Wiper/washer Systems (coupe) Audi A5 I

CONTACT CORROSION

Contact corrosion can occur if incorrect fasteners (bolts, nuts, washers, etc.) are used.

For this reason, only fasteners with a special surface coating are used.

In addition, rubber or plastic parts and adhesive consist of non-conductive materials.

If there are doubts as to whether parts are suitable or not, use new parts.

Note. We only recommend original replacement parts, they have been tested and are compatible with aluminum. We recommend using Audi accessories. Damage resulting from contact corrosion is not covered by warranty.

SPRAY NOZZLES

Note. The nozzles are already adjusted by the manufacturer and must not be adjusted after installation.

WASHER FLUID LINES

The following descriptions can be found in electrical system general information. Refer to General Information

1. Washer fluid line hose connections, disconnecting and connecting
2. Corrugated hose washer fluid line, repairing

WINDSHIELD WIPERS, BRINGING INTO SERVICE POSITION

Note. If the windshield wiper motor is to be run during the work procedure, the hood must be closed, otherwise the voltage supply of the wiper motor will be interrupted.

Make sure the wiper blades are not frozen.

Switch on ignition.

Activate the menu point Windshield Wipers "on" in the "MMI". Refer to the Owner's Manual.

1. The windshield wipers run into service position.

Turn off the ignition.

Scheme 13

1. Headlamp Washer System Spray Nozzle Overview, refer to «HEADLAMP WASHER FLUID RESERVOIR, WASHER FLUID HOSE AND NOZZLE OVERVIEW»(/audi/a5/i-2007-2011/remont/wiperwasher-systems/#wiperwasher-systems-coupe) . Removing and installing, refer to «HEADLAMP WASHER SYSTEM SPRAY NOZZLES»(/audi/a5/i-2007-2011/remont/wiperwasher-systems/#wiperwasher-systems-coupe__headlamp-washer-system-spray-nozzles) .
2. Spray Nozzle Overview, refer to «WINDSHIELD WASHER FLUID RESERVOIR, WASHER FLUID LINES AND NOZZLE OVERVIEW»(/audi/a5/i-2007-2011/remont/wiperwasher-systems/#wiperwasher-systems-coupe) . Removing and installing, refer to «WINDSHIELD WASHER SPRAY NOZZLES»(/audi/a5/i-2007-2011/remont/wiperwasher-systems/#wiperwasher-systems-coupe__windshield-washer-spray-nozzles) .
3. Wiper Arm Overview, refer to «WINDSHIELD WIPER SYSTEM OVERVIEW»(/audi/a5/i-2007-2011/remont/wiperwasher-systems/#wiperwasher-systems-coupe) . Removing and installing, refer to «WIPER ARMS»(/audi/a5/i-2007-2011/remont/wiperwasher-systems/#wiperwasher-systems-coupe__wiper-arms) .
4. Windshield Wiper Motor With Wiper Motor Control Module -J400- Overview, refer to «WINDSHIELD WIPER SYSTEM OVERVIEW»(/audi/a5/i-2007-2011/remont/wiperwasher-systems/#wiperwasher-systems-coupe) . Removing and installing, refer to «WIPER MOTOR WITH WINDSHIELD WIPER MOTOR CONTROL MODULE -J400»(/audi/a5/i-2007-2011/remont/wiperwasher-systems/#wiperwasher-systems-coupe__wiper-motor-with-windshield-wiper-motor) .
5. Rain/Light Recognition Sensor -G397- Removing and installing, refer to «Removal and Installation»(/audi/a5/i-2007-2011/remont/windows/#glass-window-regulators-coupe) .
6. Grommet For the windshield washer fluid hose inside the hood.
7. Washer Fluid Reservoir Overview, refer to «WINDSHIELD WASHER FLUID RESERVOIR, WASHER FLUID LINES AND NOZZLE OVERVIEW»(/audi/a5/i-2007-2011/remont/wiperwasher-systems/#wiperwasher-systems-coupe) . Removing and installing, refer to «WINDSHIELD WASHER FLUID RESERVOIR»(/audi/a5/i-2007-2011/remont/wiperwasher-systems/#wiperwasher-systems-coupe__windshield-washer-fluid-reservoir) .
8. Fuel Filler Tube For washer fluid reservoir Overview, refer to «WINDSHIELD WASHER FLUID RESERVOIR, WASHER FLUID LINES AND NOZZLE OVERVIEW»(/audi/a5/i-2007-2011/remont/wiperwasher-systems/#wiperwasher-systems-coupe) . Removing and installing, refer to «WINDSHIELD WASHER FLUID RESERVOIR FILLER NECK»(/audi/a5/i-2007-2011/remont/wiperwasher-systems/#wiperwasher-systems-coupe__windshield-washer-fluid-reservoir-filler-neck) .

