Self-Leveling Suspension (coupe) Audi A5 I

GENERAL REPAIR INFORMATION

General Information

To perform a problem-free and successful repair, extreme caution and cleanliness, as well as properly functioning tools are an important requirement. Understandably, general safety guidelines apply when performing repairs.

A series of applicable general notes for individual repair procedures - otherwise listed several times at many points in the repair information - has been collected here. They apply for this repair information.

1. Thoroughly clean connecting points and their surrounding areas before loosening.
2. Place removed parts on a clean surface and cover to prevent contamination. Use foils and paper. Only use lint-free cloths!
3. Only install clean components: Only unpack replacement parts immediately prior to installation.
4. Use exclusively lubricants and sealants marked with part numbers.
5. Carefully cover or seal open components, if repairs are not carried out immediately.

Seals, Sealing Rings

1. Always replace seals and gaskets.
2. After removing seals/boots, inspect the contact surfaces on housings and shafts for burrs and damage and repair if necessary.

Bolts and Nuts

Scheme 1

1. Loosen and tighten the bolts and nuts of covers and housings in a diagonal sequence.
2. Components that are extremely sensitive must not be distorted and should be loosened and tightened in stages in a diagonal sequence.
3. Torque specifications for unlubricated bolts and nuts are given.
4. Always replace self-locking nuts and bolts.
5. Always replace the bolts and nuts, which are tightened with an additional tightening angle.

Electrical Components

Surely everyone has been shocked at one time or another when coming into contact with a metal object. The reason for this is the build-up of static electricity in the human body. This build-up can lead to malfunctions when contacting electrical components.

Touch a grounded object - for example a water pipe or a vehicle hoist - before working on electrical components. Do not make direct contact on connector terminals.

DYNAMIC RIDE CONTROL (DRC)

The DRC counteracts the pitching and rolling motions of the vehicle body around the longitudinal and cross axles and thus optimizes the vehicle driving characteristics. The Audi RS 5 has a DRC with a variable damping that can be shifted.

In addition to reducing the pitching and rolling motions of the vehicle body (identical to the hydraulic DRC), the adjustable DRC with variable damping allows the driver to adjust and the damping level using the Audi drive select controls. Each shock absorber has an additional component with an integrated electric motor. The electronic damping control module -J250- controls the electric motors.

There are several damping settings

1. "COMFORT"
2. "DYNAMIC"
3. "AUTO"
4. "INDIVIDUAL"

Only approved oil for filling and draining must be used. .

Filling must only be performed at ambient temperature of approximately 20 °C (68 °C).

As a replacement part, shock absorbers and lines are delivered empty.

Lines/dampers and central valves may only be suctioned, evacuated and filled when they are installed and connected.

When the DRC system is disconnected from the individual components (for example, the connection between the line/damper/central valve), the vehicle must not be standing on its wheels.

While filling the DRC system, the gas reservoir to the pressure clamps is checked for leaks on the piston on the inside of the central valve.

If, while filling of the DRC system, a pressure of 22 bar cannot be reached or continually drops, then check all connections for damage and leakage. If no issues are found on the outside, the gas reservoir to the pressure clamps on the piston on the inside of the central valve is leaking. Replace the central valve.

If the DRC system is being extracted, evacuated or filled, then this must be performed on the front and rear extraction/filling valves for each damper line. Note the following

Before removing or disconnecting any DRC components, extract the affected line completely.

Shock absorbers must only be filled when installed and connected.

Vehicle must never be placed on wheels with closed, filled system and locked central valves. This inevitably leads to leaks and system malfunction.

Lines must not be bent.

Small oil leak with locked central valve which results from connecting or disconnected charging device V.A.S 6209/2 at connection is not critical. Avoid repeating measurements because a small quantity of oil is removed from the system every time the V.A.S 6209/2 is connected. Every connection results in a pressure decrease of approximately 0.3 bar from the previous reading. Multiple repeated measurements decrease system pressure below minimum pressure or failure.

