Wiring diagram: Interior lights — Courtesy lamps circuit Audi A5 I
All systems
- Air conditioning 2
- Anti-lock brakes
- Anti-theft
- Body control modules 3
- Computer data lines
- Cooling fan
- Cruise control
- Defoggers
- Electronic power steering
- Electronic suspension
- Engine performance 3.2l
- Exterior lights 2
- Ground distribution
- Headlights 3
- Horn
- Instrument cluster 3
- Interior lights 2
- Memory systems 3
- Navigation 6
- Power distribution
- Power door locks
- Power mirrors 3
- Power seats 5
- Power top/sunroof
- Power windows
- Radio 7
- Shift interlock 3
- Starting/charging 2
- Supplemental restraints
- Transmission 3
- Trunk, tailgate, fuel door
- Warning systems 2
- Wiper/washer 2
Courtesy lamps circuit (1 of 2) — Interior lights Audi A5 I
Components on the diagram
Courtesy lamps circuit (2 of 2) — Interior lights Audi A5 I
Components on the diagram
Components on these wiring diagrams
Click a component to highlight it on every diagram it appears on.
