Exterior Lights, Switches (coupe) Audi A5 I

CONTACT CORROSION

Contact corrosion can occur if incorrect fasteners (bolts, nuts, washers, etc.) are used.

For this reason, only fasteners with a special surface coating are used.

In addition, rubber or plastic parts and adhesive consist of non-conductive materials.

If there are doubts as to whether parts are suitable or not, use new parts.

Note. We only recommend original replacement parts, they have been tested and are compatible with aluminum. We recommend using Audi accessories. Damage resulting from contact corrosion is not covered by warranty.

HEADLAMPS

Note. Headlamps must be adjusted after performing measures that could influence headlamp adjustment. Refer to HALOGEN HEADLAMP, ADJUSTING or HID HEADLAMP, ADJUSTING .

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

HID HEADLAMPS, USAGE AND SAFETY PRECAUTIONS

Refer to General Information

STEERING COLUMN SWITCH MODULE AND ELECTRONIC IGNITION LOCK

1. The steering column switch module consists of coil connector with slip ring, steering angle sensor -G85-, steering column switch (turn signal indicator switch, wiper switch, cruise control switch) and steering column electronic systems control module -J527-.
2. Fault finding is done in Guided Fault Finding using the Vehicle diagnostic tester.

ACCESS/START AUTHORIZATION SWITCH, CONNECTOR ASSIGNMENT

Connector mount

Scheme 1

3 - Not used

4 - Not used

5 - S-contact

6 - Terminal 15

7 - LIN

8 - Terminal 30

9 - Not used

10 - Not used

11 - Not used

12 - Not used

13 - RED2, terminal 15

14 - RED, terminal 15

15 - Ignition/starter switch +

16 - Terminal 31

Scheme 2

1. Right Headlamp Beam Adjustment Motor -V49- Various periods of time are determined depending on the model version. Removing and installing Through MY 2011, refer to «HEADLAMP BEAM ADJUSTMENT MOTORS -V48- / -V49»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) . From MY 2012, refer to «HEADLAMP BEAM ADJUSTMENT MOTORS -V48- / -V49»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
2. Control Module Vehicles without cornering lamp: Headlamp Range Control Module -J431-. Vehicles with cornering lamps: headlamp range/cornering lamp control module -J745-. Removing and installing, refer to «CONTROL MODULES -J431-, -J745»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__control-modules-j431-j745) . Integrated in the vehicle electrical system control module -J519- depending on the date of manufacture from MY 2012.
3. Electrical Connector
4. Left Rear Level Control System Sensor -G76- Component location: On rear left control arm. Removing and installing, refer to «Removal and Installation»(/audi/a5/i-2007-2011/remont/suspension-rear/#rear-suspension-coupe) .
5. Left Front Level Control System Sensor -G78- Component location: On left front control arm Depending on the date of manufacture Removing and installing, refer to «Removal and Installation»(/audi/a5/i-2007-2011/remont/suspension-front/#front-suspension-coupe) .
6. Left Headlamp Beam Adjustment Motor -V48- Various periods of time are determined depending on the model version. Removing and installing Through MY 2011, refer to «HEADLAMP BEAM ADJUSTMENT MOTORS -V48- / -V49»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) . From MY 2012, refer to «HEADLAMP BEAM ADJUSTMENT MOTORS -V48- / -V49»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .

BI-XENON HEADLAMPS WITH CORNERING LAMP OVERVIEW, THROUGH MY 2011

Observe notes on contact corrosion, refer to CONTACT CORROSION .

Note. Headlamps must be adjusted after performing measures that could influence headlamp adjustment. Refer to HID HEADLAMP, ADJUSTING .

Scheme 3

1. Headlamp Washer System Spray Nozzle
2. Mount For headlamp washer system washer fluid line
3. Screw Tightening specification, refer to «HEADLAMP HOUSING BRACKET AND MOUNT OVERVIEW - VEHICLES THROUGH MY 2011»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
4. Bracket Overview, refer to «HEADLAMP HOUSING BRACKET AND MOUNT OVERVIEW - VEHICLES THROUGH MY 2011»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
5. Screw Tightening specification, refer to «HEADLAMP HOUSING BRACKET AND MOUNT OVERVIEW - VEHICLES THROUGH MY 2011»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
6. Screw 1.4 Nm
7. Retaining Plate Removing and installing, refer to «HEADLAMP POWER OUTPUT STAGES -J667- / -J668»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__headlamp-power-output-stages-j667) .
8. Screw 1.4 Nm
9. HID Headlamp Control Module Left high-intensity gas discharge lamp control module -J343- Right high-intensity gas discharge lamp control module -J344- Removing and installing, refer to «HID LAMP CONTROL MODULE -J343- /J344»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__hid-lamp-control-module-j343-j344) .
10. Sealing Ring
11. Headlamp Housing Removing and installing, refer to «HEADLAMP HOUSING»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__headlamp-housing) . The left and right LED parking lamp/DRL modules -L176- / -L177-, the left and right low beam reflector motors -V294- / -V295- and the left and right dynamic cornering lamp motors -V318- / -V319- cannot be replaced separately.
12. Screw 4.5 Nm
13. Screw 4.5 Nm
14. Housing Cover For the front turn signal/parking lamp.
15. Front Turn Signal Lamp Left front turn signal lamp -M5- Right front turn signal lamp -M7- 12 V, 21 W (H21W) Bulb, replacing, refer to «FRONT TURN SIGNAL LAMP BULBS -M5- / -M7»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
16. Lamp Socket For the front turn signal
17. Parking Lamp Bulb Left parking lamp -M43- Right parking lamp -M44- Glass socket lamp 12V, 5 W Bulb, replacing, refer to «PARKING LAMP BULBS -M43- / -M44»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
18. Lamp Socket For the parking lamp bulb
19. Screw 4.5 Nm
20. Screw 4.5 Nm
21. Headlamp Housing Bracket
22. Speed Nut
23. Ball Joint For headlamp height adjustment
24. Adjusting Nut For headlamp height adjustment
25. Sealing Ring
26. Headlamp Range Control Positioning Motor Left headlamp beam adjustment motor -V48- Right headlamp beam adjustment motor -V49- Removing and installing, refer to «HEADLAMP BEAM ADJUSTMENT MOTORS -V48- / -V49»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
27. Housing Cover For low beam
28. Gas-Discharge Lamp With integrated ignition coil Left HID headlamp bulb -L13- Right HID headlamp bulb -L14- 42 V, 35 W (D3S) Bulb, replacing, refer to «HID HEADLAMP BULBS -L13- / -L14»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__hid-headlamp-bulbs-l13-l14) .
29. Lamp Socket For the front side marker lamp bulb
30. Front Side Marker Lamp Bulb Left front side marker lamp -M33- Right front side marker lamp -M34- 12V, 5 W Bulb, replacing, refer to «FRONT SIDE MARKER LAMP BULBS -M33- / -M34»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
31. Power Output Stage Only for vehicles with cornering lamps Left Headlamp Power Output Stage -J667- Right Headlamp Power Output Stage -J668- Removing and installing, refer to «HEADLAMP POWER OUTPUT STAGES -J667- / -J668»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__headlamp-power-output-stages-j667) .
32. Gasket
33. Screw Tightening specification, refer to «HEADLAMP HOUSING BRACKET AND MOUNT OVERVIEW - VEHICLES THROUGH MY 2011»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
34. Speed Nut
35. Mount Overview, refer to «HEADLAMP HOUSING BRACKET AND MOUNT OVERVIEW - VEHICLES THROUGH MY 2011»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
36. Screw Tightening specification, refer to «HEADLAMP HOUSING BRACKET AND MOUNT OVERVIEW - VEHICLES THROUGH MY 2011»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
37. Screw Tightening specification, refer to «Description and Operation»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe) .
38. Front Airbag Crash Sensor Removing and installing, refer to «Removal and Installation»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe) .

Scheme 4

Tighten the screws -1- and -3- to 6 Nm.

Scheme 5

1. Mirror Glass
2. Mirror Adjusting Unit Mount
3. Exterior Rearview Mirror Housing
4. Exterior Rearview Mirror Turn Signal Bulb Driver exterior mirror turn signal lamp -L131- Front Passenger exterior mirror turn signal lamp -L132- Removing and installing, refer to «EXTERIOR MIRROR TURN SIGNAL LAMPS -L131- / -L132-, THROUGH 05.09»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
5. Screw 0.9 Nm

Scheme 6

1. Mirror Glass
2. Mirror Adjusting Unit Mount
3. Exterior Rearview Mirror Housing
4. Exterior Rearview Mirror Turn Signal Bulb Driver exterior mirror turn signal lamp -L131- Front Passenger exterior mirror turn signal lamp -L132- Removing and installing, refer to «EXTERIOR MIRROR TURN SIGNAL LAMPS -L131- / -L132-, FROM 06.09»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
5. Screw 0.9 Nm

Scheme 7

1. Air Inlet Grille
2. Screw 4.5 Nm
3. Fog Lamp Bulb Left front fog lamp -L22- Right front fog lamp -L23- 12 V, 55 W (H11) Removing and installing, refer to «FOG LAMP BULBS -L22- / -L23-, THROUGH MY 2011»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
4. Electrical Connector
5. Fog Lamps Removing and installing, refer to «FOG LAMPS, THROUGH MY 2011»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
6. Screw 4.5 Nm

Scheme 8

1. Air Inlet Grille
2. Fog Lamps Different versions. Removing and installing, refer to «FOG LAMPS, FROM MY 2012»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
3. Screw 4.5 Nm Quantity: 3
4. Fog Lamp Bulb Left front fog lamp -L22- Right front fog lamp -L23- 12 V, 35 W (H8) Removing and installing, refer to «FOG LAMP BULBS -L22- / -L23-, FROM MY 2012»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .

HALOGEN HEADLAMPS OVERVIEW, THROUGH 10.08

Observe notes on contact corrosion, refer to CONTACT CORROSION .

Note. Headlamps must be adjusted after performing measures that could influence headlamp adjustment. Refer to HALOGEN HEADLAMP, ADJUSTING .

Scheme 9

1. Headlamp Washer System Spray Nozzle
2. Mount For headlamp washer system washer fluid line.
3. Screw Tightening specification, refer to «HEADLAMP HOUSING BRACKET AND MOUNT OVERVIEW - VEHICLES THROUGH MY 2011»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
4. Bracket Overview, refer to «HEADLAMP HOUSING BRACKET AND MOUNT OVERVIEW - VEHICLES THROUGH MY 2011»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
5. Screw Tightening specification, refer to «HEADLAMP HOUSING BRACKET AND MOUNT OVERVIEW - VEHICLES THROUGH MY 2011»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
6. Screw Tightening specification, refer to «HEADLAMP HOUSING BRACKET AND MOUNT OVERVIEW - VEHICLES THROUGH MY 2011»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
7. Headlamp Housing Removing and installing, refer to «HEADLAMP HOUSING»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
8. Screw 4.5 Nm
9. Housing Cover For the front turn signal and high beam/daytime running lamp.
10. Front Turn Signal Lamp Left front turn signal lamp -M5- Right front turn signal lamp -M7- 12V, 24 W Bulb, replacing, refer to «FRONT TURN SIGNAL LAMP BULBS -M5- / -M7»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
11. Lamp Socket For the front turn signal lamp
12. High Beam Headlamp/Daytime Running Lamps Left high beam headlamp -M30- Right high beam headlamp -M32- Left daytime running lamp -L174- Right daytime running lamp -L175- Daytime running lamp dimmed 70% 12 V, 55 W (H7) Bulb, replacing, refer to «LOW BEAM HEADLAMP -M30- / -M32- OR DAYTIME RUNNING LAMP BULBS -L174- / -L175»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
13. Screw 4.5 Nm
14. Adjustment Screw For headlamp height adjustment
15. Screw 4.5 Nm
16. Screw 4.5 Nm
17. Headlamp Housing Bracket
18. Speed Nut
19. Headlamp Range Control Positioning Motor Left headlamp beam adjustment motor -V48- Right headlamp beam adjustment motor -V49- Not for USA vehicles Removing and installing, refer to «HEADLAMP BEAM ADJUSTMENT MOTORS -V48- / -V49»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
20. Housing Cover For the low beam headlamp/parking lamp/side marker lamp.
21. Low Beam Headlamp Bulb Left low beam headlamp -M29- Right low beam headlamp -M31- 12 V, 55 W (H7) Bulb, replacing, refer to «LOW BEAM HEADLAMP BULB -M29- / -M31»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
22. Lamp Socket For the parking lamp/front side marker lamp bulb.
23. Parking Lamp/Front Side Marker Lamp Bulb Left parking lamp -M1- Right parking lamp -M3- Left front side marker lamp -M33- Right front side marker lamp -M34- 12V, 5 W Bulb, replacing, refer to «PARKING LAMP -M1- / -M3- OR FRONT SIDE MARKER LAMP BULBS -M33- / -M34»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
24. Speed Nut
25. Mount Overview, refer to «HEADLAMP HOUSING BRACKET AND MOUNT OVERVIEW - VEHICLES THROUGH MY 2011»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
26. Screw Tightening specification, refer to «HEADLAMP HOUSING BRACKET AND MOUNT OVERVIEW - VEHICLES THROUGH MY 2011»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
27. Screw Tightening specification, refer to «Description and Operation»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe) .
28. Front Airbag Crash Sensor Removing and installing, refer to «Removal and Installation»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe) .

TIGHTENING SPECIFICATION, HEADLAMP HOUSING REPAIR SET

Tighten the screws -1- and -3- to 6 Nm.

HALOGEN HEADLAMPS OVERVIEW, FROM 11.08

Observe notes on contact corrosion, refer to CONTACT CORROSION .

Note. Headlamps must be adjusted after performing measures that could influence headlamp adjustment. Refer to HALOGEN HEADLAMP, ADJUSTING .

Scheme 10

1. Headlamp Housing Removing and installing, refer to «HEADLAMP HOUSING»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
2. Screw 4.5 Nm
3. Front Turn Signal Lamp Left front turn signal lamp -M5- Right front turn signal lamp -M7- 12V, 24 W Bulb, replacing, refer to «FRONT TURN SIGNAL LAMP BULBS -M5- / -M7»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
4. Housing Cover For the front turn signal and high beam/daytime running lamp.
5. High Beam Headlamp/Daytime Running Lamp Bulb Left high beam headlamp -M30- Right high beam headlamp -M32- Left daytime running lamp -L174- Right daytime running lamp -L175- 12 V, 15/55 W (H15) Bulb, replacing, refer to «LOW BEAM HEADLAMP -M30- / -M32- OR DAYTIME RUNNING LAMP BULBS -L174- / -L175»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
6. Screw 4.5 Nm
7. Screw 4.5 Nm
8. Headlamp Housing Bracket
9. Speed Nut
10. Adjustment Screw For Headlamp height adjustment
11. Housing Cover For the low beam headlamp/parking lamp/side marker lamp.
12. Headlamp Range Control Positioning Motor Left headlamp beam adjustment motor -V48- Right headlamp beam adjustment motor -V49- Not for USA vehicles Removing and installing, refer to «HEADLAMP BEAM ADJUSTMENT MOTORS -V48- / -V49»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
13. Low Beam Headlamp Bulb Left low beam headlamp -M29- Right low beam headlamp -M31- 12 V, 55 W (H7) Bulb, Replacing, refer to «LOW BEAM HEADLAMP BULB -M29- / -M31»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
14. Lamp Socket For the parking lamp/front side marker lamp bulb.
15. Parking Lamp/Front Side Marker Lamp Bulb Left parking lamp -M1- Right parking lamp -M3- Left front side marker lamp -M33- Right front side marker lamp -M34- 12V, 5 W Bulb, replacing, refer to «PARKING LAMP -M1- / -M3- OR SIDE MARKER LAMP BULBS -M33- / -M34»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .

Tighten the screws -1- and -3- to 6 Nm.

HALOGEN HEADLAMPS OVERVIEW, FROM MY 2012

Note the information about contact corrosion, refer to CONTACT CORROSION .

Note. Headlamps must be adjusted after performing measures that could influence headlamp adjustment. Refer to HALOGEN HEADLAMP, ADJUSTING .

Part 1 - Headlamp Housing, Bulbs, Control Modules

Scheme 11

1. Sealing Frame Removing and installing, refer to «SEALING FRAME»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
2. Ventilation For headlamp housing
3. Inner Headlamp Housing Bracket Removing and installing, refer to «INNER HEADLAMP HOUSING BRACKET»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
4. Screw 4.5 Nm
5. Screw 6 Nm Quantity: 2
6. Front Turn Signal Lamp Left front turn signal lamp -M5- Right front turn signal lamp -M7- Removing and installing, refer to «FRONT TURN SIGNAL LAMP BULBS -M5- / -M7»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
7. Power Output Stage For The Front Side Marker Lamp Left front side marker lamp -M33- Right front side marker lamp -M34- Removing and installing, refer to «POWER OUTPUT STAGE FOR FRONT SIDE MARKER LAMP»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
8. High Beam Headlamp Bulb Left high beam headlamp -M30- Right high beam headlamp -M32- 12 V, 55 W (H7) Bulb, replacing, refer to «HIGH BEAM HEADLAMP BULBS -M30- / -M32»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
9. Screw 4.5 Nm
10. Housing Cover
11. Impact Screw For aligning headlamp housing to contour of chassis. Must rest against lock carrier.
12. Upper Bracket For The Headlamp Housing Removing and installing, refer to «UPPER HEADLAMP HOUSING BRACKET»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
13. Screw 4.5 Nm
14. Housing Cover
15. Low Beam Headlamp Bulb Left low beam headlamp -M29- Right low beam headlamp -M31- 12 V, 55 W (H7) Bulb, replacing, refer to «LOW BEAM HEADLAMP BULB -M29- / -M31»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
16. Speed Nut
17. Parking Lamp/Daytime Running Lamp Bulb Left Parking Lamp -M1- Right Parking Lamp -M3- Left daytime running lamp -L174- Right daytime running lamp -L175- 12 V, 26 W (PSX26W) Bulb, replacing, refer to «PARKING LAMP BULBS -M1- / -M3- OR DAYTIME RUNNING LAMP BULBS -L174- / -L175»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
18. Screw 4.5 Nm
19. Adjusting Element For adjusting the headlamp housing to the bumper contour.
20. Headlamp Housing Front side marker lamp bulb -M33- / -M34- depending on the country. Cannot be replaced separately. Removing and installing, refer to «HEADLAMP HOUSING»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .

Part 2 - Repair Kit

Scheme 12

1. Headlamp Housing Removing and installing, refer to «HEADLAMP HOUSING»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
2. Headlamp Beam Adjustment Motor Left Headlamp Beam Adjustment Motor -V48- Right Headlamp Beam Adjustment Motor -V49- Removing and installing, refer to «HEADLAMP BEAM ADJUSTMENT MOTOR -V48- / -V49»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__headlamp-beam-adjustment-motor-v48) .
3. Headlamp Beam Adjusting Motor Housing Cover The headlamp housing must be cut open to replace the positioning motor. A housing cover can be ordered to seal the assembly opening. Removing and installing, refer to «HEADLAMP BEAM ADJUSTMENT MOTOR -V48- / -V49»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__headlamp-beam-adjustment-motor-v48) .
4. Screw 2 Nm From the repair kit for the headlamp range control positioning motor cover. Quantity: 2
5. Screw 1.4 Nm Quantity: 2

Scheme 13

1. Headlamp Washer System Spray Nozzle
2. Mount For headlamp washer system washer fluid line
3. Screw 8 Nm
4. Bracket For the headlamp housing mount Removing and installing, refer to «HEADLAMP HOUSING MOUNT BRACKET»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
5. Screw 8 Nm
6. Ventilation For headlamp housing
7. Ventilation Hose For headlamp housing
8. Screw 4.5 Nm
9. Speed Nut
10. Mount For headlamp housing Removing and installing, refer to «HEADLAMP HOUSING MOUNT»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
11. Screw 4.5 Nm
12. Screw Tightening specification, refer to «Description and Operation»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe)
13. Front Airbag Crash Sensor Removing and installing, refer to «Removal and Installation»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe)

Scheme 14

1. Screw 8 Nm
2. Bracket For the headlamp housing mount. Removing and installing, refer to «HEADLAMP HOUSING MOUNT BRACKET»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
3. Adjusting Nut For adjustment of the front bumper cover contour
4. Screw 8 Nm
5. Screw 8 Nm
6. Mount For headlamp housing Removing and installing, refer to «HEADLAMP HOUSING MOUNT»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
7. Ventilation ose For headlamp housing
8. Screw 4.5 Nm Quantity: 2
9. Upper mount For headlamp housing Removing and installing, refer to «UPPER HEADLAMP HOUSING MOUNT - VEHICLES FROM MY 2012»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
10. Screw 4.5 Nm Quantity: 2
11. Speed nut Quantity: 2
12. Screw 4.5 Nm Quantity: 2

HID HEADLAMPS, OVERVIEW, FROM MY 2012

Observe notes on contact corrosion, refer to CONTACT CORROSION .

Note. Headlamps must be adjusted after performing measures that could influence headlamp adjustment. Refer to HID HEADLAMP, ADJUSTING .

Part 1 - Headlamp Housing, Bulbs, Control Modules

Scheme 15

1. Screw 1.5 Nm Quantity: 3
2. Daytime Running Lamp and Parking Lamp Control Module Daytime running lamp and left parking lamp control module -J860- Daytime running lamp and right parking lamp control module -J861- Removing and installing, refer to «DAYTIME RUNNING LAMP AND PARKING LAMP CONTROL MODULE -J860- / -J861»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__daytime-running-lamp-and-parking-lamp) .
3. Sealing Frame Removing and installing, refer to «SEALING FRAME»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
4. Ventilation For headlamp housing
5. Inner Headlamp Housing Bracket Removing and installing, refer to «INNER HEADLAMP HOUSING BRACKET»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
6. Screw 4.5 Nm
7. Screw 6 Nm Quantity: 2
8. Screw 1.5 Nm Quantity: 3
9. HID Headlamp Control Module Left High-intensity Gas Discharge Lamp Control Module -J343- Right High-intensity Gas Discharge Lamp Control Module -J344- Removing and installing, refer to «HIGH-INTENSITY GAS DISCHARGE LAMP CONTROL MODULE -J343- /J344»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__high-intensity-gas-discharge-lamp-control-module) .
10. Front Turn Signal Lamp Left front turn signal lamp -M5- Right front turn signal lamp -M7- 12 V, 24 W (F024MD) Bulb, replacing, refer to «FRONT TURN SIGNAL LAMP BULBS -M5- / -M7»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
11. Housing Cover
12. Screw 1.5 Nm Quantity: 3
13. Headlamp Power Output Stages Only for vehicles with cornering lamps. Left Headlamp Power Output Stage -J667- Right Headlamp Power Output Stage -J668- Removing and installing, refer to «HEADLAMP POWER OUTPUT STAGE -J667- / -J668»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__headlamp-power-output-stage-j667) .
14. Stationary Cornering Lamp Bulb Left stationary cornering lamp -M51- Right stationary cornering lamp -M52- 12 V, 55 W (H7) Bulb, replacing, refer to «STATIC CORNERING LAMP BULB -M51- / -M52»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
15. Impact Screw For aligning headlamp housing to contour of chassis. Must rest against lock carrier.
16. Screw 4.5 Nm
17. Upper Bracket Fro The Headlamp Housing Removing and installing, refer to «UPPER HEADLAMP HOUSING BRACKET»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
18. Screw 4.5 Nm
19. Speed Nut
20. Housing Cover
21. Gas-Discharge Lamp With integrated ignition coil Left high intensity gas discharge (HID) lamp -L13- Right high intensity gas discharge (HID) lamp -L14- 42 V, 35 W (D3S) Bulb, replacing, refer to «HID HEADLAMP BULBS -L13- / -L14»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
22. Screw 4.5 Nm
23. Adjusting Element For adjusting the headlamp housing to the bumper contour.
24. Headlamp Housing Left with left daytime running lamp and parking lamp LED module -L176-. Right with right LED daytime running lamp and parking lamp LED module -L177-. Front side marker lamp bulb -M33- / -M34- depending on the country. Cannot be replaced separately. Removing and installing, refer to «HEADLAMP HOUSING»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .

Part 2 - Repair Kit

Scheme 16

1. Headlamp Housing Removing and installing, refer to «HEADLAMP HOUSING»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
2. Headlamp Beam Adjustment Motor Left Headlamp Beam Adjustment Motor -V48- Right Headlamp Beam Adjustment Motor -V49- Removing and installing, refer to «HEADLAMP BEAM ADJUSTMENT MOTORS -V48- / -V49»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
3. Grommet The headlamp housing must be opened to replace the positioning motor. A grommet can be ordered to seal the assembly opening. Removing and installing, refer to «HEADLAMP BEAM ADJUSTMENT MOTORS -V48- / -V49»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
4. Screw 1.4 Nm Quantity: 2

Scheme 17

1. License Plate Lamp Different versions. Removing and installing, refer to «LICENSE PLATE LAMPS, 2-DOOR»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
2. License Plate Lamp Depending on the date of manufacture Left license plate lamp -X4- Right license plate lamp -X5- 12V, 5 W Bulb, replacing, refer to «LICENSE PLATE LAMPS, 2-DOOR»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
3. High Mounted Brake Lamp High-mounted brake lamp bulb -M25- Removing and installing, refer to «HIGH-MOUNTED BRAKE LAMP BULB, 2-DOOR»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .

Scheme 18

1. Left License Plate Lamp Different versions. Removing and installing, refer to «LICENSE PLATE LAMPS, 5-DOOR»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
2. Left License Plate Lamp Bulb -X4- Depending on the date of manufacture 12V, 5 W Bulb, replacing, refer to «LICENSE PLATE LAMPS, 5-DOOR»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe)
3. Nut Tightening specifications and sequence. Refer to «HIGH-MOUNT BRAKE LAMP AND LICENSE PLATE LAMPS, 5-DOOR OVERVIEW»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
4. Small Seal Self-adhesive Replace For the correct seals
5. Nut Tightening specifications and sequence. Refer to «HIGH-MOUNT BRAKE LAMP AND LICENSE PLATE LAMPS, 5-DOOR OVERVIEW»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
6. Small Seal Self-adhesive Replace For the correct seals
7. High Mounted Brake Lamp With high-mounted brake lamp bulb -M25- Removing and installing, refer to «HIGH-MOUNTED BRAKE LAMP BULB, 5-DOOR»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__high-mounted-brake-lamp-bulb-5-door) .
8. Small Seal Self-adhesive Replace For the correct seals
9. Nut Tightening specifications and sequence, refer to «HIGH-MOUNT BRAKE LAMP AND LICENSE PLATE LAMPS, 5-DOOR OVERVIEW»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
10. Small Seal Self-adhesive Replace For the correct seals
11. Nut Tightening specifications and sequence, refer to «HIGH-MOUNT BRAKE LAMP AND LICENSE PLATE LAMPS, 5-DOOR OVERVIEW»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
12. Large Seal Self-adhesive Replace For the correct seals
13. Nut Tightening specifications and sequence, refer to «HIGH-MOUNT BRAKE LAMP AND LICENSE PLATE LAMPS, 5-DOOR OVERVIEW»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
14. Right License Plate Lamp -X5- Depending on the date of manufacture 12V, 5 W Bulb, replacing, refer to «LICENSE PLATE LAMPS, 5-DOOR»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
15. Right License Plate Lamp Different versions. Removing and installing, refer to «LICENSE PLATE LAMPS, 5-DOOR»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .

Scheme 19

Tighten the nut to 2.5 Nm in the following sequence -1 to 5-.

Scheme 20

1. Inner Tail Lamp Removing and installing, refer to «INNER TAIL LAMPS»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
2. Gasket Replace if damaged
3. Tail Lamp and Fog Lamp Bulb Left rear parking/fog lamp bulb -M41- Right rear parking/fog lamp bulb -M42- 12V, 21 W Bulb, replacing, refer to «REAR PARKING/FOG LAMPS AND BACK-UP LAMPS 2»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__rear-parkingfog-lamps-and-back-up-lamps) .
4. Lamp Socket Removing and installing, refer to «REAR PARKING/FOG LAMPS AND BACK-UP LAMPS 2»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__rear-parkingfog-lamps-and-back-up-lamps) .
5. Large Clamping Bracket For securing tail lamp to the rear lid.
6. Nut 4 Nm
7. Nut 4 Nm
8. Small Clamping Bracket For securing tail lamp to the rear lid.
9. Left Back-Up Lamp 2 Left back-up lamp 2 bulb -M76- Right back-up lamp 2 bulb -M77- 12V, 18 W W16W Bulb, replacing, refer to «REAR PARKING/FOG LAMPS AND BACK-UP LAMPS 2»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__rear-parkingfog-lamps-and-back-up-lamps) .

Scheme 21

1. Outer Tail Lamps Removing and installing, refer to «OUTER TAIL LAMPS»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
2. Left Back-Up Lamp Left back-up lamp bulb -M16- Right back-up lamp bulb -M17- 12V, 18 W W16W Bulb, replacing, refer to «BULB SOCKET»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
3. Brake, Turn Signal and Tail Lamp Bulb Left brake/turn signal/tail lamp bulb -M69- Right brake/turn signal/tail lamp bulb -M70- 12V, 21 W Bulb, replacing, refer to «BULB SOCKET»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
4. Rear Side Marker Lamp Bulb Left rear side marker lamp bulb -M37- Right rear side marker lamp bulb -M38- Integrated in the bulb socket Removing and installing, refer to «REAR SIDE MARK LAMPS»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__rear-side-mark-lamps) .
5. Lamp Socket For bulbs Removing and installing, refer to «BULB SOCKET»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
6. Brake, Turn Signal and Tail Lamp Bulb Left brake lamp/turn signal/tail lamp bulb 2 -M72- Right brake lamp/turn signal/tail lamp bulb 2 -M73- 12V, 21 W Bulb, replacing, refer to «BULB SOCKET»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
7. Threaded Studs 3.5 Nm
8. Screw 1.7 Nm
9. Cover

Scheme 22

1. Outer Tail Lamps Removing and installing, refer to «OUTER TAIL LAMPS»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__outer-tail-lamps) .
2. Left Back-Up Light Left back-up lamp -M16- Right Back-Up Lamp -M17- 12V, 18 W W16W Bulb, replacing, refer to «BULB SOCKET»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__bulb-socket) .
3. O-ring
4. Rear Side Marker Lamp Bulb Left rear side marker lamp -M37- Right rear side marker lamp -M38- Integrated in the bulb socket Cannot be replaced separately if faulty.
5. Bulb Socket Central Connector Bulb socket, removing and installing, refer to «BULB SOCKET»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__bulb-socket) .
6. Threaded Studs 3.5 Nm

Scheme 23

1. Inner Tail Lamp Removing and installing Audi A5, refer to «INNER TAIL LAMPS»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__inner-tail-lamps) . Audi RS 5, refer to «INNER TAIL LAMPS»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
2. Gasket Replace if damaged
3. Rear Fog Lamp Bulb Left rear fog lamp bulb -L46- Right rear fog lamp bulb -L47- 12V, 21 W Changing bulbs Audi A5, refer to «REAR FOG LAMP BULB»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__rear-fog-lamp-bulb) . Audi RS 5, refer to «REAR FOG LAMP BULB»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
4. O-ring
5. Large Clamping Bracket For securing tail lamp assembly to the rear lid.
6. Nut 4 Nm
7. Central Connector For lamp sockets
8. Nut 4 Nm
9. Small Clamping Bracket For securing tail lamp assembly to the rear lid.
10. O-ring
11. Left Back-Up Lamp Left back-up lamp bulb -M16- Right back-up lamp bulb -M17- 12V, 18 W W16W Changing bulbs Audi A5, refer to «BACKUP LAMP BULB -M16- / -M17»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__backup-lamp-bulb-m16-m17) . Audi RS 5, refer to «BACKUP LAMP BULB -M16- / -M17»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .

Scheme 24

1. Outer Tail Lamps Removing and installing, refer to «OUTER TAIL LAMPS»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
2. Left Back-Up Light Left back-up lamp -M16- Right Back-Up Lamp -M17- 12V, 18 W W16W Bulb, replacing, refer to «BACKUP LAMP BULB -M16- / -M17»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
3. Lamp Socket Removing and installing, refer to «BACKUP LAMP BULB -M16- / -M17»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
4. Threaded Studs 3.5 Nm

Scheme 25

1. Inner Tail Lamps Removing and installing, refer to «INNER TAIL LAMPS»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe).
2. Gasket Replace if damaged
3. Lower Clamping Bracket To secure the tail lamp to the rear lid.
4. Nut Tightening specifications and sequence (Scheme 26)
5. Upper Clamping Bracket To secure the tail lamp to the rear lid.
6. Nut Tightening specifications and sequence (Scheme 26)
7. Nut Tightening specifications and sequence (Scheme 26)
8. Large Clamping Bracket To secure the tail lamp to the rear lid.

Scheme 26

Tighten the nuts to 4 Nm in sequence -1, 2 and 3-.

Scheme 27

1. Right Front Center Parking Aid Sensor -G253- Removing and installing: Audi A5 through MY 2011, refer to «FRONT PARKING AID SENSORS -G252- / -G253- / -G254- / -G255-, THROUGH MY 2011»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) . Audi A5 from MY 2012, refer to «FRONT PARKING AID SENSOR -G252- / -G253- / -G254- / -G255-, FROM MY 2012»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) . Audi RS 5, refer to «FRONT PARKING AID SENSORS -G252- / -G253- / -G254- / -G255»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
2. Right Front Parking Aid Sensor -G252- Removing and installing: Audi A5 through MY 2011, refer to «FRONT PARKING AID SENSORS -G252- / -G253- / -G254- / -G255-, THROUGH MY 2011»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) . Audi A5 from MY 2012, refer to «FRONT PARKING AID SENSOR -G252- / -G253- / -G254- / -G255-, FROM MY 2012»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) . Audi RS 5, refer to «FRONT PARKING AID SENSORS -G252- / -G253- / -G254- / -G255»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
3. Parking Aid Button -E266- Only with 8-channel parking aid Component location, refer to «PARKING AID OVERVIEW»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
4. Rear Parking Aid Warning Buzzer -H15- 2-door Removing and installing, refer to «REAR PARKING AID WARNING BUZZER -H15-, 2-DOOR»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) . 5-door Removing and installing, refer to «REAR PARKING AID WARNING BUZZER -H15-, 5-DOOR»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
5. Parking Aid Control Module -J446- Vehicles without a trailer hitch Removing and installing, refer to «PARKING AID CONTROL MODULE -J446-, WITHOUT TRAILER HITCH»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__parking-aid-control-module-j446-without) Vehicles with a trailer hitch or a spoiler Removing and installing, refer to «PARKING AID CONTROL MODULE -J446-, WITH TRAILER HITCH»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__parking-aid-control-module-j446-with) .
6. Right Rear Parking Aid Sensor -G206- Removing and installing, refer to «REAR PARKING AID SENSORS -G203- / -G204- / -G205- / -G206-, 2-DOOR»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
7. Right Rear Parking Aid Sensor -G206- 2-door Removing and installing, refer to «REAR PARKING AID SENSORS -G203- / -G204- / -G205- / -G206-, 2-DOOR»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) . 5-door Removing and installing, refer to «REAR PARKING AID SENSORS -G203- / -G204- / -G205- / -G206-, 5-DOOR»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
8. Right Rear Center Parking Aid Sensor -G205- 2-door Removing and installing, refer to «REAR PARKING AID SENSORS -G203- / -G204- / -G205- / -G206-, 2-DOOR»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) . 5-door Removing and installing, refer to «REAR PARKING AID SENSORS -G203- / -G204- / -G205- / -G206-, 5-DOOR»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
9. Left Rear Center Parking Aid Sensor -G204- 2-door Removing and installing, refer to «REAR PARKING AID SENSORS -G203- / -G204- / -G205- / -G206-, 2-DOOR»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) . 5-door Removing and installing, refer to «REAR PARKING AID SENSORS -G203- / -G204- / -G205- / -G206-, 5-DOOR»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
10. Left Rear Parking Aid Sensor -G203- 2-door Removing and installing, refer to «REAR PARKING AID SENSORS -G203- / -G204- / -G205- / -G206-, 2-DOOR»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) . 5-door Removing and installing, refer to «REAR PARKING AID SENSORS -G203- / -G204- / -G205- / -G206-, 5-DOOR»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
11. Front Parking Aid Warning Buzzer -H22- Only with 8-channel parking aid Removing and installing, refer to «FRONT PARKING AID WARNING BUZZER -H22-, 8-CHANNEL PARKING AID»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
12. Left Front Parking Aid Sensor -G255- Removing and installing: Audi A5 through MY 2011, refer to «FRONT PARKING AID SENSORS -G252- / -G253- / -G254- / -G255-, THROUGH MY 2011»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) . Audi A5 from MY 2012, refer to «FRONT PARKING AID SENSOR -G252- / -G253- / -G254- / -G255-, FROM MY 2012»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) . Audi RS 5, refer to «FRONT PARKING AID SENSORS -G252- / -G253- / -G254- / -G255»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
13. Left Front Center Parking Aid Sensor -G254- Removing and installing: Audi A5 through MY 2011, refer to «FRONT PARKING AID SENSORS -G252- / -G253- / -G254- / -G255-, THROUGH MY 2011»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) . Audi A5 from MY 2012, refer to «FRONT PARKING AID SENSOR -G252- / -G253- / -G254- / -G255-, FROM MY 2012»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) . Audi RS 5, refer to «FRONT PARKING AID SENSORS -G252- / -G253- / -G254- / -G255»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .

Component location Parking Aid Button -E266

Scheme 28

1. In switch unit in center console -arrow-.
2. Removing and installing vehicles with MMI Basic, refer to «CENTER CONSOLE BUTTON UNIT, MMI BASIC»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#interior-lights-switches-coupe) , vehicles with MMI Comfort, refer to «INSTRUMENT PANEL BUTTON UNIT, WITH MMI COMFORT EQUIPMENT»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#interior-lights-switches-coupe__instrument-panel-button-unit-with-mmi) .

Note. The illustration shows the Comfort multimedia control head -E380-.

Scheme 29

1. Nut - 3 Nm
2. Parking aid control module retaining frame
3. Nut - 3 Nm
4. Cable ties

Scheme 30

1. Screw 0.5 Nm
2. Transport Protection
3. Steering Column Electronic Systems Control Module -J527- CAUTION: Risk of damaging coil connector. Coil connector with slip ring is not to be turned following removal. With airbag spiral spring/return spring with slip ring -F138-, steering angle sensor -G85- Removing and installing, refer to «STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE -J527»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__steering-column-electronic-systems-control-module) . Connector assignment of Steering Column Electronic Systems Control Module -J527-. Refer to «STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE CONNECTOR ASSIGNMENT -J527»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__steering-column-electronic-systems-control-module) .
4. Mount With turn signal switch -E2-, windshield wiper/washer switch -E22-. On vehicles with cruise control with cruise control switch -E45-. Removing and installing, refer to «TURN SIGNAL SWITCH, CRUISE CONTROL SWITCH AND WINDSHIELD WIPER AND WASHER INTERMITTENT SWITCH»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
5. Clamping Ring
6. Screw 4 Nm
7. Steering Column
8. Access/Start Authorization Switch -E415- Removing and installing, refer to «ACCESS/START AUTHORIZATION SWITCH»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__accessstart-authorization-switch) .
9. Divider For access/start authorization switch Removing and installing, refer to «ACCESS/START AUTHORIZATION SWITCH»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__accessstart-authorization-switch) .
10. Ignition Key

Scheme 31

Tighten the bolt -2- on the access/start authorization switch -item 1- to 3 Nm.

STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE CONNECTOR ASSIGNMENT -J527

1. The Steering Column Electronic Systems Control Module -J527- is part of the complete system steering column switch module and receives signals from steering column switch, for example.
2. Check the steering column electronic systems control module -J527- in "Guided Fault Finding" using the Vehicle diagnostic tester.

Scheme 32

1. A - Connector Mount Turn Signal Switch/Cruise Control 1 - Cruise control lever ground 2 - Cruise control set 3 - ACC 4 - Cruise control Res (+)/Set (-) 5 - Voltage supply (terminal 15) 6 - Cruise control ground/turn signal switch 7 - Cruise control off 8 - Cruise control Res/Soft 9 - Radio (AIA) 10 - Headlamp flasher 11 - High beams 12 - Turn signal switch 13 - Ground, turn signal switch
2. B - Spiral Spring/Airbag/Multifunction Steering Wheel/Signal Horn Connector Mount 1 - ground 2 - Horn signal 3 - Airbag 1 + 4 - Airbag 1 - 5 - Airbag 2 + 6 - Airbag 2 - 7 - Tip down 8 - Terminal 30 9 - LIN 10 - Tip up 11 - Dimming (terminal 58s) 12 Tip ground
3. C - Connector Mount, Airbag Control Module 3 - Airbag 1 - 4 - Airbag 1 + 5 - Airbag 2 + 6 - Airbag 2
4. D - Electrical System Connector Mount 1 - Not used 2 - Not used 3 - Voltage supply terminal 30 4 - Powertrain CAN bus shielding 5 - Cruise control latched Off 6 - Not used 7 - Radio/radio button 8 - Comfort CAN bus Low 9 - Comfort CAN bus High 10 - Voltage supply terminal 31 11 - Powertrain CAN bus High 12 - Powertrain CAN bus Low 13 - Signal, electronic ignition switch, terminal 15 14 - Not used 15 - Not used 16 - Not used
5. E - Connector Mount Wiper System/DIS 1 - Windshield washer ground 2 - Windshield wiper switch 3 - Wash 4 - DIS signal 5 - Intermittent wipe potentiometer 6 - DIS ground

FASTENER TIGHTENING SPECIFICATIONS

HALOGEN HEADLAMP, ADJUSTING

Checking and Adjusting Conditions

1. Tire pressure OK
2. The headlamp lens must be clean and dry.
3. The headlamp lens may not be damaged.
4. Headlamp reflectors and bulbs OK.
5. Vehicle load must be created.

Vehicle load on driver's seat in otherwise unloaded vehicle (curb weight).

1. One person or 75 kg (165 lb.).

The curb weight is the weight of the operational vehicle with completely full fuel tank, including the weight of all equipment carried in operation.

1. Fuel tank: at least 90% full.
2. Equipment: for example, spare wheel, tools, vehicle jack, fire extinguisher, etc.

If the fuel tank is not at least 90% full, the load must be created as follows.

Check fuel tank fill lever in instrument cluster tank gauge and compare with the following table. Place additional weight in the luggage compartment, if necessary.

Note. Use fuel containers filled with water as additional weight (a 5 liter (1.3 gal.) fuel container filled with water weighs 5 kg (11 lb.).

Scheme 33

Scheme 34

1. Roll the vehicle several yards or move it back and forth several times to seat the springs.
2. The electromechanical parking brake must not be engaged so vehicle is not under stress.
3. Vehicle and headlamp adjusting unit must be on a level surface.
4. The headlamp adjusting unit must be aligned to the vehicle. Refer to the Headlamp adjusting unit instructions.
5. The headlamp adjuster must be distance -a- 30 to 70 cm (12 to 27.5 in.) in front of the headlamp and should not deviate more than dimension -b- = 3 cm from the headlamp center point.
6. The inclination dimension is set on the headlamp adjusting unit. Refer to Headlamp adjusting unit operating instructions.
7. The angle dimension -arrow- is stamped on the upper edge of the headlamp -1- in "%".

Note. The headlamp must be adjusted according to the angle dimension stamped on the headlamp. The percentage indicator is based on a 10 meter projection distance. At an angle dimension of 1.0%, for example, converts to 10 cm (4 in.).

Procedure

The vehicles must be standing on a flat surface.

Turn the headlamp switch to "low beam" - not "Auto".

Set the range position thumbwheel to the "0" position.

Headlamp adjustment

Scheme 35

1. The horizontal light-dark border must touch the dividing line -1- on the adjusting unit test surface.
2. The point -2- between the left horizontal part and the right vertical part of the light-dark border must run vertically through the central mark -3-. The bright core of the light beam must be to the right of the vertical.

Note. To determine the point -2- more easily, cover and uncover the left half of the headlamp several times. Then check low beam again. After correct headlamp adjustment, the center of the high beam light beam must be on the central marking -3-.

To adjust the height of the headlamp, set the light-dark border just under the dividing line with the adjustment screw -1-.

Scheme 36

Then adjust the light-dark border, starting from the bottom, on the dividing line.

For side adjustment, turn adjusting screw -2-.

Note. The allocation on the right headlamp is reversed.

HID HEADLAMP, ADJUSTING

Checking and Adjusting Conditions

1. Tire pressure OK
2. The headlamp lens must be clean and dry.
3. The headlamp lens may not be damaged.
4. Headlamp reflectors and bulbs OK.

Vehicle load on driver's seat in otherwise unloaded vehicle (curb weight).

1. One person or 75 kg (165 lb.).

The curb weight is the weight of the operational vehicle with completely full fuel tank, including the weight of all equipment carried in operation.

1. Fuel tank: at least 90% full.
2. Equipment: for example, spare wheel, tools, vehicle jack, fire extinguisher, etc.

If the fuel tank is not at least 90% full, the load must be created as follows.

Check fuel tank fill lever in instrument cluster tank gauge and compare with the following table. Place additional weight in the luggage compartment, if necessary.

Note. Use fuel containers filled with water as additional weight (a 5 liter (1.3 gal.) fuel container filled with water weighs 5 kg (11 lb.).

1. Roll the vehicle several yards or move it back and forth several times to seat the springs.
2. The electromechanical parking brake must not be engaged so vehicle is not under stress.
3. Vehicle and headlamp adjusting unit must be on a level surface.
4. The headlamp adjusting unit must be aligned to the vehicle. Refer to the Headlamp adjusting unit instructions.
5. The headlamp adjuster must be distance -a- 30 to 70 cm (12 to 27.5 in.) in front of the headlamp and should not deviate more than dimension -b- = 3 cm from the headlamp center point.
6. The inclination dimension is set on the headlamp adjusting unit. Refer to the Headlamp adjusting unit operating instructions.
7. The angle dimension -arrow- is stamped on the upper edge of the headlamp -1- in "%".