DYNAMIC RIDE CONTROL (DRC), DRAINING AND FILLING

Note. Extracting, evacuating and filling the whole DRC line (lines/damper and central valve) is performed with the Filling device for DRC system VAS 6544 Depending on the DRC system equipment in the dealership, the equipment may need to modified or updated to match VAS 6544. The following choices are possible

Special tools and workshop equipment required

1. Upgrade kit, Filling device for DRC system VAS 6209/4. The VAS 6209/4 serves as an upgrade to the charging device for DRC system VAS 6209 already found in dealerships.
2. Retrofit kit, DRC system VAS 6209/5. The VAS 6209/5 is needed if the dealership has the pressure pump VAS 6209/3 and wants to upgrade the filling device for DRC system VAS 6544. The supplement set, DRC system VAS 6209/6 is also necessary.
3. Supplement set, DRC system VAS 6209/6. The VAS 6209/6 is needed up upgrade the already available pressure pump VAS 6209/3 in the filling device for DRC system VAS 6544. The requirement is that the dealership already have the charging device for DRC system VAS 6209. If the dealership does have the charging device for DRC system VAS 6209, then the retrofit kit, DRC system VAS 6209/5 must be obtained.
4. Charging device for DRC system VAS 6544

Note. Updating the equipment for the DRC system must be done one time only. It is not necessary to convert back again. The procedure for draining and filling the complete DRC system is described using the V.A.S 6544.

Only approved oil for filling and draining must be used.

As a replacement part, shock absorbers and lines are delivered empty.

Filling must only be performed at ambient temperature of approximately 20 °C (68 °F).

Lines/dampers and central valves may only be suctioned, evacuated and filled when they are installed and connected.

Note. The shut-off valve for the wiring harness at the central valve must remain open when extracting, evacuating and filling the DRC system (lines/damper and central valve).

While filling the DRC system, the gas reservoir to the pressure clamps is automatically checked for leaks at the piston in the central valve.

Valves of filling device are open when ratchet levers are parallel to direction of flow.

Note. The valves must be kept closed during transport and storing the VAS 6544.

Lines must not be bent.

Required Equipment

Scheme 2

1. Front Shock Absorber Adapter Not for this model.
2. Rear Shock Absorber Adapter Not for this model
3. Fill Lines with Quick-Release Fastener
4. Venturi Injector with Exhaust Hose From the charging device for DRC system VAS 6209.
5. Connecting Hose From the VAS 6209
6. Charging Device for DRC System VAS 6544
7. Container for Used Oil Empty before starting the work. Identification: Red dot

Note. Before filling the DRC system, make sure the oil reservoir for the VAS 6544 and the line between the pressure pump and oil reservoir are filled with oil. The used oil container on the VAS 6544 must be empty and must be emptied after each charge.

Drain the old oil reservoir.

Scheme 3

Remove the cap -arrow- from the old oil reservoir -1- and drain the old oil.

Install the cap -arrow- on the old oil reservoir -1-.

Fill and bleed the VAS 6544.

Fill the oil reservoir -2- with new oil up to the marking and position the o-ring to the height of the oil level.

Close the shut-off valve -A- and -C- on the VAS 6544.

Scheme 4

Close the needle valve -B-.

Connect the hose -2- to the old oil reservoir -arrow- and to the quick-release fastener -4- on the VAS 6544.

Scheme 5

Connect the Venturi injector -3- and vent hose to the old oil reservoir -arrow- as illustrated.

Connect the compressed air to the Venturi injector -3-.

Open the locking valve -C-.

Scheme 6

Open the locking valve -A- briefly, for approximately 1-2 seconds, until the connecting line -1- between the oil reservoir -2- and pressure pump is filled and does not contain bubbles.

Close the locking valve -C-. Remove the compressed air connector form the Venturi injector.

Suctioning

Turn the front wheel on the side to be suctioned toward the outside.

Remove the dust cap from the front suction/fill valve.

Connect the fill line and quick-release fastening -1- from the VAS 6544 to the front suction/fill valve on the line to be suctioned, refer to 3 .

Scheme 7

Remove the rear wheel on the side of the line to be suctioned.

Free up the wheel housing liner for the rear suction/fill valve.

Remove the dust cap from the rear suction/fill valve.

Connect the fill line and quick-release fastening -1- from the VAS 6544 to the rear suction/fill valve on the line to be suctioned, refer to 3 .

Scheme 8

Connect the fill lines to the connections -A- and -B- on the VAS 6544, refer to 3 .

