 2
REAR SUNROOF CONTROL MODULE
REAR VIEW CAMERA SYSTEM MODULE SHIELD
REAR WINDOW DEFOGGER RELAY
RECIRCULATION PUMP
RIGHT FRONT FOOTWELL ILLUMINATION BULB
VALET PARKING LOCK BUTTON
Go to component: -> Ground distribution circuit (3 of 10) -> BRN WIRE
Wiring diagram brn (105 of 196)
2.9L
A/C SYSTEM PARTICULATE MATTER CONCENTRATION SENSOR
BRN WIRE
ELECTRONIC STEERING COLUMN LOCK CONTROL MODULE
EXHAUST DOOR CONTROL UNIT
FRAGRANCE DIFFUSER SYSTEM CONTROL MODULE
GARAGE DOOR OPENER CONTROL MODULE
INFORMATION ELECTRONICS CONTROL MODULE 1
INSTRUMENT CLUSTER CONTROL MODULE
INSTRUMENT PANEL AMBIENT LIGHTING LAMP 1
INSTRUMENT PANEL AMBIENT LIGHTING LAMP 2
INSTRUMENT PANEL AMBIENT LIGHTING LAMP 3
INSTRUMENT PANEL CONTOUR ILLUMINATION LAMP 1
IONIZER CONTROL MODULE
LANE CHANGE ASSISTANCE CONTROL MODULE
LEFT CENTER VENT POSITION SENSOR
LEFT FRONT FOOTWELL ILLUMINATION BULB
LIGHT SWITCH
POWER ADJUSTABLE STEERING COLUMN CONTROL MODULE
REAR AXLE STEERING CONTROL MODULE
RIGHT TAIL LAMP
STEERING COLUMN ELECTRONICS CONTROL MODULE
TO CENTER COUPLING POINT ON INSTRUMENT PANEL (DIAGRAM 5 OF 10)
W/ AMBIENT LIGHTING
W/ AUXILIARY LAMPS
WINDSHIELD DEFOGGER CONTROL MODULE
WINDSHIELD PROJECTION HEAD UP DISPLAY CONTROL MODULE
Go to component: -> Ground distribution circuit (4 of 10) -> BRN WIRE
Wiring diagram brn (106 of 196)
AUXILIARY DISPLAY CONTROL HEAD 1
BRN WIRE
CENTER COUPLING POINT ON INSTRUMENT PANEL
CIGARETTE LIGHTER
CLOSE RANGE COMMUNICATION CONTROL MODULE 2
COUPLING POINT ON LEFT REAR BUMPER
DATA BUS ON BOARD DIAGNOSTIC INTERFACE
DIGITAL SOUND SYSTEM CONTROL MODULE
DRIVETRAIN CONTROL MODULE
EXHAUST DOOR CONTROL UNIT 2
FRONT CENTER CONSOLE AMBIENT LIGHTING BULB 1
FRONT CENTER CONSOLE AMBIENT LIGHTING BULB 2
FRONT CENTER CONSOLE AMBIENT LIGHTING BULB 3
FRONT CENTER CONSOLE AMBIENT LIGHTING BULB 4
LANE CHANGE ASSISTANCE CONTROL MODULE 2
LEFT LICENSE PLATE LAMP
LEFT LUGGAGE COMPARTMENT LAMP
LEFT REAR UPPER BODY VENT POSITION SENSOR
LEFT TAIL LAMP 2
LEVEL CONTROL SYSTEM COMPRESSOR ELECTRONICS
MOBILE DEVICE CHARGER 1
POWER REAR LID OPENING CONTROL MODULE
REAR CENTER AIR VENT ILLUMINATION BULB
REAR CIGARETTE LIGHTER
REAR LID CLOSING AID
REAR LID CONTROL HEAD
REAR LID HANDLE RELEASE BUTTON
REAR LID LOCK UNIT
REAR VIEW CAMERA SYSTEM CONTROL MODULE
REAR WINDOW SHADE MOTOR
RIGHT CENTER ARMREST ILLUMINATION BULB
RIGHT LICENSE PLATE LAMP
RIGHT TAIL LAMP 2
ROOF ANTENNA
SEDAN
SELECTOR LEVEL SENSOR
TIRE PRESSURE MONITORING CONTROL MODULE
W/ AMBIENT LIGHTING
W/ AMPLIFIER W/O BANG, OLUFSEN SOUND
W/ AMPLIFIER, BANG, OLUFSEN SOUND
