Audi A6 C5 (1997-2001) 8-fold relay panel fuse 142 wiring diagram
This page shows the only wiring diagram for the component.8-fold relay panel fuse 142, which is found in the car Audi A6 C5 (1997-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
8-fold relay panel fuse 142 wiring diagram (1 of 1)
8-FOLD RELAY PANEL FUSE 142
A/C CLUTCH
A/C CLUTCH RELAY (ON 13-FOLD RELAY PANEL)
A/C CONTROL HEAD
AIR QUALITY SENSOR
ANTI-LOCK BRAKES SYSTEM
BLK/BLU WIRE
BLK/BRN WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/RED WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLU WIRE
BLU/VIO WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/GRY WIRE
BRN/VIO WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COOLANT FAN AFTER-RUN COOLANT PUMP
COOLANT FAN CONTROL MODULE
COOLANT FAN CONTROL THERMAL SWITCH (ON LOWER RIGHT SIDE OF RADIATOR)
DATA LINK CONNECTOR (BELOW LEFT SIDE OF DASH)
DEFOGGER SYSTEM
FUSE 42
FUSE PANEL FUSE 25 FUSE 26 FUSE 5
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/VIO WIRE
GRN/YEL WIRE
GRY WIRE
GRY/BLU WIRE
GRY/RED WIRE
GRY/VIO WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT IN RUN
HOT W/ LOAD REDUCTION RELAY ENERGIZED
INSTRUMENT CLUSTER
MOTRONIC ENGINE CONTROL MODULE (IN ELECT BOX, LEFT SIDE OF FRESH AIR PLENUM)
RED WIRE
RED/BLK WIRE
RED/BRN WIRE
RED/GRY WIRE
RED/YEL WIRE
TACHOMETER
VIO/BRN WIRE
VIO/GRY WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/GRY WIRE
WHT/RED WIRE
WHT/VIO WIRE
WHT/YEL WIRE
WIPER/WASHER SYSTEM
YEL/BLU WIRE
YEL/GRY WIRE
YEL/VIO WIRE
YEL/WHT WIRE
Go to component -> Automatic a/c circuit (1 of 2) -> 8-FOLD RELAY PANEL FUSE 142