Scheme 14

1. Screw Tightening sequence, refer to «WINDSHIELD WIPER SYSTEM OVERVIEW»(/audi/a5/i-2007-2011/remont/wiperwasher-systems/#wiperwasher-systems-coupe)
2. Windshield Wiper Motor With wiper motor control module -J400- Removing and installing, refer to «WIPER MOTOR WITH WINDSHIELD WIPER MOTOR CONTROL MODULE -J400»(/audi/a5/i-2007-2011/remont/wiperwasher-systems/#wiperwasher-systems-coupe__wiper-motor-with-windshield-wiper-motor) .
3. Screw Tightening sequence, refer to «WINDSHIELD WIPER SYSTEM OVERVIEW»(/audi/a5/i-2007-2011/remont/wiperwasher-systems/#wiperwasher-systems-coupe)
4. Nut 17 Nm
5. Cap
6. Windshield Wiper Arm, Passenger's Side Different lengths, Removing and installing, refer to «WIPER ARMS»(/audi/a5/i-2007-2011/remont/wiperwasher-systems/#wiperwasher-systems-coupe__wiper-arms) . Adjusting, refer to «WINDSHIELD WIPER ARMS, ADJUSTING»(/audi/a5/i-2007-2011/remont/wiperwasher-systems/#wiperwasher-systems-coupe) .
7. Windshield Wiper Blade, Passenger's Side Different lengths, Replacing, refer to «WIPER BLADES, REPLACING»(/audi/a5/i-2007-2011/remont/wiperwasher-systems/#wiperwasher-systems-coupe__wiper-blades-replacing) .
8. Windshield Wiper Blade, Driver's Side Different lengths, Replacing, refer to «WIPER BLADES, REPLACING»(/audi/a5/i-2007-2011/remont/wiperwasher-systems/#wiperwasher-systems-coupe__wiper-blades-replacing) .
9. Windshield Wiper Arm, Driver's Side Different lengths, Removing and installing, refer to «WIPER ARMS»(/audi/a5/i-2007-2011/remont/wiperwasher-systems/#wiperwasher-systems-coupe__wiper-arms) . Adjusting, refer to «WINDSHIELD WIPER ARMS, ADJUSTING»(/audi/a5/i-2007-2011/remont/wiperwasher-systems/#wiperwasher-systems-coupe) .
10. Cap
11. Nut 17 Nm
12. Screw Tightening sequence, refer to «WINDSHIELD WIPER SYSTEM OVERVIEW»(/audi/a5/i-2007-2011/remont/wiperwasher-systems/#wiperwasher-systems-coupe)
13. Water Drain Channel

Scheme 15

Tighten the bolts in -1, 2, 3- sequence in 2 stages as follows

Install by hand as far as the stop.

Tighten to 8 Nm.