Shut-off valve -A- and -C- on the VAS 6544 closed.

Needle valve -B- closed.

Hose connected -2- to the old oil reservoir -arrow- and to the VAS 6544 -4-.

Venturi injector -3- connected to the old oil reservoir vent hose -arrow- on the VAS 6544.

Compressed air to the Venturi injector -3- connected.

Open the valve -C- until the last of the oil is extracted from the DRC system. (Visible on the return hose -2- to the used oil reservoir).

When the pressure manometer shows approximately negative 0.9 bar, close the valve -C- and disconnect the compressed air hose from the Venturi injectors.

1. Check for leaks.

Note. Vacuum must be stable for at least 2 minutes at negative 0.9 bar.

Check the oil level on the oil reservoir, fill with new oil up to the marking if necessary and position the o-ring to the height of the oil level.

Filling

Open the needle valve -B- approximately 2 turns and let the oil run out of the oil reservoir on the VAS 6544 into the evacuated DRC system.

Oil flows from the reservoir into the connected DRC system. This is shown by the decreasing oil level in the oil reservoir. Depending on the amount of oil remaining after extraction, the procedure may take several minutes. As the system fills up, the oil level goes down slower. If the level of the oil no longer moves, the first step of the filling process is complete.

Close the needle valve -B-.

Open the valve -A- and fill the DRC system to 22 bar by pumping the lever on the hand pump -1- several times.

Scheme 9

Note. While filling, make sure the oil reservoir on the VAS 6544 does not run dry; fill with reservoir with new oil if necessary.

1. When a pressure of 22 bar is reached, close the valve -A- and do not pump the hand pump lever any more.

Note. Exceeding the maximum pressure of 22 bar does not improve the filling process. Caution! Danger of damaging DRC system components as well as the VAS 6544. If the pressure does not reach 22 bar or if it continually drops, check all connections for damage or leaks. If no issues are found on the outside, the gas reservoir to the pressure clamps on the piston on the inside of the central valve is leaking. Replace the central valve.

Open the needle valve -B- slightly and let the pressure drop to 20 bar.

1. Close the valve -B- when the indicator on the pressure manometer reaches the 20 bar marking.

Note. The 16-bar graduation line on the scale is colored in green depending and the version and model of the pressure gauge. The marking has no meaning for this procedure.

DRC system is filled.

Disconnect the fill line and quick-release fastener on the VAS 6544 from the rear and front suction/fill valve, refer to item: 3 .

Mount the rear wheel.

Install the dust cap on the rear and front suction/fill valve.

