Audi A6 C5 (1997-2001) memory operating unit light Wiring diagram
This page shows the only wiring diagram for the component.memory operating unit light, which is found in the car Audi A6 C5 (1997-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram memory operating unit light (1 of 1)
A/C CONTROL HEAD
A/T CONSOLE LIGHT
ANTI-SLIP CONTROL SWITCH
BLK WIRE
BLU WIRE
BRN WIRE
CENTER INSTRUMENT PANEL VENT ILLUMINATION
CIGARETTE LIGHTER
COMBINATION PROCESSOR
EMERGENCY FLASHER SWITCH
EXTERIOR LIGHTS
FUSE 3
FUSE PANEL (LEFT SIDE OF DASH)
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRY WIRE
GRY/BLU WIRE
GRY/GRN WIRE
HEATED DRIVER'S SEAT ADJUSTER
HEATED PASSENGER'S SEAT ADJUSTER
HOT AT ALL TIMES
INSTRUMENT CLUSTER
INSTRUMENT PANEL LIGHT DIMMER SWITCH
LEFT INSTRUMENT PANEL VENT ILLUMINATION
LEFT REAR HEATED SEAT REGULATING SWITCH
LIGHT SWITCH
MEMORY OPERATING UNIT LIGHT
MIRROR ADJUSTMENT SWITCH
OFF HEAD PARK
RADIO
REAR CIGARETTE LIGHTER
REAR SEAT OUTLET CENTER LIGHT
RED WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT FRONT MAP/READING LIGHT AND LEFT FRONT READING LIGHT
RIGHT INSTRUMENT PANEL VENT ILLUMINATION
RIGHT REAR HEATED SEAT REGULATING SWITCH
Go to component: -> Interior lights circuit (1 of 3) -> MEMORY OPERATING UNIT LIGHT