Scheme 16

1. Screw Tightening sequence, refer to «WINDSHIELD WASHER FLUID RESERVOIR, WASHER FLUID LINES AND NOZZLE OVERVIEW»(/audi/a5/i-2007-2011/remont/wiperwasher-systems/#wiperwasher-systems-coupe)
2. O-ring Replace if damaged
3. Sealing Grommet Replace if damaged
4. Fuel Filler Tube For washer fluid reservoir Removing and installing, refer to «WINDSHIELD WASHER FLUID RESERVOIR FILLER NECK»(/audi/a5/i-2007-2011/remont/wiperwasher-systems/#wiperwasher-systems-coupe__windshield-washer-fluid-reservoir-filler-neck) .
5. Support Ring
6. Nut Threaded connection shared with tower brace. Tightening specification, refer to «Specifications»(/audi/a5/i-2007-2011/remont/suspension-front/#front-suspension-coupe) .
7. Cover For the filler neck
8. Washer Fluid Line For windshield washer system
9. Right Washer Nozzle Depending on equipment, with Right Washer Nozzle Heater -Z21-. Removing and installing, refer to «WINDSHIELD WASHER SPRAY NOZZLES»(/audi/a5/i-2007-2011/remont/wiperwasher-systems/#wiperwasher-systems-coupe__windshield-washer-spray-nozzles) . Adjusting, refer to «WINDSHIELD WASHER SPRAY NOZZLES, ADJUSTING»(/audi/a5/i-2007-2011/remont/wiperwasher-systems/#wiperwasher-systems-coupe__windshield-washer-spray-nozzles-adjusting) .
10. Left Washer Nozzle Depending on equipment, with Left Washer Nozzle Heater -Z20-. Removing and installing, refer to «WINDSHIELD WASHER SPRAY NOZZLES»(/audi/a5/i-2007-2011/remont/wiperwasher-systems/#wiperwasher-systems-coupe__windshield-washer-spray-nozzles) . Adjusting, refer to «WINDSHIELD WASHER SPRAY NOZZLES, ADJUSTING»(/audi/a5/i-2007-2011/remont/wiperwasher-systems/#wiperwasher-systems-coupe__windshield-washer-spray-nozzles-adjusting) .
11. Washer Fluid Reservoir Removing and installing, refer to «WINDSHIELD WASHER FLUID RESERVOIR»(/audi/a5/i-2007-2011/remont/wiperwasher-systems/#wiperwasher-systems-coupe__windshield-washer-fluid-reservoir) .
12. Headlamp Washer System Pump -V11
13. Sealing Grommet
14. Washer Fluid Line For headlamp washer system
15. Retaining Ring For Windshield Washer Pump -V5
16. Windshield Washer Pump -V5- Removing and installing, refer to «WINDSHIELD WASHER PUMP -V5»(/audi/a5/i-2007-2011/remont/wiperwasher-systems/#wiperwasher-systems-coupe__windshield-washer-pump-v5) .
17. Sealing Grommet
18. Screw Tightening sequence, refer to «WINDSHIELD WASHER FLUID RESERVOIR, WASHER FLUID LINES AND NOZZLE OVERVIEW»(/audi/a5/i-2007-2011/remont/wiperwasher-systems/#wiperwasher-systems-coupe) .
19. Sealing Grommet
20. Windshield Washer Fluid Level Sensor -G33- Removing and installing, refer to «WINDSHIELD WASHER FLUID LEVEL SENSOR -G33»(/audi/a5/i-2007-2011/remont/wiperwasher-systems/#wiperwasher-systems-coupe__windshield-washer-fluid-level-sensor-g33) .

Scheme 17

Tighten the washer fluid bolts in the sequence specified

Tighten the bolt -3- to 7 Nm.

Tighten the bolt -4- to 7 Nm.

Scheme 18

1. Right Washer Nozzle Removing and installing, refer to «HEADLAMP WASHER SYSTEM SPRAY NOZZLES»(/audi/a5/i-2007-2011/remont/wiperwasher-systems/#wiperwasher-systems-coupe__headlamp-washer-system-spray-nozzles) .
2. Right Mount For the spray nozzle and headlamp
3. Washer Fluid Hose For the right spray nozzle Secured on the bumper with cable ties
4. Left Mount For the spray nozzle and headlamp.
5. Washer Fluid Reservoir
6. Headlamp Washer Pump -V11- Removing and installing, refer to «HEADLAMP WASHER PUMP -V11»(/audi/a5/i-2007-2011/remont/wiperwasher-systems/#wiperwasher-systems-coupe__headlamp-washer-pump-v11) .
7. Sealing Grommet For the headlamp washer pump.
8. Washer Fluid Hose From the headlamp washer pump.
9. Washer Fluid Hose To the spray nozzles
10. Left Washer Nozzle Removing and installing, refer to «HEADLAMP WASHER SYSTEM SPRAY NOZZLES»(/audi/a5/i-2007-2011/remont/wiperwasher-systems/#wiperwasher-systems-coupe__headlamp-washer-system-spray-nozzles) .
11. Washer Fluid Hose For the left spray nozzle
12. Impact Member