W/ KEYLESS ACCESS
Go to component: -> Ground distribution circuit (6 of 10) -> BRN WIRE
Wiring diagram brn (107 of 196)
BRN WIRE
BRN/YEL WIRE
COUPLING POINT IN LEFT REAR SEAT
COUPLING POINT IN THE LEFT REAR DOOR
COUPLING STATION IN LEFT FRONT SEAT
DRIVER ASSISTANCE SYSTEMS CONTROL MODULE
DRIVER BACKREST HEATING ELEMENT
DRIVER HEATED SEAT EXTENSION
DRIVER SEAT BACKREST BLOWER FAN
DRIVER SEAT BACKREST COUPLING POINT
DRIVER SEAT BOLSTER HEATER
DRIVER SEAT COUPLING POINT
DRIVER SEAT CUSHION BLOWER FAN
DRIVER SEAT HEATING ELEMENT
DRIVER SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH
DRIVER SIDE REAR DOOR CLOSING AID MOTOR
DRIVER SIDE REAR DOOR CONTROL MODULE
DRIVER SIDE REAR DOOR LOCK UNIT
DRIVER SIDE REAR EXTERIOR DOOR HANDLE ILLUMINATION LAMP
LEFT FOOTWELL LAMP
LEFT FRONT SEAT BELT
LEFT REAR BACKREST HEATING ELEMENT
LEFT REAR BENCH SEAT HEATING ELEMENT
LEFT REAR DOOR AMBIENT LIGHTING BULB 1
LEFT REAR DOOR CONTOUR ILLUMINATION LAMP
LEFT REAR DOOR CONTOUR ILLUMINATION LAMP 2
LEFT REAR DOOR COUPLING POINT
LEFT REAR EXTERIOR DOOR HANDLE TOUCH SENSOR
LEFT REAR SEAT COUPLING STATION
MEMORY SEAT/STEERING COLUMN ADJUSTMENT CONTROL MODULE
TO DRIVER SEAT COUPLING STATION (DIAGRAM 8 OF 10)
W/ AMBIENT LIGHTING
W/ AUXILIARY LAMPS
W/ MEMORY
W/ SEAT VENTILATION
W/O MEMORY
WHT WIRE
YEL WIRE
Go to component: -> Ground distribution circuit (7 of 10) -> BRN WIRE
Wiring diagram brn (108 of 196)
AIR QUALITY SENSOR
ALARM HORN
BATTERY MONITORING CONTROL MODULE
BLK WIRE
BRAKE PEDAL POSITION SENSOR
BRAKE PEDAL SWITCH
BRN WIRE
BRN/WHT WIRE
DRIVER SEAT BELT SWITCH
DRIVER SEAT COUPLING POINT
DRIVER SIDE REAR SIDE SILL PANEL STRIP AMBIENT LIGHTING LAMP
DRIVER SIDE SILL PANEL STRIP AMBIENT LIGHTING LAMP
DRIVER SIDE WINDSHIELD WIPER ARM THERMAL RESISTOR 1
DRIVER THORAX AIR BAG IGNITER
EXTERIOR AIR QUALITY, HUMIDITY SENSOR
FROM DRIVER SEAT COUPLING POINT (DIAGRAM 7 OF 10)
FROM FRONT PASSENGER SEAT COUPLING POINT (DIAGRAM 9 OF 10)
FRONT PASSENGER SEAT BELT SWITCH
FRONT PASSENGER SEAT COUPLING POINT
FRONT PASSENGER SIDE SILL PANEL STRIP AMBIENT LIGHTING LAMP
FRONT PASSENGER SIDE WINDSHIELD WIPER ARM THERMAL RESISTOR 1
FRONT PASSENGER THORAX AIR BAG IGNITER
FRONT PASSENGER VANITY MIRROR LAMP CONTACT SWITCH
FRONT ROOF MODULE
HEADLAMP WASHER SYSTEM PUMP
IGNITION COIL 1 W/ POWER OUTPUT STAGE
IGNITION COIL 2 W/ POWER OUTPUT STAGE
IGNITION COIL 3 W/ POWER OUTPUT STAGE
IGNITION COIL 4 W/ POWER OUTPUT STAGE
IGNITION COIL 5 W/ POWER OUTPUT STAGE
IGNITION COIL 6 W/ POWER OUTPUT STAGE
LEFT REAR AIR VENT ILLUMINATION BULB
LEFT WASHER NOZZLE HEATER