Note. The headlamp must be adjusted according to the angle dimension stamped on the headlamp. The percentage indicator is based on a 10 meter projection distance. At an angle dimension of 1.0%, for example, converts to 10 cm.

Procedure

The vehicles must be standing on a flat surface.

Turn the headlamp switch to "low beam" - not "Auto".

Close all the doors and the rear lid and keep them closed for the duration of the testing/adjusting procedure.

To prepare for the headlamp adjustment, in "Guided Functions", select "basic setting" on the Vehicle Diagnostic Tester.

Note. The headlamps move into the basic setting with this program.

Select the function or path

During the program, you will be asked to perform a headlamp adjustment.

Headlamp adjustment

1. The horizontal light-dark border must touch the dividing line -1- on the adjusting unit test surface.
2. The point -2- between the left horizontal part and the right vertical part of the light-dark border must run vertically through the central mark -3-. The bright core of the light beam must be to the right of the vertical.

Note. To determine the point -2- more easily, cover and uncover the left half of the headlamp several times. Then check low beam again. After correct headlamp adjustment, the center of the high beam light beam must be on the central marking -3-.

To adjust the height of the headlamp, set the light-dark border just above the dividing line with the adjustment screw -1-.

Then adjust the light-dark border, starting from the top, on the dividing line.

For side adjustment, turn adjusting screw -2-.

Note. The allocation on the right headlamp is reversed.

After the headlamp is adjusted, complete the "basic setting". Switch off the ignition and disconnect the diagnostic connector.

FOG LAMPS, ADJUSTING

Checking and Adjusting Conditions

1. Tire pressure OK.
2. The fog lamp lens must be clean and dry.
3. The fog lamp lens may not be damaged.
4. Fog lamp-reflector and lamp OK.
5. Roll the vehicle several yards or move it back and forth several times to seat the springs.
6. Parking brake must not be engaged so vehicle is not under stress.
7. Vehicle and headlamp adjusting unit must be on a level surface.
8. The headlamp adjusting unit must be aligned to the vehicle. Refer to the Headlamp adjusting unit instructions.
9. The inclination dimension is set on the headlamp adjusting unit. Refer to the Headlamp adjusting unit operating instructions.
10. Vehicle load must be created.

Vehicle load on driver's seat in otherwise unloaded vehicle (curb weight).

1. One person or 75 kg (165 lb.).

Procedure

The vehicles must be standing on a flat surface.

Turn the headlamp switch to "low beam" - not "Auto".

Pull the headlamp switch to "fog lamp".

During the program, you will be asked to perform a headlamp adjustment.

Fog lamp adjustment

Scheme 37

To adjust fog lamp range, turn adjusting screw -arrow-.

1. Angle dimension: 2%.

Note. The percentage indicator is based on a 10 meter projection distance. At an angle dimension of 2.0%, for example, converts to 20 cm (7 in.). Side adjustment is not intended.

AUXILIARY HEADLAMPS, ADJUSTING

Retrofitted auxiliary headlamps must be checked and adjusted according to the guidelines used for other systems.

ACCESS/START AUTHORIZATION SWITCH

Special tools and workshop equipment required

1. Special pliers VAS 6339

Note. Induction coil for immobilizer is secured to access/start authorization switch -E415- and cannot be replaced separately. If induction coil is malfunctioning, access/start authorization switch must be replaced. If access/start authorization switch is replaced, no adaptation of immobilizer is necessary. Lock in access/start authorization switch is not coded mechanically. Keys must therefore not be replaced when access/start authorization switch is replaced; present keys continue to match.

REMOVING

Remove the driver side instrument panel cover. Refer to Removal and Installation .

On USA vehicles, remove the right impact bar. Refer to Removal and Installation .

Remove the MMI screen cover. Refer to Removal and Installation .

Remove the instrument cluster gap cover. Refer to Removal and Installation .

Remove the bolt -2- for the trim -1-.

Scheme 38

Insert the VAS 6339 through the trim flaps.

Scheme 39

Position the tips of the VAS 6339 on both holes -A arrows- on the access/start authorization switch -E415- -2-.

Press the VAS 6339 together -B arrows- to spread the tips of the pliers and release the trim retaining tabs.

Hold the VAS 6339 pressed with one hand and remove the trim -1- with the other hand -arrow C-.

Note. Only use the VAS 6339 to release. Remove the trim by hand.

Remove bolt -2-.

Scheme 40

Remove the access/start authorization switch -1- from the instrument panel and into the passenger compartment.

Disconnect the connector -3- by sliding the retainer -4- up -arrow- and pressing the release.

INSTALLING

1. Tightening specification, refer to «STEERING COLUMN SWITCH MODULE AND ELECTRONIC IGNITION LOCK OVERVIEW»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .

Install in reverse order of removal, observing the following

Install the instrument cluster gap cover. Refer to Removal and Installation .

Install the MMI screen cover. Refer to Removal and Installation .

On USA vehicles, install the right impact bar. Refer to Removal and Installation .

Install the driver side instrument panel cover. Refer to Removal and Installation .

Scheme 41

Remove headlamp housings. Refer to HEADLAMP HOUSING .

Release spring clip -arrow- and remove gas discharge lamp housing cover -1- from headlamp housing.

Remove the light bulb and socket -1- from the reflector -arrow-.

Scheme 42

Remove the side marker lamp bulb -2- from the socket.

Install in reverse order of removal, observing the following

Insert the new bulb into the socket without touching the bulb with bare hands.

Push socket into reflector until it engages noticeably.

Close the housing cover and secure it the spring clip.

Install the headlamp housing. Refer to HEADLAMP HOUSING .

Scheme 43

Remove headlamp housings. Refer to HEADLAMP HOUSING .

Remove the turn signal/parking lamp housing cover -1- from the headlamp housing -arrow-.

Turn socket -1- counterclockwise -arrow- and remove from housing.

Scheme 44

Remove the bulb -2- from the socket -1-.

Scheme 45

Scheme 46

Install in reverse order of removal, observing the following

Insert the new bulb in the socket without touching the bulb with bare hands.

Close the housing cover -1-. When doing this, the strap -2- must align with the mark -3- on the headlamp housing.

Install the headlamp housing. Refer to HEADLAMP HOUSING .

Remove headlamp housings. Refer to HEADLAMP HOUSING .

Release spring clip -arrow- and remove gas discharge lamp housing cover -1- from headlamp housing.

Turn the headlamp height adjustment screw -3- clockwise as far as the stop -arrow-.

Scheme 47

1. This guides the lamp unit in the headlamp into the high position.

Disconnect the electrical connector -2-.

Rotate the positioning motor -1- on the left headlamp clockwise and the one on the right headlamp counterclockwise.

Disengage positioning motor from headlamp housing.

Note. Positioning motor axle should not be disengaged from headlamp

Pull the adjusting motor -1- back gently until the motor axle can be removed from the headlamp lamp unit ball joint -3-.

Scheme 48

1. Axle pins are then in ball joint cut-outs -arrows-.

Remove the adjustment motor from the headlamp housing.

Note. Components are shown without headlamp housing to provide a better illustration.

1. Tightening specification, refer to «BI-XENON HEADLAMPS WITH CORNERING LAMP OVERVIEW, THROUGH MY 2011»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__bi-xenon-headlamps-with-cornering-lamp-overview) .

Install in reverse order of removal, observing the following

Make sure the ball joint -3- is inside the guide for the headlamp light unit.

Pull headlamp light unit in headlamp housing toward back and hold it firmly.

Engage the adjusting motor axle pins in the ball joint.

1. The axle pins must engage in cut-outs on ball joint -arrows-.

Position the quick release on the adjusting motor on the headlamp housing.

Engage the adjusting motors -1- by rotating counterclockwise on the left headlamp and clockwise on the right headlamp.

Connect the electrical connector -2- to the adjusting motor.

Note. Ignore the -arrow- and -item 3-.

Close the housing cover and secure it the spring clip.

Install the headlamp housing. Refer to HEADLAMP HOUSING .

HEADLAMP HOUSING

Scheme 49

With ignition switched off, disconnect battery ground wire. Refer to BATTERY, DISCONNECTING AND CONNECTING .

Remove the lock carrier cover. Refer to Removal and Installation .

Disconnect the electrical connector -4-.

Remove the screws -2- and -5-.

Loosen the lower bolt -3- on the headlamp housing using a long wrench.

Note. Ignore items -6 and 7-.

Remove headlamp -1- toward front from body.

Scheme 50

1. Tightening specification, refer to «HALOGEN HEADLAMPS OVERVIEW, THROUGH 10.08»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__halogen-headlamps-overview-through-1008) .

Install in reverse order of removal, observing the following

When inserting the headlamp -2- into the mount -1-, make sure the guide tracks on the headlamp engage in the guides on the mount -arrows-.

1. Headlamp must slide gently into mount and without using force.

When sliding the headlamp -4- in, make sure the headlamp ventilation -3- slides evenly into the mount -2- for the ventilation hose -1- -arrow-.

Scheme 51

Tighten the screws -2, 3 and 5-.

Install the lock carrier cover. Refer to Removal and Installation .

Connect battery. Required actions, refer to BATTERY, DISCONNECTING AND CONNECTING .

HEADLAMP HOUSING REPAIR SET, INSTALLING

Note. Headlamp mounting tabs that have broken off can be replaced by installing the repair set. Completely replacing the headlamp is not necessary. There are different repair kits for left and right headlamps. .

Procedure

1. Tightening specification, refer to «BI-XENON HEADLAMPS WITH CORNERING LAMP OVERVIEW, THROUGH MY 2011»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__bi-xenon-headlamps-with-cornering-lamp-overview) .

Remove headlamp with broken mounting tab. Refer to HEADLAMP HOUSING .

Remove remains of broken mounting tab at headlamp housing.

Place mounting straps -2- and -4- from repair kit on headlamp housing and secure tabs with straps -1- and -3-.

HEADLAMP POWER OUTPUT STAGES -J667- / -J668

Scheme 52

Remove headlamp housings. Refer to HEADLAMP HOUSING .

Remove the bolts -arrows-.

Remove the retaining plate -1-.

Remove the headlamp power output module -5- from the headlamp housing.

Scheme 53

Disconnect the connectors -1, 2 and 4-.

1. Tightening specification, refer to «BI-XENON HEADLAMPS WITH CORNERING LAMP OVERVIEW, THROUGH MY 2011»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__bi-xenon-headlamps-with-cornering-lamp-overview) .

Install in reverse order of removal, observing the following

Check the seal -3- between the power output stage and headlamp housing.

Install the headlamp housing. Refer to HEADLAMP HOUSING .

HID HEADLAMP BULBS -L13- / -L14

Remove headlamp housings. Refer to HEADLAMP HOUSING .

Release spring clip -arrow- and remove gas discharge lamp housing cover -1- from headlamp housing.

Disconnect the electrical connector -1-.

Scheme 54

Turn the locking ring -3- in -direction of arrow- and remove the HID bulb -2-.

Install in reverse order of removal, observing the following

Insert the new HID bulb into the housing without touching the bulb with bare hands.

1. Installation location, the electrical connection faces down.

Secure HID lamp with circlip.

Close the housing cover and secure it the spring clip.

Install the headlamp housing. Refer to HEADLAMP HOUSING .

HID LAMP CONTROL MODULE -J343- /J344

Scheme 55

Remove headlamp housings. Refer to HEADLAMP HOUSING .

Remove the bolts -arrows-.

Remove control module -1- from headlamp housing.

Disconnect the adapter cable -2- and the electrical connector -3- on the HID headlamp control module -1-.

Scheme 56

Remove the HID headlamp control module.

1. Tightening specification, refer to «BI-XENON HEADLAMPS WITH CORNERING LAMP OVERVIEW, THROUGH MY 2011»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__bi-xenon-headlamps-with-cornering-lamp-overview) .

Install in reverse order of removal, observing the following

Check seal -4- between gas discharge headlamp control module and headlamp housing for damage.

Install the headlamp housing. Refer to HEADLAMP HOUSING .

LED PARKING LAMP/DRL MODULES -L176- / -L177

The daytime running lamps and parking lamps are LED lamps and are integrated in the headlamp housing. The LEDs cannot be replaced. The entire headlamp must be replaced.

Replace the headlamp housing. Refer to HEADLAMP HOUSING .

LEFT AND RIGHT ADAPTIVE CORNERING LAMP MOTORS V318/V319

The dynamic cornering lamp position motor sits in the headlamp housing and cannot be replaced separately if it is faulty.

Replace the headlamp housing. Refer to HEADLAMP HOUSING .

LOW BEAM REFLECTOR MOTORS -V294- / -V295

The lower beam cover sits in the headlamp housing and cannot be replaced separately if it is faulty.

Replace the headlamp housing. Refer to HEADLAMP HOUSING .

Remove headlamp housings. Refer to HEADLAMP HOUSING .

Remove the turn signal/parking lamp housing cover -1- from the headlamp housing -arrow-.

Turn the turn signal socket -1- counterclockwise -arrow- and remove it from the housing.

Pull the socket -1- with the bulb out of the reflector in -the direction of the arrow-.

Scheme 57

Remove Parking Lamp from socket.

Install in reverse order of removal, observing the following

Insert the new bulb into the socket without touching the bulb with bare hands.

Push socket into reflector until it engages noticeably.

Close the housing cover -1-. When doing this, the strap -2- must align with the mark -3- on the headlamp housing.

Install the headlamp housing. Refer to HEADLAMP HOUSING .

CONTROL MODULES -J431-, -J745

The parking aid control module is integrated in the vehicle electrical system control module -J519- depending on the date of manufacture from MY 2012 and cannot be replaced separately if defective.

Replace the vehicle electrical system control module, refer to VEHICLE ELECTRICAL SYSTEM CONTROL MODULE -J519 .

If the control module was replaced, select the "Replace" function for the respective control module in Guided Fault Finding or Guided Functions using the Vehicle diagnostic tester.

Scheme 58

Remove the glove compartment. Refer to Removal and Installation .

Release the retaining clip -arrow- and remove the -1- from the retaining frame.

Disconnect the electrical connector -2-.

To disconnect electrical connector, press catch -1-, turn retaining bracket in -direction of arrow- and remove connector.

Scheme 59

Install in reverse order of removal, observing the following

Install the glove compartment. Refer to Removal and Installation .

Scheme 60

Remove the exterior mirror. Refer to Removal and Installation .

Note. To protect the paint in the area around the mirror housing, tape it off with a soft cloth.

Remove the bolts -4- and -5-.

Release the retaining tabs -3- in the -direction of arrow A-.

Release the retaining clip -1- and remove the exterior rearview mirror housing from the cover -2- -B arrows-.

Press the mirror adjusting unit down and remove the exterior rearview mirror housing upward.

Scheme 61

If applicable, disconnect the lane change assistance warning lamp electrical connector -2- on the front side of the mirror adjusting unit mount -3-.

Pull the exterior mirror housing upward and disconnect the electrical connector -3-.

Scheme 62

Remove screws -1- and -4-.

Tilt the turn signal housing -2- out of the exterior rearview mirror housing -arrow-.

Scheme 63

1. Tightening specifications, refer to «EXTERIOR REARVIEW MIRROR TURN SIGNALS OVERVIEW, THROUGH 05.09»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .

Install in reverse order of removal, observing the following

Note. The entire exterior mirror turn signal must be replaced if an LED is faulty.