FASTENER TIGHTENING SPECIFICATIONS

PROCEDURE

Note. If the windshield wiper motor is to be run during the work procedure, the hood must be closed, otherwise the voltage supply of the wiper motor will be interrupted.

Remove wiper arms. Refer to WIPER ARMS .

Switch on ignition.

Activate one-touch wiping and let wiper motor run to end position.

Note. Every second time the wiper motor is switched off, it returns the wiper arms to a slightly lower rest position, thus tipping the wiper blade lips the other way. To do so, the wiper motor moves the wiper arms farther down than to rest position and then a bit up again. This lower rest position must not be used to adjust the wiper crank. Only use end position where wiper arms run directly end position with no understroke. Activate one-touch wiping again if necessary.

Turn off the ignition.

Position wiper arm with wiper blade installed at wiper axles and align wiper blade at windshield as follows

Scheme 19

1. Dimension -a- = 0 + 10 mm.
2. Dimension -b- = 0 + 10 mm.

Note. The dimensions give the distance of the wiper blade tips to the cowl panel trim on the lower edge of the windshield.

Tighten the nuts -2- for the wiper arms -1-.

Scheme 20

1. Tightening specification, refer to «WINDSHIELD WIPER SYSTEM OVERVIEW»(/audi/a5/i-2007-2011/remont/wiperwasher-systems/#wiperwasher-systems-coupe) .

Switch on ignition.

Operate one-touch wiping and let wiper arms run to end position.

Turn off the ignition.

Check adjustment of wiper arms again, correct if necessary.

Press the caps -arrows- onto the wiper arms.

WINDSHIELD WASHER SPRAY NOZZLES, ADJUSTING

Special tools and workshop equipment required

1. Windshield washer aiming tool T40187 equipped with Replacement Tips For T10127 3125/5A

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Adjusting

Scheme 21

Note. The settings indicate the values for a moving vehicle, i.e. the spray from the jets is slightly offset when the vehicle is stationary.

Mark the six points on windshield using a water soluble marker

Scheme 22

Unlock long cover -1- on the T40187 -arrow A- and push it back -arrow B-.

Scheme 23

Place adjusting pin -2- on the respective nozzle -arrow- of nozzle unit -1- and aim at the points on the windshield and adjust if necessary.

Scheme 24

If the spray field does not correspond to the specifications, clean dirty spray jet.

Cleaning the nozzle

Remove nozzle. Refer to WINDSHIELD WASHER SPRAY NOZZLES .

Flush nozzle opposite to spray direction using clear water.

To remove remaining impurities, the nozzle must only be blown out opposite to spray direction using compressed air.

If the spray field still does not correspond to the specifications, replace the spray jet.

WINDSHIELD WIPER MOTOR WITH WIPER MOTOR CONTROL MODULE -J400- REPLACING

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Procedure

If the control module was replaced, select the "Replace" function for the respective control module in Guided Fault Finding or Guided Functions of the Vehicle diagnostic tester.

WIPER BLADES, REPLACING

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Scheme 25

Bring windshield wiper into service position. Refer to WINDSHIELD WIPERS, BRINGING INTO SERVICE POSITION .

Lift off wiper arm from front windshield.

Press the retaining clip -arrow A-.

Push wiper blade -1- off the wiper arm -2- -arrow B-.

Remove wiper blade.