Scheme 10

1. Charisma Switch Module -E592- Component location: The charisma switch module is installed in the instrument panel.
2. Electronic Damping Control Module -J250- Removing and installing, refer to «Electronic Damping Control Module -J250-, WITH ELECTRONICALLY CONTROLLED DAMPING»(/audi/a5/i-2007-2011/remont/electronic-suspension/#self-leveling-suspension-coupe) . Component location: The electronic damping control module is located behind the right luggage compartment side trim panel. If the electronic damping control module is being replaced, then the control position must be programmed once again. Refer to «CONTROL POSITION, PROGRAMMING USING VEHICLE DIAGNOSTIC TESTER»(/audi/a5/i-2007-2011/remont/electronic-suspension/#self-leveling-suspension-coupe__control-position-programming-using-vehicle-diagnostic) . If the control position was reprogrammed on vehicles with lane assist, the directional stabilization assistance control module -J759- must be recalibrated. Refer to «LANE ASSIST CALIBRATION PROCEDURE»(/audi/a5/i-2007-2011/remont/wheel-tire-system/#suspension-wheels-steering-coupe__lane-assist-calibration-procedure) .
3. Shock Absorber with Right Rear Dampening Adjustment Valve -N339- Removing and installing, refer to «SHOCK ABSORBER»(/audi/a5/i-2007-2011/remont/suspension-rear/#rear-suspension-coupe__shock-absorber) . Removing and installing, refer to «SHOCK ABSORBER»(/audi/a5/i-2007-2011/remont/suspension-rear/#rear-suspension-coupe) .
4. Left Rear Level Control System Sensor -G76- and Right Rear Level Control System Sensor -G77- Removing and installing, refer to «LEVEL CONTROL SYSTEM SENSOR»(/audi/a5/i-2007-2011/remont/suspension-rear/#rear-suspension-coupe__level-control-system-sensor) . If the sensor was removed and installed or if the linkage was loosened, the control position must be reprogrammed on vehicles with electronically controlled damping. Refer to «CONTROL POSITION, PROGRAMMING USING VEHICLE DIAGNOSTIC TESTER»(/audi/a5/i-2007-2011/remont/electronic-suspension/#self-leveling-suspension-coupe__control-position-programming-using-vehicle-diagnostic) . If the control position was reprogrammed on vehicles with lane assist, the directional stabilization assistance control module -J759- must be recalibrated. Refer to «LANE ASSIST CALIBRATION PROCEDURE»(/audi/a5/i-2007-2011/remont/wheel-tire-system/#suspension-wheels-steering-coupe__lane-assist-calibration-procedure) . On vehicles with automatic headlamp range control system, perform a basic setting on the headlamps. Refer to «[For engine(s) CAUA, CAEB, CALA] Diagnosis and Testing»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
5. Rear Body Acceleration Sensor -G343- Removing and installing, refer to «Rear Body Acceleration Sensor -G343»(/audi/a5/i-2007-2011/remont/electronic-suspension/#self-leveling-suspension-coupe__rear-body-acceleration-sensor-g343) .
6. Shock Absorber with Left Rear Dampening Adjustment Valve -N338- Removing and installing, refer to «SHOCK ABSORBER»(/audi/a5/i-2007-2011/remont/suspension-rear/#rear-suspension-coupe__shock-absorber) . Removing and installing, refer to «SHOCK ABSORBER»(/audi/a5/i-2007-2011/remont/suspension-rear/#rear-suspension-coupe) .
7. Left Front Body Acceleration Sensor -G341- and Right Front Body Acceleration Sensor -G342- Removing and installing, refer to «Left Front Body Acceleration Sensors -G341- AND Right Front Body Acceleration Sensors -G342»(/audi/a5/i-2007-2011/remont/electronic-suspension/#self-leveling-suspension-coupe__left-front-body-acceleration-sensors-g341) .
8. Shock Absorber with Left Front Dampening Adjustment Valve -N336- Suspension strut, removal and installation, refer to «SUSPENSION STRUT WITH MOUNTING BRACKET»(/audi/a5/i-2007-2011/remont/suspension-front/#front-suspension-coupe__suspension-strut-with-mounting-bracket) . installing the suspension strut, refer to «SUSPENSION STRUT AND MOUNTING BRACKET»(/audi/a5/i-2007-2011/remont/suspension-front/#front-suspension-coupe__suspension-strut-and-mounting-bracket) .
9. Left Front Level Control System Sensor -G78- and Right Front Level Control Sensor -G289- Removing and installing, refer to «LEVEL CONTROL SYSTEM SENSOR»(/audi/a5/i-2007-2011/remont/suspension-front/#front-suspension-coupe__level-control-system-sensor) If the sensor was removed and installed or if the linkage was loosened, the control position must be reprogrammed on vehicles with electronically controlled damping. Refer to «CONTROL POSITION, PROGRAMMING USING VEHICLE DIAGNOSTIC TESTER»(/audi/a5/i-2007-2011/remont/electronic-suspension/#self-leveling-suspension-coupe__control-position-programming-using-vehicle-diagnostic) . If the control position was reprogrammed on vehicles with lane assist, the directional stabilization assistance control module -J759- must be recalibrated. Refer to «LANE ASSIST CALIBRATION PROCEDURE»(/audi/a5/i-2007-2011/remont/wheel-tire-system/#suspension-wheels-steering-coupe__lane-assist-calibration-procedure) . On vehicles with automatic headlamp range control system, perform a basic setting on the headlamps. Refer to «[For engine(s) CAUA, CAEB, CALA] Diagnosis and Testing»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe) .
10. Shock Absorber with Right Front Dampening Adjustment Valve -N337- Suspension strut, removing and installing, refer to «SUSPENSION STRUT WITH MOUNTING BRACKET»(/audi/a5/i-2007-2011/remont/suspension-front/#front-suspension-coupe__suspension-strut-with-mounting-bracket) . installing the suspension strut, refer to «SUSPENSION STRUT AND MOUNTING BRACKET»(/audi/a5/i-2007-2011/remont/suspension-front/#front-suspension-coupe__suspension-strut-and-mounting-bracket) .