Insert the tip of the turn signal in the slit in the exterior rearview mirror housing -3- -arrow A-.

Tilt the turn signal bulb housing -4- into the exterior rearview mirror housing -arrow B-. The locking tab -2- must engage in the mount -1-.

Install the exterior rearview mirror housing. Refer to Removal and Installation .

Scheme 64

Remove the mirror glass. Refer to Removal and Installation .

Note. To protect the paint in the area around the mirror housing, tape it off with a soft cloth.

Remove the screws -4- and -5-.

Open the clips -2- and remove the exterior mirror housing -3- from the cover -1- -arrows-.

On vehicles with lane change assist, pull the exterior mirror housing -1- just far enough until the connector is visible.

Scheme 65

Disconnect the electrical connector -2- for the lane change assist warning lamp on the front side of the mirror adjusting unit mount -3-.

Pull the exterior mirror housing -2- upward and disconnect the connector -3-.

Scheme 66

Remove screws -1- and -4-.

Tilt the turn signal housing -5- out of the exterior rearview mirror housing -arrow-.

Scheme 67

1. Tightening specifications, refer to «EXTERIOR REARVIEW MIRROR TURN SIGNALS OVERVIEW, FROM 06.09»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .

Install in reverse order of removal, observing the following

Note. The entire exterior mirror turn signal must be replaced if an LED is faulty.

Insert the tip of the turn signal -3- into the opening in the exterior mirror housing -4- -arrow-.

Place the turn signal bulb housing -2- into the outside mirror housing; make sure the groove fits into the guide -1-.

Install the exterior rearview mirror housing. Refer to Removal and Installation .

Scheme 68

Switch off ignition and remove ignition key.

Turn light switch into "0" position.

Remove the air intake grille. Refer to Removal and Installation .

Remove screws -1- and -2-.

Remove the fog lamp -3- from the bumper cover while guiding the retaining tab -arrow- out of the mount.

Disconnect the electrical connector.

1. Tightening specification, refer to «FOG LAMPS OVERVIEW, THROUGH MY 2011»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .

Install in reverse order of removal, observing the following

Install the air intake grille. Refer to Removal and Installation .

Adjusting fog lamps, refer to FOG LAMPS, ADJUSTING .

Scheme 69

Loosen the front area of the front wheel housing liner. Refer to Removal and Installation .

Disconnect the electrical connector -1- on the bulb.

Remove the vent hose -3- on the left side of the fog lamp.

Rotate the bulb -2- counterclockwise -arrow- and remove it from the fog lamp housing.

Install in reverse order of removal, observing the following

Insert the new bulb into the housing without touching the bulb with bare hands.

Rotate the bulb clockwise to secure.

Mount the vent hose on the left side of the fog lamp.

Install the front wheel housing liner. Refer to Removal and Installation .

Scheme 70

Switch off ignition and remove ignition key.

Turn light switch into "0" position.

Remove the air intake grille. Refer to Removal and Installation .

Remove the bolts -arrows-.

Remove the fog lamp -1- from the bumper cover.

Disconnect the connector.

1. Tightening specification, refer to «FOG LAMPS, OVERVIEW, FROM MY 2012»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .

Install in reverse order of removal. Note the following

Install the air intake grille. Refer to Removal and Installation .

Adjusting fog lamps, refer to FOG LAMPS, ADJUSTING .

Scheme 71

Remove fog lamp. Refer to FOG LAMPS, FROM MY 2012 .

Rotate the bulb -1- counterclockwise -arrow- and remove it from the fog lamp housing -2-.

Install in reverse order of removal. Note the following

Insert new bulb in the housing. Do not touch the glass bulbs with bare hands.

Rotate the bulb clockwise to secure.

Install fog lamp. Refer to FOG LAMPS, FROM MY 2012 .

Remove headlamp housings. Refer to HEADLAMP HOUSING .

Remove the high beam housing cover -1- from the headlamp housing -arrow-.

Turn socket -1- counterclockwise -arrow- and remove from housing.

Scheme 72

Remove the bulb -2- from the socket -1-.

Install in reverse order of removal, observing the following

Insert the new bulb into the housing without touching the bulb with bare hands.

Close the housing cover -1-. When doing this, the strap -2- must align with the mark -3- on the headlamp housing.

Install the headlamp housing. Refer to HEADLAMP HOUSING .

Remove headlamp housings. Refer to HEADLAMP HOUSING .

Release the wire clamp -arrow- and remove the low beam/daytime running lamp bulb housing cover -1- from the headlamp housing.

Turn the headlamp height adjustment screw -2- clockwise as far as the stop -arrow A-.

Scheme 73

1. This guides lamp unit in headlamp into low position.

Insert a screwdriver from behind into the headlamp housing -1- and press the headlamp height adjusting screw up out of the housing -arrow B-.

Disconnect the electrical connector -2-.

Scheme 74

Remove the headlamp range adjustment positioning motor -1- by the left headlamp clockwise -arrow A- and by the right headlamp counterclockwise.

Disengage positioning motor from headlamp housing.

Slide the adjusting axle ball head -4- out of the ball socket -3- by tilting the positioning motor -1- upward -arrow B-.

Press reflector forward and remove adjusting motor.

1. Tightening specification, refer to «HALOGEN HEADLAMPS OVERVIEW, THROUGH 10.08»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__halogen-headlamps-overview-through-1008) .

Install in reverse order of removal, observing the following

Insert the adjusting axle ball head into the reflector ball socket from above while pulling the reflector back.

Position the headlamp range adjustment positioning motor quick release on the headlamp housing.

Engage the headlamp range adjustment positioning motor counterclockwise on the left headlamp and clockwise on the right headlamp.

Connect the electrical connector on the headlamp range adjustment positioning motor.

Close the housing cover and secure it the spring clip.

Install the headlamp housing. Refer to HEADLAMP HOUSING .

Switch off ignition and remove ignition key.

Turn light switch into "0" position.

Remove the lock carrier cover. Refer to Removal and Installation .

Disconnect the electrical connector -4-.

Remove the screws -2- and -5-.

Loosen the lower bolt -3- on the headlamp housing using a long wrench.

Note. Ignore items -6 and 7-.

Remove headlamp -1- toward front from body.

1. Tightening specification, refer to «HALOGEN HEADLAMPS OVERVIEW, THROUGH 10.08»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__halogen-headlamps-overview-through-1008) .

Install in reverse order of removal, observing the following

When inserting the headlamp -2- into the mount -1-, make sure the guide tracks on the headlamp engage in the guides on the mount -arrows-.

1. Headlamp must slide gently into mount and without using force.

When sliding the headlamp -4- in, make sure the headlamp ventilation -3- slides evenly into the mount -2- for the ventilation hose -1- -arrow-.

Tighten the screws -2, 3 and 5-.

Install the lock carrier cover. Refer to Removal and Installation .

Note. Headlamp mounting tabs that have broken off can be replaced by installing the repair set. Completely replacing the headlamp is not necessary. There are different repair kits for left and right headlamps.

Procedure

1. Tightening specification, refer to «HALOGEN HEADLAMPS OVERVIEW, THROUGH 10.08»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__halogen-headlamps-overview-through-1008) .

Remove headlamp with broken mounting tab. Refer to HEADLAMP HOUSING .

Remove remains of broken mounting tab at headlamp housing.

Place mounting straps -2- and -4- from repair kit on headlamp housing and secure tabs with straps -1- and -3-.

Remove headlamp housings. Refer to HEADLAMP HOUSING .

Release spring clip -arrow- and remove low beam/daytime running lamp bulb housing cover -1- from headlamp housing.

Remove the bulb -2- from the spring clips.

Scheme 75

Disconnect the electrical connector -1- on the bulb.

Install in reverse order of removal, observing the following

Press the bulb into the housing past the spring clips.

Close the housing cover and secure it the spring clip.

Install the headlamp housing. Refer to HEADLAMP HOUSING .

Remove headlamp housings. Refer to HEADLAMP HOUSING .

Remove the high beam/turn signal housing cover -1- from the headlamp housing -arrow-.

Remove the bulb -1- from the spring clips.

Scheme 76

Disconnect the electrical connector -2- on the high beam bulb.

Install in reverse order of removal, observing the following

Insert the new bulb into the housing without touching the bulb with bare hands.

Position the bulb on the lower spring clip.

Press the bulb into the housing past the upper spring clips.

Close the housing cover -1-. When doing this, the strap -2- must align with the mark -3- on the headlamp housing.

Install the headlamp housing. Refer to HEADLAMP HOUSING .

Remove headlamp housings. Refer to HEADLAMP HOUSING .

Release the wire clamp -arrow- and remove the low beam/daytime running lamp bulb housing cover -1- from the headlamp housing.

Remove the lamp bulb and socket -1- from the reflector -arrow-.

Remove the parking lamp/front side marker lamp bulb -2- from the socket.

Install in reverse order of removal, observing the following

Insert the new bulb into the socket without touching the bulb with bare hands.

Push socket into reflector until it engages noticeably.

Close the housing cover and secure it the spring clip.

Install the headlamp housing. Refer to HEADLAMP HOUSING .

Remove headlamp housings. Refer to HEADLAMP HOUSING .

Remove the high beam housing cover -1- from the headlamp housing -arrow-.

Turn the bulb -1- counterclockwise -arrow- and remove it from the housing.

Scheme 77

Release the spring -3- and disconnect the connector -2- on the bulb.

Install in reverse order of removal, observing the following

Insert the new bulb into the housing without touching the bulb with bare hands.

Close the housing cover -1-. When doing this, the strap -2- must align with the mark -3- on the headlamp housing.

Install the headlamp housing. Refer to HEADLAMP HOUSING .

Remove headlamp housings. Refer to HEADLAMP HOUSING .

Release the wire clamp -arrow- and remove the low beam/daytime running lamp bulb housing cover -1- from the headlamp housing.

Turn the headlamp height adjustment screw -2- clockwise as far as the stop -arrow A-.

1. This guides lamp unit in headlamp into low position.

Insert a screwdriver from behind into the headlamp housing -1- and press the headlamp height adjusting screw up out of the housing -arrow B-.

Disconnect the electrical connector -2-.

Remove the headlamp range adjustment positioning motor -1- by the left headlamp clockwise -arrow A- and by the right headlamp counterclockwise.

Disengage positioning motor from headlamp housing.

Slide the adjusting axle ball head -4- out of the ball socket -3- by tilting the positioning motor -1- upward -arrow B-.

Press reflector forward and remove adjusting motor.

1. Tightening specification, refer to «HALOGEN HEADLAMPS OVERVIEW, FROM 11.08»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__halogen-headlamps-overview-from-1108) .

Install in reverse order of removal, observing the following

Insert the adjusting axle ball head into the reflector ball socket from above while pulling the reflector back.

Position the headlamp range adjustment positioning motor quick release on the headlamp housing.

Engage the headlamp range adjustment positioning motor counterclockwise on the left headlamp and clockwise on the right headlamp.

Connect the electrical connector on the headlamp range adjustment positioning motor.

Close the housing cover and secure it the spring clip.

Install the headlamp housing. Refer to HEADLAMP HOUSING .

Switch off ignition and remove ignition key.

Turn light switch into "0" position.

Remove the lock carrier cover. Refer to Removal and Installation .

Disconnect the electrical connector -4-.

Remove the screws -2- and -5-.

Loosen the lower bolt -3- on the headlamp housing using a long wrench.

Note. Ignore items -6 and 7-.

Remove headlamp -1- toward front from body.

1. Tightening specification, refer to «HALOGEN HEADLAMPS OVERVIEW, FROM 11.08»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__halogen-headlamps-overview-from-1108) .

Install in reverse order of removal, observing the following

When inserting the headlamp -2- into the mount -1-, make sure the guide tracks on the headlamp engage in the guides on the mount -arrows-.

1. Headlamp must slide gently into mount and without using force.

When sliding the headlamp -4- in, make sure the headlamp ventilation -3- slides evenly into the mount -2- for the ventilation hose -1- -arrow-.

Tighten the screws -2, 3 and 5-.

Install the lock carrier cover. Refer to Removal and Installation .

Note. Headlamp mounting tabs that have broken off can be replaced by installing the repair set. Completely replacing the headlamp is not necessary. There are different repair kits for left and right headlamps.

Procedure

1. Tightening specification, refer to «HALOGEN HEADLAMPS OVERVIEW, FROM 11.08»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__halogen-headlamps-overview-from-1108) .

Remove headlamp with broken mounting tab. Refer to HEADLAMP HOUSING .

Remove remains of broken mounting tab at headlamp housing.

Place mounting straps -2- and -4- from repair kit on headlamp housing and secure tabs with straps -1- and -3-.

Remove headlamp housings. Refer to HEADLAMP HOUSING .

Release spring clip -arrow- and remove low beam/daytime running lamp bulb housing cover -1- from headlamp housing.

Turn socket -1- counterclockwise -arrow- and remove from housing.

Scheme 78

Pull the bulb -2- out of the socket.

Install in reverse order of removal, observing the following

Insert the new bulb into the headlamp without touching the bulb with bare hands.

Close the housing cover and secure it the spring clip.

Install the headlamp housing. Refer to HEADLAMP HOUSING .

Remove headlamp housings. Refer to HEADLAMP HOUSING .

Remove the high beam/turn signal housing cover -1- from the headlamp housing -arrow-.

Turn the bulb -1- counterclockwise -arrow- and remove it from the housing.

Scheme 79

Install in reverse order of removal, observing the following

Insert the new bulb into the housing without touching the bulb with bare hands.

Close the housing cover -1-. When doing this, the strap -2- must align with the mark -3- on the headlamp housing.

Install the headlamp housing. Refer to HEADLAMP HOUSING .

Remove headlamp housings. Refer to HEADLAMP HOUSING .

Release the wire clamp -arrow- and remove the low beam/daytime running lamp bulb housing cover -1- from the headlamp housing.

Remove the lamp bulb and socket -1- from the reflector -arrow-.

Scheme 80

Remove the parking lamp/front side marker lamp bulb -2- from the socket.

Install in reverse order of removal, observing the following

Insert the new bulb into the socket without touching the bulb with bare hands.

Push socket into reflector until it engages noticeably.

Close the housing cover and secure it the spring clip.

Install the headlamp housing. Refer to HEADLAMP HOUSING .

Scheme 81

Right side: remove the air filter housing. Refer to [For engine(s) CALA] Removal and Installation or to [For engine(s) CAEB] Removal and Installation or to [For engine(s) CAUA] Removal and Installation .

Turn the housing cover -1- counter-clockwise -arrow- and remove it from the headlamp housing.

Release the bulb -1- : Left side, by turning counterclockwise -arrow- ; right side, by turning clockwise.

Scheme 82

Remove the bulb from the housing.

Pull the bulb -3- out of the bulb socket -2-.

Install in reverse order of removal. Note the following

Insert new bulb in the bulb socket. Do not touch the glass bulbs with bare hands.

Close the housing cover clockwise.

Right side: install the air filter housing. Refer to [For engine(s) CALA] Removal and Installation or to [For engine(s) CAEB] Removal and Installation or to [For engine(s) CAUA] Removal and Installation .

HEADLAMP BEAM ADJUSTMENT MOTOR -V48- / -V49

Special tools and workshop equipment required

1. Protective Gloves
2. Protective Eyewear
3. Box Cutter

Remove headlamp housings. Refer to HEADLAMP HOUSING .

Note. The headlamp housing must be cut at the designated location with a sharp box cutter to replace the headlamp range control positioning motor. A housing cover can be ordered to seal the assembly opening.