INSTALLING

Install in reverse order of removal, observing the following

Guide wiper blade -1- parallel into wiper arm -2- -arrow-. Slide the wiper blade on until the retaining clips engage in the wiper arm.

Scheme 26

If the windshield wiper switch is operated or a speed of 6 km/h is exceeded, the wipers leave the service position.

WIPER ARMS

Special tools and workshop equipment required

1. Windshield wiper arm tool set T10369

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

REMOVING

Note. If the windshield wiper motor is to be run during the work procedure, the hood must be closed, otherwise the voltage supply of the wiper motor will be interrupted.

Bring windshield wiper into service position. Refer to WINDSHIELD WIPERS, BRINGING INTO SERVICE POSITION .

Switch off ignition and remove ignition key.

Using a screwdriver, pry the caps -arrows- off the wiper arms -1-.

Loosen the nut -2- several turns.

Position the puller T10369/1 on the wiper arm -1- as illustrated.

Scheme 27

Position the thrust piece -2- on the wiper axle.

Rotate the bolt -3- clockwise until the wiper arm is removed from the axle.

Remove nuts completely and remove wiper arms.

Install in reverse order of removal, observing the following

Adjust wiper arms. Refer to WINDSHIELD WIPER ARMS, ADJUSTING .

WIPER MOTOR WITH WINDSHIELD WIPER MOTOR CONTROL MODULE -J400

Special tools and workshop equipment required

1. Pry Lever 80 - 200

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Scheme 28

Remove wiper arms. Refer to WIPER ARMS .

Vehicles through 05.08

Remove the seal -arrow-.

Unclip the plenum chamber cover -1 through 3- and remove it.

Vehicles from 06.08

Scheme 29

Remove the bolts -3-.

Remove the clips -2- from the mounts and remove the plenum chamber cover -1-.

All vehicles

Scheme 30

Remove the securing clips -2- -arrow A-.

Carefully remove the cowl panel trim -1- starting at the edge of the glass vertically from the windshield -arrows B

Disconnect the electrical connector -2-.

Scheme 31

Remove the drain channel -3- on the linkage -arrow A-.

Remove the bolts -4, 5 and 6-.

Rotate the wiper arm frame -1- with the linkage and wiper motor upward -arrow B- and pull it forward out of the plenum chamber.

1. Tightening specification, refer to «WINDSHIELD WIPER SYSTEM OVERVIEW»(/audi/a5/i-2007-2011/remont/wiperwasher-systems/#wiperwasher-systems-coupe) .

Install in reverse order of removal, observing the following

Insert wiper motor with wiper frame into vehicle.

Tighten bolts, refer to WINDSHIELD WIPER SYSTEM OVERVIEW .

Position the water drain channel on the wiper motor.

Adjust wiper arms. Refer to WINDSHIELD WIPER ARMS, ADJUSTING .

WINDSHIELD WASHER FLUID RESERVOIR FILLER NECK

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Vehicles through 05.08

Remove the seal -arrow- near the windshield wiper fluid reservoir filler tube.

Unclip the plenum chamber cover -3- and remove it.

Note. Ignore items -1 and 2-.

Vehicles from 06.08

Remove the bolts -3-.

Remove the clips -2- from the mounts and remove the plenum chamber cover -1-.

All Vehicles

Scheme 32

Remove the nut -1- and tilt the windshield wiper fluid container filler tube slightly upward -arrow A-.

Remove the filler neck -2- with filler tube from the washer fluid reservoir and the body opening -arrow B-.

Scheme 33

1. Tightening specification, refer to «WINDSHIELD WASHER FLUID RESERVOIR, WASHER FLUID LINES AND NOZZLE OVERVIEW»(/audi/a5/i-2007-2011/remont/wiperwasher-systems/#wiperwasher-systems-coupe) .

Install in reverse order of removal, observing the following

Slide the sealing grommet -2- on the filler neck tube -1- as far as the stop.

1. The tab must lie in the opening on the filler tube -arrows-.

Slide the filler neck into the washer fluid reservoir.

Note. Make sure the O-ring is not crushed when sliding it into the washer fluid reservoir.

