Audi A6 C5 (1997-2001) speedometer vehicle speed sensor Wiring diagram

This page shows the only wiring diagram for the component.speedometer vehicle speed sensor, which is found in the car Audi A6 C5 (1997-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram speedometer vehicle speed sensor (1 of 1)

Wiring diagram speedometer vehicle speed sensor for Audi A6 C5 (1997-2001)

Get access

BLK WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE BRAKE LIGHT SWITCH BRAKE PEDAL SWITCH BRN WIRE BRN/RED WIRE COMBINATION PROCESSOR CRUISE CONTROL MODULE (BEHIND GLOVE BOX) CRUISE CONTROL SWITCH CRUISE CONTROL VACUUM PUMP FUSE FUSE PANEL (LEFT SIDE OF DASH) GRN WIRE GRN/BLU WIRE GRY WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER MULTI-FUNCTION TRANSMISSION RANGE SWITCH RED WIRE RED/BLK WIRE RED/GRN WIRE RED/YEL WIRE SPEEDOMETER VEHICLE SPEED SENSOR TRANSMISSION CONTROL MODULE WHT WIRE WHT/BLU WIRE YEL WIRE

Go to component: -> Cruise control circuit -> SPEEDOMETER VEHICLE SPEED SENSOR
