Air conditioning — Automatic a/c circuit, basic Audi A5 I facelift
All systems — 34 systems
- Active bodyworks
- Air conditioning 2
- Anti-lock brakes
- Anti-theft
- Body control modules 3
- Computer data lines
- Cooling fan
- Cruise control
- Defoggers
- Electronic power steering 3
- Electronic suspension
- Engine performance 2.0l turbo 3
- Exterior lights 2
- Ground distribution
- Headlights 6
- Horn
- Instrument cluster
- Interior lights 2
- Memory systems 3
- Navigation 13
- Power distribution
- Power door locks
- Power mirrors 2
- Power seats 11
- Power top/sunroof 2
- Power windows
- Radio 13
- Shift interlock 3
- Starting/charging 2
- Supplemental restraints
- Transmission 3
- Trunk, tailgate, fuel door
- Warning systems 3
- Wiper/washer 2
Air conditioning
# Automatic a/c circuit, basic
# Automatic a/c circuit, basic (1 of 2)
Components on the diagram
# Automatic a/c circuit, basic (2 of 2)
Components on the diagram
Components on these wiring diagrams 61
Click a component to highlight it on every diagram it appears on.