WINDSHIELD WASHER FLUID RESERVOIR

Special tools and workshop equipment required

1. Drip tray

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Switch off ignition and remove ignition key.

Remove the washer fluid reservoir filler neck. Refer to WINDSHIELD WASHER FLUID RESERVOIR FILLER NECK .

Remove left front wheel.

Remove left front wheel housing liner. Refer to Removal and Installation .

Place a drip tray under the windshield washer fluid reservoir.

Scheme 34

Remove the hose coupling -1- from the headlamp washer system fluid line -3- by pulling the release button.

Cut through the cable ties -2- and -4-.

Remove the plastic wedge -5-.

Disconnect the electrical connectors -7- and -8-.

Scheme 35

Release the securing clip and remove the washer fluid line -9- from the windshield washer system washer fluid pump.

Loosen the wiring harness -2- from the mounts on the washer fluid reservoir.

Remove screws -1- and -3-.

Pull the washer fluid reservoir forward slightly and out.

Disconnect the electrical connector -5-.

Loosen the headlamp washer system fluid hose -6- and wiring harness -4- from the mounts on the washer fluid reservoir.

Remove the washer fluid reservoir.

1. Tightening specifications and sequence, refer to «WINDSHIELD WASHER FLUID RESERVOIR, WASHER FLUID LINES AND NOZZLE OVERVIEW»(/audi/a5/i-2007-2011/remont/wiperwasher-systems/#wiperwasher-systems-coupe) .

When inserting the washer fluid reservoir, make sure the securing tab -1- engages in the mount -2- on the fender.

Install in reverse order of removal, observing the following

Install left front wheel house liner. Refer to Removal and Installation .

Install the washer fluid reservoir filler neck. Refer to WINDSHIELD WASHER FLUID RESERVOIR FILLER NECK .

WINDSHIELD WASHER FLUID LEVEL SENSOR -G33

Special tools and workshop equipment required

1. Drip tray

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Scheme 36

Switch off ignition and remove ignition key.

Remove left front wheel.

Remove left front wheel housing liner. Refer to Removal and Installation .

Disconnect the electrical connector -1-.

Place a drip tray under the windshield washer fluid reservoir.

Remove the windshield washer fluid level sensor -G33- -item 3- from the washer fluid reservoir -4-.

Install in reverse order of removal, observing the following

Check the sealing grommet -2- for damage.

Install left front wheel house liner. Refer to Removal and Installation .

WINDSHIELD WASHER PUMP -V5

Special tools and workshop equipment required

1. Drip tray

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Scheme 37

Switch off ignition and remove ignition key.

Remove left front wheel.

Remove left front wheel housing liner. Refer to Removal and Installation .

Disconnect the electrical connector -4-.

Place a drip tray under the windshield washer fluid reservoir.

Release the securing clip -2- in the -direction of the arrow- and remove the washer fluid line -1- from the windshield washer system washer fluid pump.

Remove the windshield washer pump -item 3- upward out of the washer fluid reservoir.

Note. Replace the -1- windshield washer pump bracket if it is damaged. Push the damaged bracket out of the mount in the windshield washer fluid reservoir -2- -arrow-.

Install in reverse order of removal, observing the following

Check the sealing grommet for damage.

Install left front wheel house liner. Refer to Removal and Installation .

WINDSHIELD WASHER SPRAY NOZZLES

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Scheme 38

Unclip the windshield washer spray nozzle -1- downward from hood -arrow-.

Release the securing clip -3- in the -direction of the arrow- and remove the washer fluid line -1- from the windshield washer system spray nozzle.

Scheme 39

Disconnect electrical harness connector -1-, if present.

Install in reverse order of removal, observing the following

Make sure the securing clip engages audibly in the washer line connection when connecting the line.

Install the spray nozzle into the hood.

HEADLAMP WASHER PUMP -V11

Special tools and workshop equipment required

1. Hose clamp pliers V.A.G 1921
2. Drip tray

Scheme 40

Remove the washer fluid reservoir, but only pull it out until the headlamp washer pump is accessible. Refer to WINDSHIELD WASHER FLUID RESERVOIR .

