Audi A6 C5 (1997-2001) trunk lid central locking system motor Wiring diagram

This page shows the only wiring diagram for the component.trunk lid central locking system motor, which is found in the car Audi A6 C5 (1997-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram trunk lid central locking system motor (1 of 1)

Wiring diagram trunk lid central locking system motor for Audi A6 C5 (1997-2001)

Get access

BRN WIRE CENTRAL LOCKING CONTROL MODULE (BELOW DRIVER'S SEAT AND CARPET) GRN/YEL WIRE HOT AT ALL TIMES FUSE PANEL (LEFT SIDE OF DASH) FUSE 14 RED/BLU WIRE TRUNK LID CENTRAL LOCKING SYSTEM MOTOR TRUNK RELEASE SWITCH ULTRA-SOUND SENSOR CONTROL MODULE (BELOW LEFT "C" PILLAR) VIO/GRN WIRE YEL/RED WIRE

Go to component: -> Trunk release circuit -> TRUNK LID CENTRAL LOCKING SYSTEM MOTOR
