Audi A6 C5 (1997-2001) power antenna Wiring diagrams

This page contains all the electrical diagrams for the component. power antenna, in which he is found in the car Audi A6 C5 (1997-2001). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram power antenna (1 of 2)

Wiring diagram power antenna for Audi A6 C5 (1997-2001)

Get access

BRN WIRE POWER ANTENNA REAR WINDOW DEFOGGER/ WINDOW ANTENNA RIGHT REAR AMPLIFIER WIRES SHIELD

Go to component: -> Ground distribution circuit (2 of 2) -> POWER ANTENNA

Wiring diagram power antenna (2 of 2)

Wiring diagram power antenna for Audi A6 C5 (1997-2001)

Get access

ANTENNA LEAD BLK/RED WIRE BRN WIRE FUSE 37 FUSE 5 FUSE PANEL (LEFT SIDE OF DASH) HOT AT ALL TIMES HOT IN RUN AND START NCA WIRE POWER ANTENNA RADIO RED WIRE RED/BLU WIRE SOLID STATE WHT WIRE

Go to component: -> Power antenna circuit -> POWER ANTENNA