Cut the cover -1- out of the headlamp housing with a sharp box cutter.

Scheme 83

Note. Remove any shavings and grit on the blind cover from the headlamp housing.

Remove the housing cover -2- from the headlamp housing.

Turn the height adjustment bolt all the way with the hex socket wrench -3- -arrow A

Scheme 84

Remove the bolts -1 and 4-.

Reach through the opening in the headlamp housing and remove the adjustment motor -2- in the -direction of the arrow B- from the reflector.

Remove the adjustment motor and disconnect the connector.

1. Tightening specification, refer to «HALOGEN HEADLAMPS OVERVIEW, FROM MY 2012»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__halogen-headlamps-overview-from-my-2012) .

Install in reverse order of removal. Note the following

Turn the housing cover -1- counter-clockwise -arrow- and remove it from the headlamp housing.

When connecting the connector, install the adjustment motor.

1. Counterhold the high beam/turn signal reflector through the opening when pressing the adjusting shaft ball head into the reflector ball head mount.

Close the opening in the headlamp housing -2- with the housing cover -1- from the repair kit.

Scheme 85

Tighten the bolts -arrows-.

Close the housing cover.

Install the headlamp housing. Refer to HEADLAMP HOUSING .

Scheme 86

Switch off ignition and remove ignition key.

Turn light switch into "0" position.

Remove the lock carrier cover. Refer to Removal and Installation .

Disconnect the electrical connector -2-.

Remove the bolts -1 and 4-.

Remove the bolt -3- and remove the adjusting mechanism from the headlamp housing.

Loosen the bolt -arrows- a few turns from the headlamp housing.

Remove headlamp -5- toward front from body.

Scheme 87

1. Tightening specification, refer to «HALOGEN HEADLAMPS OVERVIEW, FROM MY 2012»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__halogen-headlamps-overview-from-my-2012) .

Install in reverse order of removal. Note the following

When inserting the headlamp -2- into the mount -1-, make sure the guide tracks on the headlamp engage in the guides on the mount -arrows-.

1. Headlamp must slide gently into mount and without using force.

When sliding the headlamp -4- in, make sure the headlamp ventilation -3- slides evenly into the mount -2- for the ventilation hose -1- -arrow-.

Tighten the bolts -1, 3, 4- and -arrows-.

Install the lock carrier cover. Refer to Removal and Installation .

Right side: remove the air filter housing. Refer to [For engine(s) CALA] Removal and Installation or to [For engine(s) CAEB] Removal and Installation or to [For engine(s) CAUA] Removal and Installation .

Turn the housing cover -1- counter-clockwise -arrow- and remove it from the headlamp housing.

Remove the bulb -1- from the spring clips -arrows-.

Scheme 88

Disconnect the electrical connector -2- on the bulb.

Install in reverse order of removal. Note the following

Push the new bulb past the resistance of the spring clips into the housing and connect the connector. This way the glass bulb is not touched with bare hands.

Close the housing cover clockwise.

Right side: install the air filter housing. Refer to [For engine(s) CALA] Removal and Installation or to [For engine(s) CAEB] Removal and Installation or to [For engine(s) CAUA] Removal and Installation .

Scheme 89

Remove the lock carrier cover. Refer to Removal and Installation .

Remove the bolts -arrows-.

Remove the bracket -2- upward from the headlamp housing -1-.

1. Tightening specification, refer to «HALOGEN HEADLAMPS OVERVIEW, FROM MY 2012»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__halogen-headlamps-overview-from-my-2012) .

Install in reverse order of removal. Note the following

Install the lock carrier cover. Refer to Removal and Installation .

Scheme 90

Right side: remove the air filter housing. Refer to [For engine(s) CALA] Removal and Installation or to [For engine(s) CAEB] Removal and Installation or to [For engine(s) CAUA] Removal and Installation .

Remove the housing cover -1- from the headlamp housing -arrow-.

Remove the bulb -2- from the spring clips -arrows-.

Scheme 91

Disconnect the electrical connector -1- on the bulb.

Install in reverse order of removal. Note the following

Push the new bulb past the resistance of the spring clips into the housing and connect the connector. This way the glass bulb is not touched with bare hands.

Close the housing cover -1-. When doing this, the strap -3- must align with the mark -2- on the headlamp housing.

Scheme 92

Right side: install the air filter housing. Refer to [For engine(s) CALA] Removal and Installation or to [For engine(s) CAEB] Removal and Installation or to [For engine(s) CAUA] Removal and Installation .

Right side: remove the air filter housing. Refer to [For engine(s) CALA] Removal and Installation or to [For engine(s) CAEB] Removal and Installation or to [For engine(s) CAUA] Removal and Installation .

Remove the housing cover -1- from the headlamp housing -arrow-.

Turn socket -4- counterclockwise -arrow- and remove from housing.

Scheme 93

Release the clips -3- and remove the connector -2- from the bulb socket -1- with the bulb.

Install in reverse order of removal. Note the following

Insert the new bulb past the resistance of the spring clips into the housing and connect to the connector. This way the glass bulb is not touched with bare hands.

Close the housing cover -1-. When doing this, the strap -3- must align with the mark -2- on the headlamp housing.

Right side: install the air filter housing. Refer to [For engine(s) CALA] Removal and Installation or to [For engine(s) CAEB] Removal and Installation or to [For engine(s) CAUA] Removal and Installation .

Right side: remove the air filter housing. Refer to [For engine(s) CALA] Removal and Installation or to [For engine(s) CAEB] Removal and Installation or to [For engine(s) CAUA] Removal and Installation .

Turn the housing cover -1- counter-clockwise -arrow- and remove it from the headlamp housing.

Turn the height adjustment bolt all the way with the hex socket wrench -5- -arrow A

Scheme 94

Open the tabs -1, 6- and remove the power output stage -2- in the direction of travel forward from out of the guide rails -arrow B-.

Remove the power output stage toward the rear out from the headlamp housing -3- -arrow C-, as shown on the illustration.

Disconnect the electrical connector -4-.

Install in reverse order of removal. Note the following

Close the housing cover clockwise.

Right side: install the air filter housing. Refer to [For engine(s) CALA] Removal and Installation or to [For engine(s) CAEB] Removal and Installation or to [For engine(s) CAUA] Removal and Installation .

Adjust the headlamp. Refer to HALOGEN HEADLAMP, ADJUSTING .

Scheme 95

Remove headlamp housings. Refer to HEADLAMP HOUSING .

Unbutton the sealing frame -3- from the under side -1- and sides of the headlamp housing -4-.

Open the tab -2- -arrows- and remove the sealing frame.

Install in reverse order of removal. Note the following

Install the headlamp housing. Refer to HEADLAMP HOUSING .

SIDE MARKER LAMP BULBS -M33- / -M34

The front side marker lamp bulb is an LED and is integrated in the headlamp housing. The LED cannot be replaced. The entire headlamp must be replaced.

Replace the headlamp housing. Refer to HEADLAMP HOUSING .

Scheme 96

Remove the bolts -2 and 3-.

Remove the bolt -1- as far as possible.

Remove the bracket -4- upward from the headlamp housing.

1. The bolt and the bracket can only be removed together.

1. Tightening specification, refer to «HALOGEN HEADLAMPS OVERVIEW, FROM MY 2012»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__halogen-headlamps-overview-from-my-2012) .

Install in reverse order.

Remove the headlamp housing

1. Halogen Headlamps: through October 2008, refer to «HEADLAMP HOUSING»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) , after November 2008, refer to «HEADLAMP HOUSING»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) , after MY 2012, refer to «HEADLAMP HOUSING»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
2. HID Headlamps: through MY 2011, refer to «HEADLAMP HOUSING»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__headlamp-housing) , after MY 2012, refer to «HEADLAMP HOUSING»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .

Remove the appropriate front wheel housing liner. Refer to Removal and Installation .

Remove the bolts -arrows-.

Scheme 97

Remove the headlamp housing mount -1-.

1. Tightening Specifications: through MY 2011, refer to «HEADLAMP HOUSING BRACKET AND MOUNT OVERVIEW - VEHICLES THROUGH MY 2011»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) , from MY 2012, refer to «HEADLAMP HOUSING BRACKET AND MOUNT OVERVIEW - VEHICLES FROM MY 2012»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .

Install in reverse order of removal. Note the following

Insert the headlamp housing mount and install the bolts -arrows- and tighten by hand.

Install the headlamp housing

1. Halogen Headlamps: through October 2008, refer to «HEADLAMP HOUSING»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) , after November 2008, refer to «HEADLAMP HOUSING»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) , after MY 2012, refer to «HEADLAMP HOUSING»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
2. HID Headlamps: through MY 2011, refer to «HEADLAMP HOUSING»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__headlamp-housing) , after MY 2012, refer to «HEADLAMP HOUSING»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .

Loosen the bolt -7- for the bracket -6- several turns.

Align the headlamp gap dimensions according to the body contours.

1. Gap dimension = even gap dimension.

Tighten the bolts -arrows- while aligning the flush to the outer edge of the fender.

Check gap dimensions again, repeat adjustment of gap dimensions if necessary, as described above.

Install the wheel housing liner. Refer to Removal and Installation .

Adjust headlamps. Refer to HALOGEN HEADLAMP, ADJUSTING or HID HEADLAMP, ADJUSTING .

Scheme 98

Remove front bumper cover. Refer to Removal and Installation .

Remove the headlamp housing

1. Halogen Headlamps: through October 2008, refer to «HEADLAMP HOUSING»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) , after November 2008, refer to «HEADLAMP HOUSING»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) , after MY 2012, refer to «HEADLAMP HOUSING»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
2. HID Headlamps: through MY 2011, refer to «HEADLAMP HOUSING»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__headlamp-housing) , after MY 2012, refer to «HEADLAMP HOUSING»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .

If equipped, remove the nozzle for the headlamp washer system. Refer to HEADLAMP WASHER SYSTEM SPRAY NOZZLES .

Disconnect the connector on the front airbag crash sensor. Refer to Removal and Installation .

Remove the bolts -1, 2 and 3-.

Release the tab -5- -arrow- and remove the bracket -4- from the lock carrier.

If the bracket is replaced

1. Remove the headlamp housing mount, refer to «HEADLAMP HOUSING MOUNT»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
2. Remove the crash sensor for the front airbag. Refer to «Removal and Installation»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe) .

1. For the correct tightening specification, refer to «HEADLAMP HOUSING BRACKET AND MOUNT OVERVIEW - VEHICLES THROUGH MY 2011»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) or «HEADLAMP HOUSING BRACKET AND MOUNT OVERVIEW - VEHICLES FROM MY 2012»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .

Install in reverse order of removal. Note the following

Install the bracket to the fender and to the lock carrier and bolts -1, 2, 3- by hand.

Install the headlamp washer system spray nozzle. Refer to HEADLAMP WASHER SYSTEM SPRAY NOZZLES .

Install the front bumper cover. Refer to Removal and Installation .

Align the bumper cover gaps according to the body contours.

1. Gap dimension = even gap dimension.

Tighten the bolts.

Inspect the gaps again and repeat the adjustment if necessary.

Install the headlamp housing

1. Halogen Headlamps: through October 2008, refer to «HEADLAMP HOUSING»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) , after November 2008, refer to «HEADLAMP HOUSING»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) , after MY 2012, refer to «HEADLAMP HOUSING»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
2. HID Headlamps: through MY 2011, refer to «HEADLAMP HOUSING»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__headlamp-housing) , after MY 2012, refer to «HEADLAMP HOUSING»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .

Adjust headlamps. Refer to HALOGEN HEADLAMP, ADJUSTING or HID HEADLAMP, ADJUSTING .

DAYTIME RUNNING LAMP AND PARKING LAMP CONTROL MODULE -J860- / -J861

Scheme 99

Remove headlamp housings. Refer to HEADLAMP HOUSING .

Remove the bolts -arrows-.

Remove the control module -1- from the headlamp housing.

Press the release -3- and disconnect the connector -2-.

Remove the control module.

1. Tightening specification, refer to «HID HEADLAMPS, OVERVIEW, FROM MY 2012»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__hid-headlamps-overview-from-my-2012) .

Install in reverse order of removal. Note the following

Make sure the seal -4- between the control module and the headlamp housing is not damaged.

Install the headlamp housing. Refer to HEADLAMP HOUSING .

FRONT SIDE MARKER LAMP BULBS -M33- / -M34

The front side marker lamp bulb is an LED and is integrated in the headlamp housing. The LED cannot be replaced. The entire headlamp must be replaced.

Replace the headlamp housing. Refer to HEADLAMP HOUSING .

Scheme 100

Right side: remove the air filter housing. Refer to [For engine(s) CALA] Removal and Installation or to [For engine(s) CAEB] Removal and Installation or to [For engine(s) CAUA] Removal and Installation .

Remove the housing cover -1- from the headlamp housing -arrow-.

Turn socket -3- counterclockwise -arrow- and remove from housing.

Scheme 101

Pull the bulb -1- out of the bulb socket -2-.

Install in reverse order of removal. Note the following

Insert new bulb in the bulb socket. Do not touch the glass bulbs with bare hands.

Close the housing cover.

Right side: install the air filter housing. Refer to [For engine(s) CALA] Removal and Installation or to [For engine(s) CAEB] Removal and Installation or to [For engine(s) CAUA] Removal and Installation .

Scheme 102

Remove headlamp housings. Refer to HEADLAMP HOUSING .

Remove the HID lamp. Refer to HID HEADLAMP BULBS -L13- / -L14 .

Counterhold from the inside and push the pin through to remove the pin -1, 2- with pliers from out of the headlamp housing.

Remove the bolts through the openings -arrows-.

Push the ball end of the positioning stem upward -arrow- and out of the ball end mount by swiveling the control motor while at the same time pushing the reflector -3- forward, to remove the headlamp beam adjustment motor -1-.

Scheme 103

Remove the adjustment motor -4- from out of the headlamp housing -5-, as shown in the illustration.

Disconnect the electrical connector -2-.

1. Tightening specification, refer to «HID HEADLAMPS, OVERVIEW, FROM MY 2012»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__hid-headlamps-overview-from-my-2012) .

Install in reverse order of removal. Note the following

When connecting the connector, install the adjustment motor.

1. Insert the adjusting axle ball head into the reflector ball socket first from below while pulling the reflector back.

Tighten the bolts.

Close the opening in the headlamp housing -1- with the grommets -2, 3- from the repair kit.

Scheme 104

Install the HID bulb. Refer to HID HEADLAMP BULBS -L13- / -L14 .

Install the headlamp housing. Refer to HEADLAMP HOUSING .

With the ignition switched off, disconnect the battery ground (GND) wire. Refer to BATTERY, DISCONNECTING AND CONNECTING .

Remove the lock carrier cover. Refer to Removal and Installation .

Note. Apply tape to the bumper at the bottom edge of the headlamp housing to protect the bumper while gently prying up on the headlamp housing to remove it.

Disconnect the electrical connector -2-.

Remove the bolts -1 and 4-.

Remove the bolt -3- and remove the adjusting mechanism from the headlamp housing.

Loosen the bolt -arrows- a few turns from the headlamp housing.

Remove headlamp -5- toward front from body.

1. Tightening specification, refer to «HID HEADLAMPS, OVERVIEW, FROM MY 2012»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__hid-headlamps-overview-from-my-2012) .

Install in reverse order of removal. Note the following

When inserting the headlamp -2- into the mount -1-, make sure the guide tracks on the headlamp engage in the guides on the mount -arrows-.