Place a drip tray under the windshield washer fluid reservoir.

Disconnect the electrical connector -1-.

Remove the washer fluid hose -3- from the headlamp washer pump.

Note. There may be a clip installed rather than a hose clamp.

Remove the headlamp washer pump -item 2- upward out of the washer fluid reservoir.

Install in reverse order of removal, observing the following

Note. Secure all hose connections using standard hose clamps.

Check the sealing grommet for damage.

Install the washer fluid reservoir. Refer to WINDSHIELD WASHER FLUID RESERVOIR .

HEADLAMP WASHER SYSTEM SPRAY NOZZLES

Special tools and workshop equipment required

1. Hose clamps up to 25 mm 3094
2. Drip tray

Scheme 41

Audi RS 5: Remove the front bumper cover. Refer to Removal and Installation .

Audi A5: Remove the air intake grille. Refer to Removal and Installation .

Open the cover -7- for the spray nozzle.

Press down the tension springs -4, 6- with a flathead screwdriver to release the spray nozzle -5-.

Remove the spray nozzle from the mount -3- towards the rear -arrow-.

Clamp off the windshield washer fluid hose -1- with hose clamps 3094.

Scheme 42

Note. Lay a cloth under the point of separation to catch any washer fluid.

Pull the release button -1- to remove the washer fluid hose -2-.

Note. If the spray nozzle cannot be removed depending on the vehicle equipment level, then remove the corresponding headlamp housing for the Audi A5. Remove the headlamp housing

1. Halogen Headlamps: through 10.08, refer to «HEADLAMP HOUSING»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) , after 11.08,, refer to «HEADLAMP HOUSING»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) , after MY 2012, refer to «HEADLAMP HOUSING»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
2. HID Headlamps: through MY 2011, refer to «HEADLAMP HOUSING»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__headlamp-housing) , after MY 2012, refer to «HEADLAMP HOUSING»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .

Scheme 43

Install in reverse order of removal, observing the following

The retaining springs -3- and -4- on the spray nozzle -2- can only engage audibly if the side guide -1- is seated correctly in the mount -5-.

Audi A5: Install the air intake grille. Refer to Removal and Installation .

Audi RS 5: Install the front bumper cover. Refer to Removal and Installation .

HEADLAMP WASHER FLUID RESERVOIR

Note. The shared windshield and headlamp washer system washer fluid reservoir is located in the left rear wheel housing. Removing and installing, refer to WINDSHIELD WASHER FLUID RESERVOIR .

SPECIAL TOOLS

Windshield wiper arm tool set T10369

Scheme 44

Pry lever 80 - 200

Scheme 45

Hose clamp pliers V.A.G 1921

Scheme 46

Hose clamps up to 25 mm 3094

Scheme 47

Drip tray

See also:
• General Information
• Removal and Installation
• Specifications
• Removal and Installation
• Removal and Installation
• HEADLAMP HOUSING
• HEADLAMP HOUSING
• HEADLAMP WASHER FLUID RESERVOIR, WASHER FLUID HOSE AND NOZZLE OVERVIEW
• HEADLAMP WASHER SYSTEM SPRAY NOZZLES
• WINDSHIELD WASHER SPRAY NOZZLES
• WIPER ARMS
• WIPER MOTOR WITH WINDSHIELD WIPER MOTOR CONTROL MODULE -J400
• WINDSHIELD WASHER FLUID RESERVOIR
• WINDSHIELD WASHER FLUID RESERVOIR FILLER NECK
• WIPER BLADES, REPLACING
• WINDSHIELD WASHER SPRAY NOZZLES, ADJUSTING
• WINDSHIELD WASHER PUMP -V5
• WINDSHIELD WASHER FLUID LEVEL SENSOR -G33
• HEADLAMP WASHER PUMP -V11
• CONTACT CORROSION
• WINDSHIELD WIPERS, BRINGING INTO SERVICE POSITION