RIGHT WASHER NOZZLE HEATER
W/ AMBIENT LIGHTING
W/ AUXILIARY LAMPS
WINDSHIELD WASHER PUMP CONTROL MODULE
WIPER MOTOR CONTROL MODULE
Go to component: -> Ground distribution circuit (8 of 10) -> BRN WIRE
Wiring diagram brn (109 of 196)
ABS CONTROL MODULE
BRN WIRE
CENTER COUPLING POINT ON INSTRUMENT PANEL
COMPUTER DATA LINES SYSTEM
ELECTRO- MECHANICAL PARKING BRAKE BUTTON
GRN WIRE
GRY WIRE
GRY/BLK WIRE
GRY/BRN WIRE
GRY/RED WIRE
GRY/YEL WIRE
LEFT DAYTIME RUNNING LAMP, POSITION LAMP LED MODULE
LEFT FRONT HEADLAMP
LEFT FRONT SIDE MARKER LAMP BULB
LEFT FRONT TURN SIGNAL BULB
LEFT HEADLAMP 12 PIN CONNECTOR
LEFT HEADLAMP 2-PIN CONNECTOR
LEFT HEADLAMP BEAM ADJUSTMENT MOTOR
LEFT HEADLAMP CURRENT CODING RESISTANCE 1
LEFT HEADLAMP CURRENT CODING RESISTANCE 2
LEFT HEADLAMP CURRENT CODING RESISTANCE 3
LEFT HEADLAMP TEMPERATURE SENSOR 1
LEFT HEADLAMP TEMPERATURE SENSOR 2
LEFT HEADLAMP TEMPERATURE SENSOR 3
LEFT HEADLAMP TEMPERATURE SENSOR 4
LEFT HEADLAMP TEMPERATURE SENSOR 5
LEFT HIGH BEAM HEADLAMP BULB
LEFT LED HEADLAMP POWER OUTPUT MODULE 1
LEFT LED HEADLAMP POWER OUTPUT MODULE 2
LEFT LOW BEAM HEADLAMP BULB
LEFT STATIONARY CORNERING LAMP
ORG/BRN WIRE
PARKING BRAKE BUTTON
PNK WIRE
VIO/WHT WIRE
WHT/GRN WIRE
WHT/RED WIRE
Go to component: -> Headlights circuit, w/o multiple matrix beam & high beam control (2 of 3) -> BRN WIRE
Wiring diagram brn (110 of 196)
ABS CONTROL MODULE
BRN WIRE
CENTER COUPLING POINT ON INSTRUMENT PANEL
COMPUTER DATA LINES SYSTEM
ELECTRO- MECHANICAL PARKING BRAKE BUTTON
GRN WIRE
GRY WIRE
GRY/BLK WIRE
GRY/BRN WIRE
GRY/RED WIRE
GRY/YEL WIRE
LEFT DAYTIME RUNNING LAMP, POSITION LAMP LED MODULE
LEFT FRONT HEADLAMP
LEFT FRONT SIDE MARKER LAMP BULB
LEFT FRONT TURN SIGNAL BULB
LEFT HEADLAMP 8-PIN CONNECTOR
LEFT HEADLAMP BEAM ADJUSTMENT MOTOR
LEFT HEADLAMP CURRENT CODING RESISTANCE 1
LEFT HEADLAMP CURRENT CODING RESISTANCE 2
LEFT HEADLAMP CURRENT CODING RESISTANCE 3
LEFT HEADLAMP TEMPERATURE SENSOR 1
LEFT HEADLAMP TEMPERATURE SENSOR 2
LEFT HEADLAMP TEMPERATURE SENSOR 3
LEFT HIGH BEAM HEADLAMP BULB
LEFT LED HEADLAMP POWER OUTPUT MODULE 1
LEFT LOW BEAM HEADLAMP BULB
LEFT STATIONARY CORNERING LAMP
ORG/BRN WIRE
PARKING BRAKE BUTTON
PNK WIRE
VIO/WHT WIRE
WHT/GRN WIRE
WHT/RED WIRE
Go to component: -> Headlights circuit, w/o multiple matrix beam w/ high beam control (2 of 3) -> BRN WIRE
Dubai Silicon Oasis - Dubai - UAE
AUTOMOTIVE ELECTRICIANS PORTAL - FZCO
© 2025 DIAGNOSTDATA
About the company
Dubai Silicon Oasis - Dubai - UAE
AUTOMOTIVE ELECTRICIANS PORTAL - FZCO
Privacy Policy
© 2025 DIAGNOSTDATA