1. Headlamp must slide gently into mount and without using force.

When sliding the headlamp -4- in, make sure the headlamp ventilation -3- slides evenly into the mount -2- for the ventilation hose -1- -arrow-.

Tighten the bolts -1, 3, 4- and -arrows-.

Install the lock carrier cover. Refer to Removal and Installation .

Connect battery. Required actions, refer to BATTERY, DISCONNECTING AND CONNECTING .

HEADLAMP POWER OUTPUT STAGE -J667- / -J668

Scheme 105

Remove headlamp housings. Refer to HEADLAMP HOUSING .

Remove the bolts -arrows-.

Remove the headlamp power output stage -2-.

1. Tightening specification, refer to «HID HEADLAMPS, OVERVIEW, FROM MY 2012»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__hid-headlamps-overview-from-my-2012) .

Install in reverse order of removal. Note the following

Make sure the seal -1- between the power output stage and the headlamp housing is not damaged.

Install the headlamp housing. Refer to HEADLAMP HOUSING .

Scheme 106

Right side: remove the air filter housing. Refer to [For engine(s) CALA] Removal and Installation or to [For engine(s) CAEB] Removal and Installation or to [For engine(s) CAUA] Removal and Installation .

Remove the housing cover -1- from the headlamp housing -arrow-.

Rotate the HID bulb -2- in the -direction of the arrow- and remove it from the housing.

Scheme 107

Disconnect the electrical connector -1-.

Install in reverse order of removal. Note the following

Insert new HID headlamp bulb in the housing. Do not touch the glass bulbs with bare hands.

1. Installation location: The electrical connection faces down.

Close the housing cover.

Right side: install the air filter housing. Refer to [For engine(s) CALA] Removal and Installation or to [For engine(s) CAEB] Removal and Installation or to [For engine(s) CAUA] Removal and Installation .

HIGH-INTENSITY GAS DISCHARGE LAMP CONTROL MODULE -J343- /J344

Scheme 108

Remove headlamp housings. Refer to HEADLAMP HOUSING .

Remove the bolts -arrows-.

Remove the control module -1- from the headlamp housing.

Disconnect the adapter cable -2- and connector -4-.

Remove the control module.

1. Tightening specification, refer to «HID HEADLAMPS, OVERVIEW, FROM MY 2012»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__hid-headlamps-overview-from-my-2012) .

Install in reverse order of removal. Note the following

Make sure the seal -3- between the control module and the headlamp housing is not damaged.

Install the headlamp housing. Refer to HEADLAMP HOUSING .

LED PARKING LAMP/DAYTIME RUNNING LAMP MODULES -L176- / -L177

The LED parking lamp/DRL modules are located on the headlamp housing and cannot be replaced separately in the event of a defect.

Replace the headlamp housing. Refer to HEADLAMP HOUSING .

LEFT AND RIGHT ADAPTIVE CORNERING LAMP MOTOR V318/V319

The dynamic cornering light position motor sits in the headlamp housing and cannot be replaced separately if it is faulty.

Replace the headlamp housing. Refer to HEADLAMP HOUSING .

LEFT AND RIGHT LOW BEAM HEADLAMP REFLECTOR MOTORS -V294- / -V295

The lower beam cover sits in the headlamp housing and cannot be replaced separately if it is faulty.

Replace the headlamp housing. Refer to HEADLAMP HOUSING .

Remove the lock carrier cover. Refer to Removal and Installation .

Remove the bolts -arrows-.

Remove the bracket -2- upward from the headlamp housing -1-.

1. Tightening specification, refer to «HID HEADLAMPS, OVERVIEW, FROM MY 2012»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__hid-headlamps-overview-from-my-2012) .

Install in reverse order of removal. Note the following

Install the lock carrier cover. Refer to Removal and Installation .

Remove headlamp housings. Refer to HEADLAMP HOUSING .

Unbutton the sealing frame -3- from the under side -1- and sides of the headlamp housing -4-.

Open the tab -2- -arrows- and remove the sealing frame.

Install in reverse order of removal. Note the following

Install the headlamp housing. Refer to HEADLAMP HOUSING .

Right side: remove the air filter housing. Refer to [For engine(s) CALA] Removal and Installation or to [For engine(s) CAEB] Removal and Installation or to [For engine(s) CAUA] Removal and Installation .

Remove the housing cover -1- from the headlamp housing -arrow-.

Remove the bulb -1- from the spring clips -arrows-.

Scheme 109

Disconnect the electrical connector -2- on the bulb.

Install in reverse order of removal. Note the following

Push the new bulb past the resistance of the spring clips into the housing and connect the connector. This way the glass bulb is not touched with bare hands.

Close the housing cover.

Right side: install the air filter housing. Refer to [For engine(s) CALA] Removal and Installation or to [For engine(s) CAEB] Removal and Installation or to [For engine(s) CAUA] Removal and Installation .

Remove the bolts -2 and 3-.

Remove the bolt -1- as far as possible.

Remove the bracket -4- upward from the headlamp housing.

1. The bolt and the bracket can only be removed together.

1. Tightening specification, refer to «HID HEADLAMPS, OVERVIEW, FROM MY 2012»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe__hid-headlamps-overview-from-my-2012) .

Install in reverse order.

Scheme 110

Do not press brake pedal.

Pull the high-mount brake lamp -2- back evenly by the cover -arrows-.

Disconnect the electrical connector -1-.

Scheme 111

Install in reverse order of removal, observing the following

Note. Entire high-mounted brake lamp must be replaced in the event of faulty LEDs.

The mount -2- for the high-mount brake lamp -3- must engage evenly at the left and right in the guide rails -1-.

Slide the high-mount brake lamp forward -arrows- evenly without tilting it until it engages audibly.

HIGH-MOUNTED BRAKE LAMP BULB, 5-DOOR

Special tools and workshop equipment required

1. Trim removal wedge 3409
2. Cleaning solution D 009 401 04

Do not press brake pedal.

Unclip the clips at the top of the rear lid trim panel and bend them away. Refer to Removal and Installation .

Scheme 112

Disconnect the electrical connector -2-.

Remove the nut -1- -arrows-.

Pry the bolt -4- on the outer side out of the clips -2- using the 3409.

Scheme 113

Loosen the self-adhesive seal -3- near the stud bolts and remove the high-mounted brake lamp -1- from the rear lid.

1. The self-adhesive seals will get damaged.

Remove the high-mounted brake lamp.

1. Tightening specification, refer to «HIGH-MOUNT BRAKE LAMP AND LICENSE PLATE LAMPS, 5-DOOR OVERVIEW»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .

Install in reverse order of removal, observing the following

Note. Entire high-mounted brake lamp must be replaced in the event of faulty LEDs.

Remove any adhesive.

Scheme 114

Clean the surface with cleaning solution D 009 401 04.

Pull the protective film off the self-adhesive seals -4- and press them onto the surface.

1. The small seals -1- and -3- go on the outside and large seal -2- goes in the middle.

Remove the protective film -5- from the self-adhesive seals.

Install the high-mounted brake lamp into the rear lid.

Tighten bolts, refer to HIGH-MOUNT BRAKE LAMP AND LICENSE PLATE LAMPS, 5-DOOR OVERVIEW .

Connect the electrical connector -A-.

Push the rubber lip under the rear window using the 3409.

Install the rear lid trim panel. Refer to Removal and Installation .

OUTER TAIL LAMPS

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Scheme 115

Switch off ignition and remove ignition key.

Turn light switch into 0 position.

Open the luggage compartment side trim cover.

Remove the threaded pins -2-.

Pivot the tail lamp -1- outward -arrow- and disengage retaining pins from the body.

Disconnect the electrical connector.

1. Tightening specification, refer to «LED OUTER TAIL LAMPS OVERVIEW, THROUGH MY 2011»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .

Install in reverse order of removal, observing the following

Note. The self-adhesive seal on the tail lamp housing must seal correctly.

Position the tail lamp on the body and press the retaining pins into the holes.

Tighten the threaded pins.

BULB SOCKET

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Scheme 116

Remove the outer tail lamp. Refer to OUTER TAIL LAMPS .

Turn the bulb socket -1- counter-clockwise -arrow- and remove it from the tail lamp housing.

Remove the bulb from the bulb socket.

Note. Disregard item -2-.

Install in reverse order of removal, observing the following

Insert the new bulb into the socket without touching the bulb with bare hands.

Turn the bulb socket clockwise to secure it.

Install the outer tail lamp. Refer to OUTER TAIL LAMPS .

INNER TAIL LAMPS

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Scheme 117

Switch off ignition and remove ignition key.

Turn light switch into 0 position.

Remove the cover -1- in -direction of arrow-.

Disconnect the electrical connector -1-.

Scheme 118

Remove the nut -2- and remove the large clamping bracket -3-.

Remove the nut -5- and the small clamping bracket -4-.

Remove the inner tail lamp toward the outside.

Install in reverse order of removal, observing the following

1. Tightening specification, refer to «LED INNER TAIL LAMP OVERVIEW, THROUGH MY 2011»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .

Note. Make sure the seal between the body and tail lamp housing seals correctly.

Position the inner tail lamp on the outer edge of the rear lid.

Slide the clamping bracket -3- onto the inner tail lamp threaded pins and install the nut -4- loosely.

Scheme 119

Slide the large clamping bracket -1- onto the threaded pins on the inner tail lamp and tighten the nuts -2- and -4-.

Note. When tightening the nuts, the clamping bracket wedges itself onto the rear lid -arrows-.

Special tools and workshop equipment required

1. Trim removal wedge 3409

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Scheme 120

Switch off ignition and remove ignition key.

Turn light switch into 0 position.

Pry the cover -1- out using a 3409 -arrow-.

Disconnect the electrical connector -5-.

Scheme 121

Remove the nut -2- and remove the large bracket -1-.

Remove the nut -4- and the clamping bracket -3-.

Remove the inner tail lamp toward the outside.

Install in reverse order of removal, observing the following

1. Tightening specification, refer to «LED INNER TAIL LAMP OVERVIEW, THROUGH MY 2011»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .

Note. Make sure the seal between the body and tail lamp housing seals correctly.

Position the inner tail lamp on the outer edge of the rear lid.

Slide the clamping bracket -3- onto the threaded pins on the inner tail lamp and install the nut -4- loosely.

Scheme 122

Slide the large clamping bracket -1- onto the threaded pins on the inner tail lamp and tighten the nuts -2- and -4-.

Note. When tightening the nuts, the clamping bracket wedges itself onto the rear lid -arrows-.

REAR FOG LAMP BULB

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Switch off ignition and remove ignition key.

Turn light switch into 0 position.

Remove the cover -1- in -direction of arrow-.

Unlock the bulb socket -1- : on the left tail lamp, turn counter-clockwise -arrow- ; on the right tail lamp, turn clockwise.

Scheme 123

Pull the bulb socket out of the tail lamp housing.

Remove the fog lamp bulb from the bulb socket.

Install in reverse order of removal, observing the following

Insert the new bulb in the socket without touching the bulb with bare hands.

Special tools and workshop equipment required

1. Trim removal wedge 3409

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Switch off ignition and remove ignition key.

Turn light switch into 0 position.

Pry the cover -1- out using a 3409 -arrow-.

Turn the bulb socket -1- counter-clockwise -arrow- and remove from the tail lamp housing.

Scheme 124

Remove the fog lamp bulb from the bulb socket.

Install in reverse order of removal, observing the following

Insert the new bulb in the socket without touching the bulb with bare hands.

BACKUP LAMP BULB -M16- / -M17

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Switch off ignition and remove ignition key.

Turn light switch into 0 position.

Remove the cover -1- in -direction of arrow-.

Remove the nut -2- and then remove the large clamping bracket -1-.

Scheme 125

Unlock the bulb socket -3- with needle nose pliers on the left tail lamp, turn counter-clockwise -arrow- ; on the right tail lamp, turn clockwise.

Pull the bulb socket out of the tail lamp housing.

Remove the back-up lamp bulb from the socket.

1. Tightening specification, refer to «LED INNER TAIL LAMP OVERVIEW, THROUGH MY 2011»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .

Install in reverse order of removal, observing the following

Insert the new bulb in the socket without touching the bulb with bare hands.

Slide the large clamping bracket -1- onto the threaded pins on the inner tail lamp and tighten the nut -2-.

Note. When tightening the nut, the clamping bracket wedges itself onto the rear lid.

Special tools and workshop equipment required

1. Trim removal wedge 3409

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Switch off ignition and remove ignition key.

Turn light switch into 0 position.

Pry the cover -1- out using a 3409 -arrow-.

Remove the nut -2- and the clamping bracket -1-.

Scheme 126

Unlock the bulb socket -3- on the left tail lamp assembly, turn counter-clockwise -arrow- ; on the right tail lamp assembly, turn clockwise.

Pull the bulb socket out of the tail lamp housing.

Remove the back-up lamp bulb from the socket.

1. Tightening specification, refer to «LED INNER TAIL LAMP OVERVIEW, THROUGH MY 2011»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .

Install in reverse order of removal, observing the following

Insert the new bulb in the socket without touching the bulb with bare hands.

Slide the large clamping bracket -1- onto the threaded pins on the inner tail lamp and tighten the nut -2-.

Note. When tightening the nut, the clamping bracket wedges itself onto the rear lid.

Switch off ignition and remove ignition key.

Turn light switch into "0" position.

Open the luggage compartment side trim cover.

Remove the threaded pins -2-.

Pivot the tail lamp -1- outward -arrow- and disengage retaining pins from the body.

Disconnect the connector.

1. Tightening specification, refer to «LED OUTER TAIL LAMP, OVERVIEW, FROM MY 2012»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .

Install in reverse order of removal. Note the following

Note. The self-adhesive seal on the tail lamp housing must seal correctly.

Position the tail lamp on the body and press the retaining pins into the holes.

Tighten the threaded pins.

Scheme 127

Remove the outer tail lamp. Refer to OUTER TAIL LAMPS .

Turn the bulb socket -1- counter-clockwise -arrow- and remove it from the tail lamp housing.

Remove the backup lamp bulb from the bulb socket.

1. Tightening specification, refer to «LED INNER TAIL LAMP OVERVIEW, THROUGH MY 2011»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .

Install in reverse order of removal. Note the following

Insert new bulb in the bulb socket. Do not touch the glass bulbs with bare hands.

Install the outer tail lamp. Refer to OUTER TAIL LAMPS .

Switch off ignition and remove ignition key.

Turn light switch into "0" position.

Remove the cover -1- in -direction of arrow-.

Disconnect the electrical connector -5-.

Scheme 128

Remove the nut -7- and remove the large clamping bracket -6-.

Remove the nuts -2, 3- and then remove the clamping bracket -1, 4-.

Remove the inner tail lamp toward the outside.

Scheme 129

Install in reverse order of removal. Note the following

1. Tightening specification (Scheme 26)

Note. Make sure the seal between the body and tail lamp housing seals correctly.

Slide the clamping brackets -1, 4, 5- onto the inner tail lamp threaded pins and turn the nuts -2, 3, 6- 3 turns.

Position the inner tail lamp on the outer edge of the rear lid so that the clamping bracket audibly engages.

Tighten the nuts (Scheme 26)

Note. When tightening the nuts, the clamping bracket wedges itself onto the rear lid -arrows-.

Scheme 130

Turn light switch into "0" position.

Remove the license plate lamp -2- from the rear lid by positioning a screwdriver -1- at the slit and sliding it in the -direction of the arrow-.

Remove the bulb -3- from the clamping socket.

Install in reverse order. Note the following

Note. If LED's are malfunctioning, license plate lamp must be completely replaced.

Turn light switch into "0" position.

