Navigation — Navigation circuit Audi A4 B9

Components on these wiring diagrams 57

Click a component to highlight it on every diagram it appears on.

• * If Equipped
• Air Bag Control Module
• Antenna
• Antenna Amplifier 2
• Antenna Amplifier 3 Digital Radio Antenna
• Antenna Amplifier Antenna
• Bottom Coupling Point On Left A-Pillar3
• Bottom Coupling Point On Right A-Pillar3
• Cellular Telephone Amplifier
• Center Coupling Point In Interior
• Center Speaker
• Data Bus On Board Diagnostic Interface
• Digital Radio Antenna
• Driver Volume Control
• External Audio Source Connection
• Front Information Display Control Head
• Front Roof Module Microphone Unit
• Fuse 10
• Fuse 14
• Fuse 2
• Fuse 5
• Fuse 8
• Fuse Panel 3
• Fuse Panel C2
• Fuse Panel F
• GPS Antenna
• Gsm Antenna2
• Information Electronics Control Module 14
• Instrument Cluster Control Module
• Left "C" Pillar
• Left Front Bass Speaker
• Left Front Door Coupling Point
• Left Front Microphone
• Left Front Treble Speaker
• Left Rear Bass Speaker
• Left Rear Door Coupling Point
• Left Rear Treble Speaker
• Lte Antenna 1
• Lte Antenna 2
• Most Data Bus Circuit
• Multimedia Button Module
• Multimedia System Control Head
• Radio Antenna 2
• Relay & Fuse Carrier 2
• Right Front Bass Speaker
• Right Front Door Coupling Point
• Right Front Microphone
• Right Front Treble Speaker
• Right Rear Bass Speaker
• Right Rear Door Coupling Point
• Right Rear Treble Speaker
• Roof Antenna
• Satellite Tuner Antenna
• Standard High
• Subwoofer
• Telephone Baseplate
• Vehicle Electrical System Control Module