CONTROL POSITION, PROGRAMMING USING VEHICLE DIAGNOSTIC TESTER

Connect Vehicle Diagnosis Tester with corresponding diagnostic cable to vehicle.

Switch on the Vehicle Diagnosis Tester.

The Vehicle Diagnosis Tester is ready for operation when the operating modes are displayed.

Switch on ignition.

Requirements

1. The vehicle must be standing on an even surface.
2. The vehicle may not be loaded.
3. The electronic damping control module -J250- must be coded.
4. The DTC memory may not contain any vehicle level sensor DTC memory entries.

Note. If control modules or electric/electronic components were replaced, then the components must be adapted under "Guided Functions".

Touch Guided Functions and the screen.

Then

Select the corresponding program in "Guided Functions".

Follow the prompts on the screen.

Note. If the control position was programmed again on vehicles with lane assist, the directional stabilization assistance control module -J759- with integrated camera must be recalibrated. Refer to LANE ASSIST CALIBRATION PROCEDURE .

DYNAMIC RIDE CONTROL INSTALLATION LOCATIONS

Dynamic Ride Control

Scheme 11

1. Front Suspension Strut With Extract/Fill Valve Refer to «FRONT SUSPENSION STRUT»(/audi/a5/i-2007-2011/remont/electronic-suspension/#self-leveling-suspension-coupe) . Additional component with an integrated electric motor - vehicle with variable damping.
2. Indicator Lamp Vehicle with variable damping.
3. Audi Drive Select Controls Vehicle with variable damping.
4. Electronic Damping Control Module -J250- Vehicle with variable damping. Removing and installing, refer to «Electronic Damping Control Module -J250-, WITH DYNAMIC RIDE CONTROL»(/audi/a5/i-2007-2011/remont/electronic-suspension/#self-leveling-suspension-coupe__electronic-damping-control-module-j250-with) .
5. Central Valves Removing and installing, refer to «CENTRAL VALVE»(/audi/a5/i-2007-2011/remont/electronic-suspension/#self-leveling-suspension-coupe) .
6. Rear Shock Absorber With Extract/Fill Valve Refer to «REAR SHOCK ABSORBER»(/audi/a5/i-2007-2011/remont/electronic-suspension/#self-leveling-suspension-coupe) . Additional component with an integrated electric motor - vehicle with variable damping.
7. Connection To The Right/Left Front Suspension Strut 14 Nm

Scheme 12

1. Front Left and Rear Right Central Valve Removing and installing, refer to «CENTRAL VALVE»(/audi/a5/i-2007-2011/remont/electronic-suspension/#self-leveling-suspension-coupe) .
2. Front Right And Rear Left Central Valve Removing and Installing, refer to «CENTRAL VALVE»(/audi/a5/i-2007-2011/remont/electronic-suspension/#self-leveling-suspension-coupe) .
3. Shut-Off Valve 5 Nm To shut off, turn clockwise all the way. To open, turn counter-clockwise all the way.
4. Shut-Off Valve Locking Nut 12 Nm
5. DRC Line To Rear Left Shock Absorber 14 Nm Green marking.
6. DRC Line To The Right Front Shock Absorber 14 Nm White marking.
7. Shut-Off Valve 5 Nm To shut off, turn clockwise all the way. To open, turn counter-clockwise all the way.
8. Shut-Off Valve 5 Nm To shut off, turn clockwise all the way. To open, turn counter-clockwise all the way.
9. DRC Line To Rear Right Shock Absorber 14 Nm Blue marking.
10. DRC Line To Left Front Shock Absorber 14 Nm Yellow marking.
11. Shut-Off Valve 5 Nm To shut off, turn clockwise all the way. To open, turn counter-clockwise all the way.
12. Shut-Off Valve 5 Nm To shut off, turn clockwise all the way. To open, turn counter-clockwise all the way.
13. Bolt 20 Nm
14. Bolt 20 Nm
15. Bracket

Scheme 13

1- Clamp

2- Union nut, 14 Nm

3- Additional element with motor, installed on vehicles with variable damping.

