Audi A6 C5 (1997-2001) left front headlight/ park light/ turn signal assembly Wiring diagram
This page shows the only wiring diagram for the component.left front headlight/ park light/ turn signal assembly, which is found in the car Audi A6 C5 (1997-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front headlight/ park light/ turn signal assembly (1 of 1)
13-FOLD RELAY PANEL
BLK WIRE
BRN WIRE
COMBINATION PROCESSOR
FOG LIGHT SWITCH OFF
FOGLIGHT CIRCUIT BREAKER (ON 13-FOLD RELAY PANEL)
FOGLIGHT IND
FOGLIGHT RELAY
FOGLIGHT SWITCH LIGHT
FRONT
FTP
FUSE 18
FUSE 19
FUSE 20 FUSE 21
FUSE 36
FUSE PANEL (LEFT SIDE OF DASH)
GRN WIRE
GRY WIRE
GRY/BLU WIRE
GRY/GRN WIRE
GRY/WHT WIRE
HEAD- LIGHTS
HEADLIGHT LEVELING CIRCUIT (HEADLIGHT ADJUSTER)
HEADLIGHT SWITCH LIGHT
HIGH BEAM IND
HOT AT ALL TIMES
HOT AT ALL TIMES IGNITION SWITCH
INSTRUMENT CLUSTER
LAMP CONTROL MODULE (ON 13-FOLD RELAY PANEL)
LEFT FOG LAMP
LEFT FRONT HEADLIGHT/ PARK LIGHT/ TURN SIGNAL ASSEMBLY
LEFT REAR FOGLIGHT
LIGHT SWITCH HEAD
LIGHT SWITCH/ FOGLIGHT SWITCH
OFF
PARK
REAR
REAR FOGLIGHT IND
RIGHT FOG LAMP
RIGHT FRONT HEADLIGHT/ PARK LIGHT/ TURN SIGNAL ASSEMBLY
RUN WIRE
TURN SIGNAL/ HEADLIGHT DIMMER/ FLASHER SWITCH
WHT WIRE
WHT/BLK WIRE
WHT/GRN WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component: -> Headlamps & fog lamps circuit, with drl -> LEFT FRONT HEADLIGHT/ PARK LIGHT/ TURN SIGNAL ASSEMBLY