Remove the license plate lamp -2- from the rear lid by positioning a screwdriver -1- at the slit and sliding it in the -direction of the arrow-.

Remove the bulb -3- from the clamping socket.

Install in reverse order. Note the following

Note. If LED's are malfunctioning, license plate lamp must be completely replaced.

PARKING AID CONTROL MODULE -J446-, WITHOUT TRAILER HITCH

The parking aid control module is integrated in the vehicle electrical system control module -J519- depending on the date of manufacture from MY 2012 and cannot be replaced separately if defective.

Replace the vehicle electrical system control module, refer to VEHICLE ELECTRICAL SYSTEM CONTROL MODULE -J519 .

If the control module was replaced, select the "Replace" function for the respective control module in "Guided Fault Finding" or "Guided Functions" using the Vehicle diagnostic tester.

Open the right luggage compartment side trim cover.

Scheme 131

Open the clip -2- and remove the parking aid control module -1- from the frame.

Disconnect electrical connectors -3 through 5-.

Install in reverse order.

PARKING AID CONTROL MODULE -J446-, WITH TRAILER HITCH

The parking aid control module is integrated in the vehicle electrical system control module -J519- depending on the date of manufacture from MY 2012 and cannot be replaced separately if defective.

Replace the vehicle electrical system control module, refer to VEHICLE ELECTRICAL SYSTEM CONTROL MODULE -J519 .

If the control module was replaced, select the "Replace" function for the respective control module in "Guided Fault Finding" or "Guided Functions" using the Vehicle diagnostic tester.

Open the right luggage compartment side trim cover.

Remove the nuts -1- and -3-.

Disengage the electrical wire from the guides -arrows- on the retaining frame -2- and disconnect the cable tie -4-.

Remove the retaining frame upward.

Disconnect electrical connectors -2 through 4-.

Scheme 132

Release the retaining clip -arrow- and remove the parking aid control module -item 5- from the retaining frame -1-.

1. Tightening specification, refer to «PARKING AID OVERVIEW»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .

Install in reverse order of removal, observing the following

Note. When installing, install cable ties at same location.

Scheme 133

Switch off ignition and remove ignition key.

Remove the driver side instrument panel cover. Refer to Removal and Installation .

Remove the bolts -1- and -3- and the front parking aid warning buzzer -item 2-.

Disconnect the electrical connector -4-.

Install in reverse order of removal, observing the following

Install the driver side instrument panel cover. Refer to Removal and Installation .

Scheme 134

Switch off ignition and remove ignition key.

Remove right rear side trim. Refer to Removal and Installation .

Remove the rear parking aid warning buzzer -3- on the right seat belt guide -1- in -direction of arrow-.

Disconnect the electrical connector -2-.

Install in reverse order of removal, observing the following

Install right rear side trim. Refer to Removal and Installation .

Scheme 135

Switch off ignition and remove ignition key.

Remove the right rear seat belt guide. Refer to Removal and Installation .

Remove the rear parking aid warning buzzer -3- on the right seat belt guide -1- in -direction of arrow-.

Disconnect the electrical connector -2-.

Install in reverse order of removal, observing the following

Install the right rear seat belt guide. Refer to Removal and Installation .

Scheme 136

Outer sensors

Remove the front wheel housing liner. Refer to Removal and Installation .

Press both retainer tabs to the side -arrows- and press the sensor -2- through from the outside towards the inside.

Disconnect the electrical connector -1- on the sensor.

Inner sensor

Scheme 137

Reach through the openings in the radiator grille behind the mounts and press both retaining tabs to the side -arrows- while pressing the sensor -2- through from the outside to the inside.

Disconnect the electrical connector -1- on the sensor.

Install in reverse order of removal, observing the following

Outer sensors

Install the front wheel housing liner. Refer to Removal and Installation .

Outer sensors

Remove the headlamp housing: Halogen headlamp, refer to HEADLAMP HOUSING , HID headlamp, refer to HEADLAMP HOUSING .

Press both retainer tabs to the side -arrows- and press the sensor -2- through from the outside towards the inside.

Disconnect the electrical connector -1- on the sensor.

Inner sensor

Scheme 138

Remove the lock carrier cover. Refer to Removal and Installation .

Reach through the openings in the radiator grille behind the mounts and press both retaining tabs to the side -arrows- while pressing the sensor -1- through from the outside to the inside.

Disconnect the electrical connector -2- on the sensor.

Install in reverse order of removal. Note the following

Outer sensors

Remove the headlamp housing: Halogen headlamp, refer to HEADLAMP HOUSING , HID headlamp, refer to HEADLAMP HOUSING .

Inner sensor

Install the lock carrier cover. Refer to Removal and Installation .

Remove front bumper cover. Refer to Removal and Installation .

Press both retainer tabs to the side -arrows- and press the sensor -2- through from the outside towards the inside.

Disconnect the electrical connector -1- on the sensor.

Install in reverse order of removal, observing the following

Scheme 139

Remove the bolts -1- and -3- on the lower section of the bumper cover -2-.

Unclip the lower section of the bumper cover -2- from the bumper cover -1- beginning above the tailpipe in the sequence -arrow A to arrow C-.

Scheme 140

Reach from below behind the bumper cover and press both retaining tabs to the side -arrows- while pressing the sensor -2- through from the outside to the inside.

Disconnect the electrical connector -1- on the sensor.

Install in reverse order of removal, observing the following

Install the lower section of the bumper cover. Refer to Removal and Installation .

Outer sensors

Reach from below behind the bumper cover and press both retaining tabs to the side -arrows- while pressing the sensor -2- through from the outside to the inside.

Disconnect the electrical connector -1- on the sensor.

Inner sensor

Remove the bumper cover. Refer to Removal and Installation .

Press both retainer tabs to the side -arrows- and press the sensor -2- through from the outside towards the inside.

Install in reverse order of removal, observing the following

Install the bumper cover. Refer to Removal and Installation .

Adjust steering wheel downward and to rear as far as possible, use entire adjustment range of steering column adjustment for this.

Remove the driver airbag. Refer to Removal and Installation .

Remove steering wheel. Refer to Removal and Installation .

Remove steering column trim. Refer to Removal and Installation .

Remove bolt -1-.

Scheme 141

Disconnect the electrical connector -2-.

Disconnect the electrical connector -3-.

Press catch -1- in -direction of arrow- until harness connector -2- disengages.

Scheme 142

Remove the steering column switch module carefully.

1. Tightening specification, refer to «STEERING COLUMN SWITCH MODULE AND ELECTRONIC IGNITION LOCK OVERVIEW»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .

Install in reverse order of removal, observing the following

Install steering column trim. Refer to Removal and Installation .

Install steering wheel. Refer to Removal and Installation .

Install the driver airbag. Refer to Removal and Installation .

STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE -J527

The airbag spiral spring/return spring with slip ring -F138- and the steering angle sensor -G85- are integrated in the steering column electronic systems control module.

If the control module was replaced, select the Replace function for the respective control module in Guided Fault Finding or Guided Functions using the Vehicle diagnostic tester.

Note. Steering must be in center position (wheels in straight ahead position) when removing and installing coil connector with slip ring.

Adjust steering wheel downward and to rear as far as possible, use entire adjustment range of steering column adjustment for this.

Remove the driver airbag. Refer to Removal and Installation .

Remove steering wheel. Refer to Removal and Installation .

Remove steering column trim. Refer to Removal and Installation .

Remove bolt -1-.

Scheme 143

Release the retaining hooks -arrows- carefully and remove the airbag spiral spring/return spring with slip ring -item 2- from the steering column switch module -3-.

Release the electrical connectors on the airbag spiral spring/return spring with slip ring -item 3- by positioning the screwdriver at the retaining hooks -2- and -4- as illustrated and carefully releasing the connectors -1- and -5- in the -direction of arrow A-.

Scheme 144

Remove the airbag spiral spring/return spring with slip ring on the steering column switch module.

Install in reverse order of removal, observing the following

Make sure all retaining hooks and connectors are engaged securely.

Install steering column trim. Refer to Removal and Installation .

Install steering wheel. Refer to Removal and Installation .

Install the driver airbag. Refer to Removal and Installation .

The steering angle sensor must be adapted in "Guided Fault Finding" or "Guided Functions" after replacing the airbag spiral spring/return spring with slip ring using the Vehicle diagnostic tester.

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Scheme 145

Switch off ignition and remove ignition key.

Turn light switch into 0 position.

Open the luggage compartment side trim cover.

Remove the threaded pins -2-.

Pivot the tail lamp -1- outward -arrow- and disengage retaining pins from the body.

Disconnect the electrical connector.

1. Tightening specification, refer to «OUTER TAIL LAMPS OVERVIEW»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .

Install in reverse order of removal, observing the following

Note. The self-adhesive seal on the tail lamp housing must seal correctly.

Position the tail lamp on the body and press the retaining pins into the holes.

Tighten the threaded pins.

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Scheme 146

Remove the outer tail lamp. Refer to OUTER TAIL LAMPS .

Turn the socket counter-clockwise -arrow- and remove it from the tail lamp housing.

Remove the bulb from the bulb socket.

Install in reverse order of removal, observing the following

Insert the new bulb into the socket without touching the bulb with bare hands.

Turn the bulb socket clockwise to secure it.

Install the outer tail lamp. Refer to OUTER TAIL LAMPS .

REAR SIDE MARK LAMPS

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Scheme 147

Remove the outer tail lamp. Refer to OUTER TAIL LAMPS .

Rotate the left side marker lamp bulb socket -1- counterclockwise -arrow A- and the right one clockwise -arrow B- and remove it from the tail lamp.

Install in reverse order of removal, observing the following

Note. Replace the entire wiring harness if an LED is faulty.

Install the outer tail lamp. Refer to OUTER TAIL LAMPS .

Special tools and workshop equipment required

1. Trim Removal Wedge 3409

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Switch off ignition and remove ignition key.

Turn light switch into 0 position.

Pry the cover -1- out using a 3409 -arrow-.

Disconnect the electrical connector -2-.

Scheme 148

Remove the nut -5- and remove the large bracket -1-.

Remove the nut -3- and the small clamping bracket -4-.

Remove the inner tail lamp toward the outside.

Install in reverse order of removal, observing the following

1. Tightening specification, refer to «INNER TAIL LAMP OVERVIEW»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .

Note. Make sure the seal between the body and tail lamp housing seals correctly.

Position the inner tail lamp on the outer edge of the rear lid.

Slide the clamping bracket -4- onto the threaded pins on the inner tail lamp and install the nut -5- loosely.

Scheme 149

Slide the large clamping bracket -3- onto the inner tail lamp threaded pins. The guide pins -2- and -6- must engage in the mounts.

Tighten the nuts -1- and -5- by hand.

Note. When tightening the nuts, the clamping bracket wedges itself onto the rear lid -arrows-.

REAR PARKING/FOG LAMPS AND BACK-UP LAMPS 2

Special tools and workshop equipment required

1. Trim removal wedge 3409

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Switch off ignition and remove ignition key.

Turn light switch into 0 position.

Pry the cover -1- out using a 3409 -arrow-.

Disconnect the electrical connector -3-.

Scheme 150

Remove the nut -1- and the clamping bracket -2-.

Remove the bulb socket -4- from the housing by press the locking bracket upward -arrows-.

Remove the tail lamp/fog lamp bulb from the socket.

Remove the back-up lamp bulb from the socket.

1. Tightening specification, refer to «INNER TAIL LAMP OVERVIEW»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .

Install in reverse order of removal, observing the following

Insert the new bulb in the socket without touching the bulb with bare hands.

Slide the large clamping bracket -3- onto the inner tail lamp threaded pins. The guide pins -2- and -6- must engage in the mounts.

Tighten the nuts -1-.

Note. When tightening the nuts, the clamping bracket wedges itself onto the rear lid -arrows-. Ignore items -4 and 5-.

Remove the steering column switch module. Refer to STEERING COLUMN SWITCH MODULE .

Remove the steering column electronic systems control module -J527-. Refer to STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE -J527 .

Remove the turn signal switch -E2-, cruise control switch -E45- and windshield wiper/washer switch -E22-.

Install in reverse order of removal, observing the following

Install the steering column electronic systems control module. Refer to STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE -J527 .

Install the steering column switch module. Refer to STEERING COLUMN SWITCH MODULE .

Scheme 151

Left: Free up the wiring harness -6-.

Remove the rear hood latch cable -5- from the clutch cable. Refer to Removal and Installation .

Remove the bolts -1, 3 and 4-.

Remove the mount -2- toward the rear.

1. Tightening specification, refer to «HEADLAMP HOUSING BRACKET AND MOUNT OVERVIEW - VEHICLES FROM MY 2012»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .

Install in reverse order of removal. Note the following

Install the rear cable for the hood latch on the clutch cable. Refer to Removal and Installation .

SPECIAL TOOLS

Trim Removal Wedge 3409

Scheme 152

Special Pliers VAS 6339

Scheme 153

See also:
• General Information
• Removal and Installation
• Removal and Installation
• Description and Operation
• CENTER CONSOLE BUTTON UNIT, MMI BASIC
• INSTRUMENT PANEL BUTTON UNIT, WITH MMI COMFORT EQUIPMENT
• Removal and Installation
• Removal and Installation
• BATTERY, DISCONNECTING AND CONNECTING
• Removal and Installation
• VEHICLE ELECTRICAL SYSTEM CONTROL MODULE -J519
• Removal and Installation
• [For engine(s) CALA] Removal and Installation
• HEADLAMP WASHER SYSTEM SPRAY NOZZLES
• Removal and Installation
• Removal and Installation
• HALOGEN HEADLAMP, ADJUSTING
• HID HEADLAMP, ADJUSTING
• CONTACT CORROSION
• HEADLAMP BEAM ADJUSTMENT MOTORS -V48- / -V49
• CONTROL MODULES -J431-, -J745
• HEADLAMP POWER OUTPUT STAGES -J667- / -J668
• HID LAMP CONTROL MODULE -J343- /J344
• HEADLAMP HOUSING
• HID HEADLAMP BULBS -L13- / -L14
• HEADLAMP BEAM ADJUSTMENT MOTOR -V48- / -V49
• DAYTIME RUNNING LAMP AND PARKING LAMP CONTROL MODULE -J860- / -J861
• HIGH-INTENSITY GAS DISCHARGE LAMP CONTROL MODULE -J343- /J344
• HEADLAMP POWER OUTPUT STAGE -J667- / -J668
• HIGH-MOUNTED BRAKE LAMP BULB, 5-DOOR
• REAR PARKING/FOG LAMPS AND BACK-UP LAMPS 2
• REAR SIDE MARK LAMPS
• OUTER TAIL LAMPS
• BULB SOCKET
• INNER TAIL LAMPS
• REAR FOG LAMP BULB
• BACKUP LAMP BULB -M16- / -M17
• PARKING AID CONTROL MODULE -J446-, WITHOUT TRAILER HITCH
• PARKING AID CONTROL MODULE -J446-, WITH TRAILER HITCH
• STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE -J527
• ACCESS/START AUTHORIZATION SWITCH
• BI-XENON HEADLAMPS WITH CORNERING LAMP OVERVIEW, THROUGH MY 2011
• HALOGEN HEADLAMPS OVERVIEW, THROUGH 10.08
• FOG LAMPS, ADJUSTING
• HALOGEN HEADLAMPS OVERVIEW, FROM 11.08
• HALOGEN HEADLAMPS OVERVIEW, FROM MY 2012
• HID HEADLAMPS, OVERVIEW, FROM MY 2012