4- DRC - shock absorber.

5- Extract/fill valve with hose line, make sure it is free of tension when installed.

6- Bracket

Scheme 14

1- Extract/fill valve with hose line, make sure it is free of tension when installed.

2- Bracket

3- Clamp

4- Union nut, 14 Nm

5- DRC - shock absorber

6- Additional element with motor, installed on vehicles with variable damping.

FASTENER TIGHTENING SPECIFICATIONS

DYNAMIC RIDE CONTROL FAULT FINDING

DYNAMIC RIDE CONTROL SYSTEM PRESSURE TEST

Special tools and workshop equipment required

1. Charging device V.A.S 6209/2
2. Hand vacuum pump VAS 6213

Bleed charging device V.A.S 6209/2

Use only approved oil for the bleeding procedure.

Note. Charging device V.A.S 6209/2 must always be bled at initial use. If charging device V.A.S 6209/2 still shows a residual pressure greater than 0.5 bar (e.g. from a previous reading), bleeding must not be done.

To bleed pressure gauge -B- and line section -A-, install special tool as shown in illustration.

Scheme 15

Note. Illustration shows bleeding process by extracting hydraulic oil with VAS 6213

Bleed process must be performed until air bubbles are no longer visible in hose -C-.

Disconnect hose -C- and -D- and perform system pressure check.

System pressure check is performed on front shock absorber of corresponding DRC line.

Scheme 16

Remove the cap from the extract/fill valve and connect the V.A.S 6209/2.

Read system pressure at V.A.S 6209/2.

Note. Pressure increase at V.A.S 6209/2 occurs slowly and takes approximately 2 minutes. DRC system pressure can only be read when V.A.S 6209/2 needle has finally come to a stop.

Disconnect V.A.S 6209/2 and install dust cap.

Note. Small oil leak which results from connecting or disconnected V.A.S 6209/2 at connection is not critical. Avoid repeating measurements because a small quantity of oil is removed from the system every time the V.A.S 6209/2 is connected. Every connection results in a pressure decrease of approximately 0.3 bar from the previous reading. Multiple repeated measurements decrease system pressure below minimum pressure or failure.

If the pressure is not OK, determine the cause and service the system.

DRC System Pressure Values

Pressure values refer to reference temperature of 20 °C (68 °F).

1. 20 bar (290 PSI) = operating pressure
2. 19 - 20 bar (276 - 290 PSI) = central valve new or as good as new.
3. 18 - 19 bar (261 - 276 PSI) = normal range of operation, system OK.
4. < 18 bar (261 PSI) = system leaking or not filled completely, air entering system, central valve has no pressure/is empty.

REMOVING

Note. The electronic damping control module is located behind the right luggage compartment side trim panel.

Switch off all electrical consumers.

Remove the ignition key.

Remove the cover from the right luggage compartment storage compartment.

Release and disconnect the connector -3-.

Scheme 17

Press the clips -2- to the side and remove the electronic damping control module -1-.

INSTALLING

Installation is the reverse of removal, with special attention to the following

Adapt the electronic damping control module. Refer to CONTROL POSITION, PROGRAMMING USING VEHICLE DIAGNOSTIC TESTER .

ELECTRONIC DAMPING CONTROL MODULE -J250-, WITH DYNAMIC RIDE CONTROL

Note. It is not necessary to code and adapt the control module when it is replaced. For this reason, it is not possible to perform "Replace" in "Guided Fault Finding" using the Vehicle Diagnostic Tester. The new electronic damping control module can be used right away. The electronic damping control module is installed behind the right side trim panel inside the luggage compartment.

Scheme 18

Switch off all electrical consumers.

Remove the ignition key.

Remove the cover from the right luggage compartment storage compartment.

Remove the nut -arrow-.

Disconnect the connectors -2 through 4- from the control module.

Remove the control module -1-.

Install in reverse order of removal. Note the following

Connect the connectors -2 through 4-.

Install the nuts -arrows- and tighten to 2 Nm.

LEFT FRONT BODY ACCELERATION SENSORS -G341- AND RIGHT FRONT BODY ACCELERATION SENSORS -G342

Special tools and workshop equipment required

1. Torque wrench V.A.G 1410

Scheme 19

Remove the wheel.

Remove the front wheel housing liner. Refer to Removal and Installation .

Release and disconnect the connector -2-.

Remove the nut -1- and sensor -3-.

Install in reverse order of removal. Note the following

When installing, always pay attention to the installation position of the sensor.

Install the sensor as illustrated.

Tighten the nuts -1- to 5 Nm.

REAR BODY ACCELERATION SENSOR -G343

Special tools and workshop equipment required

1. Torque wrench V.A.G 1410

Scheme 20

Remove the wheel.

Remove the left rear wheel housing liner. Refer to Removal and Installation .

Release and disconnect the connector -2-.

Remove the bolts -1- and the sensor -3-.

Install in reverse order of removal. Note the following

When installing, always pay attention to the installation position of the sensor.

Install the sensor as illustrated.

Tighten the bolts -1- to 5 Nm.

Note. The central valves are attached to the impact member under the bumper cover in the rear and on the left side.

Remove rear bumper cover. Refer to Removal and Installation .

Note. The DRC lines must be extracted before disconnecting them from the central valve. Refer to DYNAMIC RIDE CONTROL (DRC), DRAINING AND FILLING . Perform this step on both wiring harnesses on the central valve.

Remove the union nuts -7- and -8- or -11- and -12-, depending on the central valve.

Remove the screws -13- and the central valve.

Install in reverse order of removal. Note the following

Tightening specifications, refer to CENTRAL VALVES OVERVIEW

Install the central valve and bracket.

Install the bolts.

Install the DRC line connections for the appropriate lines on the central valve.

Note. The new central valve is filled and the shut-off valves are closed. Only when a new central valve is installed: open the shut-off valve on the new central valve and secure them with a locking nut. Refer to CENTRAL VALVES OVERVIEW .

Fill the DRC system. Refer to DYNAMIC RIDE CONTROL (DRC), DRAINING AND FILLING .

SPECIAL TOOLS

Special tools and workshop equipment required

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

1. Charging device V.A.S 6209/2
2. Hand vacuum pump VAS 6213
3. Torque wrench V.A.G 1410
4. Upgrade kit, Filling device for DRC system VAS 6209/4. The VAS 6209/4 serves as an upgrade to the charging device for DRC system VAS 6209 already found in dealerships.
5. Retrofit kit, DRC system VAS 6209/5. The VAS 6209/5 is needed if the dealership has the pressure pump VAS 6209/3 and wants to upgrade the filling device for DRC system VAS 6544. The supplement set, DRC system VAS 6209/6 is also necessary.
6. Supplement set, DRC system VAS 6209/6. The VAS 6209/6 is needed up upgrade the already available pressure pump VAS 6209/3 in the filling device for DRC system VAS 6544. The requirement is that the dealership already have the charging device for DRC system VAS 6209. If the dealership does have the charging device for DRC system VAS 6209, then the retrofit kit, DRC system VAS 6209/5 must be obtained.
7. Charging device for DRC system VAS 6544

See also:
• LANE ASSIST CALIBRATION PROCEDURE
• SHOCK ABSORBER
• SHOCK ABSORBER
• LEVEL CONTROL SYSTEM SENSOR
• [For engine(s) CAUA, CAEB, CALA] Diagnosis and Testing
• SUSPENSION STRUT WITH MOUNTING BRACKET
• SUSPENSION STRUT AND MOUNTING BRACKET
• LEVEL CONTROL SYSTEM SENSOR
• Removal and Installation
• Removal and Installation
• Electronic Damping Control Module -J250-, WITH ELECTRONICALLY CONTROLLED DAMPING
• CONTROL POSITION, PROGRAMMING USING VEHICLE DIAGNOSTIC TESTER
• Rear Body Acceleration Sensor -G343
• Left Front Body Acceleration Sensors -G341- AND Right Front Body Acceleration Sensors -G342
• Electronic Damping Control Module -J250-, WITH DYNAMIC RIDE CONTROL
• DYNAMIC RIDE CONTROL (DRC), DRAINING AND FILLING
